Summary of Contents for Motorola TELARIO TR3000
- Page 1 GUIDE 6880906Z37-O...
- Page 2 This manual may not be reproduced, in whole or in part, in any form whatsoever, without the express written permission of Motorola, Inc. Note: The Motorola products described in this manual contain one or more computer programs. These computer programs are protected by copyright laws and international treaties.
-
Page 3: Table Of Contents
Table of Contents Introduction UTAM Registration ................... 3 TR3000 Radio Features ................... 4 Inspection ......................6 Battery Installation Instructions ................ 7 To Insert Battery ..................7 To Remove Battery ..................7 Charging Instructions ..................8 Rapid Charge Method ................. 8 Slow Charge Method ................... - Page 4 Table of Contents Accessories ....................... 19 LED Indications and Alert Tones ..............20 Troubleshooting ....................21 Important Safety Information Scope ......................24 Exposure to Radio Frequency Energy............24 Portable Radio Operation and EME Exposure .......... 26 Electromagnetic Interference / Compatibility..........26 Medical Devices..................
-
Page 5: Introduction
TR3000™ Radio. The TR3000 Radio is part of the Telario™ product system, a state of the art Motorola digital communications system. Your TR3000 Radio has been designed exclusively to function with other TR3000 Radios and TC3000™... -
Page 6: Tr3000 Radio Features
Introduction TR3000 Radio Features 1. Accessory Connector – Connects audio accessories 2. Microphone 3. Battery Latch (located on both sides of the Radio) Controls 4. Control Knob – Rotate to turn radio on/off and increase or decrease volume 5. Group Selector Button – Press to select a Group Talk location 6. - Page 7 Introduction Yellow Green...
-
Page 8: Inspection
Introduction Inspection The Radio ships standard with the following items: • NiMH Battery • Belt Clip • Rapid Rate Charger with spare battery compartment & charging transformer • Manual (not shown) -
Page 9: Battery Installation Instructions
Introduction Battery Installation Instructions To Insert Battery Squeeze the two bottom side battery latches in and slide the battery tray down and out of the Radio as shown in Figure 1. Place the battery pack into the tray with the arrows facing upward. -
Page 10: Charging Instructions
Introduction Charging Instructions MPORTANT: The battery is shipped from the factory uncharged and must be charged before use. Your battery will need to be charged using the rapid charge method before operating your Radio for the first time. The rapid charge method fully charges your battery in 60 minutes. -
Page 11: Slow Charge Method
Introduction When the Radio is properly inserted into the charger pocket, the battery charging LED indicator on the radio will indicate: • Red while the battery is rapid charging. The battery fully charges in 60 minutes. • Green when the battery is fully charged. This occurs once rapid charge is completed. -
Page 12: Attaching And Removing The Belt Clip
Introduction Attaching and Removing the Belt Clip To Attach the Belt Clip Locate the grooved rails on the back of the Radio. Align the mounting rails of the belt clip with the grooved rails on the back of the radio. Refer to Figure 5. -
Page 13: Basic Functions
Basic Functions Turning the TR3000 Radio On Rotate the Control knob clockwise until it clicks. • A short, high-pitched tone will sound and the three LED Indicators will blink, indicating successful start- up. If the Radio is not operating properly, a continuous low-pitched tone will sound. -
Page 14: Battery Life Indicator
Basic Functions Battery Life Indicator Your Radio has a built-in feature to alert you when your battery life is low (approximately 5-10% charge remain- ing): • Two (2) short, low-pitched tones will sound every 10 minutes and upon release of the PTT button. Time-Out Timer Time-Out Timer limits the amount of time you have to transmit. -
Page 15: Group Talk
Group Talk Your TR3000 Radio supports two-way Group Talk communications among TR3000 Radios and TC3000 Communicators. A Group Talk is a transmission to a specific group of assigned members. Your Radio always defaults to Group Talk Service. Selecting a Group LED Indicators There are three (3) LED Indicators –... -
Page 16: Initiating A Group Talk
Group Talk Initiating a Group Talk To select your desired Group Talk location, press the Group Selector button. • A short, high-pitched tone will sound and the LED Indicator of your selected Group will light momentarily, then blink every few seconds. Press and hold the PTT button to initiate a Group Talk. -
Page 17: System Busy Auto Retry
Group Talk System Busy Auto Retry Your Radio has a built-in system busy auto retry when initiating a Group Talk. When your Group Talk is unable to be connected because the system is busy, your Radio will automatically retry for 20 seconds. When the system is available you will be alerted and can retry your Group Talk. -
Page 18: Person Link
Person Link Your TR3000 Radio supports Person Link service. A Person Link is a two-way communication that is private among TR3000 Radios and TC3000 Communicators. The TR3000 Radio can only receive and respond to a Person Link. It cannot initiate a Person Link unless one of the three Groups has been preprogrammed for Person Link service. -
Page 19: User Out Of Range
Person Link User Out of Range If a continuous, low-pitched tone is heard while attempting a Person Link, it indicates that you are out of range or the Control Station is inoperable. System Busy Signal If fast, low-pitched busy tones are heard while attempting a Person Link, it indicates that all system resources are busy. -
Page 20: Responding To A Person Link
Person Link Responding to a Person Link To accept the Person Link, press the Group Select button. Press the PTT button within 10 seconds to respond. • If you do not respond within 10 seconds, the Radio will remain in your selected Group. Release the PTT button to listen. -
Page 21: Accessories
Accessories Carrying Accessories: HLN9766 1-1/2” Spring Action Belt Clip HLN9783 Nylon Carry Case w/Belt Loop HLN9785 Hard Leather Carry Case w/Swivel Belt Loop Battery Chargers: HTN9018 120 V Desktop Rapid Charger w/Spare Battery Compartment HTN9019 120 V Multi-Unit Rapid Charger Batteries: HNN9021 650 mAH NiMH Battery... -
Page 22: Led Indications And Alert Tones
LED Indications & Alert Tones LED Indications Radio Condition LED Color(s) Group Selection Blinking Yellow, Green or Red Group Talk Transmit Continuous Yellow, Green or Red Group Talk Receive Blinking Yellow, Green or Red Continuous Yellow, Green and Red Person Link Transmit Person Link Receive Blinking Yellow, Green and Red Battery Charging Indicator LED:... -
Page 23: Troubleshooting
Troubleshooting Symptom Problem Solution... - Page 24 Troubleshooting Symptom Problem Solution...
- Page 25 Troubleshooting Symptom Problem Solution...
-
Page 26: Important Safety Information
Scope This document provides information and instructions for the safe and efficient operation of Motorola Portable and Mobile Two-Way Radios. The information provided in this document supersedes the general safety information contained in user guides published prior to 1st April 1999. - Page 27 Important Safety Information • Federal Communications Commission Report and Order No. FCC 96-326 (August 1996) • American National Standards Institute (C95-1-1992) • National Council on Radiation Protection and Measurements (NCRP - 1986) • International Commission on Non-Ionizing Radiation Protection (ICNIRP - 1988) •...
-
Page 28: Portable Radio Operation And Eme Exposure
Important Safety Information To assure optimal performance and that human exposure to radio frequency electromagnetic energy is within the guidelines set forth in the above standards, always adhere to the following procedures: 2.5 to 5.0 cm Portable Radio Operation and EME Exposure (1 to 2 in.) •... -
Page 29: Medical Devices
Important Safety Information Medical Devices Pacemakers The Health Industry Manufacturers Association recommends that a minimum separation of 6 inches (15 centimeters) be maintained between a handheld wireless phone and a pacemaker. These recommendations are consistent with the independent research by, and recommendations of, Wireless Technology Research. -
Page 30: Operational Warnings
Important Safety Information Operational Warnings Potentially Explosive Atmospheres Turn off your radio when you are in any area with a potentially explosive atmosphere, unless it is a type especially qualified for use in such areas (for example, Factory Mutual Approved). Sparks in a potentially explosive atmosphere can cause an explosion or fire resulting in bodily injury or even death. -
Page 31: Operational Cautions
Important Safety Information Operational Cautions Batteries All batteries can cause property damage and/or bodily injury such as burns if a conductive material such as jewelry, keys, or beaded chains touch exposed terminals. The conductive material may complete an electrical circuit (short circuit) and become quite hot. Exercise care in handling any charged battery, particularly when placing it inside a pocket, purse, or other container with metal objects. -
Page 32: Charging Temperatures
Charge batteries at approximately 77 ˚ ARNING: To reduce risk of injury, charge only Motorola NiMH type rechargeable batteries listed. Other types of batteries may burst, causing personal injury and damage. -
Page 33: Recycling / Disposal Of Batteries
Motorola fully endorses and encourages the recycling of NiMH batteries. In the United States, you can ship your NiMH batteries to the following address post paid to be... -
Page 34: Battery Charger
Important Safety Information Battery Charger • To reduce risk of injury, charge only rechargeable Motorola authorized batteries. Other batteries may explode, causing personal injury and damage. • Use of accessories not recommended by Motorola may result in risk of fire, electric shock, or injury. -
Page 35: Licensing
Contact your regional industry Canada licensing office. Mexico Secretaria De Comunicaciones Y Transportes Direccion General De Politicas Y Normas De Comunicaciones Av. Eugenia No. 197-5o. Piso Mexico, D.F. 06700 If your country is not listed, contact your local Motorola dealer for licensing information. -
Page 36: Service
Motorola. Furthermore, the purchase of Motorola products shall not be deemed to grant, either directly or by implication, estoppel or otherwise, any license under the copyrights, patents or patent...
