RX3i I/O Module Sweep Impact Times
The following table provides sweep impact times for modules in the Main rack and in an expansion (Exp)
rack. The base case provides the overhead for a single module in the rack. The increment (Inc) refers to
the overhead for each similar module that is added to the same rack. To estimate sweep impact for
modules in a remote rack, multiply the time in the main rack by 6:
main rack base time × 6 = approximate sweep impact in remote rack
Discrete Input 16-point
Discrete Input 16-point
(Smart Digital Input – IC695MDL664)
Discrete Input 32-point
Discrete Output 8-point
Discrete Output 16-point
Discrete Output 16-point
(Smart Digital Output – IC695MDL765)
Discrete Output 32-point
Discrete Output 32-point
(IC694MDL758)
Discrete Mixed
8-point in/ 8-point out
Analog In/Out 4-channel
Analog Input 16-channel
Analog Output 2-channel
Analog Input 6-channel, IC695ALG106
Analog Input 12-channel,
IC695ALG112
Universal Analog
IC695ALG600
Analog Input 8-channel
IC695ALG608
Analog Input 16-channel
IC695ALG616
Analog Output 4-channel
IC695ALG704
Analog Output 8-channel
IC695ALG708
GFK-2222AD
CPU310
(µs)
Main Rack Exp
Base Inc Base Inc
57.1 41.4 87.6 74.4
24.6 21.6 NA NA
78.4 59.7 105.9 96.1
61.0 40.3 84.3 74.9
61.5 38.9 87.0 74.4
24.8 21.4 NA NA
79.7 57.0 101.8 90.6
– – – – 128.6 123.7 220.9 216.0
104.5 85.7 167.0 151.7
114.9 99.0 142.7 132.0
427.7 407.1 538.8 538.0 385.3 378.8 499.9 499.3
98.3 80.8 154.4 143.4
92.9 73.4 N/A N/A
111.7 94.8 N/A N/A
90.3 77.2 N/A N/A
84.4 68.3 N/A N/A
99.5 82.6 N/A N/A
122.0 101.8 N/A N/A
121.6 103.3 N/A N/A
April 2018
Appendix A. Performance Data
CPU315/CPU320
(µs)
Main Rack Exp
Base Inc Base Inc
37.4 34.6 68.2 66.3
– – NA NA
56.2 55.3 86.1 85.7
35.6 34.7 64.5 65.5
35.4 34.5 65.2 64.9
– – NA NA
54.4 50.1 81.8 81.9
72.2 68.9 132.3 131.2
93.7 92.5 124.8 123.3
69.7 66.8 129.1 128.3
51.6 51.0 N/A N/A
66.8 58.7 N/A N/A
50.9 45.7 N/A N/A
43.3 39.8 N/A N/A
56.3 55.6 N/A N/A
54.6 48.3 N/A N/A
54.7 49.6 N/A N/A
CPE302/CPE305/CPE310
(µs)
Main Rack Exp
Base Inc Base Inc
– – – –
– – – –
– – – –
– – – –
– – – –
– – – –
– – – –
193.1 – 288.5 –
– – – –
– – – –
– – – –
– – – –
– – – –
– – – –
– – – –
– – – –
– – – –
– – – –
– – – –
283
