LG NP3530 Owner's Manual

Product Overview
Wireless Speaker
NP3530
Press and hold to turn on or off.
ENGLISH
OWNER'S MANUAL
Please read this manual carefully before operating your set and retain it
for future reference.
Printed in Indonesia
http://www.lg.com
Safety Information Using handsfree function
Preparation: Your smartphone must be paired with the unit via bluetooth.
5 V 0 2.0 A
Press and hold to reject an incoming call.
NP3530-B0_BUSALLK_OM_MFL67786219_20130328.indd 1
Charging
To use this unit more comfortably, install "LG Bluetooth Remote" on
your bluetooth devices. Select a way of installation ( ,
Approx. 3 hours
Note
Operating time is approx. 15 hours. (Based on 30% volume, 1kHz
signal, 500 mV portable input and fully charged status)
It may vary depending on the battery status and operational
conditions.
Press to hang up the call.
Press to accept an incoming call.
Press and hold to toggle the voice output.
App Installation Bluetooth Connection
or ).
Press and hold to turn on the unit.
Searching for "LG Bluetooth Remote" on the
Google Play Store.
Within 10 m
Scanning QR code below.
Tagging on the NFC sticker, if available.
About LED Indicator
Turned on red Turned on white Turned off Beep sound
In Charging Fully Charged (Power Off mode)
In Charging Fully Charged (Power On mode)
X 2
X 2
X 2 Power is turned on.
X 2
Bluetooth is paired.
X 2
X 2
X 2
Battery is discharged. (Blinks rapidly.)
X 2
X 2
A button is pressed.
X 2
X 2
The unit operates abnormally. Leave the unit at room temperature (0 - 35 °C) for a while and try again.
X 2
X 2
X 2
Wired Connection
NFC for Easy Pairing: You can pair simply and easily by
ON tagging on the NFC sticker.
Select "LG Portable(XX:XX)" on your Bluetooth device.
(XX:XX means the last four digits of BT address.)
y Depending on the bluetooth device, you need to enter the PIN code (0000).
y Once a pairing operation is performed, it does not need to be performed
again every time you turn on the unit. (Only if the PORT.IN is not connected
and the unit is registered on the Bulutooth device.)
Note: When bluetooth device is connected without BT remote
App, PORT. IN connection does NOT work.
Press and hold to disconnect.
Additional Information
LG Bluetooth Remote About Ferrite Core (Optional)
Scan to install the App.
Resetting
Reset hole
In case that the unit freezes due to malfunction, press the reset
hole for 5 seconds using an object like a thin pin.
How to attach the ferrite core
This ferrite core can reduce noises.
Notice for Auto Power Off
1. Pull the stopper [a] of the ferrite core to open.
This unit is turned off automatically, if no button is pressed for 6
2. Wind the portable cable and USB cable on the ferrite core.
hours when the bluetooth is disconnected.
3. Close the ferrite core until it clicks.
LG Customer Information Center
1-800-243-0000 USA, Consumer
1-888-865-3026 USA, Commercial
Register your product Online!
www.lg.com
2013-03-28 6:23:35
