- Page 1 English FUJITSU Server BS2000 SE700 / SE500 / SE300 Server Unit x86 Operating Manual Edition June 2015...
-
Page 2: Copyright And Trademarks
Gesellschaft für Technik-Dokumentation mbH www.cognitas.de Copyright and Trademarks Copyright © 2015 Fujitsu Technology Solutions GmbH. All rights reserved. Delivery subject to availability; right of technical modifications reserved. All hardware and software names used are trademarks of their respective manufacturers. -
Page 3: Table Of Contents
Contents Introduction ........5 Server Unit SU300 . - Page 4 Contents Related publications ........27 Index ......... . 29 U41860-J-Z126-1-76...
-
Page 5: Introduction
1 Introduction The FUJITSU Server BS2000 SE Series unites the existing server lines S servers and SQ servers in the server line SE servers. Depending on requirements, the SE server contains all the system components needed for operation as an overall application: –... - Page 6 U41860-J-Z126-1-76...
-
Page 7: Server Unit Su300
Server Units SU300. Components and ports which are not used are not described below. In the SU300 the base system X2000 enables BS2000 to execute (in Native mode or on BS2000 VMs). Optionally X2000 enables Linux/Windows systems to operate in parallel on XenVMs. -
Page 8: Switching The Server Unit On/Off
SE Manager (menu Hardware → Server (SE<model>, Units tab, "Switch off" function for the Server Unit), see the “Operation and Administration” manual [5]. When the Server Unit is switched off, the BS2000 system is shut down properly taking into account the remaining runtime specified. -
Page 9: Front Of The Server Unit
Server Unit SU300 Front of the Server Unit 2.2 Front of the Server Unit Figure 1: Server Unit (front) 1 ID card (green) 5 Video port (for Customer Support only) 2 ServerView Local Service Display 6 3x USB ports (for Customer Support only) 3 Optical drive activity indicator 7 HDD indicators 4 Operating panel (for further details see... - Page 10 Front of the Server Unit Server Unit SU300 Figure 2: Front - Detailed view: Operating panel ID button/ ID indicator 3x USB ports (for Customer Support only) Reset button Video port (for Customer Support only) NMI button HDD activity indicator On/Off button / Status indicator Global error indicator Status indicator (power cable...
-
Page 11: Controls
Server Unit SU300 Front of the Server Unit 2.2.1 Controls Identification (ID) button The ID indicators light up (blue) on the front and on the rear of the Server Unit when the ID button is pressed. The two ID indicators are synchronized. On/Off switch When the Server Unit is switched off, it is switched on again by pressing the On/Off switch once. -
Page 12: Indicators On The Operating Panel
Front of the Server Unit Server Unit SU300 2.2.2 Indicators on the operating panel ID indicator (blue) Lights up blue when the Server Unit has been selected by pressing the ID button. To deactivate, press the button again. The ID indicator can also be activated via the ServerView Operations Manager and the iRMC web interface, and its status can be reported to the ServerView Operations Manager and the iRMC. - Page 13 Server Unit SU300 Front of the Server Unit Global error indicator (yellow) Lights up yellow when a prefailure event was detected which requires Customer Support to become active (by way of precaution). Flashes yellow when an error was detected which requires Customer Support to become active.
-
Page 14: Indicators On The Operable Drives/Components
Front of the Server Unit Server Unit SU300 2.2.3 Indicators on the operable drives/components Optical drive activity indicator Lights up green when the storage medium is accessed. ServerView Local Service Display A tray mechanism enables you to pull the ServerView Local Service Display out of the computer housing to read information. -
Page 15: Hard Disks
Server Unit SU300 Front of the Server Unit 2.2.4 Hard disks Figure 3: Indicators on a hot-plug HDD module 1 HDD BUSY (green) – Lights up: HDD in active phase (drive active, access to drive) – Does not light up: HDD inactive 2 HDD FAULT (orange) –... -
Page 16: Dvd-Rw Drive
BS2000 operation by using BS2000 commands ( /ATTACH-DEVICE /CHECK-TAPE (see the “Operation and Administration” manual [5]. The device must be detached in BS2000 to permit it to be used in X2000 or for installation of the BS2000 emergency system. 2.2.5.1 Components of the drive... -
Page 17: Inserting A Cd/Dvd
Make sure that no application is using the device. 1. When the drive indicator has gone out, the CD/DVD can then be ejected using /UNLOAD- (if the device is still attached in the BS2000 system) or by briefly pressing the eject TAPE button. -
Page 18: Precautionary Measures When Handling Cds And Dvds
Front of the Server Unit Server Unit SU300 2.2.5.5 Precautionary measures when handling CDs and DVDs CAUTION! Data carrier damage Only use high-quality data carriers. ● Avoid touching the surface of a CD/DVD. ● Handle CDs/DVDs only by their edges. Do not use a ballpoint pen or pencil to mark the CD/DVD label. -
Page 19: Rear Of The Server Unit
Server Unit SU300 Rear of the Server Unit 2.3 Rear of the Server Unit Global error indicator and CSS indicator Figure 5: Global error indicator and CSS indicator, ID button and ID indicator U41860-J-Z126-1-76... - Page 20 Rear of the Server Unit Server Unit SU300 CSS indicator (yellow) Lights up yellow when a prefailure event was detected which requires Customer Support to become active (by way of precaution). Flashes yellow when an error was detected which requires Customer Support to become active.
- Page 21 Server Unit SU300 Rear of the Server Unit LAN ports SYS2 SYS1 Figure 6: LAN indicators 1 LAN link/transfer Lights up green if a LAN connection exists. (System LAN port SYS1 Does not light up if no LAN connection exists. or SYS2) Flashes green when a LAN transfer is in progress.
- Page 22 Rear of the Server Unit Server Unit SU300 Indicators on the power supply units Figure 7: Indicators on the power supply units Power supply unit fault indicator and Lights up amber when a critical event occurs warning indicator (power supply unit switches off). Call Customer Support.
- Page 23 SU300 models (10A through 10F). They can optionally be upgraded with two further processor chips without changing the BS2000 performance so that additional Linux/Windows guest systems can be operated on XenVM and the full number of PCIe slots is also available.
- Page 24 Rear of the Server Unit Server Unit SU300 U41860-J-Z126-1-76...
-
Page 25: What To Do If
Requirement Logging into the SE Manager as administrator or a privileged operator. 1. In the menu Systems → <se-server> → <su-name>(SU300) → BS2000 select the Operation tab (in VM2000 mode the tab must be selected on the monitor VM). 2. Perform the BS2000 Dump IPL action. -
Page 26: Creating Diagnostic Documentation
Creating diagnostic documentation What to do if ... 3.2 Creating diagnostic documentation Requirement Logging into the SE Manager as administrator or a privileged operator. 1. In the menu Hardware → Server (SE<model>) → <su-name>(SU300) → Service select the Diagnostics tab. 2. -
Page 27: Related Publications
Related publications You will find the manuals on the internet at http://manuals.ts.fujitsu.com. You can order printed versions of manuals which are displayed with the order number. FUJITSU Server BS2000 SE700 / SE500 / SE300 Basic Operating Manual FUJITSU Server BS2000... - Page 28 Related publications U41860-J-Z126-1-76...
- Page 29 Index BS2000 power-on indicator controls Reset button 11, CSS indicator 13, Server Unit diagnostic documentation controls creating hard disks drive indicator switching off switching on DVD-RW drive 7, Server Unit x86 shutdown SU300 eject button (DVD drive) switching off, Server Unit...
- Page 30 Index U41860-J-Z126-1-76...
