Important instructions Attention It is absolutely essential that the EIB bus is installed by an authorized electrician. Laying and connection of bus line and applications devices must be effected in conformity with valid regulations according to DIN - VDE and the EIB manual of the ZVEI / ZVEH. Connect the touch contact input to the same phase as the device’s power supply.
Page 3
Technical data / Connection EIB connection Nominal voltage: 24 V Current consumption: < 10 mA Switching connection Nominal voltage: 230V - 50 Hz 10 A, cos ϕ 0.6 Switching current: Touch contact input: 230 V, 50 Hz Line length of the touch contact input: max.
Page 4
Installation / Fig. 1 Switch off supply voltage ! Remove both outer caps from the device. The device is fixed in the lamps by means of screws put through the long holes (cf. Fig. 1 below, positions 1; 7 ). The connection of supply voltage and control line is effected at the 7-pin terminal block (pos.
Page 5
Adapt bus coupling process Assign physical address • Connect a PC equipped with the EIBA software (ETS) to the EIB bus line via an EIB-RS 232 interface. • Press the programming key (pos. 5) at the actuator: the red programming LED (pos. 4) will become illuminated.
Page 6
Adapt bus coupling process Alternative application Version 1 This device offers the following functions: • Switching of lamps on-site via several conventional touch contacts (e. g. 2020 US without lighting). • Dimming of lamps with electronic ballasts (0-10 V control input) via EIB sensors (e. g. 6118xx). •...
Page 7
Adapt bus coupling process Version 2 This device may be used as a pure switching actuator. Then, its contact time behavior may be adjusted via the „parameters“ option (e. g. staircase lighting time-switch).
