NEC Express5800/R320f
Configuration Guide
VMware model
Introduction
This document contains product and configuration information that will enable you to configure your system. The guide will
ensure fast and proper configuration of your NEC Express5800 server.
February 13, 2018
Revision 2.0
NEC Corporation
Advertisement
Table of Contents
Related Manuals for NEC Express5800/R320f
Summary of Contents for NEC Express5800/R320f
-
Page 1: Configuration Guide
Configuration Guide VMware model Introduction This document contains product and configuration information that will enable you to configure your system. The guide will ensure fast and proper configuration of your NEC Express5800 server. February 13, 2018 Revision 2.0 NEC Corporation... -
Page 2: Table Of Contents
Boot Mode Setup Option ..................... 15 REFERENCES....................... 16 Server Management ..........................16 Supported PCI Cards and Installable Slots ..................17 Notes for using VMware vSphere 6.5 on Express5800/R320f ............18 Copyright Notice and Liability Disclaimer ..................19 REVISION HISTORY ..................... 20 NEC Corporation... -
Page 3: Technical Specification
– CONFIGURATION GUIDE NEC Express5800/R320f / VMware model Technical Specification Specification Model R320f-E4 R320f-M4 Part Number N8800-218F N8800-219F Processor Type Intel® Xeon® processor Intel® Xeon® processor E5-2630 v4 E5-2671 v4 Clock speed 2.20 GHz 2.30 GHz Logical Number of 1 or 2... -
Page 4: External Views
– CONFIGURATION GUIDE NEC Express5800/R320f / VMware model External Views Front and Rear Views Front View Legend Drive Bays Memory Fault LED UID Button UID Button Optical Disk Drive Module Power LED System Power LED SAFE TO PULL LED System Status LED... - Page 5 – CONFIGURATION GUIDE NEC Express5800/R320f / VMware model Rear View for R320f-E4 Legend USB Connectors Module ID LED USB Connectors (option, for backup use) Management LAN Connector PCI Slots (Low-Profile) VGA Connector Power supply unit Serial Port Connector 2 Data LAN Connector Serial Port Connector 1 For service personnel only.
- Page 6 – CONFIGURATION GUIDE NEC Express5800/R320f / VMware model Rear View for R320f-M4 Legend USB Connectors Management LAN Connector USB Connectors (option, for backup use) VGA Connector PCI Slots (Low-Profile) Serial Port Connector 2 Power supply unit Serial Port Connector 1...
-
Page 7: Dimensions (Mm)
– CONFIGURATION GUIDE NEC Express5800/R320f / VMware model Dimensions (mm) Rack mount Tower Conversion (Optional) NEC Corporation Revision 2.0, February 2018... -
Page 8: Configuration Diagram
– CONFIGURATION GUIDE NEC Express5800/R320f / VMware model Configuration Diagram Server CHASSIS CHASSIS Optical Drive Bay REAR FRONT CPU/IO Module CPU/IO Module R320f-E4 Legend: Mandatory components Standard components NEC Corporation Revision 2.0, February 2018... - Page 9 – CONFIGURATION GUIDE NEC Express5800/R320f / VMware model R320f-M4 Legend: Mandatory components Standard components NEC Corporation Revision 2.0, February 2018...
-
Page 10: Server Configuration
– CONFIGURATION GUIDE NEC Express5800/R320f / VMware model Server Configuration Base Models Product Name / Description Part Number Express5800/R320f-E4(10C/E5-2630v4) N8800-218F no RAM, no 2.5-inch HDD Including: Intel Xeon Processor E5-2630 v4, 1 x DVD Super Multi, EXPRESSBUILDER DVD Express5800/R320f-M4(14C/E5-2671v4) N8800-219F no RAM, no 2.5-inch HDD... -
Page 11: Internal Hard Disk Drives
– CONFIGURATION GUIDE NEC Express5800/R320f / VMware model Memory Configuration Guideline See the table below for the number of memory kits required in accordance with logical main memory size and number of logical processors. Memory configurations which are not listed below are not supported in the system. -
Page 12: Pci Card
- Installation in full height slots only supported on R320f-M4 NOTE: For supported NEC Storage products to connect with N8803-040AF, contact your sales representative or refer to the NEC Storage WEB site. (http://www.nec.com/global/prod/storage/) NEC Corporation Revision 2.0, February 2018... -
Page 13: Other Add-In Components
– CONFIGURATION GUIDE NEC Express5800/R320f / VMware model Other Add-in Components Input Devices Category Product Name / Description Part Number Keyboard USB Keyboard N8870-002AF Mouse USB Optical Wheel Mouse N8870-012 Cable USB cable : 1.5m USB extension cable K410-177(1A) Add-on Components... -
Page 14: Operating System
– CONFIGURATION GUIDE NEC Express5800/R320f / VMware model Operating System The R320f VMware models support VMware ESXi 6.5. For installation, please download the image data from VMware website. Please note that the Part Number differs by the end user’s country. -
Page 15: Dust Proof Filter
– CONFIGURATION GUIDE NEC Express5800/R320f / VMware model Dust Proof Filter The server supports the dust resistant feature. Choose the following kit to install the system in dusty places. Category Product Name / Description Part Number Filter 4U-FT Dust Filter... -
Page 16: References
– CONFIGURATION GUIDE NEC Express5800/R320f / VMware model References Server Management The EXPRESSSCOPE Engine 3, integrated into the server, provides superior remote control and system management features listed in the table below. Hardware monitoring Temperature/voltage/power/ fan /degeneration (memory/hard drive) ... -
Page 17: Supported Pci Cards And Installable Slots
– CONFIGURATION GUIDE NEC Express5800/R320f / VMware model Supported PCI Cards and Installable Slots R320f-E4 Part Number Product Name Slots Notes Slot # : PCI Slot: Card height: Slot type: N8804-012 1000BASE-T 2ch board kit N8804-011 10GBASE-T 1ch board set Max. -
Page 18: Notes For Using Vmware Vsphere 6.5 On Express5800/R320F
A dedicated server for data backup is recommended. Network Adapter Types Do not choose E1000 or E1000E for the virtual machines on the NEC Express5800/ft series. If you choose E1000 or E1000E, the CPU modules may not synchronize. NEC Corporation... -
Page 19: Copyright Notice And Liability Disclaimer
All other products, brands, or trade names used in this document are trademarks or registered trademarks of their respective holders. NEC shall not be liable for technical or editorial errors or omissions contained herein. For hard drive capacity measurements, 1 GB = 1 billion bytes. Actual formatted capacity is less. -
Page 20: Revision History
– CONFIGURATION GUIDE NEC Express5800/R320f / VMware model Revision History Revision Date Description January 19, 2018 Initial release February 13, 2018 Deleted the description of the Network configuration limitation on vSphere6.5 NEC Corporation Revision 2.0, February 2018...
