Page 3
Screen Front 150 mm (6 in) and above 300 mm 300 mm (12 in) and (12 in) and above above 150 mm (6 in) and 200 mm above (8 in) and Front above...
Page 4
■ Horizontal Position Vertical Position: 0% (Center) Up to about 43% of the projected image* Extend Contract Feet 4 Locations ■ Vertical Position Horizontal Position: 0 % (Center) Up to about 100% of the projected image* * 16:9 image...
This Unit Laptop, etc. BD/DVD Recorder, etc. To [HDMI 1] or [HDMI 2] input terminal HDMI Output Terminal HDMI Cable (Sold Separately) This Unit Speakers BD/DVD Recorder, etc. HDMI Cable Speaker (Sold Separately) To [HDMI 1] or [HDMI 2] Cable (Sold input terminal Separately) HDMI Cable (Sold Separately)
WARNING LIGHT STANDBY/ON “STANDBY/ON” lights up (red) “STANDBY/ON” lights up (green) “STANDBY/ON” light off Remote Control In standby state When LD block is starting up When in “ECO Mode” WARNING LIGHT STANDBY/ON ANDBY/ WARNING LIGHT STANDBY/ON ANDBY/ WARNING LIGHT STANDBY/ON MODE 1 MODE 2 MODE 3...
Page 7
Focus MODE 1 MODE 2 MODE 3 SETTING MEMORY ANAMO. ABCD ABCD ABCD PICTURE COLOR GAMMA MODE PROFILE SETTINGS C.M.D. Focus Adjustment Zoom (Screen Size) Shift (Screen Position) Adjustment Adjustment This Unit 3D GLASSES PK-AG3 3D SYNCHRO EMITTER PK-EM2...
Page 10
WARNING LIGHT STANDBY/ON The indicator lights up. The indicator appears blinking. “STANDBY/ON” lights up (red) “STANDBY/ON” lights up (green) All lights off In standby state When LD block is starting up During projection ・ ・ ・ ・ When in “ECO Mode” WARNING LIGHT STANDBY/ON...
Page 19
Écran Avant 150 mm (6 pouces) et plus 300 mm 300 mm (12 pouces) (12 pouces) et plus et plus 150 mm (6 pouces) 200 mm et plus (8 pouces) Avant et plus...
Page 20
■ Position horizontale Position verticale : 0 % (Centre) Jusqu’à environ 43% de l’image projetée* Augmenter Diminuer Pieds 4 emplacements ■ Position verticale Position horizontale : 0 % (Centre) Jusqu’à environ 100% de l’image projetée* * Image 16:9...
Cet appareil Ordinateur portable, etc. Enregistreur BD/DVD, etc. À la borne d’entrée [HDMI 1] ou [HDMI 2] Borne de sortie HDMI Câble HDMI (vendu séparément) Enceintes Cet appareil Enregistreur BD/DVD, etc. Câble HDMI Câble enceinte (vendu séparément) À la borne d’entrée (vendu [HDMI 1] ou [HDMI 2] séparément)
Mise au Point MODE 1 MODE 2 MODE 3 SETTING MEMORY ANAMO. ABCD ABCD ABCD PICTURE COLOR GAMMA MODE PROFILE SETTINGS C.M.D. Réglage de la Mise au Réglage du Zoom Réglage du Décalage Point (taille de l’écran) (position de l’écran) Cet appareil LUNETTES 3D PK-AG3...
Page 25
2 3 4 Filtre à air (Blanc) Filtre éponge (Gris)
Page 26
WARNING LIGHT STANDBY/ON L’indicateur s’allume. L’indicateur apparaît clignotant. “STANDBY/ON” s’allume (rouge) “STANDBY/ON” s’allume (vert) Tous les témoins sont éteints En état de veille Lorsque le bloc LD démarre Au cours de la projection ・ ・ ・ Lorsque dans “ECO Mode” ・...
Page 35
Pantalla Frente 150 mm (6 in) y superior 300 mm 300 mm (12 in) y (12 in) y superior superior 150 mm (6 in) y 200 mm superior (8 in) y Frente superior...
Page 36
■ Posición horizontal Posición vertical: 0% (Centro) Hasta aprox. un 43 % de la imagen proyectada* Extender Contraer Patas de soporte 4 Ubicaciones ■ Posición vertical Posición horizontal: 0 % (Centro) Hasta aprox. un 100 % de la imagen proyectada* * Imagen 16:9...
Page 37
Esta unidad Portátil, etc. Grabadora de BD/DVD, etc. Hacia el terminal de entrada [HDMI 1] o [HDMI 2] Terminal de salida HDMI Cable HDMI (no incluido/se vende aparte) Altavoces Esta unidad Grabadora de BD/DVD, etc. Cable de los Cable HDMI (no incluido / altavoces se vende aparte) Hacia el terminal de entrada...
WARNING LIGHT STANDBY/ON Control remoto “STANDBY/ON” iluminado (rojo) “STANDBY/ON” iluminado (verde) La luz “STANDBY/ON” se apaga En estado de espera Cuando el bloque LD se está iniciando Cuando en “ECO Mode” WARNING LIGHT WARNING LIGHT WARNING LIGHT STANDBY/ON ANDBY/ STANDBY/ON ANDBY/ STANDBY/ON MODE 1...
Page 41
2 3 4 Filtro del aire (blanco) Filtro de esponja (gris)
Page 42
WARNING LIGHT STANDBY/ON El indicador se ilumina. El indicador parpadea. “STANDBY/ON” iluminado (rojo) “STANDBY/ON” iluminado (verde) Todas las luces apagadas En estado de espera Cuando el bloque LD se está Durante la proyección ・ ・ ・ iniciando Cuando en “ECO Mode” ・...
