2. PART NO. and DESCRIPTION You can find it in your SERVICE MANUAL. IMPORTANT Inferior silicon grease can damage IC's and transistors. When replacing an IC's or transistors, use only specified silicon grease (YG6260M). Remove all old silicon before applying new silicon. 26HF84A A1-1...
When soldering or unsoldering, completely remove all of the solder from the pins or solder area, and be sure to heat the soldering points with the lead free solder until it melts sufficiently. Recommendations Recommended lead free solder composition is Sn-3.0Ag-0.5Cu. A1-2 26HF84A...
W at AC 120 V 60 Hz Per Year kWh/Year Protector Power Fuse Safety Circuit IC Protector(Micro Fuse) Regulation Safety UL/CSA Radiation FCC/IC X-Radiation DHHS/HWC Temperature Operation +5oC ~ +40oC Storage -20oC ~ +60oC Operating Humidity Less than 80% RH A3-1 26HF84A(FOR USA)
Page 6
Treble Balance Image Tilt Picture Scroll Stereo, SAP, Mono Video Color Stream(Component) HDMI Channel(TV/Cable) CH Label Video Label Clock Game Timer Front Panel Lock On Timer Sleep Timer Reset Sound Mute V-chip Rating NOT AVAILABLE Picture Size A3-2 26HF84A(FOR USA)
Page 7
(DVD Keys) Enter (TV / DVD Keys) SLEEP/TOP MENU RECALL(Call) / (Display) Menu/Enter / DVD MENU Exit / DVD CLEAR (DVD / VCR Keys) Pause/Still Play Stop <</Skip / Search Forward >>/Skip / Search Forward (VCR Keys) TV/VCR A3-3 26HF84A(FOR USA)
Page 8
FBT Leak Test Protect Video Lock Game Timer(Max Time:120Min) Energy Star Favorite CH Variable Audio Out Virtual Dolby Picture Size Color Temperature Control Mode(Picture Preference) Front Panel Lock Available Scan Rates (Component/HDMI) 480i/480p/720p/1080i Menu=Volume Up+Volume Down Auto Setup(Language/CH Program) A3-4 26HF84A(FOR USA)
Page 9
Ext Speaker VHF/UHF Antenna Input F Type AC Outlet G-14 Set Size Approx. W x D x H (mm) 700 x 502 x 495.5 G-15 Weight Net (Approx.) 36.0 kg ( 79.4 lbs) Gross (Approx.) 41.5kg ( 91.5lbs) A3-5 26HF84A(FOR USA)
Page 10
/ 4 Surfaces Height (cm) 60 (ORION SPEC:31) Container Stuffing Sets/40' container G-17 Cabinet Material Cabinet Cabinet Front PS 94V0 DECABROM Cabinet Rear PS 94V0 NON-DECABROM Non-Halogen Demand Eyelet Demand G-18 Environment Pb Free Pb-free Solder Other Cd Free A3-6 26HF84A(FOR USA)
Page 11
W at AC 120 V 60 Hz Per Year kWh/Year Protector Power Fuse Safety Circuit IC Protector(Micro Fuse) Regulation Safety UL/CSA Radiation FCC/IC X-Radiation DHHS/HWC Temperature Operation +5oC ~ +40oC Storage -20oC ~ +60oC Operating Humidity Less than 80% RH A3-7 26HF84A(FOR CANADA)
Page 12
Treble Balance Image Tilt Picture Scroll Stereo, SAP, Mono Video Color Stream(Component) HDMI Channel(TV/Cable) CH Label Video Label Clock Game Timer Front Panel Lock On Timer Sleep Timer Reset Sound Mute V-chip Rating NOT AVAILABLE Picture Size A3-8 26HF84A(FOR CANADA)
Page 13
(DVD Keys) Enter (TV / DVD Keys) SLEEP/TOP MENU RECALL(Call) / (Display) Menu/Enter / DVD MENU Exit / DVD CLEAR (DVD / VCR Keys) Pause/Still Play Stop <</Skip / Search Forward >>/Skip / Search Forward (VCR Keys) TV/VCR A3-9 26HF84A(FOR CANADA)
Page 14
FBT Leak Test Protect Video Lock Game Timer(Max Time:120Min) Energy Star Favorite CH Variable Audio Out Virtual Dolby Picture Size Color Temperature Control Mode(Picture Preference) Front Panel Lock Available Scan Rates (Component/HDMI) 480i/480p/720p/1080i Menu=Volume Up+Volume Down Auto Setup(Language/CH Program) A3-10 26HF84A(FOR CANADA)
Page 15
HDMI Input1(w/ Analog Audio L/R) HDMI x 1(RCA x 2) HDMI Input2(w/ Analog Audio L/R) Diversity Ext Speaker VHF/UHF Antenna Input F Type AC Outlet G-14 Set Size Approx. W x D x H (mm) 700 x 502 x 495.5 A3-11 26HF84A(FOR CANADA)
Flip up the sides of the Rubber Cap in the direction of the arrow and remove one side of the support. (Refer to Fig. 1-2.) Rubber Cap Support Fig. 1-5 Support Confirm that the Support is securely connected. Fig. 1-2 Put on the Rubber Cap without moving any parts. B1-1 26HF84A...
IC leads completely. NOTE Do not move the Braided Shield Wire in the vertical direction towards the IC pattern. Blower type IC desoldering machine Braided Shield Wire Soldering Iron IC pattern Fig. 2-4 Fig. 2-2 B2-1 26HF84A...
Page 19
Fig. 2-6 Absorb the solder left on the lead using the Braided Shield Wire. (Refer to Fig. 2-7.) NOTE Do not absorb the solder to excess. Soldering Iron Braided Shield Wire Fig. 2-7 B2-2 26HF84A...
POWER ON total hours. CRT ON 0010 = (16 x 16 x 16 x thousands digit value) MICON Version OEC7118A_32 + (16 x 16 x hundreds digit value) + (16 x tens digit value) + (ones digit value) FIG. 1 26HF84A...
Page 21
If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to TABLE 1. ADDRESS DATA INIT CRT ON 0010 OEC7118A_32 FIG. 1 CANADA Table 1 26HF84A...
Press both VOL. DOWN button on the set and Channel button (1) on the remote control for more than 2 seconds. After the finishing of the initializing of shipping, the unit will turn off automatically. The unit will now have the correct DATA for the new MEMORY IC. 26HF84A...
B.BIAS(W), R/G.DRV(W) and B/R.DRV(W)”at each step the VOL.DOWN button on the set and the channel (9) tone sections equally. on the remote control for more than 2 seconds. Perform the above adjustments 5 and 6 until the white color is looked like a white. 26HF84A...
Page 24
Activate the adjustment mode display of Fig. 1-1 and press the channel button (04) on the remote control to select “H. SIZE”. Press the VOL. UP/DOWN button on the remote control until the SHIFT quantity of the OVER SCAN on right and left becomes 7.5%. 26HF84A...
Page 25
Press the VOL. UP/DOWN button on the remote control until the both ends vertical lines become straight. Set the screen mode to 4:3. Press the VOL. UP/DOWN button on the remote control until the both ends vertical lines of the screen become parallel. 26HF84A...
Page 26
HD-MI mode. Then perform the above adjustments CORNER 2~8. C.PARA C.SAW V.SYMM R-Y GAIN R-Y PHASE G-Y GAIN G-Y PHASE BRI.MAX BRI.MIN CONT.CENT "A" CONT.MAX "A" CONT.MIN Fig. 2-2 COL.MAX COL.MIN White 0% SHARP.CENT SHARP.MAX SHARP.MIN TEST STEREO TEST AUDIO 110% White 100% Fig. 2-3 26HF84A...
Confirm red and blue color. WEDGE Adjust the slant of the deflection yoke while watching the screen, then tighten the fixing screw. WEDGE POSITION DEFLECTION YOKE DEFLECTION YOKE SCREW Fig. 3-2-b MAGNET SCREW PURITY MAGNETS 6 POLE MAGNETS 4 POLE MAGNETS Fig. 3-1 26HF84A...
Page 28
S853 S854 CP852 CP808B CRT PCB CP802B CP851B MAIN PCB AV PCB PCB CP808A FB401 J705 CP510 CP404 CP851A CP509 CP501 CP602 DEGAUSS COIL CD603 CP403 AC IN CD501 FRONT JACK PCB J2201 CD2251 CD2201 CD1004 CD1003 SPEAKER CD1001 26HF84A...
ANALOG OSD G IN OSD_G VSM OUT 54 BUFFER MICON1/ V.OUTPUT PIN CUSHION ANALOG OSD B IN STEREO OSD_B IC602 TA1317ANG IC401 LA78041 SDA1 VP OUT 27 SCL1 DEF/DAC Vcc T401 FB401 Q401 Q403 Y/C Vcc H-OUT 26 H.DRIVE FL OUT 26HF84A...
Page 30
OUTM1 OAOUT2 OUTM2 MICOM1/ SPEAKER STEREO AUDIO_R INV2 SP1002 VOUTP2 AUDIO_MUTE MUTE VDDA VDD1 VDD1 VDD2 SOUND+B VDD2 FRONT JACK J2204 FRONT_A_IN_R FRONT JACK FRONT_A_IN_L J2203 SYNC COUNT/ FRONT JACK CONNECTOR FRONT_V_IN J2202 FRONT_S_C FRONT JACK FRONT_S_Y J2201 FRONT_S_SW 26HF84A...
WAVEFORMS CHROMA/PROGRESSIVE/ PIN CUSHION 10µs 10µs 1.0V 0.5V 1.0V DEFLECTION 20µs 10µs 10µs 2.0V 1.0V 1.0V 10µs 10µs 0.5V 1.0V 1.0V 10µs 1.0V 5.0V 0.5V SOUND AMP/ FRONT AV 10µs 20µs 200m 0.5V 1.0V NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.
WAVEFORMS MICON1 20ms 200m 1.0V 1.0V STEREO 20ms 0.5ms 1.0V 200mV 1.0V 10ms 20ms 1.0V 200mV 1.0V SYNC COUNT/ CONNECTOR 20µs 20ms 1.0V 1.0V 1.0V 20µs 20ms 1.0V 1.0V 1.0V NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.
WAVEFORMS 10µs 20µs 20µs 200mV 1.0V 1.0V 10µs 20µs 20µs 200mV 1.0V 20µs 20µs 500µs 200mV 1.0V CRT/CVM 20µs 500µs 20µs 1.0V 200mV INTERFACE MICON2 10µs 20µs 500µs 200mV 1.0V 1.0V NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.
Page 44
WAVEFORMS 500µs 1.0V NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.
