- Page 1 OWNER’S MANUAL DLP PROJECTOR Please read this manual carefully before operating your set and retain it for future reference. BX503 BX403B www.lg.com Downloaded From projector-manual.com LG Manuals...
- Page 2 - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Downloaded From projector-manual.com LG Manuals...
-
Page 3: Table Of Contents
5. The fluorescent lamp used in this product contains a small amount of mercury. Do not dispose of this product with general household waste. Disposal of this product must be carried out in accordance to the regulations of your local authority. Downloaded From projector-manual.com LG Manuals... -
Page 4: Safety Instructions
If grounding methods are not possible, have a qualified electrician install a separate circuit breaker. Do not try to ground the unit by connecting it to telephone wires, lightening rods, or gas pipes. Downloaded From projector-manual.com LG Manuals... - Page 5 Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance. Downloaded From projector-manual.com LG Manuals...
- Page 6 This may cause the batteries to over- This could cause damage to the Accumulated dust may cause a fire haz- heat and leak. remote control. ard or damage to the unit! Downloaded From projector-manual.com LG Manuals...
-
Page 7: Names Of Parts
Adjusts functions of menus. AUTO Button ◉ OK Button It automatically corrects the Checks present mode and saves the position and the shaking of the image at the RGB mode. function changes. POWER Button Turn ON/OFF the projector. Downloaded From projector-manual.com LG Manuals... -
Page 8: Connecting Part
Names of parts Connecting Part VIDEO IN RGB IN-2 RGB IN-1 USB(SVC only) RGB OUT HDMI IN RS-232C Rear remote control sensor Kensington Security System Connector (Refer to page 14) AC IN Downloaded From projector-manual.com LG Manuals... -
Page 9: Remote Control
• Open the battery compartment cover on the back of the remote control. • Insert the specified type of batteries with correct polarity, match “+” with “+”, and match “-” with “-”. • Install two 1.5V AAA batteries. Don’t mix used batteries with new batteries. Downloaded From projector-manual.com LG Manuals... -
Page 10: Projector Status Indicators
A high temperature state has been detected. Turn the Orange Projector off. Temperature Indicator The Projector has turned off due to excessive heat. Power has turned off due to problem with the internal Red (flashing) cooling fan. Contact your service center. Downloaded From projector-manual.com LG Manuals... -
Page 11: Accessories
* Optional parts can be changed without notice to improve the quality of the product, and new optional parts can be added. Ceiling installer for projector LAN Cable Lamp Projection Screen HDMI Cable RS-232C Cable Component Cable Video Cable RCA to D-Sub Adapter HDMI to DVI Cable Downloaded From projector-manual.com LG Manuals... -
Page 12: Installing And Composition
When the remote control does not work during operation. The remote control may not work when a lamp equipped with electronic ballast or a three-wavelength lamp is installed. Replace those lamps with international standard products to use the remote control normally. Downloaded From projector-manual.com LG Manuals... -
Page 13: Basic Operation Of The Projector
Projection distance (D) 4 : 3 Scale Projection Distance Diagonal Size Horizontal Size Vertical Size Wide Distance Tele Distance (mm) (mm) (mm) (mm) (mm) * The longest/shortest distance show status when adjusted by the zoom function. Downloaded From projector-manual.com LG Manuals... -
Page 14: Using Kensington Security System
Security System set. And for further information, contact http://www.kensington.com, the internet homepage of the Kensington company that • deals with expensive electronic equipment such as notebook PCs or projectors. • Kensington Security System is an optional item. Downloaded From projector-manual.com LG Manuals... -
Page 15: Turning On The Projector
Quick Power On/Off The projector enters into Standby mode without waiting it is cooled. If Standby mode continues for a certain amount of time, the projector can operate without cooling when it is turned on. Downloaded From projector-manual.com LG Manuals... -
Page 16: Focus And Position Of The Screen Image
• It is possible to watch by selecting RGB 1 for Component 1 input and RGB 2 for Component 2 input, and in case of Component, even though there ’s an input signal, the OSD item is not activated. Downloaded From projector-manual.com LG Manuals... -
Page 17: Connection
• You can connect a VCR, a camcorder or any other compatible video image source to the projector. < How to connect > Connect the Video input jacks of the projector to the output jacks of the A/V source with Video cable. Video Cable <VCR> Downloaded From projector-manual.com LG Manuals... -
Page 18: Connecting To A Dvd
<D-TV Set-Top Box> with the component cable.(Y=green, P =blue, P =red) * You can also connect to the RGB IN 2 port. No support of audio. Component cable RCA to D-Sub adapter <D-TV Set-Top Box> Downloaded From projector-manual.com LG Manuals... -
Page 19: Function
＜ ＞ User ＜ ＞ Film ＜ ＞ Bright Game Golf ＜ ＞ ＜ ＞ ＜ ＞ You can use this function through the MENU button. To exit the menu display, press the EXIT button. Downloaded From projector-manual.com LG Manuals... -
Page 20: Color Temperature Control
* Press the MENU button twice or the EXIT button to exit the menu screen. ꕍ Gamma Curve Shift Red Gamma Curve Shift Green 0 Gamma Curve Shift Blue Reset ꕌ ◉ Prev. Move Adjust ꕍ ＜＞ Downloaded From projector-manual.com LG Manuals... -
Page 21: Brilliant Color Tm Function
Move Select ＜＞ ꕍ When you watch the movie, this function adjusts the set to the best picture appearance. Adjusting the contrast and the brightness of the screen using the black level of the screen. Downloaded From projector-manual.com LG Manuals... -
Page 22: Expert Color Function
Press the MENU button twice or the EXIT button to exit the menu screen. An advanced settings function is possible to be saved according to an image mode. Reset ◉ ∧,∨ OK button. To return to the factory default settings, select [Reset] with buttons and press Downloaded From projector-manual.com LG Manuals... -
Page 23: Special Menu Options
Zoom -/+ in Digital Zoom is Overscan Auto Power set to a value other than 100%. ＞ ＜ Press the MENU button twice or the EXIT button to exit the menu screen. ꕌ MENU Prev. Move Select ＜＞ ꕍ Downloaded From projector-manual.com LG Manuals... -
Page 24: Flip Horizontal Function
10 Min 20 Min 30 Min 60 Min 180 Min 120 Min 90 Min 240 Min You can use this function through the MENU button. To exit the menu display press the EXIT button. Downloaded From projector-manual.com LG Manuals... -
Page 25: Auto Sleep Function
(Off, 1, 2, 3, 4, ...., 8, 9, 10, 15, 20, 25, ...., 55, 60 minutes). You can use this function through the MENU button. Press the EXIT button to exit the menu screen. Downloaded From projector-manual.com LG Manuals... -
Page 26: Using Digital Zoom Function
• Off : Connecting power cord to the projector makes the projector in standby Presentation timer state. Digital Zoom • Press the MENU button twice or the EXIT button to exit the menu screen. Auto Power ＞ ＜ ꕌ ◉ OK MENU Prev. Move ꕍ Downloaded From projector-manual.com LG Manuals... -
Page 27: Using Keystone Function
To temporarily turn off the lamp, press BLANK on the remote control. Do not block the projection lens with any objects when the projector is under operation as this could cause the objects to become heated and deformed or even cause a fire. Downloaded From projector-manual.com LG Manuals... -
Page 28: Selecting Blank Image
• It is automatically changed into power saving mode at specific temperature (more than 35°C). • You can use this function through the MENU button. • To exit the menu display, press the EXIT button. Downloaded From projector-manual.com LG Manuals... -
Page 29: Using Monitor Out Function
1. Press the STILL button of remote control. ꕍ * You can freeze the input image. <Moving Image> <Still Image> 2. To exit STILL, press any button . * The STILL function will release automatically after approximately 10 minutes. Downloaded From projector-manual.com LG Manuals... -
Page 30: Screen Menu Options
• Clock adjustment range is -20 ~ 20. Vertical • The variable range can be different depends on input resolutions. ꕌ ꘀ Prev. Move Adjust ＜＞ ꕍ • Press the MENU button twice or the EXIT button to exit the menu screen. Downloaded From projector-manual.com LG Manuals... -
Page 31: Using Horizontal Function
• Vertical adjustment range is -25 ~ 25. Vertical • The variable range can be different depends on input resolutions. ꕌ ꘀ Prev. Move Adjust ＜＞ ꕍ • Press the MENU button twice or the EXIT button to exit the menu screen. Downloaded From projector-manual.com LG Manuals... -
Page 32: Rs-232C
Communication Parameter Setup • Baud Rate : 9600 bps(UART) • Data Length : 8 bit • Parity : none • Stop bit : 1 bit • Flow Control : none • Communication code : ASCII code Downloaded From projector-manual.com LG Manuals... - Page 33 0 ~ 1 16. Auto Configure 17. Input Select 18. Key Key code * Refer to the detailed information for data with [*] mark. Communication Protocol * Real data mapping 1 * Real data mapping 2 Downloaded From projector-manual.com LG Manuals...
- Page 34 1 : Screen Mute On (Picture Off) status about each function. [d] [ ] [Set ID] [ ] [OK] [Data] [x] Data 0 : Screen Mute Off (Picture On) 1 : Screen Mute On (Picture Off) Downloaded From projector-manual.com LG Manuals...
- Page 35 Min : 0 ~ Max : 64 Data Min : 0 ~ Max : 64 * Refer to ‘Real data mapping 1’ . [k] [ ] [Set ID] [ ] [OK] [Data] [x] Data Min : 0 ~ Max : 64 Downloaded From projector-manual.com LG Manuals...
- Page 36 [ j ] [u] [ ] [Set ID] [ ] [Data] [Cr] Sleep Time Data 1 : To set Auto Configure FILP V. [u] [ ] [Set ID] [ ] [OK] [Data] [x] FILP H. Data 1 : To set Downloaded From projector-manual.com LG Manuals...
-
Page 37: Information
2 5 5 . 2 5 5 . 2 5 5 . 0 0 0 Gateway 1 9 2 . 1 6 8 . 0 0 0 . 0 0 1 IP setting is succeeded. ꘀ Prev. 자동설정으로 네트워크 설정이 완료되었습니다. Downloaded From projector-manual.com LG Manuals... - Page 38 Press OK Key ꕌ ꘀ Adjust Prev. Move ＜＞ ꕍ 7. IP 설정 후 ◉ 확인 버튼을 누르세요. IP 주소가 저장됩니다. 8. 수동설정으로 네트워크 설정이 완료됩니다. IP setting in progress, Please wait… IP setting is succeeded. Downloaded From projector-manual.com LG Manuals...
-
Page 39: Supported Monitor Display
(Display registration information)’ . (ex, The optimum vertical frequency may be displayed up to 85Hz or under in the resolution of 640X480 or 800X600.) <DVD/DTV Input> Signal Component-*1 HDMI(DTV)-*2 480i 480p 59.94 / 60Hz 720p 1080i 576i 576p 50Hz 720p * Cable type 1080i 1- RCA to D-Sub Adapter 24/25/30Hz 1080p 2- HDMI to HDMI Cable Downloaded From projector-manual.com LG Manuals... -
Page 40: Replacing The Lamp
- Never touch the lamp unit glass otherwise image quality may be compromised or lamp life maybe reduced. To obtain a replacement Lamp unit Lamp model number is on page 42. Check the lamp model and then purchase it from an LG Electronics Service Center. Using another manufacturers lamp may cause damage to the projector. - Page 41 수직으로 힘을 가하지 말고 대각선 밀착시키세요. 방향으로 힘을 주어 밀어 넣듯이 램프 탈부착시 하기 끝단부위에 (기울기를 30°정도 유지하세요.) 삽입하세요. 무리한 힘이 가하지 않도록 하세요. 지지선 측면부위 스크류 체결시 무리한 힘으로 조여지지 않도록 하세요. 끝단부위 고정시 토오크(torque)는 4~5kgf.cm의 힘으로 고정하세요. Downloaded From projector-manual.com LG Manuals...
-
Page 42: How To Fix The Lens Cap To The Projector
Fix the strap at the hole of the projector into the hole of the lens cap, and then pass the lens cap They are completely assembled as shown at the below figure. through the strap lasso. Downloaded From projector-manual.com LG Manuals... -
Page 43: Specifications
Information Specifications BX503 (BX503-JD) / BX403B (BX403B-JD) MODEL AC 100 - 240V~ 50/60Hz, 4.3A Power Resolution 1024(Horizontal) x 768(Vertical)pixel Horizontal / Vertical Ratio 4:3(horizontal:vertical) DLP panel size(mm) 17.8 Screen size Wide : 1.0 ~ 7.5m (Projection distance) Tele : 1.2 ~ 8.7m... - Page 44 The model and serial number of the projector is located on the back or one side of the projector. Record it below should you ever need service. MODEL SERIAL Downloaded From projector-manual.com LG Manuals...
