SERVICE MANUAL
Warning
The technical information and parts shown in this
manual are not to be used for: the development,
design, production, storage or use of nuclear, chemical,
biological or missile weapons or other weapons of
mass destruction; or military purposes; or purposes that
endanger global safety and peace. Moreover, do not
sell, give, or export these items, or grant permission for
use to parties with such objectives. Forward all inquiries
to Hitachi Ltd.
Be sure to read this manual before servicing. To assure safety from fi re, electric shock, injury, harmful
radiation and materials, various measures are provided in this Hitachi Multimedia LCD Projector. Be
sure to read cautionary items described in the manual to maintain safety before servicing.
1. When replace the lamp, to avoid burns to your fi ngers. The lamp becomes too hot.
2. Never touch the lamp bulb with a fi nger or anything else. Never drop it or give it a shock. They may
cause bursting of the bulb.
3. This projector is provided with a high voltage circuit for the lamp. Do not touch the electric parts of
power unit (main), when turn on the projector.
4. Do not touch the exhaust fan, during operation.
5. The LCD module assembly is likely to be damaged. If replacing to the LCD LENS/PRISM assembly,
do not hold the FPC of the LCD module assembly.
6. Use the cables which are included with the projector or specifi ed.
1. Features -----------------------------------------------2
2. Specifi cations -----------------------------------------2
3. Names of each part ---------------------------------3
4. Adjustment --------------------------------------------5
5. Troubleshooting ------------------------------------ 12
6. Service points -------------------------------------- 17
7. Wiring diagram ------------------------------------- 30
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT.
Multimedia LCD Projector
Caution
Service Warning
Contents
August 2004 Digital Media Division
No.0547E
YK
CP-S335(C9SM)
CP-X340(C9X)
CP-X345(C9XM)
8. Disassembly diagram ----------------------------- 36
9. Replacement parts list ---------------------------- 42
10.RS-232C commands ----------------------------- 44
11. Block diagram -------------------------------------- 53
12. Connector connection diagram ---------------- 54
13.Basic circuit diagram ------------------------------ 55
Advertisement
Table of Contents
Related Manuals for Hitachi CP-S335
Summary of Contents for Hitachi CP-S335
-
Page 1: Table Of Contents
No.0547E CP-S335(C9SM) SERVICE MANUAL CP-X340(C9X) CP-X345(C9XM) Warning The technical information and parts shown in this manual are not to be used for: the development, design, production, storage or use of nuclear, chemical, biological or missile weapons or other weapons of mass destruction;... -
Page 2: Features
Drive system Liquid crystal Panel size 1.8 cm (0.7 type) panel Number of pixels CP-S335 : 800 (H) × 600 (V) CP-X340/X345 : 1024 (H) x 768(V) Lamp 165W UHB Video: Analog 0.7Vp-p(75Ω termination) RGB IN H/V. sync.: TTL level (positive/negative) signal Composite sync.: TTL level... -
Page 3: Names Of Each Part
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 3. Names of each part ● Part names Projector Remote sensor Zoom knob Speaker Focus ring Vent Elevator button Lens cover (Slide door) Elevator foot Front-Right side Lens Lamp cover Filter cover (Lamp unit is inside.) (Air filter and intake vent are inside.) -
Page 4: Control Buttons
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Control buttons LAMP indicator LAMP TEMP indicator TEMP POWER indicator POWER Cursor buttons ▲,▼,◄,► STANDBY/ON INPUT MENU STANDBY/ON button INPUT button Remote control SEARCH button RGB button STANDBY/ON button VIDEO button STANDBY/ON VIDEO SEARCH AUTO button ASPECT button ASPECT... -
Page 5: Adjustment
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 4. Adjustment 4-1 Before adjusting 4-1-1 Selection of adjustment When any parts in the table 4-1 are changed, choose the proper adjusting items with the chart. Table 4-1: Relation between the replaced part and adjustment Adjustment Replaced White Color... - Page 6 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 4-2 Convergence adjustment 1. Open FACTORY MENU and then select Signal pattern for internal adjustment OPTION > CNV-V. Use R and/or B so that three colors of images can be converged at center, top and bottom of the screen.
- Page 7 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 4-5 Flicker adjustment (V.COM adjustment) Adjustment procedure Signals for internal adjustment 1. Make this adjustment after completing the adjustment in 4-4 Ghost adjustment. 2. Use DAC-P - V.COM - R: in the FACTORY MENU to adjust so that the flicker at the center of the screen is less than the flicker at the periphery.
-
Page 8: Color Uniformity Adjustment
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 4-8 Color uniformity adjustment Preparations 1. Perform these adjustments after the white balance 6. To temporarily turn correction off, place the adjustment described in Section 4-7. cursor on [C.UNIF.] in the Adjust Tone menu and 2. Make a color uniformity adjustment for the follow- press the [ ] key. - Page 9 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Adjustment procedure 1 (When a color differential meter is used) 9. Similarly, measure adjustment points [No.3] to 1. First adjust [MID-L] tone [G:]. [No.17] and adjust their color coordinates start- 2. Select adjustment point [No.2][G:]. ing in order from the small number points.
- Page 10 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Adjustment procedure 2 (visual inspection) 1. First adjust [MIN] tone [G:]. 6. View measurement points [No.2], [No.3], 2. Select [No.2] [G:]. [No.10] and [No.11]. Adjust the [R] and [B] of If the background is [G] monochrome, press the each measurement point so that they have the [ENTER] key on the Remote control transmitter same color as measurement point [No.1].
- Page 11 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 4-9 AIR-FLOW-SENS adjustment When the PWB assembly MAIN is replaced, perform this adjustment after completing reassembling the pro- jector. 1. Set the item “WHISPER” to “NORMAL”, then warm up for 5 minutes or more. 2. Open HIDDEN SERVICE MENU with the following procedure and choose ”AIR-FLOW-SENS” by using [▼] button.
-
Page 12: Troubleshooting
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 5. Troubleshooting Check points Temperature SW(TSW) PWB assembly SW CNLC E800 EPSL IS02 E801 E803 E804 IT03 IT02 E806 E301 E802 PWB assembly MAIN P501 D303 (LAMP) ET01 D301 (POWER) E805 CNCT E807 D302 P601 (TEMP) to PWB assembly... - Page 13 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Power can not be turned on Disconnect voltage input at TSW form Power unit pins (1)(3)(5)(7) of E800 Open (circuit). And check on the PWB assembly TSW short or Main at standby open? mode? (1): +0V (3): +17V Short (5): +6.6V...
- Page 14 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Lamp does not light What is the Light state of LAMP indicator Is the LAMP Install the Lamp D303 during operation? installation correct? Not light Light Change the lamp. Lamp Does lamp light? Not light Is the voltage at the "L"...
- Page 15 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Picture is not displayed only when the RGB signal is input Check at operating mode voltage input at pins(1)(3)(5)(7) of Power unit E800 on the PWB (circuit) assembly MAIN? (1):+13.2V (3):+17V (5):+6.6V (7):+4.1V Are the proper waveform IS02 observed at the pins (4)
- Page 16 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Can not control to RS-232C The check after parts change 1. PC power supply OFF 2. Connection of cable 3. Projector starting 4. PC starting Check the *When not operating : RS-232C cable. Use cross cable PC set up change of cable.
-
Page 17: Service Points
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 6. Service points 6-1 Lead free solder [CAUTION] This product uses lead free solder (unleaded) to help preserve the environment. Please read these instructions before attempting any soldering work. CAUTION Always wear safety glasses to prevent fumes or molten solder from getting into the eyes. Lead free solder can splatter at high temperatures (600˚C). - Page 18 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 6-2 Before Replacing The LCD/Lens Prism You should not replace separately the parts of the liquid crystal LCD/Lens prism because it works properly only when used together. Therefore, regarding these parts, you can either replace part, LCD/Lens prism assembly, or send the whole unit LCD/Lens prism assembly back to HITACHI, where we will replace the malfunctioning part, recondition the device and send it back to you.
- Page 19 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 3. Maintenance point Swab Each color part has same Holder construction. Optical filter By using swab and air duster, Panel you can easily remove dust from panel and optical filter. Actua l formation Separatied formation 4. Cleaning the panels and optical filters (1) Turn on the set and lit on the lamp.
-
Page 20: Putting Batteries
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 6-4 Putting batteries WARNING Always handle the batteries with care and use them only as directed. Improper use may result in battery explosion, cracking or leakage, which could result in fi re, injury and/or pollution of the surrounding environ- ment. - Page 21 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 6-5 Air filter WARNING ● Before caring, make sure the power switch is off and the power cable is not plugged in, and then allow the projector to cool suffi ciently. The care in a high temperature state of the projector could cause a burn and/ or malfunction to the projector.
- Page 22 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 6-6 Lamp WARNING HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE ● The projector uses a high-pressure mercury glass lamp. The lamp can break with a loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time. Note that each lamp has a different life- time, and some may burst or burn out soon after you start using them.
- Page 23 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Replacing the Lamp When the indicators or a message prompts you to replace the lamp, replace the lamp as soon as possible. 1. Turn the projector off, and unplug the power cord. Allow the lamp to cool for at least 45 minutes.
- Page 24 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 6-7 Other care WARNING Before caring, make sure the power switch is off and the power cable is not plugged in, and then allow the projector to cool suffi ciently. The care in a high temperature state of the projector could cause a burn and/ or malfunction to the projector.
- Page 25 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 6-8 Notice of AUTO adjustment Use of AUTO adjustment with the image through RGB input optimizes V_POSI, H_POSI, H_SIZE and H_PHASE automatically. In case that projected image has dark tone around its peripheral, AUTO operation sometimes makes artifacts in the image, shifts capture area and so on. Those failures are caused by period of image data is not exactly distinguished to period of blanking on signal processing.
- Page 26 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 6-9 PIN LOCK System If the following PIN BOX menu appears after power on the projector, the PIN LOCK system has been activated. Under such a condition, key operations and signal displaying are inhibited. To open the PIN LOCK system, we need to input the correct 4 digits PIN CODE.
-
Page 27: Related Messages
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 6-10 Related Messages When the unit’s power is on, messages such as those shown below may be displayed. When any such message is displayed on the screen, please respond as described below. Although these messages will be automatically disappeared around several minutes, it will be reappeared every time the power is turned on. -
Page 28: Regarding The Indicator Lamps
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 6-11 Regarding the indicator lamps Lighting and flashing of the POWER indicator, the LAMP indicator, and the TEMP indicator have the mean- ings as described in the table below. Please respond in accordance with the instructions with in the table. - Page 29 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 6-12 HIDDEN SERVICE MENU To display the OSD for “HIDDEN SERVICE MENU” set up. HIDDEN SERVICE By the control panel By the remote control transmitter FILTER TIME 1. Display the Advance menu by 1. Display the menu by the...
-
Page 30: Wiring Diagram
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 7. Wiring diagram... - Page 31 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) EM01...
- Page 32 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM)
- Page 33 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM)
- Page 34 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM)
- Page 35 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM)
-
Page 36: Disassembly Diagram
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 8. Disassembly diagram M:Meter Screw T:Tapping Screw (Notice1) 18 (Notice5) M3x6 M3x6 T3x12 M3x6 M3x8 M3x8 LAMP FAN/DUCT (Notice4) POWER SUPPLY UNIT (Notice2,3,6) T3x12 T3x12 DICHROIC OPTICS UNIT LCD/LENS PRISM... - Page 37 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) LAMP FAN/DUCT (Notice4) POWER SUPPLY UNIT T3x12 (Notice6) (Notice2) (Notice3) T3x16 DICHROIC OPTICS UNIT LCD/LENS PRISM T3x8 M3x8 T3x35...
- Page 38 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Notice 1. Attaches UPPER CASE assembly The screw hole (a4) is weaker than the others (2) Take the Power Center Sheet and the Power (a1),(a2) and (a3). Side Sheet off. Tighten this screw carefully in accordance with screw torque below.
- Page 39 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 3. Putting the power supply unit together after the maintenance of the POWER UNIT (CIRCUIT) and/or the POWER UNIT (BALLAST). (3) Attaching the Power Sheet WARNING Power Sheet Assemble the power supply unit with care to achieve the required insulation.
- Page 40 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Please follow the procedure below in removing the LAMP FAN/DUCT at maintenance; remove the POWER UNIT prior to the LAMP FAN/DUCT, because the WIRE is routed underneath the POWER SUPPLY UNIT. 1) Unscrew the SCREW-1 and SCRW-2, and remove the POWER SUPPLY UNIT.
- Page 41 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 5. Cautions when removing the PWB assembly MAIN When removing the PWB assembly MAIN, there is danger of damaging the connector connecting cables. 1) Disconnect 13 cables and remove 2 screws. 2 screws PWB assembly MAIN 2) Remove 1 screw.
-
Page 42: Replacement Parts List
PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing any of there components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety of the projector through improper servicing. - Page 43 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) CP-X345 SYMBOL PARTS SYMBOL PARTS DESCRIPTION DESCRIPTION QD38741 UPPER CASE SASS’Y HA01381 POWER UNIT(CIRCUIT) QD38761 BOTTOM CASE SASS’Y 2722448 FUSE 6.3A PE00111 RUBBER FOOT GK00397 SPEAKER QJ01111 ADJUST FOOT FH00282 TEMP. SENSOR QD38801 FILTER COVER ASS’Y DT00671 LAMP UNIT ASS’Y QD38781 LAMP DOOR ASS’Y...
-
Page 44: Rs-232C Commands
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 10. RS-232C communication RS-232C cable(Cross) CONTROL port RS-232C port of the projector of a computer - (1) (1) CD RD (2) (2) RD TD (3) (3) TD - (4) (4) DTR GND (5) (5) GND - (6) (6) DSR... - Page 45 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Requesting projector status (Get command) (1) Send the request code Header + Command data (‘02H’+‘00H’+ type (2 bytes)+ ‘00H’+‘00H’) from the computer to the projector. (2) The projector returns the response code ‘1DH’+ data (2 bytes) to the computer.
-
Page 46: Command Data Chart
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Command data chart Command Data Names Operation Type Header Action Type Setting Code Power Turn off BE EF 06 00 2A D3 01 00 00 60 00 00 Turn on BE EF 06 00 BA D2 01 00 00 60... - Page 47 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Command Data Names Operation Type Header Action Type Setting Code User Gamma Pattern BE EF 06 00 FB FA 01 00 80 30 00 00 9 step gray scale BE EF 06 00 6B FB 01 00 80 30...
- Page 48 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Command Data Names Operation Type Header Action Type Setting Code COLOR TEMP GAIN G BE EF 06 00 70 F4 02 00 B2 30 00 00 Increment BE EF 06 00 16 F4 04 00 B2 30 00 00...
- Page 49 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Command Data Names Operation Type Header Action Type Setting Code OVER SCAN BE EF 06 00 91 70 02 00 09 22 00 00 Increment BE EF 06 00 F7 70 04 00 09 22 00 00 Decrement BE EF...
- Page 50 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Command Data Names Operation Type Header Action Type Setting Code FRAME LOCK TURN OFF BE EF 06 00 CB D6 01 00 14 30 00 00 TURN ON BE EF 06 00 5B D7 01 00 14 30 01 00...
- Page 51 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Command Data Names Operation Type Header Action Type Setting Code MENU POSITION H BE EF 06 00 04 D7 02 00 15 30 00 00 Increment BE EF 06 00 62 D7 04 00 15 30 00 00 Decrement...
- Page 52 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) Command Data Names Operation Type Header Action Type Setting Code LAMP TIME BE EF 06 00 C2 FF 02 00 90 10 00 00 LAMP TIME Reset Execute BE EF 06 00 58 DC 06 00 30 70 00 00...
-
Page 53: Block Diagram
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 11. Block diagram... -
Page 54: Connector Connection Diagram
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 12. Connector connection diagram Connector connection diagram (C9SM/C9X/C9XM) -
Page 55: Basic Circuit Diagram
CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) 13. Basic circuit diagram Parts with hatching are not mounted. PWB assembly SW (C9SM/C9X/C9XM) PWB assembly REMC (C9SM/C9X/C9XM) - Page 56 CP-S335(C9SM)/CP-X340(C9X)/CP-X345(C9XM) MEMO...
- Page 57 4parallel 3series POWER UNIT (BALLAST) (C9SM/C9X/C9XM) Warning For handling of the circuit diagram, refer to the warning on the cover.
- Page 59 PWB assembly CONTROL (C9SM/C9X/C9XM)
- Page 60 PWB assembly MAIN 1 (C9SM/C9X/C9XM)
- Page 61 PWB assembly MAIN 2 (C9SM/C9X/C9XM)
- Page 62 PWB assembly MAIN 3 (C9SM/C9X/C9XM)
- Page 63 PWB assembly MAIN 4 (C9SM/C9X/C9XM)
- Page 64 PWB assembly MAIN 5 (C9SM/C9X/C9XM)
- Page 65 C9SM : not mounted C9X/C9XM : mounted C9SM : not mounted C9X/C9XM : mounted PWB assembly MAIN 6 (C9SM/C9X/C9XM)
- Page 66 C9SM : not mounted C9X/C9XM : mounted C9SM : not mounted C9X/C9XM : mounted PWB assembly MAIN 7 (C9SM/C9X/C9XM)
- Page 67 C9SM : not mounted C9X/C9XM : mounted C9SM : not mounted C9X/C9XM : mounted PWB assembly MAIN 8 (C9SM/C9X/C9XM)
- Page 68 PWB assembly MAIN 9 (C9SM/C9X/C9XM)
- Page 69 PWB assembly MAIN 10 (C9SM/C9X/C9XM)
- Page 70 PWB assembly MAIN 11 (C9SM/C9X/C9XM)
- Page 71 PJ-TX100(C11H) Basic circuit diagram list PWB assembly SW PWB assembly MAIN 4 PWB assembly REMC PWB assembly MAIN 5 POWER UNIT BALLAST PWB assembly MAIN 6 POWER UNIT CIRCUIT PWB assembly MAIN 7 PWB assembly CONTROL PWB assembly MAIN 8 PWB assembly MAIN 1 PWB assembly MAIN 9 PWB assembly MAIN 2...
- Page 72 CP-S335 YK No.0547 Digital Media Division CP-X340 CP-X345 QR62111 Printed in Japan (JE)
