Summary of Contents for Electrolux 63K914
- Page 1 Models EOC617 EOC627/63K906 BUILT - IN COOKING APPLIANCES EXC617 EGC627/EXC627 User Manual EOC647/63K914...
-
Page 2: Table Of Contents
63K914 ..............4 avoid misuse and hazards. For future reference, please store Before operating your appliance for the first time ..5 this booklet in a safe place. -
Page 3: General Safety
general safety an important read to avoid an electric shock or fire grill warnings Meanings of symbols used in this manual are shown below: DO NOT leave grill on unattended. This symbol indicates never to do this The grill door must be left fully open whilst grilling in a separate grill wall oven. -
Page 4: Description Of Your Appliance
Oven Temperature Selector Grill Temperature Selector One Hour Timer Oven Temperature Selector Grill Temperature Selector One Hour Timer Model: eoC647/63K914 underbench oven Multifunction 5 Function Selector 3 Button Programmable Clock Oven/Grill Temperature Selector Function Selector 3 Button Programmable Timer Oven/Grill Temperature Selector... -
Page 5: Before Operating Your Appliance For The First Time
before operating your appliance for the first time 1. side racks TIPS & INFORMATION tips & information Separate grill wall ovens come with side racks that are to be fitted to the smaller “grill cavity”. setting the time These can be attached to either side in the following manner: After electrically connecting the appliance, you must set the time of the day before you can operate your oven. -
Page 6: Operating The Programmable Clock
3 button programmable clock Your oven is equipped with a 3 button timer that has the following features: • T imer - you can set a countdown time that will beep when the set time has elapsed. • C ook time - you can set cooking duration. -
Page 7: Using Your Oven
using your oven to check or cancel settings • T o insert the grill tray in a separate grill underbench, fully open the grill drawer and position the tray so that the slots • T o check your settings, press the MODE button until the on the outer edges fit on the tabs on the slides. indicator you want is flashing. -
Page 8: Cooling/Venting Fan
using your oven You can use the “Bake” function for single trays of biscuits, scones, muffins, cakes, slices, casseroles, baked puddings, roasts and delicate egg dishes. Maxi Grill “Maxi grill” directs radiant heat from 2 powerful upper elements onto the food. You can use the “maxi grill” function defrost for tender cuts of meat, steak, chops, sausages, fish, cheese toasties and other quick cooking foods. -
Page 9: Condensation
Condensation With “Fan Forced” Excess condensation may fog the oven door. This may 1. It is recommended to preheat your appliance when happen when you are cooking large quantities of food cooking or baking. from a cold start. You can minimise condensation by: 2. -
Page 10: Cooking Guide
cooking guide on completion of cooking oven shelf location The oven will turn off, the timer will beep and the “end time“ Your oven comes with formed “easy clean” runners that allow and/or “cook time“ indicators will flash. five positions for shelves. These are numbered from 1 (the lowest shelf position) to 5 (the highest shelf position). -
Page 11: Choosing The Best Oven Settings
cooking guide Choosing the best oven settings The following table is intended as a guide and experience may show some variation in cooking times necessary to meet individual requirements. For best baking results preheat oven for 30 minutes. food non fan forced mode fan forced oven time in minutes Temperature... -
Page 12: Roasting Meat
cooking guide roasting Meat roasting poultry and fish 1. Place the meat in the oven and set the temperature 1. Place the poultry or fish in an oven set at a moderate between 180°C and 200°C. (It is recommended to wrap temperature of 180°C. -
Page 13: Grilling Guide
grilling guide grilling hints guide to better grilling No definite times can be given for grilling because this depends on your own tastes and the size of the food. These WARNING warning times should only be used as a guide and remember to turn Note: Always clean the grill/oven dish after every use. -
Page 14: Dealing With Cooking Problems
dealing with cooking problems Problem Causes remedy Uneven cooking Incorrect shelf position Select shelf that puts food in centre of oven Oven tray too large Try other trays or dishes Trays not in centre Put trays in centre Air flow in oven uneven Rotate food during cooking Grill tray affecting thermostat Remove grill tray from oven on bake modes... -
Page 15: Get To Know Your Oven
get to know your oven get to know your new oven with this Method: ‘simple test Cake’ 1. Butter base and sides of two, 20cm straight-sided round Although we strive for a perfect performing oven, it’s or square cake pans. Then line the base with grease possible that there will be some variation in colour when proof or baking paper. -
Page 16: Cleaning Your Appliance
Removing the shelves from your appliance • U se a stainless steel cleaner only where the stainless steel • S lide the shelves towards you until they reach the front stop. is extremely dirty and/or discoloured. A suitable cleaner can be purchased from Electrolux Service or Spares. See • T ilt them up at the front, taking care not to spill any contents. back cover. • Lift them clear. Note: Make sure you follow the polish or brushing lines • Wash the dish and insert the shelves in hot soapy water. - Page 17 • T urn oven light glass anticlockwise to remove it for globe • R otate latch 180º. replacement. The element will drop down freely. • A special high temperature resistant globe should be used. This can be purchased from the Electrolux Customer Care Centre. WARNING warning Important: Make sure the appliance is turned off before you remove or replace parts, to avoid the possibility of electric shock.
-
Page 18: Cleaning Your Oven Door
cleaning your oven door • G rasp the oven door with a hand each side of the door WARNING warning and remove it from the oven by pulling it towards you. Do not lift the door by the handle. Rough handling will cause glass to break. Removing the oven door Your oven is equipped with a door that can be disassembled in order to clean all the panes of glass. - Page 19 cleaning your oven door Re-assembling bottom trim • P ush down to “snap” each side of bottom trim back into door columns. Cleaning door glass panels WARNING warning Do not to use harsh abrasives on the glass panes as the reflective surface plays a role in the function of the oven. Re-assembling door glass panels Do not place glass in dishwasher.
- Page 20 cleaning your oven door Re-assembling top door trim • O pen the door fully to access the hinges then rotate the ‘stirrups’ (highlighted in the image) on both hinges back to • T ake hold of the top door trim at each side and position it their original positions. to the inside edge of the glass. The oven door may now be closed. • P ush the trim down with its top edge over glass panel until the clip snaps in on each side of the trim.
-
Page 21: Solving Problems
Note: We may charge for service even in the guarantee Problem Possible Cause Oven or grill not working • Time of day not set. • Power not turned on. • Controls are incorrectly set. • Household fuse has blown or power supply is off. • Child-proof oven lock activated. (Refer to operating instructions) Note: If the household fuse continues to blow, call the Electrolux Customer Care Centre. Oven light not working • Lamp blown or loose in socket. • Household fuse has blown. Note: If the household fuse continues to blow, call the Electrolux Customer Care Centre. Oven not heating enough • Foil or trays on bottom of oven. Oven not working • Timer is in “AUTO” mode. (Refer to timer operating instructions) • Household fuse has blown. -
Page 22: Installation
installation • W here the appliance is built into a cabinet, the cabinet WARNING warning material must be capable of withstanding 70°C. Installation into low temperature tolerant cabinetry (e.g. vinyl coated) USE AN AUTHORISED PERSON may result in deterioration of the low temperature coating by As stated in the local municipal building codes and other relevant discolouring or bubbling. -
Page 23: Cabinet Construction For Your Appliance
installation Cabinet construction for your appliance A recess of 20mm is ideal. It can also be installed using a proud fit with the surrounding cupboard (figure B). For the best integration within a kitchen, install this appliance in a standard 600mm wide cupboard that gives a flush fit with the Note: Your appliance must be mounted on a flat surface for surrounding cupboard fronts (figure A). -
Page 24: Separate Grill Underbench Ovens
installation separate grill underbench ovens Recommended Cabinet design NOTE TO INSTALLER: For Separate Grill Underbench Installations where a Cooktop is installed directly above the appliance, a minimum clearance distance of 10mm must be allowed for between the bottom of the cooktop and the top of the Separate Grill Underbench Oven. 720mm Module(s) Bench top Cleat (2) Infill panel (2) Cooker 720mm Module(s) platform Kick Panel Supporting shelf 8mm below door line to give perfect alignment of cooker &... -
Page 25: Separate Grill Wall Ovens
installation separate grill Wall ovens Hard Wiring Detail 1. Remove terminal cover plate from rear panel of appliance. 2. Fit wires through hole in cover plate and make connections to terminals. Second active wire only 3. Engage wires into plastic clip. Secure plastic clip with two required (optional) for multi-phase products. -
Page 26: Notes
notes 26 NOTES Built-in Cooking... -
Page 27: Warranty
Australia or New Zealand. the Appliances come with a guarantee by Electrolux that cannot be 3. During the Warranty Period Electrolux or its ASC will, at no extra charge excluded under the ACL. You are entitled to a replacement or refund... - Page 28 ........ customercare@electrolux.co.nz website ..........www.simpson.co.nz top service Top Service encompasses the after sales service provided by The Electrolux Group to consumers including delivery, home service and spare parts. We are part of the electrolux family. share more of our thinking at www.electrolux.com ©...
