Owner's Manual IPS LED MOnItOr (LED MOnItOr*) *LG LED Monitors are LCD Monitors with LED Backlighting. Please read the safety information carefully before using the product. IPS LED Monitor (LED Monitor) Model List 27UD88 www.lg.com...
Installing the Monitor - Assembling the stand base - Using the cable holder sPeCIFICAtIons - Installing onto a table 27UD88 - Adjusting the angle Factory Support Mode (Preset Mode, PC) - Adjusting the Stand Height HDMI - Pivot Feature...
LICense Each model has different licenses. Visit www.lg.com for more information on the license. the terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
It is recommend that use the supplied components. If you use generic cables not certified by LG, the screen may not display or there may be image noises. note note that the components may look different from those shown here.
CoLoR PRo optional required and recommended: You can download and install the latest version from the enclosed CD or from the LGE website (www.lg.com) . Optional: You can download and install the latest version from the LGE website (www.lg.com) .
Component and Button Description Joystick Button Power LED On: power is on Off: power is off How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with your finger. Basic Functions Press the joystick button once with your finger to turn on the Power on...
Moving and Lifting the Monitor CAUtIon When moving or lifting the monitor, follow these instructions As far as possible, avoid touching the monitor screen. to prevent the monitor from being scratched or damaged and this may result in damage to the screen or some of to ensure safe transportation regardless of its shape or size.
Installing the Monitor Assembling the stand base CAUtIon to protect the screen from scratches, cover the surface with a soft cloth. stand Body note stand Base Press the stand until the button reaches the top.
Using the cable holder CAUtIon Arrange the cables using the cable holder as shown in the Illustrations in this document represent typical illustration. procedures, so they may look different from the actual product. Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this way will not be covered by the product warranty.
Installing onto a table Cautions When Connecting Power Cord Lift the monitor and place it on the table in an upright position. Place at least 10 cm away from the wall to ensure suf- ficient ventilation. 10 cm 100-240 V ~ 10 cm 10 cm 10 cm...
Adjusting the stand Height Adjusting the angle Handle the monitor with both hands for safety. Place the monitor in an upright position, mounted on the stand base. Adjust the angle of the screen. the angle of the screen can be adjusted forwards or backwards for a comfortable viewing experience.
Pivot Feature rotate the monitor clockwise as shown in the figure. the pivot feature allows the monitor to rotate 90° clockwise. Head Complete the installation by rotating the monitor 90° as Stand shown below. WARnInG to avoid scratching the stand base, make sure that when rotating the monitor using the pivot feature, the stand does not make contact with the monitor.
Detaching the stand Body WARnInG take care when rotating the monitor if the cable is Place the monitor’s screen face down. to protect the connected. screen from scratches, cover the surface with a soft to avoid injury when rotating the display, do not place cloth.
Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Please use the genuine LG wall 10 cm mounting bracket. For more information, contact your local retail store or a qualified installer.
DP version of the PC. If you use generic cables not certified by LG, the screen may not display or there may be image noises. UsB-C connection transmits digital video and audio signals and USB data from your PC to the monitor.
Connecting to AV Devices Connecting Peripherals HDMI connection USB Cable connection - PC Transmits the digital video and audio signals from your PC The USB port on the product functions as a USB hub. and A/V devices to the monitor. Connect your PC and AV de- Please connect the USB C-C or USB C-A cable to the PC.
Connecting Headphones service only port Connect peripherals to the monitor via the headphones port. Connect as illustrated. the port is used only for “Service” . SERVICE ONLY (sold separately) note Peripheral devices are sold separately. If you use angled earphones, it may cause a problem with connecting another external device to the monitor.
UseR settInGs Activating the Main Menu Press the joystick button on the bottom of the monitor. Move the joystick up/down ( ▲ / ▼ ) and left/right( ◄ / ► ) to set the options. Press the joystick button once more to exit the main menu. Joystick Button Button Menu status...
Customizing settings Menu settings -Quick settings to view the osD menu, press the joystick button at the bot- tom of the monitor and then enter the Menu. Go to Quick settings > by moving the joystick. Brightness Configure the options following the instructions that appear in the bottom right corner.
-PBP to view the osD menu, press the joystick button at the bottom of the monitor and then enter the Menu. Go to PBP by moving the joystick. Configure the options following the instructions that appear in the bottom right corner. to return to the upper menu or set other menu items, move the joystick to ◄...
-Picture to view the osD menu, press the joystick button at the bot- tom of the monitor and then enter the Menu. Go to by moving the joystick. Picture Configure the options following the instructions that appear in the bottom right corner. to return to the upper menu or set other menu items, move the joystick to ◄...
Page 23
Picture Adjust sUPeR ResoLUtIon+ High Optimized picture quality is displayed when a user wants crystal clear images. It is effective for high quality video or game. Middle the optimized picture quality is displayed when a user wants images between low and high modes for comfortable viewing. It is effective for UCC or SD video.
Page 24
Game Adjust Response time Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Middle. For a fast-moving picture, it is recommended that you use high. Setting to High may cause image sticking.
-General to view the osD menu, press the joystick button at the bot- tom of the monitor and then enter the Menu. Go to by moving the joystick. General Configure the options following the instructions that appear in the bottom right corner. to return to the upper menu or set other menu items, move the joystick to ◄...
Page 26
Menu > General Description Quick Charge Quick Charge is a feature that rapidly charges the device connected to the USB 3.0 port. Enables Quick Charge. Disables Quick Charge. note When Quick Charge is set to on, data transmission through the USB1/2 port is not available (e.g. con- necting your keyboard, mouse, or other USB storage devices to the monitor).
-Reset to view the osD menu, press the joystick button at the bot- tom of the monitor and then enter the Menu. Go to by moving the joystick. Reset Configure the options following the instructions that appear in the bottom right corner. to return to the upper menu or set other menu items, move the joystick to ◄...
tRoUBLesHootInG nothing is displayed on the screen. Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. Is the power LED on? Check the power cable connection and press the power button. Check that the connected input is enabled (Menu >...
Page 29
Have you installed the display driver? comes with your display. Or, you can also download the driver from our web site: http://www.lg.com. Make sure to check if the video card supports Plug&Play function. no sound from the headphone port or speaker.
27UD88 LCD Screen type tFt (thin Film transistor) LCD (Liquid Crystal Display) Screen Pixel Pitch 0.1554 mm x 0.1554 mm resolution Maximum resolution 3840 x 2160 @ 60 Hz recommended resolution 3840 x 2160 @ 60 Hz Video Signal...
HDMI timing (Video) Factory support mode Horizontal Vertical Remarks (Preset Mode) Frequency(kHz) Frequency(Hz) 480p 31.5 720p 45.0 1080p 67.5 When HDMI ULtrA HD Deep Color is set to 2160p Power LeD Mode LeD Color On Mode White Sleep Mode Flashing White Off Mode...
PRoPeR PostURe Proper Posture for Using the Monitor Adjust the screen so that you can comfortably view at a slight downward angle from your natural eye level. take a break for approximately ten minutes every hour to reduce any fatigue caused by long-time usage. the stand of the touch monitor allows the product to be used in the optimum position.
Electronics will also provide open source code to you on CD-rOM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
