0_D73PAL_E(cover) 02.12.26 9:17 PM Page 1
Downloaded From VideoCamera-Manual.com Manuals
Mini
Digital
Video
Cassette
This instruction manual covers the MV650i, MV630i, MV600i and MV600. Please note
that illustrations and explanation in this manual are based on the MV650i.
PUB.DIE-181
Digital Video Camcorder
English

Instruction Manual

Introduction
Mastering
the Basics
Using the
Full Range
of Features
Editing
MV650i
MV630i
Using a
Memory Card
Additional
Information
PAL

Advertisement

Table of Contents
loading

Related Manuals for Canon MV650i

Summary of Contents for Canon MV650i

  • Page 1: Instruction Manual

    MV650i MV630i Using a Mini Digital Memory Card Video Cassette This instruction manual covers the MV650i, MV630i, MV600i and MV600. Please note that illustrations and explanation in this manual are based on the MV650i. Additional Information Downloaded From VideoCamera-Manual.com Manuals...

  • Page 2: Important Usage Instructions

    1_D73PAL_E(02-12) 02.12.26 9:20 PM Page 2 Important Usage Instructions WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

  • Page 3: Reference Guide

    USB cable. You can add sample images for Card Mix and My Camera settings from the supplied DIGITAL VIDEO SOLUTION DISK. Trademark Acknowledgements • Canon is a registered trademark of Canon Inc. • D is a trademark. •...

  • Page 4: Table Of Contents

    1_D73PAL_E(02-12) 02.12.26 9:20 PM Page 4 Table of Contents Introduction Reference Guide ......................3 Thank You for Choosing a Canon ................7 Introducing the MV650i/MV630i/MV600i/MV600 ............8 Components Guide ......................9 Mastering the Basics Preparations Using a Household Power Source ................13 Attaching and Charging the Battery Pack ..............14 Installing the Backup Battery ..................17...
  • Page 5 Photo Search/Date Search....................84 Returning to a Pre-marked Position ................85 Editing Recording to a VCR or Digital Video Device ............86 Recording from Analog Video Devices MV650i MV630i MV600i (VCR, TV or Camcorder)....................88 Recording from Digital Video Devices (DV Dubbing) ..89 MV650i...
  • Page 6 CARD CAMERA CAMERA CARD CARD PLAY (VCR) PLAY (VCR) CARD : MV650i and MV630i only. Shaded area Available functions depend upon the operating mode. It is indicated as follows: CAMERA : Function can be used in this mode. CAMERA : Function cannot be used in this mode.

  • Page 7: Thank You For Choosing A Canon

    1_D73PAL_E(02-12) 02.12.26 9:20 PM Page 7 Thank You for Choosing a Canon The Canon MV650i/MV630i/MV600i/MV600 provides a full range of options and functions. We recommend reading this manual thoroughly before you use the camcorder. It will help you to become more familiar with your camcorder, and learn how to operate it properly.

  • Page 8: Introducing The Mv650I/Mv630I/Mv600I/Mv600

    Super Night Mode and Low Light merged into one panoramic scene with Plus Mode (MV650i) the supplied software. With the MV650i’s Super Night mode (in Direct Print (MV650i/MV630i) CAMERA mode) and Low Light Plus You can print still images by connecting...

  • Page 9: Components Guide

    1_D73PAL_E(02-12) 02.12.26 9:20 PM Page 9 Components Guide MV650i/MV630i/MV600i/MV600 REC SEARCH + button (p. 33) / (fast forward) button (p. 35) / REC (record) SEARCH – button (p. 33) / CARD + button* (p. 110) Record review button (p. 33) / (rewind) button (p.
  • Page 10 1_D73PAL_E(02-12) 02.12.26 9:20 PM Page 10 Diopter adjustment lever (p. 18) Viewfinder protect PHOTO button (p. 54, 103) cover (p. 141) Advanced accessory MV650i shoe (p. 72) MV630i MV600i MV600 Accessory shoe (p. 149) Zoom lever (p. 28) Built-in speaker (p.
  • Page 11 1_D73PAL_E(02-12) 02.12.26 9:20 PM Page 11 Terminal cover Assist lamp MV650i (White LED) (p. 58) Remote sensor (p. 22) Stereo microphone (p. 70) Terminal cover S-video IN/OUT terminal * (p. 40) DV IN/OUT terminal * MIC terminal (p. 70) (p. 86)

  • Page 12: Wireless Controller

    1_D73PAL_E(02-12) 02.12.26 9:20 PM Page 12 Wireless Controller WL-D79 WL-D80 MV650i MV630i MV600i MV600 START ZOOM START /STOP PHOTO ZOOM /STOP PHOTO SELF T. D.EFFECT. MENU SELF T. D.EFFECT. MENU TV SCREEN ON/OFF ON/OFF TV SCREEN INDEX SLIDE SHOW CARD...

  • Page 13: Using A Household Power Source

    2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 13 Using a Household Power Source You can operate the camcorder from a household power source using the supplied power adapter. The power adapter converts current from a power outlet (100-240 V AC, 50/60 Hz) to the DC current used by the camcorder. 1.

  • Page 14: Attaching And Charging The Battery Pack

    2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 14 Attaching and Charging the Battery Pack Charge the battery pack with the supplied power adapter before you use the camcorder for the first time and subsequently when the message “CHANGE THE BATTERY PACK” appears. 1.
  • Page 15 Below times are approximate and vary according to the charging, recording or playback conditions. Charging Time Battery Pack Charging Time BP-508 (MV630i/MV600i/MV600) 110 min. BP-512 (MV650i/optional) 120 min. BP-511 (Optional) 120 min. BP-522 (Optional) 210 min. BP-535 (Optional) 310 min.
  • Page 16 2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 16 How much power is left? The battery symbols indicate the charge status of the battery pack. When the battery pack is empty, “CHANGE THE BATTERY PACK” appears for 4 seconds and starts flashing. The battery charge indicators are not constant – they vary according to the condition under which battery pack and camcorder are used.

  • Page 17: Installing The Backup Battery

    2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 17 Installing the Backup Battery The backup battery allows the camcorder to retain date, time and other camcorder settings while the power source is disconnected. Power the camcorder from a household power source or with a battery pack when replacing the backup battery. 1.

  • Page 18: Preparing The Camcorder

    2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 18 Preparing the Camcorder Adjusting the Viewfinder (Diopter Adjustment) 1. Turn on the camcorder and keep the LCD panel closed to adjust the viewfinder. 2. Adjust the diopter adjustment lever. Do not leave the viewfinder exposed to direct sunlight as it may melt (due to concentration of light by the lens).

  • Page 19: Attaching The Shoulder Strap

    Pass the ends through the strap mount and adjust the length of the strap. Mounting the Wide Attachment MV650i The WA-30.5 Wide Attachment gives you a wide perspective for indoor shots or panoramic views (0.6×). The wide attachment is for use at maximum wide-angle.

  • Page 20: Loading A Cassette

    2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 20 Loading a Cassette Use only video cassettes marked with the D logo. Loading and Unloading 1. Slide and hold the OPEN/EJECT switch and open the cassette Tape compartment cover. protection tab The cassette compartment opens automatically.
  • Page 21 2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 21 Protecting Tapes from Accidental Erasure To protect your recordings from accidental erasure, slide the tab on the cassette to the left. (This switch position is usually labelled SAVE or ERASE OFF.) SAVE If you load a protected cassette in CAMERA SAVE mode, the message “THE TAPE IS SET FOR ERASURE PREVENTION”...

  • Page 22: Using The Wireless Controller

    Following functions cannot be operated without the wireless controller: • Some special playback modes ( • Photo/date search ( • Zero set memory ( • MV650i MV630i MV600i Analog line-in ( • DV dubbing ( MV650i...

  • Page 23: Setting The Time Zone, Date And Time

    2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 23 Setting the Time Zone, Date and Time Set the time zone, date and time when you first start using your camcorder. Install the backup battery before you begin ( 17). Setting the Time Zone/Daylight Saving Time CAMERA PLAY (VCR) CARD CAMERA...

  • Page 24: Setting The Date And Time

    2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 24 14 15 16 17 18 19 20 21 22 23 24 1 10 11 12 13 Time zone Time zone WELLGTN (Wellington) LONDON PARIS SAMOA CAIRO HONOLU. (Honolulu) MOSCOW ANCHOR. (Anchorage) DUBAI L.A. (Los Angeles) KARACHI DENVER DACCA...
  • Page 25 2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 25 2. Turn the selector dial to select [SYSTEM] and press the selector dial. 3. Turn the selector dial to select [D/TIME SET] and press the selector dial. The year display starts to flash. 4. Turn the selector dial to select the year, and press the selector dial. •...

  • Page 26: Recording Movies On A Tape

    141). Preparations Connect a power source. Load a cassette. Recording 1. Remove the lens cap. MV650i/MV630i 2. Set the camcorder to CAMERA mode. TAPE CARD If you have not set the time zone, date and time, “SET THE TIME ZONE, DATE AND TIME”...
  • Page 27 2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 27 When You Have Finished Recording 1. Turn the POWER switch to OFF. 2. Close the LCD panel. 3. Replace the lens cap. 4. Unload the cassette. 5. Disconnect the power source. When recording outdoors or through a window, do not leave LCD screen, viewfinder or lens exposed to direct sunlight as it may cause damage.

  • Page 28: Zooming

    The camcorder automatically switches between optical zooming and digital zooming. Image resolution is slightly lower with the digital zoom. Zoom in Zoom out Optical Zoom MV650i MV630i MV600i MV600 22× optical zoom 20× optical zoom 18× optical zoom Move the zoom lever toward W to zoom out (wide- angle).
  • Page 29 ❍ Keep at least 1m to the subject. At wide-angle, you can focus on a subject as close as 1cm. ❍ Digital zoom cannot be used in the Night mode and Super Night (MV650i) mode. ❍ Digital zoom cannot be used when the multi-image screen is selected.

  • Page 30: Using The Lcd Screen

    2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 30 Using the LCD Screen 1. Push the OPEN button at the LCD panel and open the LCD panel. The LCD screen switches on and the viewfinder switches off. 2. Rotate the LCD panel and choose the angle of the screen.
  • Page 31 2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 31 Adjusting the Brightness of the LCD Screen CAMERA PLAY (VCR) CARD CAMERA CARD PLAY (VCR) DISPLAY SET UP BRIGHTNESS•• – 1. Press the MENU button to open the menu. MENU 2. Turn the selector dial to select [DISPLAY SET UP] and press the selector dial.
  • Page 32 2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 32 PLAY (VCR) CARD PLAY (VCR) CAMERA CARD CAMERA DISPLAY SET UP LCD MIRROR••ON 1. Press the MENU button to open the menu. 2. Turn the selector dial to select [DISPLAY SET UP] and press the selector dial.

  • Page 33: Searching And Reviewing When Recording

    2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 33 Searching and Reviewing when Recording REC SEARCH + button REC (record) SEARCH – button/ v Record review button Record Review PLAY (VCR) CARD CAMERA CARD PLAY (VCR) CAMERA In record pause mode, this function allows you to review the last few seconds of your recording to check if it has been recorded properly.

  • Page 34: Tips For Making Better Videos

    2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 34 Tips for Making Better Videos Holding the Camcorder For maximum stability, grip the camcorder in your right hand and keep your right elbow pressed against your body. If necessary, support the camcorder with your left hand.

  • Page 35: Playing Back A Tape

    5. Press the button to stop playback. ❍ If the playback picture is distorted, clean the video heads using a Canon Head Cleaning Cassette or a commercially available digital video head-cleaning cassette. ❍ To use the viewfinder, close the LCD panel. The built-in speaker does not sound.

  • Page 36: Special Playback Modes

    2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 36 Special Playback Modes Special playback modes (except of playback pause and fast/rewind playback) can only be operated with the wireless controller. ` (rewind) button 1 (fast forward) button PLAY STOP PAUSE SLOW 3 (stop) button e/a (play/pause) button e/a (Playback Pause) To pause playback, press the e/a button.
  • Page 37 2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 37 Playing Back with the Built-in Speaker/Headphones Built-in speaker H (phones) terminal MENU button Selector dial When using the built-in speaker, make sure that “H” is not displayed on the screen. When using the headphones, make sure that “H” is displayed. Change the setting as necessary following the procedure below.
  • Page 38 2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 38 Adjusting the Volume CAMERA* PLAY (VCR) CARD CAMERA* CARD PLAY (VCR) *Headphone volume only. Turn the selector dial up to increase the volume, and down to lower the volume. • A volume bar appears for 4 seconds. •...

  • Page 39: Playing Back On A Tv Screen

    2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 39 Playing Back on a TV Screen You can connect the camcorder to a TV or VCR to play back your recordings on a TV screen. ❍ Make sure that “H” is not displayed on the screen. If “H” is displayed on the screen, change the setting ( 37).
  • Page 40 2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 40 4. If connecting to a TV, set the input selector to VIDEO. If connecting to a VCR, set the input selector to LINE. The SCART Adapter PC-A10 is for output only. For analog line-in recording or analog-digital conversion, please use a SCART adapter with input capability (commercially available).
  • Page 41 2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 41 TVs with Audio/Video Terminals Refer also to the TV or VCR instruction manual. VIDEO AUDIO Signal flow STV-250N Stereo Video Cable (supplied) 1. Turn off all devices before starting the connections. 2. Connect the STV-250N Stereo Video Cable to the camcorder’s AV terminal and the audio/video terminals on the TV/VCR.
  • Page 42 2_D73PAL_E(13-42) 02.12.26 9:22 PM Page 42 Selecting the Audio Output Channel You can select the output channels when playing back a tape with audio recorded on two channels. CAMERA CARD CAMERA CARD PLAY (VCR) PLAY (VCR) AUDIO SET UP OUTPUT CH•••L/R 1.

  • Page 43: Menus And Settings

    Many of the camcorder’s advanced functions are selected from menus that appear on the screen. Selecting Menus and Settings 1. Set the camcorder to the correct operating mode. MV650i/MV630i TAPE CARD 2. Press the MENU button to open the menu.
  • Page 44 ANIMAT. TYPE CORNER, STRAIGHT, RANDOM MIX LEVEL CAMERA SET UP SHUTTER AUTO, 1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000 D. ZOOM MV650i MV630i MV600i/MV600 28 OFF, 88×, 440× OFF, 80×, 400× OFF, 72×, 360× IMAGE S. ON, OFF 16:9 ON, OFF AUTO, SET W, INDOOR T, OUTDOOR U WHITE BAL.
  • Page 45 S-UP IMAGE* ON, OFF SHTR SOUND * PATTERN1, PATTERN2, PATTERN3 S-UP SOUND PATTERN1, PATTERN2, PATTERN3 S/STOP SOUND PATTERN1, PATTERN2, PATTERN3 SELF-T SOUND PATTERN1, PATTERN2, PATTERN3 Does not appear with the Downloaded From VideoCamera-Manual.com Manuals MV650i MV650i MV630i MV600i MV600 MV600...
  • Page 46 3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 46 CARD CAMERA Menu (C. CAM. MENU) MV650i MV630i CAMERA PLAY (VCR) CARD PLAY (VCR) CARD CAMERA Submenu Menu Item Setting Options CAMERA SET UP SHUTTER AUTO, 1/50, 1/120, 1/250 AUTO, SET W, INDOOR T, OUTDOOR U WHITE BAL.
  • Page 47 ON, OFF T.ZONE/DST See list of time zones D/TIME SET MY CAMERA CREATE START-UP IMAGE SEL. S-UP IMG NO IMAGE, CANON LOGO, MY IMAGE SHTR SOUND PATTERN1, PATTERN2, PATTERN3 S-UP SOUND PATTERN1, PATTERN2, PATTERN3 S/STOP SOUND PATTERN1, PATTERN2, PATTERN3 SELF-T SOUND...

  • Page 48: Changing The Remote Sensor Mode

    3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 48 Changing the Remote Sensor Mode Two remote sensor modes and an off setting are available to prevent interference from other Canon wireless controllers being used nearby. Turning the Remote Sensor Off CAMERA PLAY (VCR)

  • Page 49: Customizing The Camcorder

    You can personalise your camcorder by customizing the start-up image and the sound it makes for start-up, shutter*, start/stop and self-timer (collectively called the My Camera settings). * MV650i and MV630i only. With the MV650i and MV630i, you can also create your own start-up image. See Creating a Start-up Image ( 129).

  • Page 50: Mv650I Setting The Light-Up Buttons

    3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 50 Setting the Light-up Buttons MV650i The buttons above the LCD panel light up when the camcorder’s power is on, or when you press a button. This is helpful if, for example, you wish to play back a tape in dark places.

  • Page 51: Other Camcorder Settings

    3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 51 Other Camcorder Settings Beep You will hear a beep upon camcorder operations such as power on/off, start/stop, self- timer countdown, automatic shut-off, and unusual conditions of the camcorder. The beep will not be recorded. If you turn off the beep, all camcorder sounds including the ones of the My Camera settings will be turned off.

  • Page 52: Demonstration Mode

    The demonstration mode displays the camcorder’s main features. It starts automatically when you leave the camcorder turned on without loading a cassette (MV650i/MV630i: and without inserting a memory card) for more than 5 minutes. You can also start the demonstration mode through the menu.

  • Page 53: Changing The Recording Mode (Sp/Lp)

    CARD CAMERA CAMERA PLAY (VCR)* CARD PLAY (VCR) * MV650i/MV630i/MV600i only. VCR SET UP REC MODE••••SP To change to LP mode, open the menu and select [VCR SET UP]. Select [REC MODE], set it to [LP] and close the menu.

  • Page 54: Recording Still Images On A Tape

    3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 54 Recording Still Images on a Tape You can record still images on the tape. Starting your recording with a still image allows you to easily locate the beginning of the recording with the Photo Search function ( 84).
  • Page 55 3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 55 ❍ When you turn the POWER switch to OFF while the camcorder is recording the still image, it will not turn off until recording is complete. ❍ Record still images under sufficient lighting condition (in which you can identify the subject on the screen).

  • Page 56: Using The Recording Programs

    *1 MV650i only. *2 The image stabilizer cannot be used in CARD CAMERA mode. *3 Available effects depend upon the program AE mode. *4 MV650i and MV630i only. Easy Recording Program The camcorder adjusts focus, exposure and other settings automatically, allowing you to just point and shoot.
  • Page 57 3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 57 Sports Use this mode to record sports scenes (such as tennis or golf), moving objects (such as roller coasters) or when recording from a moving car. ❍ This mode is set at a high shutter speed and should therefore be used in sufficient light.
  • Page 58 Use this mode to record in dark places. The shutter speed is adjusted automatically. It is useful when recording in places with changing light conditions (such as in amusement parks). ❍ MV650i MV630i Night mode cannot be used in CARD CAMERA mode.
  • Page 59 3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 59 Selecting the Program AE Mode PLAY (VCR) CARD PLAY (VCR) CAMERA CARD CAMERA 1. Slide the program selector to Q (program AE). 2. Press the selector dial. A list of the program AE modes appears. 3.

  • Page 60: Using Digital Effects

    Available i: Not available *1: Black and White only. *2: Cannot be used in Night and Super Night (MV650i) mode. ❍ Turn off the digital effect when you do not use it. Press the DIGITAL EFFECTS button to open the menu. Select [D.EFFECTS |] and press the ON/OFF button.
  • Page 61 3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 61 Faders Fade Trigger (FADE-T) The image gradually fades in. The image gradually fades out. Wipe (WIPE) The image begins as a vertical line in the centre and expands sideways until it fills the whole screen. The image is wiped off from the sides of the screen.
  • Page 62 3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 62 Puzzle (PUZZLE) The image appears in 16 pieces. The pieces move around until the puzzle is solved. The image is divided into 16 pieces. The pieces move around and disappear. Zigzag (ZIGZAG) The image appears in zigzag from the top of the screen.
  • Page 63 Fade out: During playback, press the ON/OFF button and pause playback by pressing the e/a button. The fader can be activated/deactivated by pressing the ON/OFF button. Faders cannot be selected when Card Mix is activated. MV650i MV630i Downloaded From VideoCamera-Manual.com Manuals...
  • Page 64 The image becomes a rhombus surrounded by a masking frame that changes the colours. Mirror (MIRROR) Creates a symmetrical image as if there would be a mirror in the centre of the screen. Only Black and White can be used in CARD CAMERA mode. MV650i MV630i Downloaded From VideoCamera-Manual.com Manuals...
  • Page 65 5. Press the ON/OFF button. ON/OFF • The name of the selected effect stops flashing. • The effect can be activated/deactivated by pressing the ON/OFF button. Selecting an Effect in CARD CAMERA Mode MV650i MV630i CAMERA PLAY (VCR) CARD PLAY (VCR) CARD CAMERA 1.

  • Page 66: Using The Multi-Image Screen

    3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 66 Using the Multi-Image Screen The multi-image screen captures moving subjects in 4, 9 or 16 sequences of still images with the Image Capture feature and displays them at one time. Sound will be recorded normally. This feature can be used in CAMERA and PLAY (VCR) mode. You can choose the transition speed at which to capture the subject from manual, fast (every 4 frames), moderate (every 6 frames*) or slow (every 8 frames*).
  • Page 67 11.Press the start/stop button begin recording. The multi-image screen is recorded on the tape. ❍ The multi-image screen cannot be operated in Night and Super Night (MV650i) mode. ❍ You can operate the multi-image screen only in the following playback modes: - When [S.SPEED] is set to [MANUAL]: Playback pause, slow forward/reverse...

  • Page 68: Turning Off The Image Stabilizer

    ❍ The image stabilizer is designed to compensate a normal degree of camcorder shake. ❍ The image stabilizer cannot be used in CARD CAMERA MV650i MV630i mode. ❍ The image stabilizer might not be as effective in Low Light, Night and Super Night (MV650i) mode. Downloaded From VideoCamera-Manual.com Manuals...

  • Page 69: Recording With The Self-Timer

    • The camcorder records the still image for approx. 6 seconds and returns to record pause mode (MV650i/MV630i: In CARD CAMERA mode, it displays the still image when recording is complete). ❍ To cancel the self-timer, press the (self-timer) button, start/stop button (when recording movies) or PHOTO button (when recording still images).

  • Page 70: Audio Recording

    Select the 16-bit mode for higher sound quality. CARD CAMERA CAMERA PLAY (VCR)* CARD PLAY (VCR) * MV650i/MV630i/MV600i only. AUDIO SET UP AUDIO MODE••12bit Open the menu and select [AUDIO SET UP]. Select [AUDIO MODE], set it to [16bit] and close the menu.

  • Page 71: Wind Screen

    (when [AUDIO DUB.] is set to [MIC. IN] in the [AUDIO SET UP] submenu). ❍ The wind screen function cannot be used when an external microphone is connected to the MIC terminal (MV650i: or when the DM-50 Microphone is attached to the advanced accessory shoe). Downloaded From VideoCamera-Manual.com Manuals...

  • Page 72: Mv650I Using The Vl-3 Video Light (Optional)

    3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 72 Using the VL-3 Video Light (Optional) MV650i This video light enables you to record brightly in colour even in dark places. This VL-3 Video Light attaches to the camcorder’s advanced accessory shoe for cable-free operation and is powered by the camcorder’s power supply.

  • Page 73: Mv650I Using The Dm-50 Microphone (Optional)

    3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 73 Using the DM-50 Microphone (Optional) MV650i The high sensitive Directional Stereo Microphone DM-50 attaches to the advanced accessory shoe for cable-free operation and is powered by the camcorder’s power supply. Use it for recording or dubbing audio.

  • Page 74: Adjusting The Focus Manually

    3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 74 Adjusting the Focus Manually Some subjects may not be suitable for autofocus. In such case, focus manually. Autofocus may not work well on the following subjects: Subjects with Reflective surfaces low contrast Fast Moving Subjects Horizontal Stripes (e.g.
  • Page 75 3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 75 5. Press the FOCUS button to return to autofocus. FOCUS The setting resets to autofocus when you switch the program selector to [. Infinity Focus Use this function when you wish to focus on faraway subjects such as mountains or fireworks.

  • Page 76: Adjusting The Ae Shift

    2. Set the program AE mode to Auto, Sports, Portrait, Light or Low Light Plus (MV650i) mode. 3. Press the AE SHIFT button. “AE ±0” appears in light blue. AE SHIFT 4. Turn the selector dial to adjust the AE shift level.

  • Page 77: Setting The Shutter Speed

    2. Set the program AE mode to the Auto mode. 3. Open the menu and select [CAMERA SET UP]. 4. Select [SHUTTER]. 5. Select the shutter speed and press the selector dial. MV650i MV630i CAMERA Mode CARD CAMERA Mode AUTO...
  • Page 78 3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 78 ❍ Guidelines for Recording with High Shutter Speeds: - Outdoor sports such as golf or tennis: 1/2000 - Moving objects such as cars or roller coasters: 1/1000, 1/500 or 1/250 - Indoor sports such as basketball: 1/120 Downloaded From VideoCamera-Manual.com Manuals...

  • Page 79: Setting The White Balance

    3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 79 Setting the White Balance The camcorder’s auto white balance system adjusts the colours to appear natural for different lighting conditions. However, you can use the preset modes to reproduce colours more accurately, or set a custom white balance to obtain the optimal setting. Zoom lever White sheet or paper Program selector...
  • Page 80 3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 80 PLAY (VCR) CARD PLAY (VCR) CAMERA CARD CAMERA CAMERA SET UP WHITE BAL.••AUTO For T (Indoor) or U (Outdoor) Setting: 1. Set the program selector to Q. 2. Open the menu and select [CAMERA SET UP]. 3.

  • Page 81: Magnifying The Image

    • Turn the selector dial to move the image to the right and left, or up and down. Pressing the selector dial switches between the directions. • To cancel the magnification, move the zoom lever toward W. Movies played back from a memory card cannot be magnified. MV650i Downloaded From VideoCamera-Manual.com Manuals...

  • Page 82: Displaying The Data Code

    Once date and time are set, the camcorder maintains a data code containing recording date and time and other camera data such as shutter speed and exposure (f-stop). (MV650i/MV630i: Only date and time appear when playing back a memory card).
  • Page 83 3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 83 Selecting the Date/Time Display Combination CAMERA CARD CAMERA PLAY (VCR) CARD PLAY (VCR) DISPLAY SET UP D/TIME SEL.•DATE & TIME Open the menu and select [DISPLAY SET UP]. Select [D/TIME SEL.], set it to [DATE] or [TIME] and close the menu.

  • Page 84: Photo Search/Date Search

    3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 84 Photo Search/Date Search You can search for a still image recorded SEARCH SELECT button anywhere on the tape with the photo search function, or locate the change of the Search buttons date/time zone with the date search function. STOP 3 button CAMERA CARD CAMERA...

  • Page 85: Returning To A Pre-Marked Position

    3_D73PAL_E(43-85) 02.12.26 9:26 PM Page 85 Returning to a Pre-marked Position If you wish to return to a particular scene later, mark the point with the zero set REW ` button memory and the tape will stop at that point PLAY e button when you rewind/fast forward the tape.

  • Page 86: Recording To A Vcr Or Digital Video Device

    4_D73PAL_E(86-98) 02.12.26 9:28 PM Page 86 Recording to a VCR or Digital Video Device You can copy your recordings by connecting the camcorder to a VCR or a digital video device. If you connect a digital video device, you can copy recordings with virtually no generation loss in image and sound quality.
  • Page 87 4_D73PAL_E(86-98) 02.12.26 9:28 PM Page 87 Connecting a Digital Video Device Refer also to the instruction manual of the digital video device. Side with an arrow Signal flow 4 pin – 4 pin: CV-150F DV Cable (optional) 4 pin – 6 pin: CV-250F DV Cable (optional) Downloaded From VideoCamera-Manual.com Manuals...

  • Page 88: Recording From Analog Video Devices (Vcr, Tv Or Camcorder)

    4_D73PAL_E(86-98) 02.12.26 9:28 PM Page 88 MV650i MV630i MV600i Recording from Analog Video Devices (VCR, TV or Camcorder) You can record videos or TV programs from a VCR or analog camcorder on the tape in the camcorder. ❍ Anomalous signals sent from the connected device may be recorded as anomalous picture (although it may not appear so on the screen), or it may not be recorded at all.

  • Page 89: Mv650I Mv630I Mv600I Recording From Digital Video Devices (Dv Dubbing)

    4_D73PAL_E(86-98) 02.12.26 9:28 PM Page 89 MV650i MV630i MV600i Recording from Digital Video Devices (DV Dubbing) You can record from other digital video devices equipped with a DV terminal with virtually no loss in picture and sound quality. ❍ When recording from digital video devices, make sure that “AV \ DV” is not displayed on the screen.
  • Page 90 4_D73PAL_E(86-98) 02.12.26 9:28 PM Page 90 Concerning Copyright Copyright Precaution Certain pre-recorded video tapes, films and other materials, as well as some television programmes are copyrighted. Unauthorised recording of these materials may violate copyright protection laws. Copyright Signals During playback: If you try to play back a tape that contains copyright control signals for protection of software, “COPYRIGHT PROTECTED PLAYBACK IS RESTRICTED”...

  • Page 91: Mv650I Mv630I Mv600I

    4_D73PAL_E(86-98) 02.12.26 9:28 PM Page 91 MV650i MV630i MV600i Converting Analog Signals into Digital Signals (Analog-Digital Converter) By connecting the camcorder to a VCR or 8mm video camcorder, you can convert analog video/audio signals to digital signals and output the digital signals via the DV terminal.
  • Page 92 4_D73PAL_E(86-98) 02.12.26 9:28 PM Page 92 Turning On the Analog-Digital Converter CAMERA CARD CAMERA CARD CAMERA PLAY (VCR) Press the AV \ DV button on the wireless controller. VCR SET UP DV OUT••OFF Open the menu and select [VCR SET UP]. Select [AV \ DV OUT], set it to [ON] and close the menu.

  • Page 93: Mv650I Mv630I Mv600I

    4_D73PAL_E(86-98) 02.12.26 9:28 PM Page 93 MV650i MV630i MV600i Replacing Existing Scenes (AV Insert) You can insert and replace images/audio on the tape of the camcorder with images/audio from other video devices connected via AV terminal or DV terminal. Scene to be inserted...
  • Page 94 4_D73PAL_E(86-98) 02.12.26 9:28 PM Page 94 Example: AV Insert from a VCR CAMERA CARD CAMERA CARD CAMERA PLAY (VCR) 1. Connect the camcorder to the VCR. See Playing Back on a TV Screen ( 39). 2. VCR: Load a recorded cassette. Locate the scene you wish to insert and pause playback shortly before the scene.

  • Page 95: Audio Dubbing

    ❍ If you add sound to a tape not recorded with this camcorder, sound quality may decrease. ❍ Sound quality may decrease when you add sound to the same scene for more than 3 times. Connecting an Audio Device MV650i MV630i MV600i Signal flow STV-250N Stereo Video Cable (supplied) ❍...
  • Page 96 ❍ When using an external microphone: Connect it to the microphone terminal. ❍ When using the DM-50 Microphone: Do not connect any cables to the MV650i microphone terminal. ❍ When you connect a TV via the S-video terminal, you can check the picture on the TV screen and the sound with headphones connected to the camcorder.
  • Page 97 AUDIO OUT AUDIO DUB. PAUSE SLOW Audio device: Stop playback. MV650i MV630i MV600i AV INSERT AV DV REMOTE SET Set the zero set memory at the end of the scene you wish to dub audio. The camcorder will automatically stop audio dubbing at that point.

  • Page 98: Connecting To A Computer Using A Dv (Ieee1394) Cable

    ❍ Refer also to the instruction manual of the computer. Optional software required. Refer also to the instruction manual of the software. ❍ For transferring recordings from a memory card to the MV650i MV630i computer using a USB cable, see p. 128. DV NETWORK SOLUTION DISK (Windows XP Users)

  • Page 99: Inserting And Removing The Memory Card

    5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 99 Inserting and Removing the Memory Card The chapter Using a Memory Card ( 99 - 132) refers to functions of the MV650i and MV630i only. Terminals You can use SD Memory Cards or a commercially available MultiMediaCards with this camcorder.

  • Page 100: Selecting The Image Quality/Size

    5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 100 Selecting the Image Quality/Size Changing the Still Image Quality You can choose between Superfine, Fine and Normal. CAMERA CARD PLAY (VCR) PLAY (VCR) CARD CAMERA CARD SET UP SI QUALITY••FINE Open the menu and select [CARD SET UP]. Select [SI QUALITY], set it to [SUPER FINE] or [NORMAL] and close the menu.

  • Page 101: Changing The Movie Size

    2 images at once. ❍ All indicators are displayed in green when a memory card is played back. ❍ MV650i The remaining image capacity indicates the number of still images, even when movies are recorded. Changing the Movie Size MV650i You can choose between 320 ×...
  • Page 102 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 102 When you record 3 images on the supplied memory card. 101-0101 CONTINUOUS RESET 101-0102 101-0103 When you replace the memory card and record an image. 101-0104 101-0101 CAMERA CARD PLAY (VCR) PLAY (VCR) CARD CAMERA CARD SET UP FILE NOS.•••CONTINUOUS To change the setting, open the menu and select [CARD SET UP].

  • Page 103: Recording Still Images On A Memory Card

    5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 103 Recording Still Images on a Memory Card You can record still images with the Card access PHOTO button camcorder, from a tape in the camcorder indicator 104), or from devices connected via the DV terminal or AV terminal ( 105).
  • Page 104 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 104 Recording from a Tape in the Camcorder You can record images from a tape in the camcorder as still images on a memory card. CAMERA CARD CAMERA CARD PLAY (VCR) PLAY (VCR) 1. Set the camcorder to PLAY (VCR) mode. 2.
  • Page 105 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 105 Recording from Other Video Devices You can record images from devices connected via the S-video terminal or AV terminal (analog line-in function), or via the DV terminal as still images on a memory card. When recording via the AV terminal, make sure that “AV \ DV”...

  • Page 106: Recording Panoramic Images (Stitch Assist Mode)

    5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 106 Recording Panoramic Images (Stitch Assist Mode) You can shoot a series of overlapping images and merge them into one large panoramic scene using the supplied software (PhotoStitch) on a computer. When Recording in Stitch Assist Mode: PhotoStitch detects the overlapping portion of adjoining images and merges them.
  • Page 107 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 107 ❍ Compose each image so that it overlaps 30 to 50% of the adjoining image. Try to keep the vertical misalignment within 10%. ❍ Do not include moving subject in the overlapping portion. ❍ Do not try to stitch images that include both distant and close subjects. They may appear warped or doubled up.

  • Page 108: Mv650I Recording Motion Jpeg Movies On A Memory Card

    5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 108 Recording Motion JPEG Movies on a Memory Card MV650i You can record Motion JPEG movies with the camcorder, from a tape in the camcorder 109), or from devices connected via the AV terminal (analog line-in) or the DV terminal ( 109).
  • Page 109 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 109 Recording from a Tape in the Camcorder You can record movies from a tape in the camcorder on a memory card. CAMERA CARD CAMERA CARD PLAY (VCR) PLAY (VCR) 1. Set the camcorder to PLAY (VCR) mode. 2.

  • Page 110: Playing Back A Memory Card

    1. Set the camcorder to CARD PLAY (VCR) mode. • The last recorded image appears. • MV650i Movies are displayed with the first scene as a still image indicated by “e/a”. 2. Press the CARD+/– button to move between images.

  • Page 111: Index Screen

    1. In single image display, press the (index screen) button. AE SHIFT • Up to 6 images appear. • MV650i Movies are displayed with the first scene as a still image indicated by “ ”. 2. Press the CARD +/– button to change the image selection.
  • Page 112 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 112 Card Jump Function You can locate still images/movies without displaying them one by one. The number in the upper right of the screen indicates the image number of the current image by the total number of images. CAMERA PLAY (VCR) CARD CAMERA...

  • Page 113: Protecting Images

    ❍ The sample images recorded on the supplied SD Memory Card are already protected. ❍ MV650i Movies can only be protected when the first or last scene is displayed as a still image. They cannot be protected during playback pause.

  • Page 114: Erasing Images

    ❍ Protected images cannot be erased. ❍ Movies can only be erased when the first or last scene is displayed as MV650i a still image. They cannot be erased in playback pause mode. ❍ Make sure to insert a memory card that contains images.

  • Page 115: Selecting Still Images For Printing (Print Order)

    Digital Print Order Format (DPOF) standards. ❍ Make sure to insert a memory card that contains images. ❍ A maximum of 200 still images can be selected. ❍ Movies cannot be printed. MV650i Selecting in Single Image Display CAMERA PLAY (VCR) CARD CAMERA CARD PLAY (VCR) 1.
  • Page 116 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 116 Erasing All Print Orders CAMERA PLAY (VCR) CARD CAMERA CARD PLAY (VCR) CARD OPERATIONS PRINT ORDERS ALL ERASE 1. In single image display, open the menu and select [CARD OPERATIONS]. 2. Select [ PRINT ORDERS ALL ERASE]. “ERASE ALL PRINT ORDERS?”, [NO] and [YES] appears.

  • Page 117: Printing With The Direct Print Function

    5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 117 Printing with the Direct Print Function You can print still images by connecting the camcorder to a Canon Bubble Jet Printer with Direct Print function. The Direct Print function can also be used with the print order settings ( 115).
  • Page 118 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 118 Printing CAMERA PLAY (VCR) CARD CAMERA CARD PLAY (VCR) 1. In single image display, select the still image you wish to print and press the selector dial. The print setting menu appears. 2. Set the number of copies and the print style. •...
  • Page 119 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 119 Selecting the paper size: 1. In the print setting menu, turn the selector dial to select [Style] and press the selector dial. 2. Make sure that is selected and press the selector dial. 3. Turn the selector dial to select the paper size and press the selector dial. 4.

  • Page 120: Printing With Print Order Settings

    5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 120 Printing with Print Order Settings You can print still images you have selected with the Print Order function. If you wish to print more than 1 copy, set the number of copies in the print order ( 115).

  • Page 121: Combining Images (Card Mix)

    Choose one of the sample images provided on the supplied SD Memory Card (such as picture frames, backgrounds and animations) and combine it with the live video recording. ❍ Card Mix cannot be used in the Night and Super Night (MV650i) mode. ❍ Movies recorded on a memory card cannot be combined with MV650i camcorder recordings.
  • Page 122 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 122 Card Luminance Key (CARD LUMI.) Combines illustrations or title with your recordings. The live video recording will appear in place of the light area of the card mix image. You can create your own title or illustration by drawing on a white paper and recording it to the memory card.
  • Page 123 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 123 Selecting the Card Mix Effect PLAY (VCR) CARD CAMERA CARD PLAY (VCR) CAMERA CARD MIX MIX TYPE•••CARD CHROMA MIX LEVEL•• – 1. Set the program selector to Q. 2. Open the menu and select [\ CARD MIX]. The card mix menu appears.
  • Page 124 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 124 Recording with the Card Mix Effect Movie: 1. Press the start/stop button to begin recording. The combined image is recorded on the tape. 2. Press the start/stop button to end recording. Still Image: 1. Press the PHOTO button halfway. F flashes in white and turns green when focus is adjusted.

  • Page 125: Copying Still Images

    5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 125 Copying Still Images You can copy still images from tape to memory card, or from memory card to tape. ❍ All still images from the selected still image onward will be copied. ❍ The image size of a still image copied from tape to memory card will be 640 × 480.
  • Page 126 5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 126 Copying Still Images from Memory Card to Tape Load a cassette with enough free space, and insert a recorded memory card. Make sure that the protect tab on the cassette is set to allow recording. CAMERA PLAY (VCR) CARD CAMERA...

  • Page 127: Formatting A Memory Card

    5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 127 Formatting a Memory Card Format new memory cards, or when you get the message “CARD ERROR”. You can also format a memory card to erase all images recorded on it. The camcorder formats memory cards in the Design rule for Camera File system (DCF) standard.

  • Page 128: Connecting To A Computer Using A Usb Cable

    ❍ The light-up buttons turn off during USB connection. MV650i ❍ For transferring recordings from to a computer using a DV cable, see p. 98. ❍ Still images/movies recorded on a tape cannot be transferred to a computer via USB interface.

  • Page 129: Creating A Start-Up Image

    5_D73PAL_E(99-132) 02.12.26 9:30 PM Page 129 Creating a Start-up Image You can create a start-up image using a still image on the memory card or a sample start-up image provided on the DIGITAL VIDEO SOLUTION DISK and save it as [MY IMAGE].

  • Page 130: Memory Card Information

    ❍ We recommend saving backups of memory card images on your computer’s hard drive or other external memory device. Image data may be corrupted or lost due to memory card defects or exposure to static electricity. Canon Inc. makes no warranties for corrupted or lost data.

  • Page 131: Sample Images

    5_D73PAL_E(99-132) 02.12.26 9:31 PM Page 131 Sample Images 27 sample images are pre-recorded on the supplied SD Memory Card: 8 card chroma key images, 5 card luminance key images, 2 camera chroma key images and 12 card animation images. Card Chroma Key Card Luminance Key Camera Chroma Key Card Animation...
  • Page 132 If you have mistakenly erased the Card Mix sample images on the supplied SD Memory Card, they can be downloaded from the following homepages: http://www.canon-europa.com/products/products.html http://www.canon-asia.com/ http://www.canon.com.au For details on how to add the downloaded images to the memory card, refer to Adding Still Images from Your Computer to the Memory Card in the DIGITAL VIDEO SOLUTION DISK Software Instruction Manual.

  • Page 133: Screen Displays

    • Warning messages still appear, and the data code appears if turned on. • Tape operation displays appear for 2 seconds. • Displays cannot be hidden on the index screen. MV650i MV630i TV Screen Displays When you connect a TV for recording/playback, you can hide the displays on the TV screen.
  • Page 134 6_D73PAL_E(133-154) 02.12.26 9:32 PM Page 134 Screen Displays during Basic Recording/Playback indicates flashing. CAMERA mode (battery pack attached): S PAUSE 0:00:00 5m i n • Remote sensor mode and audio mode disappear after 4 seconds. 12b i t PLAY (VCR) mode: STEREO1 STOP 0:00:00:00...
  • Page 135 6_D73PAL_E(133-154) 02.12.26 9:32 PM Page 135 Screen Displays during Advanced Recording/Playback CAMERA Mode MV650i MV650i MV630i Recording reminder/ Image stabilizer ( Self-timer countdown ( Photo recording timer ( Zoom ( Recording mode AE shift ( Program AE ( Self-timer (...
  • Page 136 6_D73PAL_E(133-154) 02.12.26 9:32 PM Page 136 CARD CAMERA Mode MV650i MV630i MV650i Recording on a memory Stitch assist ( 106) card ( 103) Still image quality ( 100) Zoom ( Remaining card capacity 100) Program AE ( S.FINE Still image size...

  • Page 137: List Of Messages

    6_D73PAL_E(133-154) 02.12.26 9:32 PM Page 137 List of Messages Message Explanation SET THE TIME ZONE, You have not set the time zone, date and time. This message DATE AND TIME appears each time you turn the power on until you set the time zone, date and time.
  • Page 138 6_D73PAL_E(133-154) 02.12.26 9:32 PM Page 138 Memory Card Related Messages MV650i MV630i Message Explanation NO CARD Memory card not is inserted into the camcorder. THE TAPE IS SET FOR SD Memory Card is set for erasure prevention. Replace the ERASURE PREVENTION card or change the position of the protect switch.
  • Page 139 Waste tank is full. You can restart printing by pressing the RESUME/CANCEL button on the Bubble Jet Printer. Request replacement of the waste tank at the shop where you purchased the printer or the nearest Canon customer support centre listed in the Bubble Jet Quick Start Guide. Printer error Turn off the printer and turn it back on.

  • Page 140: Maintenance

    6_D73PAL_E(133-154) 02.12.26 9:32 PM Page 140 Maintenance Camcorder Handling Precautions ❍ Do not carry the camcorder by the LCD panel or viewfinder. ❍ Do not leave the camcorder in places subject to high temperatures, such as a sun- heated car, and high humidity. ❍...
  • Page 141 ❍ When the playback picture becomes distorted, the video heads need to be cleaned. ❍ To maintain the best picture quality, we recommend cleaning the video heads frequently with the Canon DVM-CL Digital Video Head Cleaning Cassette or a commercially available dry cleaning cassette.
  • Page 142 6_D73PAL_E(133-154) 02.12.26 9:32 PM Page 142 Condensation Moving the camcorder rapidly between hot and cold temperature may cause condensation (water droplets) to form on its internal surfaces. Stop using the camcorder if condensation is detected. Continued use may damage the camcorder. Condensation may form in the following cases: When the camcorder is moved from an When the camcorder is moved from a...

  • Page 143: Using The Camcorder Abroad

    You can use the compact power adapter to operate the camcorder and to charge battery packs in any country with power supply between 100 and 240 V AC, 50/60 Hz. Consult the Canon Service Centre for information on plug adapters for overseas use. Playback on a TV Screen You can only play back your recordings on TVs with PAL system.

  • Page 144: Troubleshooting

    6_D73PAL_E(133-154) 02.12.26 9:32 PM Page 144 Troubleshooting If you have a problem with your camcorder, refer to this checklist. Consult your dealer or a Canon Service Centre if the problem persists. Power Source Problem Cause Solution Camcorder will not turn Battery pack is exhausted.
  • Page 145 6_D73PAL_E(133-154) 02.12.26 9:32 PM Page 145 Recording Problem Cause Solution Image will not appear Camcorder is not set to Set the camcorder to on the screen. CAMERA mode. CAMERA mode. “Set the time zone, date Time zone, date and time Set the time zone, date and and time”...
  • Page 146 6_D73PAL_E(133-154) 02.12.26 9:32 PM Page 146 Memory Card Operation MV650i MV630i Problem Cause Solution Memory card cannot be Memory card was not facing Turn the memory card over inserted. the correct direction. and reinsert it. Memory card cannot be Memory card is full.

  • Page 147: System Diagram

    6_D73PAL_E(133-154) 02.12.26 9:32 PM Page 147 System Diagram (Availability differs from area to area) WS-20 Wrist Strap MV650i SS-800 Shoulder Strap WA-30.5 Wide Attachment MV650i MV630i BP-500 Series WL-D79 Wireless Battery Pack Controller WD-30.5 Wide- MV600i MV600 CG-570 converter WL-D80 Wireless...

  • Page 148: Optional Accessories

    6_D73PAL_E(133-154) 02.12.26 9:32 PM Page 148 Optional Accessories Call or visit your local retailer/dealer for genuine Canon video accessories. BP-500 Series Battery Packs BP-512 BP-522 BP-535 When you need extra battery packs, select from the following: BP-511, BP-512, BP-522 or BP-535.
  • Page 149 • Approximate usage time: BP-915: 60 min., BP-930: 120 min., BP-945: 170 min. • BP-900 series battery packs are charged with the CA-920 Compact Power Adapter. VL-3 Video Light MV650i This video light enables you to record brightly in colour even in dark places. It attaches to the camcorder’s advanced accessory shoe for cable-...
  • Page 150 A handy camcorder bag with padded compartments and plenty of space for accessories. This mark identifies genuine Canon video accessories. When you use Canon video equipment, we recommend Canon-brand accessories or products bearing the same mark. Downloaded From VideoCamera-Manual.com Manuals...

  • Page 151: Specifications

    (80 min. cassette): Fast forward/rewind time: Approx. 2 min. 20 sec. (with a 60 min. cassette) Lens: MV650i: F1.6-3.6, 22x power zoom, f=2.8-61.6 mm; MV630i: F1.6-3.2, 20x power zoom, f=2.8-56 mm; MV600i/MV600: F1.6-2.9, 18x power zoom, f=2.8-50.4 mm Focusing system:...
  • Page 152 ø3.5 mm stereo minijack Operating temperatures: 0 – 40˚C 103 × 58 × 147 mm Dimensions: Weight: MV650i: 525 g, MV630i/MV600i/MV600: 520 g MV650i/MV630i only MV650i/MV630i/MV600i only CA-570 Compact Power Adapter Power supply: 100 – 240 V AC, 50/60 Hz...

  • Page 153: Index

    Digital zoom ....28 Microphone....70 Not available with the MV650i MV650i MV630i MV600 Downloaded From VideoCamera-Manual.com Manuals...
  • Page 154 Search select ....84 Self-timer ....69 MV650i MV650i MV630i Downloaded From VideoCamera-Manual.com Manuals...
  • Page 155 Canon UK Ltd. Ribcon Way Luton Bedfordshire LU4 9UR Telephone 0870-241-2161 Canon Australia Pty. Ltd 1 Thomas Holt Drive, North Ryde, N.S.W. 2113, Australia Telephone 805-2000, Fax 887-4484 Canon New Zealand Ltd Akoranga Business Park, Akoranga Drive, Northcote, Auckland, New Zealand Telephone: 489-0300, Fax: 489-0380 Canon Singapore Pte.

This manual is also suitable for:

Mv600iMv600Mv630i

Table of Contents
