OWNER'S MANUAL
DRYER
Before beginning installation, read these instructions carefully. This
will simplify installation and ensure that the dryer is installed correctly
and safely. Leave these instructions near the dryer after installation
for future reference.
DLE4801W
DLG4802W
P/No. 3828EL2001F
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG DLE4801W

Summary of Contents for LG DLE4801W

  • Page 1 OWNER’S MANUAL DRYER Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the dryer is installed correctly and safely. Leave these instructions near the dryer after installation for future reference. DLE4801W DLG4802W www.lg.com P/No. 3828EL2001F...

  • Page 2: Special Features

    SPECIAL FEATURES SPECIAL FEATURES EASY-TO-USE CONTROL PANEL An entire selection of user-friendly functions make operating the dryer easy. EASY-ACCESS REVERSIBLE DOOR The wide-opening door provides easy access for loading and unloading. The door hinge can be reversed to adjust for installation location. FLOW SENSE™...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, death. Your Safety and the safety of others is very important.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, death. WARNING To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: of children is necessary when the dryer is used near children.
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, death. This appliance must be grounded.
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, death. WARNING To reduce the risk of injury to persons, follow all industry recommended safety procedures including the use of long sleeved gloves and safety glasses.
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, death. WARNING To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: prong from the power cord.

  • Page 8: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS SPECIAL FEATURES TROUBLESHOOTING Before Calling for Service IMPORTANT SAFETY INSTRUCTIONS SPECIFICATIONS WHAT TO DO IF YOU SMELL GAS BASIC SAFETY PRECAUTIONS CALIFORNIA SAFE DRINKING WATER AND TOXIC USING SMARTDIAGNOSIS ENFORCEMENT ACT GROUNDING INSTRUCTIONS WARRANTY SAFETY INSTRUCTIONS FOR INSTALLATION SAFETY INSTRUCTIONS FOR CONNECTING ELECTRICITY...

  • Page 9: Parts And Features

    PARTS AND FEATURES PARTS AND FEATURES Components Control panel Reversible door Terminal Block Power Cord Access Panel Location (Electric Models) (Gas Models) Exhaust Duct Lint filter Gas Connection Outlet Location Leveling feet (Gas Models) NOTE malfunction or accidents caused by the use of separately purchased unauthorized components or parts. without prior notice for product improvement purposes.

  • Page 10: Control Panel Features

    PARTS AND FEATURES Control panel features Following are instructions for starting and using your new dryer. Please refer to specific sections of this manual for more detailed information. WARNING : To reduce the risk of fire, electric shock, or injury to persons, read this entire manual, including the Important Safety Instructions, before operating this dryer.

  • Page 11: Installation Instructions

    INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS Preview installation order Checking and choosing Leveling the dryer Venting the Dryer the proper location 120V 240V Connecting Electric Dryers Plugging in the power Connecting Gas Dryers (Electric Dryer Type) cord and grounding (Gas Dryer Type) Duct check test Test run (Refer to page 26.)

  • Page 12: Installation Location Requirements

    INSTALLATION INSTRUCTIONS Installation location requirements WARNING It is important that you review this entire manual before installing and using your dryer. Detailed instructions concerning electrical connections, gas connections, and exhaust requirements are provided on the following pages. must be exhausted to the outdoors. See kg).

  • Page 13: Leveling The Dryer

    INSTALLATION INSTRUCTIONS Clearance (Cont.) RECOMMENDED INSTALLATION SPACING FOR CABINET INSTALLATION For cabinet installation with a door, minimum ventilation openings in the top of the cabinet are required. 7"* (17.8 cm) 7"* (17.8 cm) *Required spacing **For side or bottom venting, 1"...

  • Page 14: Reversing The Door

    INSTALLATION INSTRUCTIONS Reversing the door WARNING 4. Remove the 4 screws securing the hinges to the door frame. Remove the two plastic cover caps. Reinstall the hinges To avoid damage to the dryer or the door, support the door with a stool and cover caps on the opposite sides from which they were or box that fits under the door, or have an assistant support the weight of the door.

  • Page 15: Changing The Dryer Vent Location

    Cover Plate An adapter kit, part number , may be purchased from your LG retailer. This kit contains the necessary duct Elbow components to change the dryer vent location. " (3.8 cm) OPTION 2: BOTTOM VENTING exhaust duct.

  • Page 16: Venting The Dryer

    INSTALLATION INSTRUCTIONS Venting the dryer WARNING To reduce the risk of fire, electric shock, or personal injury when using this appliance, follow basic precautions, including the following: Failure to follow these instructions can result in fire or death. when it is impossible to make a connection with the above Failure to follow these instructions can result in fire or death.
  • Page 17 INSTALLATION INSTRUCTIONS Venting the dryer (cont.) Ductwork Recommended 4" (10.2 cm) 4" (10.2 cm) Use Only for Short Run Installations " (6.35 cm) NOTE ROUTING AND CONNECTING DUCTWORK NOTE Follow the guidelines below to maximize drying performance and reduce lint buildup and condensation in the ductwork. Ductwork and fittings are NOT included and must be purchased separately.

  • Page 18: Connecting Gas Dryers

    INSTALLATION INSTRUCTIONS Connecting gas dryers WARNING To reduce the risk of fire, electric shock, or personal injury when using this appliance, follow basic precautions, including the following: Connect the dryer to the type of gas shown on the nameplate. As shipped from the factory, this dryer is configured for use Failure to do so can result in fire, explosion, or death.
  • Page 19 INSTALLATION INSTRUCTIONS Connecting gas dryers (cont.) WARNING Connecting the Gas Supply To reduce the risk of fire, electric shock, or personal injury when OFF. Confirm that the type of gas available in your laundry room using this appliance, follow basic precautions, including the following: is appropriate for the dryer.

  • Page 20: Connecting Electric Dryers

    INSTALLATION INSTRUCTIONS Connecting electric dryers WARNING WARNING To help prevent fire, electric shock, serious injury, or death, the To reduce the risk of fire, electric shock, or personal injury when wiring and grounding must conform to the latest edition of the using this appliance, follow basic precautions, including the following: regulations.
  • Page 21 INSTALLATION INSTRUCTIONS Connecting electric dryers (cont.) USA only WARNING minimum copper conductor and closed loop or forked terminals with upturned ends. wire should be connected to same color screw. Wire color indicated on manual is connected to the same color screw in block.
  • Page 22 INSTALLATION INSTRUCTIONS Connecting electric dryers (cont.) USA only WARNING conductor cable. wire should be connected to same color screw. Wire color indicated on manual is connected to the same color screw reinstallation of the dryer. in block. Failure to follow these instructions may result in a short or overload.
  • Page 23 INSTALLATION INSTRUCTIONS Connecting electric dryers (cont.) USA only WARNING minimum copper conductor and closed loop or forked terminals with upturned ends. wire should be connected to same color screw. Wire color indicated on manual is connected to the same color screw in block.
  • Page 24 INSTALLATION INSTRUCTIONS Connecting electric dryers (cont.) USA only WARNING conductor cable. wire should be connected to same color screw. Wire color indicated on manual is connected to the same color screw reinstallation of the dryer. in block. Failure to follow these instructions may result in a short or overload.

  • Page 25: Special Requirements For Manufactured Or Mobile Homes

    INSTALLATION INSTRUCTIONS Special requirements for manufactured or mobile homes Final installation check Any installation in a manufactured or mobile home must comply with the Manufactured Home Construction and Safety Standards Title 24 CFR, Part 32-80 or Standard CAN/CSA0Z240 MH and local codes and ordinances.

  • Page 26: Installation Test (Exhaust Check)

    INSTALLATION INSTRUCTIONS Installation test (Exhaust check) 4. Check the display for results. Once you have completed the installation of the dryer, use this test to make sure the condition of the exhaust system is adequate During the two minute test cycle, monitor the FLOW SENSE display on the control panel.
  • Page 27 INSTALLATION INSTRUCTIONS Installation test (Exhaust check) (cont.) Error Code Possible Causes Solutions Temperature sensor failure Turn off the dryer and call for service. Humidity Sensor failure. Turn off the dryer and call for service. Electric dryer power cord is not Check the power supply or the connected correctly, or house power connection of power cord to the...

  • Page 28: How To Use

    HOW TO USE HOW TO USE Operating the dryer If the lint filter has not already been cleaned, lift out the filter and remove the lint from the last load. This will help ensure the fastest and most efficient drying performance. Lint Filter Load the dryer with the wet laundry from the washer.

  • Page 29: Cycle Guide

    Sensor Dry Cycles Manual Dry Cycles Sensor Dry cycles utilize LG’s unique dual sensor system to detect Use Manual Dry cycles to select a specific amount of drying time and compare the moisture level in clothes and in the air and and a drying temperature.

  • Page 30: Sorting Load

    HOW TO USE Following are instructions for starting and using your new dryer. Please refer to specific sections of this manual for more detailed information. Check the lint filter before every Sorting load load Fabric Care Labels Most articles of clothing feature fabric care labels that include Always make sure the lint filter is clean before starting a new load;...

  • Page 31: Cycle Setting Buttons

    HOW TO USE SIGNAL Cycle setting buttons Adjusts the volume of the Signal or turns off the Signal.Press the button repeatedly until the desired volume setting is illuminated. SENSOR DRY cycles have preset settings that are selected automatically. MANUAL DRY cycles have default settings, but you may also customize the settings using the cycle setting buttons.

  • Page 32: Maintenance

    MAINTENANCE MAINTENANCE Cleaning the Lint Filter Regular cleaning Always clean the lint filter after every cycle. WARNING To reduce the risk of fire, electric shock, or personal injury when using this appliance, follow basic precautions, including the following: shock. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

  • Page 33: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING Before calling for service Your dryer is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If your dryer does not function properly or does not function at all, check the following before you call for service. Solutions Dryer will not turn on...

  • Page 34: Specifications

    Opening the door or pressing the POWER button will turn off the display. SPECIFICATIONS Dryer models DLE4801W DLG4802W Description Dryer Electrical Requirements* Please refer to the rating label regarding detailed information.

  • Page 35: Warranty

    WARRANTY Your LG Dryer will be will repaired or replaced, at LG’s option, if it proves to be defective in material or workmanship under normal purchase of the product. This warranty is good only to the original purchaser of the product and effective only when used in the United States, including Alaska, Hawaii, and U.S.
  • Page 36 LG Customer Information Center 1-800-243-0000 1-888-542-2623 CANADA Register your product Online! www.lg.com...

This manual is also suitable for:

Dlg4802w

Table of Contents
