Operating and installation instructions
Salamander
CS 1421
en - GB
To avoid the risk of accidents or
damage to the appliance it is
essential to read these
instructions before it is installed
and used for the first time.
M.-Nr. 07 180 450

Advertisement

Table of Contents
loading

Related Manuals for Miele Salamander CS 1421

Summary of Contents for Miele Salamander CS 1421

  • Page 1 Operating and installation instructions Salamander CS 1421 en - GB To avoid the risk of accidents or damage to the appliance it is essential to read these instructions before it is installed and used for the first time. M.-Nr. 07 180 450...

  • Page 2: Table Of Contents

    Contents Guide to the appliance ..........3 Warning and Safety instructions .

  • Page 3: Guide To The Appliance

    Guide to the appliance a Motor-driven browning unit Display b Ceramic standing surface, removable c Display f In-operation indicator Controls: g Residual heat indicator d For setting the power level e For selecting the height of the browning element...

  • Page 4: Warning And Safety Instructions

    Warning and Safety instructions This appliance complies with all current local and national safety requirements. Improper use can, however, present a risk of both personal injury and material damage. To avoid the risk of accidents and damage to the appliance, please read these instructions carefully before installation and before using it for the first time.
  • Page 5 The appliance is intended for domestic use only to cook food and keep it warm. Any other use is not supported by the manufacturer and could be dangerous. Miele cannot be held liable for damage resulting from incorrect or improper use or operation.
  • Page 6 Warning and Safety instructions Safety with children The appliance is not a toy! To prevent the risk of injury, do not let children play with the appliance or its controls. Children under 8 years of age must be kept away from the hob unless they are constantly supervised.
  • Page 7 Miele cannot be held liable for the consequences of an inadequate earthing system (e.g. electric shock). Before connecting the appliance to the mains...
  • Page 8 Repairs and other work by unqualified persons could be dangerous. Miele cannot be held liable for unauthorised work. During installation, maintenance and repair work, the appliance must be disconnected from the mains electricity supply.
  • Page 9 Miele cannot be held liable for damage caused by incorrect installation or connection.
  • Page 10 Warning and Safety instructions In areas which may be subject to infestation by cockroaches or other vermin, pay particular attention to keeping the appliance and its surroundings clean at all times. Any damage caused by cockroaches or other vermin will not be covered by the guarantee. Correct use The appliance gets hot when in use and remains hot for quite a while after being switched off.
  • Page 11 Warning and Safety instructions Do not use the top of the appliance as a resting place for anything and do not leave heat-sensitive items near the appliance. The article could melt or catch fire if the appliance is switched on by mistake or if residual heat is still present.
  • Page 12 Only close the door when the appliance is switched off and the residual heat indicator has gone out. Miele cannot be held liable for damage caused by non-compliance with these Warning and Safety instructions.

  • Page 13: Caring For The Environment

    Caring for the environment Disposal of the packing Disposal of your old appliance material Electrical and electronic appliances often contain materials which, if The transport and protective packing handled or disposed of incorrectly has been selected from materials which could be potentially hazardous to are environmentally friendly for human health and to the environment.

  • Page 14: Before Using For The First Time

    Before using for the first time Please stick the extra data plate for the The metal components have a appliance supplied with this protective coating which may give off documentation in the space provided in a slight smell when heated up for the the "After sales service, data plate, first time.

  • Page 15: Operation

    Operation Raising and lowering the Switching on and off browning unit Do not leave the appliance ^ To raise the browning unit, turn the unattended whilst it is being used. left-hand control to -. The appliance is switched on by The browning unit will extend up to its turning the right-hand control to the full height, even if you release the...

  • Page 16: To Brown Or Crisp Food

    Operation To brown or crisp food Useful tips ^ Raise the browning unit. The Salamander is perfect for browning and crisping food topped with cheese ^ Place the dish containing food to be (e.g. meat and pasta dishes, croque browned on the ceramic standing monsieur, vegetable gratin) and surface.

  • Page 17: Safety Features

    Safety features Thermal retraction stop sensor Obstruction sensor Your Salamander is fitted with a thermal If the browning unit meets an retraction stop sensor to prevent obstruction (e.g. a dish) whilst it is damage to the appliance when being lowered, it stops immediately and lowering the browning unit.

  • Page 18: Cleaning And Care

    Cleaning and care Miele offer a range of cleaning and To avoid damaging the surface of conditioning agents for your appliance. your appliance, do not use: See "Optional accessories". – cleaning agents containing soda, alkalines, ammonia, acids or Do not use a steam cleaning chlorides, appliance to clean this appliance.

  • Page 19: Stainless Steel

    Cleaning and care Stainless steel Building-in frame The Miele ceramic and stainless steel Clean the building-in frame regularly. hob cleaning agent is suitable for Remove any food deposits or liquid im- cleaning stainless steel surfaces (see mediately. Clean it with an E-Cloth or "Optional accessories").

  • Page 20: Problem Solving Guide

    The residual heat – the mains fuse has tripped. If it has, indicator must have gone out. contact a qualified electrician or the Miele Service department. – the ceramic standing surface is positioned correctly..the appliance does not heat up.

  • Page 21: Optional Accessories

    Optional accessories Miele offer a comprehensive range of useful accessories as well as cleaning and conditioning products for your Miele appliances. These can be ordered online at: or from Miele (see back cover for contact details). Ceramic and stainless steel hob cleaner 250 ml...

  • Page 22: Safety Instructions For Installation

    Safety instructions for installation Do not use any sealant except To avoid the risk of damaging the where expressly instructed to do so. appliance fit the wall units and The seal underneath the appliance extractor hood before installing it. provides a sufficient seal for the worktop.
  • Page 23 Safety instructions for installation Safety distance above the appliance A minimum safety distance must be maintained between the appliance and the cooker hood above it. See the cooker hood manufacturer's operating and installation instructions for details. If the manufacturer's instructions are not available for the cooker hood, a minimum safety distance of at least 760 mm must be maintained.
  • Page 24 Safety instructions for installation Safety distances to the sides of and behind the appliance Ideally the Salamander should be installed with plenty of space on either side. There may be a wall at the rear and a tall unit or wall at one side. On the other side, however, no unit or divider should stand higher than the built-in appliance (see illustrations).

  • Page 25: Appliance And Building-In Dimensions

    Appliance and building-in dimensions a Spring clamps b Front c Casing depth d Mains connection box with mains connection cable, L = 1440 mm e Browning unit, height-adjustable...

  • Page 26: Preparing The Worktop

    Preparing the worktop ^ Make the worktop cut-out for one or more appliances in accordance with the building-in diagrams. Remember to maintain a minimum safety distance from the back wall, as well as from any tall unit or side wall to the right or left of the appliance.

  • Page 27: Installation Of Several Appliances

    Installation of several appliances When installing two or more appliances next to each other a spacer bar b must be used between each one. See "Fixing the spring clamps and spacer bars". Worktop cut-out Worktop cut-out - two appliances - three appliances To calculate the cut-out width (D) required: Add up the widths of each appliance (e.g.
  • Page 28 Installation of several appliances a Spring clamps b Spacer bars c Gaps between spacer bars and worktop d Cover strips The illustration shows a worktop cut-out with spring clamps a and spacer bars b for 3 appliances. An additional spacer bar is required for each additional appliance. The position for securing each additional spacer bar will depend on the width of appliance B (288 mm / 380 mm / 576 mm).

  • Page 29: Fixing The Spring Clamps And Spacer Bars

    Fixing the spring clamps and spacer bars Wooden worktops ^ Position the spring clamps supplied a and spacer bars b on the top edge of the cut-out in the positions marked. ^ Secure the spring clamps and spacer bars with the 3.5 x 25 mm screws supplied.
  • Page 30 Fixing the spring clamps and spacer bars Granite and marble worktops The screws are not required for granite or marble worktops. ^ Apply silcone to the side edges and the lower edges of spring clamps a and spacer bars b. ^ Then fill gap e between the spacer bars and the worktop with silicone.

  • Page 31: Installing The Appliance(S)

    Installing the appliance(s) ^ Feed the connection cable down ^ Starting at the front, position the next through the cut-out. appliance in the worktop cut-out. ^ Starting at the front, position the ^ Connect the appliance(s) to the appliance in the worktop cut-out. mains (see "Electrical connection").

  • Page 32: General Installation Tips

    General installation tips Seal between the appliance and the Tiled worktop worktop Grout lines a and the hatched area The sealing strip under the edge of the top part of the appliance provides a underneath the surface of the sufficient seal for the worktop. appliance must be smooth and even.

  • Page 33: Electrical Connection

    H 05 V V-F be provided for all poles. (pvc insulated), available from Miele. For extra safety it is advisable to protect the appliance with a suitable residual Installation, repairs and other work current device (RCD).
  • Page 34 Electrical connection Important The electrical safety of this appliance can only be guaranteed when continuity is complete between the appliance and an effective earthing system, which complies with local and national regulations. It is most important that this basic safety requirement is present and tested regularly and if there is any doubt the electrical wiring in the home should be inspected by a...

  • Page 35: After Sales Service, Data Plate, Guarantee

    Please note that telephone calls may be monitored and recorded to improve our service. When contacting Miele, please quote the model and serial number of your appliance which are given on the data plate. N.B. A call-out charge will be applied for service visits where the problem could have been resolved as described in these instructions.
  • Page 36 Alteration rights reserved/ 4111 M.-Nr. 07 180 450 / 08...
