Summary of Contents for Yamaha FJR13AZ
- Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL FJR13AZ(C) LIT-11626-23-70 1CY-28199-10...
- Page 2 EAU10042 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
- Page 3 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.
-
Page 4: Important Manual Information
IMPORTANT MANUAL INFORMATION EAU10132 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. - Page 5 IMPORTANT MANUAL INFORMATION EAU10193 FJR13AZ(C) OWNER’S MANUAL ©2009 by Yamaha Motor Corporation, U.S.A. 1st edition, November 2009 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.
-
Page 6: Table Of Contents
TABLE OF CONTENTS LOCATION OF IMPORTANT Accessory box ......4-20 Checking the spark plugs .... 7-14 LABELS ..........1-1 Adjusting the headlight beams ..4-21 Canister (for California only) ..7-15 Handlebar position ....... 4-21 Engine oil and oil filter cartridge ... 7-15 SAFETY INFORMATION ....2-1 Opening and closing the Final gear oil ........ - Page 7 Lubricating the rear suspension ...7-32 MOTORCYCLE LIMITED Checking the front fork ....7-32 WARRANTY ......10-7 Checking the steering ....7-33 YAMAHA EXTENDED SERVICE Checking the wheel bearings ..7-33 (Y.E.S.) ........10-9 Battery ..........7-34 Replacing the fuses ......7-35 Replacing a headlight bulb ...7-36 Front turn signal light ....7-37...
-
Page 8: Location Of Important Labels
Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer. 1,2,3,4... - Page 9 LOCATION OF IMPORTANT LABELS 1 California only 3 California only PRESS. REGULATOR 2 California only LOAD LIMIT 3 kg (7 lbs) 3TB-24877-A0 LOAD LIMIT 1 kg (2 lbs) 4BR-24877-A0...
- Page 10 LOCATION OF IMPORTANT LABELS NOTICE • Cleaning with alkaline or acid cleaner, 270 kPa, {2.70 kgf/cm }, 39 psi gasoline or solvent will damage windshield. 290 kPa, {2.90 kgf/cm }, 42 psi • Use neutral detergent. 8ET-2815K-00 270 kPa, {2.70 kgf/cm }, 39 psi 290 kPa, {2.90 kgf/cm }, 42 psi...
-
Page 11: Safety Information
SAFETY INFORMATION EAU10283 Safe Riding • Ride where other motorists can Perform the pre-operation checks each see you. Avoid riding in another time you use the vehicle to make sure it motorist’s blind spot. Be a Responsible Owner is in safe operating condition. Failure to Many accidents involve inexperi- As the vehicle’s owner, you are respon- inspect or maintain the vehicle properly... - Page 12 SAFETY INFORMATION due to excessive speed or under- This motorcycle is designed for on- A passenger should also observe cornering (insufficient lean angle road use only. It is not suitable for the above precautions. for the speed). off-road use. • Always obey the speed limit and Avoid Carbon Monoxide Poisoning never travel faster than warrant- Protective apparel...
- Page 13 Yamaha accessories, which are avail- Shifting weights can create a sud- accessories to your motorcycle. Use able only from a Yamaha dealer, have den imbalance. Make sure that ac- extra care when riding a motorcycle been designed, tested, and approved cessories and cargo are securely that has added cargo or accessories.
-
Page 14: Specifications
SAFETY INFORMATION modifications not specifically recom- clearance or cornering clearance, tor and may limit control ability, mended by Yamaha, even if sold and limit suspension travel, steering therefore, such accessories are installed by a Yamaha dealer. travel or control operation, or ob- not recommended. -
Page 15: Description
DESCRIPTION EAU10410 Left view 1. Accessory box (page 4-20) 9. Shock absorber assembly spring preload adjusting lever (page 4-25) 2. Front fork spring preload adjusting bolt (page 4-23) 10.Air filter element (page 7-20) 3. Front fork rebound damping force adjusting knob (page 4-23) 11.Shift pedal (page 4-11) 4. -
Page 16: Right View
DESCRIPTION EAU10420 Right view 11 10 1. Storage compartment (page 4-19) 9. Brake pedal (page 4-12) 2. Fuel tank cap (page 4-13) 10.Shock absorber assembly rebound damping force adjusting knob (page 4-25) 3. Fuse box (page 7-35) 11.Rear brake fluid reservoir (page 7-27) 4. -
Page 17: Controls And Instruments
DESCRIPTION EAU10430 Controls and instruments 1. Rear view mirror (page 4-23) 9. Right handlebar switches (page 4-9) 2. Clutch lever (page 4-10) 10.Brake lever (page 4-11) 3. Left handlebar switches (page 4-9) 11.Throttle grip (page 7-22) 4. Clutch fluid reservoir (page 7-27) 12.Main switch/steering lock (page 4-1) 5. -
Page 18: Instrument And Control Functions
INSTRUMENT AND CONTROL FUNCTIONS EAU10460 EAU10661 To lock the steering Main switch/steering lock All electrical systems are off. The key can be removed. EWA10061 WARNING Never turn the key to “OFF” or “LOCK” while the vehicle is moving. Otherwise the electrical systems will be switched off, which may result in loss of control or an accident. -
Page 19: Indicator And Warning Lights
“ON”, EAU11030 or if the warning light remains on, have Turn signal indicator lights “ ” a Yamaha dealer check the electrical and “ ” circuit. The corresponding indicator light flash- es when the turn signal switch is... -
Page 20: Speedometer
If this warning light comes on or flashes warning light may flicker when riding on while riding, the ABS may not work cor- rectly. If this occurs, have a Yamaha a slope or during sudden acceleration or deceleration, but this is not a mal- dealer check the system as soon as function. -
Page 21: Tachometer
INSTRUMENT AND CONTROL FUNCTIONS EAU11872 EAU40298 a fuel reserve tripmeter (which Tachometer Multi-function display shows the distance traveled on the fuel reserve) a clock a fuel meter a coolant temperature meter a transmission gear display an ambient temperature display a fuel consumption display (instan- taneous and average consumption functions) a self-diagnosis device... - Page 22 INSTRUMENT AND CONTROL FUNCTIONS Odometer and tripmeter modes case, pushing the select button switch- Clock es the display between the various trip- meter and odometer modes in the following order: Trip F → ODO → Trip 1 → Trip 2 → Trip When selecting “Trip 1”, “Trip 2”...
- Page 23 INSTRUMENT AND CONTROL FUNCTIONS Fuel meter segments will start flashing. If this oc- ECA10021 NOTICE curs, have a Yamaha dealer check the electrical circuit. Do not continue to operate the en- gine if it is overheating. Coolant temperature meter Transmission gear display 1.
- Page 24 INSTRUMENT AND CONTROL FUNCTIONS Ambient temperature, instanta- Ambient temperature mode 20 km/h (12.5 mi/h)] or when neous fuel consumption and aver- stopped at traffic signals, railroad age fuel consumption modes crossings, etc. Instantaneous fuel consumption mode 1. Ambient temperature This display shows the ambient tem- 1.
- Page 25 If the multi-function display indicates ECA15472 such an error code, note the code num- NOTICE ber, and then have a Yamaha dealer If there is a malfunction, “– –.–” will check the vehicle. be displayed. Have a Yamaha dealer ECA11790 check the vehicle.
-
Page 26: Handlebar Switches
INSTRUMENT AND CONTROL FUNCTIONS EAU12348 Right EAU12493 Handlebar switches Windshield position adjusting switch “ ” Left To move the windshield up, push this switch in direction (a). To move the windshield down, push the switch in di- rection (b). 1. Engine stop switch “ ”... -
Page 27: Clutch Lever
INSTRUMENT AND CONTROL FUNCTIONS EAU12660 The hazard lights are used in case of EAU12830 Engine stop switch “ ” Clutch lever an emergency or to warn other drivers Set this switch to “ ” before starting when your vehicle is stopped where it the engine. -
Page 28: Shift Pedal
INSTRUMENT AND CONTROL FUNCTIONS Make sure that the appropriate setting EAU12870 EAU26823 Shift pedal Brake lever on the adjusting dial is aligned with the The brake lever is located at the right arrow mark on the clutch lever. handlebar grip. To apply the front The clutch lever is equipped with a brake, pull the lever toward the handle- clutch switch, which is part of the igni-... -
Page 29: Brake Pedal
EAU39533 even slightly applied, a vibration Brake pedal can be felt at the lever and pedal, The Yamaha ABS (Anti-lock Brake but these do not indicate a mal- System) features a dual electronic con- function. trol system, which acts on the front and When the ABS is activated, the rear brakes independently. -
Page 30: Fuel Tank Cap
INSTRUMENT AND CONTROL FUNCTIONS EAU13074 Fuel tank cap The fuel tank cap cannot be closed un- less the key is in the lock. In addition, the key cannot be removed if the cap is not properly closed and locked. EWA11091 WARNING Make sure that the fuel tank cap is properly closed after filling fuel. -
Page 31: Fuel
EWA15151 refueling, be sure to insert the WARNING Your Yamaha engine has been de- pump nozzle into the fuel tank filler Gasoline is poisonous and can signed to use regular unleaded gaso- hole. Stop filling when the fuel cause injury or death. -
Page 32: Fuel Tank Breather/Overflow Hose
Do not park the vehicle near ohol containing methanol possible fire hazards such as recommended by Yamaha because it grass or other materials that can cause damage to the fuel system easily burn. or vehicle performance problems. 1. Fuel tank breather/overflow hose... -
Page 33: Seats
INSTRUMENT AND CONTROL FUNCTIONS ECA10701 EAU39492 To install the passenger seat Seats NOTICE 1. Insert the projections on the rear of the passenger seat into the seat Use only unleaded gasoline. The use Passenger seat of leaded gasoline will cause unre- holders as shown, and then push pairable damage to the catalytic the front of the seat down to lock it... -
Page 34: Adjusting The Rider Seat Height
INSTRUMENT AND CONTROL FUNCTIONS 2. Install the passenger seat. EAU39632 Adjusting the rider seat height The rider seat height can be adjusted to Make sure that the seats are prop- one of two positions to suit the rider’s erly secured before riding. preference. - Page 35 INSTRUMENT AND CONTROL FUNCTIONS 6. Align the projection on the bottom of the rider seat with the “H” posi- tion slot, and then push the rear of the seat down to lock it in place as shown. 1. Rider seat height position adjuster 1.
-
Page 36: Storage Compartments
INSTRUMENT AND CONTROL FUNCTIONS 6. Align the projection on the bottom EAU40251 Storage compartments of the rider seat with the “L” posi- This vehicle is equipped with two stor- tion slot, and then push the rear of age compartments. the seat down to lock it in place as Storage compartment A is located un- shown. -
Page 37: Accessory Box
INSTRUMENT AND CONTROL FUNCTIONS washing the vehicle, be careful not to EAU39480 Accessory box let any water enter a storage compart- The accessory box is located beside ment. the meter panel. To open the accessory box 1. Insert the key into the main switch, and then turn it to “ON”. -
Page 38: Adjusting The Headlight Beams
The headlight beam adjusting knobs Do not place heat-sensitive items in erence. Have a Yamaha dealer adjust are used to raise or lower the height of the accessory box. The accessory the position of the handlebars. -
Page 39: Opening And Closing The Cowlings
INSTRUMENT AND CONTROL FUNCTIONS EAU39621 Opening and closing the cowl- ings The cowlings can be tilted back 30 mm (1.18 in) for added ventilation to suit the riding conditions. 1. Quick fastener screw 1. Quick fastener screw 2. Pull the cowling to the open posi- 2. -
Page 40: Rear View Mirrors
INSTRUMENT AND CONTROL FUNCTIONS EAU39671 EAU14732 To increase the spring preload and Rear view mirrors Adjusting the front fork thereby harden the suspension, turn The rear view mirrors of this vehicle can EWA10180 the adjusting bolt on each fork leg in di- WARNING be folded forward or backward for park- rection (a). - Page 41 INSTRUMENT AND CONTROL FUNCTIONS Rebound damping force Compression damping force Although the total number of clicks of a damping force adjusting mechanism may not exactly match the above spec- ifications due to small differences in production, the actual number of clicks always represents the entire adjusting range.
-
Page 42: Adjusting The Shock Absorber Assembly
INSTRUMENT AND CONTROL FUNCTIONS EAU14915 For riding solo, move the spring preload Rebound damping setting: Adjusting the shock absorber adjusting lever in direction (a). For Minimum (soft): assembly riding with a passenger, move the 20 click(s) in direction (b)* This shock absorber assembly is Standard: spring preload adjusting lever in direc- 12 click(s) in direction (b)*... -
Page 43: Sidestand
INSTRUMENT AND CONTROL FUNCTIONS Do not subject the shock ab- EAU15303 below and have a Yamaha dealer re- Sidestand sorber assembly to an open pair it if it does not function proper- The sidestand is located on the left side flame or other high heat source. -
Page 44: Ignition Circuit Cut-Off System
INSTRUMENT AND CONTROL FUNCTIONS EAU44902 Ignition circuit cut-off system The ignition circuit cut-off system (com- prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions. It prevents starting when the trans- mission is in gear and the side- stand is up, but the clutch lever is not pulled. - Page 45 ”. stand during this inspection. • 3. Turn the key on. If a malfunction is noted, have a Yamaha 4. Shift the transmission into the neutral position. dealer check the system before riding. 5. Push the start switch. Does the engine start? With the engine still running: The neutral switch may not be working correctly.
-
Page 46: Auxiliary Dc Jack
INSTRUMENT AND CONTROL FUNCTIONS EAU39653 Auxiliary DC jack ECA15431 NOTICE The accessory connected to the auxiliary DC jack should not be used with the engine turned off, and the load must never exceed 30 W (2.5 A), otherwise the fuse may blow or the battery may discharge. -
Page 47: For Your Safety - Pre-Operation Checks
• If necessary, add recommended coolant to specified level. 7-19 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary. - Page 48 • Make sure that operation is smooth. • Check cable free play. Throttle grip 7-22, 7-29 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 7-29 •...
- Page 49 FOR YOUR SAFETY – PRE-OPERATION CHECKS ITEM CHECKS PAGE Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-26 • If system is not working correctly, have Yamaha dealer check vehicle.
-
Page 50: Operation And Important Riding Points
Yamaha dealer. The transmission is in the neutral gine in case of a turnover. In this position. -
Page 51: Shifting
NOTICE tral position. (See page 6-2.) The neutral indicator light should come Even with the transmission in on. If not, ask a Yamaha dealer to the neutral position, do not check the electrical circuit. coast for long periods of time 3. -
Page 52: Engine Break-In
OPERATION AND IMPORTANT RIDING POINTS 4. At the recommended shift points 3. Shift the transmission into the neu- EAU16841 Engine break-in shown in the following table, close tral position when the motorcycle There is never a more important period the throttle, and at the same time, is almost completely stopped. -
Page 53: Parking
Do not park on a slope or on soft cur during the engine break-in ground, otherwise the vehicle period, immediately have a may overturn, increasing the Yamaha dealer check the vehi- risk of a fuel leak and fire. cle. Do not park near grass or other flammable... -
Page 54: Periodic Maintenance And Adjustment
(if applicable). Yamaha your risk of injury or death during dealers are trained and equipped to perform these particular services. -
Page 55: Owner's Tool Kit
If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you. -
Page 56: Periodic Maintenance Chart For The Emission Control System
From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months. Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the service. EAU17601... - Page 57 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Evaporative emis-...
-
Page 58: General Maintenance And Lubrication Chart
PERIODIC MAINTENANCE AND ADJUSTMENT EAU32186 General maintenance and lubrication chart INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months... - Page 59 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
- Page 60 16000 mi (25000 km) or 24 months. Front and rear brake √ √ √ √ √ √ 25 * • Check operation. switches • Apply Yamaha chain and cable √ √ √ √ √ √ 26 * Control cables lube or engine oil thoroughly.
- Page 61 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
-
Page 62: Removing And Installing Panels
PERIODIC MAINTENANCE AND ADJUSTMENT EAU18771 Removing and installing pan- The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed. 1. - Page 63 PERIODIC MAINTENANCE AND ADJUSTMENT 2. Remove the bolt and quick fasten- To install the panel er, and then remove the panel. 1. Place the panel in the original posi- NOTICE: Do not remove the tion, and then install the bolt and headlight beam adjusting cable.
- Page 64 PERIODIC MAINTENANCE AND ADJUSTMENT 1. Panel D 1. Panel D 1. Panel E 2. Bolt 2. Bolt 2. Install panels B and C. 3. Quick fastener 3. Quick fastener screw EAU47050 Panels E and F To remove one of the panels 1.
- Page 65 PERIODIC MAINTENANCE AND ADJUSTMENT 3. Pull the bottom of the panel out- ward, pull the front of the panel downward, and then slide the pan- el forward to release it in the rear as shown. 1. Panel E 1. Panel F 1.
- Page 66 PERIODIC MAINTENANCE AND ADJUSTMENT 1. Panel E 1. Panel E 1. Panel F 2. Rear cowling 2. Fuel tank side cover 1. Panel F 1. Panel E 2. Rear cowling 1. Panel F 2. Fuel tank side cover 3. Install the bolts and the quick fas- 2.
-
Page 67: Checking The Spark Plugs
Do not attempt to diagnose 0.7–0.8 mm (0.028–0.031 in) such problems yourself. Instead, have a Yamaha dealer check the vehicle. Clean the surface of the spark plug If a spark plug shows signs of electrode gasket and its mating surface, and then... -
Page 68: Canister (For California Only)
PERIODIC MAINTENANCE AND ADJUSTMENT EAU19681 EAU19886 Canister (for California only) Engine oil and oil filter car- tridge The engine oil level should be checked before each ride. In addition, the oil must be changed and the oil filter car- tridge replaced at the intervals speci- fied in the periodic maintenance and lubrication chart. - Page 69 Make sure that the O-ring is properly An oil filter wrench is available at a seated. 1. Engine oil filler cap Yamaha dealer. 2. Engine oil drain bolt 7. Install the new oil filter cartridge, 3. Gasket 6. Apply a thin coat of clean engine...
- Page 70 Do off and have a Yamaha dealer check the bolt to the specified torque. not use oils with a diesel speci- the vehicle.
-
Page 71: Final Gear Oil
23 Nm (2.3 m·kgf, 17 ft·lbf) filler hole. for oil leakage before each ride. If any leakage is found, have a Yamaha deal- To change the final gear oil er check and repair the vehicle. In addi- 1. Place the vehicle on a level sur- tion, the final gear oil level must be face. -
Page 72: Coolant
PERIODIC MAINTENANCE AND ADJUSTMENT EAU20070 Tightening torque: Coolant Final gear oil drain bolt: The coolant level should be checked 23 Nm (2.3 m·kgf, 17 ft·lbf) before each ride. In addition, the cool- ant must be changed at the intervals 5. Refill with the recommended final specified in the periodic maintenance gear oil to the brim of the filler hole. -
Page 73: Cleaning The Air Filter Element
Have a the periodic maintenance and lubrica- hot. NOTICE: If coolant is [EWA15161] Yamaha dealer change the coolant. tion chart. Clean or, if necessary, re- not available, use distilled water WARNING! Never attempt to remove place the air filter element more or soft tap water instead. - Page 74 PERIODIC MAINTENANCE AND ADJUSTMENT out with compressed air as shown. If the air filter element is damaged, replace it. 1. Air filter case cover 1. Fuel tank breather/overflow hose 2. Screw 8. Install the intake air shroud by in- 4. Pull the air filter element out. stalling the screw and the quick 6.
-
Page 75: Checking The Engine Idling Speed
To prevent this necessary, have it corrected by a from occurring, the valve clearance Yamaha dealer. must be adjusted by a Yamaha dealer at the intervals specified in the periodic Engine idling speed: 1000–1100 r/min maintenance and lubrication chart. -
Page 76: Tires
FJR13AZC 211 kg (465 lb) tact a Yamaha dealer immediately and tires (i.e., when the temperature * Total weight of rider, passenger, car- go and accessories of the tires equals the ambient have the tire replaced. - Page 77 This motorcycle is fitted with super- ed below have been approved for this high-speed tires. Note the following model by Yamaha Motor Co., Ltd. points in order to make the most ef- ficient use of these tires. Use only the specified replace- ment tires.
-
Page 78: Cast Wheels
Always adjust the tire air pres- fore each ride. If any damage is 7-27.) If the clutch lever free play does sure according to the operating found, have a Yamaha dealer re- become excessive, and shifting be- conditions. place the wheel. Do not attempt... -
Page 79: Checking The Brake Lever Free Play
If necessary, have a Yamaha deal- er adjust the brake light switches. 1. No brake lever free play There should be no free play at the brake lever end. -
Page 80: Checking The Front And Rear Brake Pads
EAU22392 cator groove has almost disappeared, EAU40270 Checking the front and rear Checking the brake and clutch have a Yamaha dealer replace the brake pads fluid levels brake pads as a set. The front and rear brake pads must be... - Page 81 However, if the brake fluid level goes down sud- 1. Minimum level mark DOT 4 brake fluid denly, have a Yamaha dealer Insufficient brake fluid may allow air to check the cause. Refill with the same type of brake enter the brake or clutch systems, pos- fluid.
-
Page 82: Changing The Brake And Clutch Fluids
Checking and lubricating the clutch fluids cables throttle grip and cable Have a Yamaha dealer change the The operation of all control cables and The operation of the throttle grip should brake and clutch fluids at the intervals the condition of the cables should be be checked before each ride. -
Page 83: Checking And Lubricating The Brake And Shift Pedals
PERIODIC MAINTENANCE AND ADJUSTMENT EAU44272 EAU43600 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease brake and shift pedals brake and clutch levers Brake pedal Brake lever Shift pedal Clutch lever The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each... -
Page 84: Checking And Lubricating The Centerstand And Sidestand
EWA10741 WARNING If the centerstand or sidestand does not move up and down smoothly, have a Yamaha dealer check or re- pair it. Otherwise, the centerstand or sidestand could contact the ground and distract the operator, resulting in a possible loss of control. -
Page 85: Lubricating The Swingarm Pivots
The swingarm pivots must be lubricat- The pivoting points of the rear suspen- face and hold it in an upright posi- ed by a Yamaha dealer at the intervals sion must be lubricated by a Yamaha tion. WARNING! To avoid injury,... -
Page 86: Checking The Steering
Yamaha dealer check or re- tion chart. If there is play in the wheel ward and backward. If any free pair it. -
Page 87: Battery
To charge the battery Electrolyte is poisonous and [ECA16302] Have a Yamaha dealer charge the bat- 2. If the battery will be stored for more dangerous since it contains sul- tery as soon as possible if it seems to... -
Page 88: Replacing The Fuses
PERIODIC MAINTENANCE AND ADJUSTMENT 3. Fully charge the battery before in- EAU23659 Replacing the fuses stallation. The main fuse, the fuse boxes and the 4. After installation, make sure that ABS motor fuse are located under pan- the battery leads are properly con- el A. -
Page 89: Replacing A Headlight Bulb
If a headlight bulb burns possibly a fire. 4. If the fuse immediately blows [EWA15131] out, replace it as follows. again, have a Yamaha dealer ECA10650 Specified fuses: check the electrical system. NOTICE Main fuse: 50.0 A... -
Page 90: Front Turn Signal Light
If a front turn signal light does not come bulb. on, have a Yamaha dealer check its electrical circuit or replace the bulb. 1. Do not touch the glass part of the bulb. 1. Remove panel D (if replacing the left headlight bulb) or panel C (if re- 1. -
Page 91: Replacing A Rear Turn Signal Light Bulb Or A Tail/Brake Light Bulb
PERIODIC MAINTENANCE AND ADJUSTMENT EAU27003 6. Install the passenger seat. EAU24313 Replacing a rear turn signal Replacing the license plate light bulb or a tail/brake light light bulb bulb 1. Remove the license plate light unit by removing the screws. 1. -
Page 92: Troubleshooting
3. Remove the burnt-out bulb by pull- self. However, should your motorcycle ing it out. require any repair, take it to a Yamaha 4. Insert a new bulb into the socket. dealer, whose skilled technicians have 5. Install the socket (together with the the necessary tools, experience, and bulb) by pushing it in. -
Page 93: Troubleshooting Charts
Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good. - Page 94 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.
-
Page 95: Motorcycle Care And Storage
Be ble. Rust and corrosion can develop ECA10772 even if high-quality components are sure to consult a Yamaha dealer for NOTICE used. A rusty exhaust pipe may go un- advice on what products to use be- Avoid using strong acidic wheel fore cleaning the vehicle. - Page 96 MOTORCYCLE CARE AND STORAGE off any detergent residue using Test the product on a small hid- plenty of water, as it is harmful den part of the windshield to Salt sprayed on roads in the winter may to plastic parts. make sure that it does not leave remain well into spring.
-
Page 97: Storage
WARNING To prevent corrosion, avoid Contaminants on the brakes or tires Consult a Yamaha dealer for ad- damp cellars, stables (because can cause loss of control. vice on what products to use. of the presence of ammonia) - Page 98 MOTORCYCLE CARE AND STORAGE 3. Perform the following steps to pro- 4. Lubricate all control cables and the tect the cylinders, piston rings, etc. pivoting points of all levers and from corrosion. pedals as well as of the side- a. Remove the spark plug caps stand/centerstand.
-
Page 99: Specifications
SPECIFICATIONS Dimensions: Engine oil: Radiator capacity (including all routes): 2.60 L (2.75 US qt, 2.29 Imp.qt) Overall length: Recommended brand: Air filter: 2230 mm (87.8 in) YAMALUBE Overall width: Type: Air filter element: 750 mm (29.5 in) SAE 20W-40 or 20W-50 Dry element Overall height: Fuel:... - Page 100 SPECIFICATIONS Secondary reduction ratio: Rear tire: Rear: 35/37 × 21/27 × 33/9 (2.698) 290 kPa (2.90 kgf/cm², 42 psi) Type: Transmission type: Front wheel: Tubeless Constant mesh 5-speed Size: Wheel type: Operation: 180/55 ZR17M/C (73W) Cast wheel Left foot operation Manufacturer/model: Rim size: Gear ratio:...
- Page 101 SPECIFICATIONS Rear suspension: Neutral indicator light: Auxiliary DC jack fuse: 3.0 A Type: High beam indicator light: Backup fuse: Swingarm (link suspension) 10.0 A Spring/shock absorber type: Oil level warning light: Coil spring/gas-oil damper Wheel travel: Turn signal indicator light: 125.0 mm (4.92 in) Electrical system: Engine trouble warning light:...
-
Page 102: Consumer Information
Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1. - Page 103 This informa- illustration. This label shows specifica- tion will be needed when ordering tions related to exhaust emissions as spare parts from a Yamaha dealer. required by federal law, state law and Environment Canada. 10-2...
-
Page 104: Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. -
Page 105: Motorcycle Noise Regulation
CONSUMER INFORMATION EAU26560 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new ve- hicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person. -
Page 106: Maintenance Record
CONSUMER INFORMATION EAU26632 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required. - Page 107 CONSUMER INFORMATION Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-6...
-
Page 108: Yamaha Motor
CONSUMER INFORMATION EAU26663 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants that CUSTOMER’S RESPONSIBILITY under this Engine new Yamaha motorcycles will be free from defects in warranty shall be to: Displacement Period... - Page 109 CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.
-
Page 110: Yamaha Extended Service (Y.e.s.)
This excellent Y.E.S. plan coverage is only available to dealer to see how comforting uninterrupted factory- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts. - Page 111 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
- Page 112 INDEX Engine oil and oil filter cartridge ... 7-15 Maintenance record ......10-5 Engine stop switch........ 4-10 Matte color, caution.........8-1 ABS............4-12 Engine trouble warning light ....4-3 Model label..........10-2 ABS warning light........4-3 Multi-function display.......4-4 Accessory box........4-20 Air filter element, cleaning..... 7-20 Final gear oil .........
- Page 113 INDEX Tachometer ..........4-4 Throttle cable free play, checking..7-22 Throttle grip and cable, checking and lubricating ........... 7-29 Tires............7-23 Tool kit ............ 7-2 Troubleshooting........7-39 Troubleshooting charts ......7-40 Turn signal indicator lights ...... 4-2 Turn signal light or tail/brake light bulb, replacing..........
- Page 116 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2009.11-0.3×1 CR...
