  • Page 1 3.0-6.0kW G2 Single Phase User Manual V1.1 HYBRID INVERTER www.gesolarinverter.com...
  • Page 2 Copyright Statement User Manual V1.1-2023-06-20 NOTICE The information in this user manual is subject to change due to product updates or other reasons. This guide cannot replace the product labels or the safety precautions in the user manual unless otherwise specified. All descriptions in the manual are for guidance only.

  • Page 3: Table Of Contents

    Content User Manual V1.1-2023-06-20 CONTENT 1 About This Manual ���������������������������������������������������������������������������� 1 1.1 Applicable Model ........................1 1.2 Target Audience ........................1 1.3 Symbol Definition ........................1 1.4 Updates ............................1 2 Safety Precaution ����������������������������������������������������������������������������� 2 2.1 General Safety ..........................2 2.2 PV String Safety ........................2 2.3 Inverter Safety ..........................3 2.4 Battery .............................4 2.5 Personnel Requirements ......................4...
  • Page 4 User Manual V1.1-2023-06-20 Content 6.5 Connecting the DC Input Cable(PV) ..................30 6.6 Connecting the battery cable ....................32 6.7 Communication ........................34 6.7.1 Connecting the COM cable (Load Control, Remote Shutdown, DI Signal, Generator Control, DRED, RCR and EMS) ..............................34 6.7.2 Connecting BMS or Meter COM Cable ....................

  • Page 5: About This Manual

    This manual is subject to update without notice. For more product details and latest documents, visit www.gesolarinverter.com. 1.1 Applicable Model This manual applies to the listed inverters below: Hybrid Inverter • GEH3.0-1LU-20 • GEH3.6-1LU-20 • GEH3.6M-1LU-20 • GEH5.0M-1LU-20 • GEH5.0-1LU-20 • GEH6.0-1LU-20 •...

  • Page 6: Safety Precaution

    02 Safety Precaution User Manual V1.1-2023-06-20 2 Safety Precaution Please strictly follow these safety instructions in the user manual during the operation. NOTICE The inverters are designed and tested strictly complies with related safety rules. Read and follow all the safety instructions and cautions before any operations. Improper operation might cause personal injury or property damage as the inverters are electrical equipment.

  • Page 7: Inverter Safety

    User Manual V1.1-2023-06-20 02 Safety Precaution 2.3 Inverter Safety WARNING • The voltage and frequency at the connecting point should meet the on-grid requirements. • Additional protective devices like circuit breakers or fuses are recommended on the AC side. Specification of the protective device should be at least 1.25 times the AC rated output current.

  • Page 8: Battery

    02 Safety Precaution User Manual V1.1-2023-06-20 2.4 Battery WARNING • The battery used with the inverter shall be approved by the inverter manufacturer. The approved battery list can be obtained through the official website. • Before installations, read through the corresponding battery's User Manual to learn about the product and the precautions.

  • Page 9: Product Introduction

    The power generated in the PV system can be used, stored in the battery, output to the Utility Grid, etc. Model This manual applies to the listed inverters below: Hybrid Inverter • GEH3.0-1LU-20 • GEH3.6-1LU-20 • GEH3.6M-1LU-20 • GEH5.0M-1LU-20 • GEH5.0-1LU-20 •...

  • Page 10: Application Scenarios

    The supported loads are as follows: • For GEH3.0-1LU-20, GEH3.6-1LU-20, GEH5.0-1LU-20, GEH6.0-1LU-20, GEH6.0-1LU-BR20: the total power of inductive load and capacitive load is no more than the inverter's rated output power.
  • Page 11 The battery breakers shall be prepared by the customers with the following Breaker specifications: • For GEH3.0-1LU-20, GEH3.6M-1LU-20, GEH5.0M-1LU-20 and GEH6.0M-1LU-20: the nominal current ≥ 75A and the nominal voltage ≥ 60V. • For GEH3.6-1LU-20: the nominal current ≥ 100A and the nominal voltage ≥ 60V.

  • Page 12: Working Mode

    03 Product Introduction User Manual V1.1-2023-06-20 Parallel Inverter System NOTICE The hybrid inverter supports multiple inverters in parallel. For details, please refer to the Parallel Inverter System Solution User Manual. Parallel Inverter System Solution User Manual 3.3 Working Mode 3.3.1 System working mode Economic mode NOTICE •...
  • Page 13 User Manual V1.1-2023-06-20 03 Product Introduction Self consumption mode NOTICE • For solar power, consider self consumption mode as priority: the excess power charges the battery in day time; the battery supplies power to the load when there is no solar power generated at night.
  • Page 14 03 Product Introduction User Manual V1.1-2023-06-20 Back-up mode NOTICE • The back-up mode is mainly applied to the scenario where the grid is unstable and there is an important load. When the grid is disconnected, the inverter turns to off-grid mode to supply power to the load;...

  • Page 15: Inverter Operation Mode

    User Manual V1.1-2023-06-20 03 Product Introduction 3.3.2 Inverter operation mode Waiting mode Off-grid mode Self-check mode Grid-Tied mode Fault mode Parts Description Waiting Waiting stage after the inverter is powered on. mode • When the conditions are met, it enters the self-check mode. •...

  • Page 16: Functionality

    03 Product Introduction User Manual V1.1-2023-06-20 3.4 Functionality Power derating For a safe operation, the inverter will automatically reduce the output power when the operating environment is not ideal. The following are the factors that may occur power derating. Please try to avoid them during usage.
  • Page 17 User Manual V1.1-2023-06-20 03 Product Introduction Circuit Breaker Inverter Load Communication The inverter supports setting via WiFi or Bluetooth in a short distance: connected to the Server via WiFi or LAN to monitor the inverter and power plant operations, etc. •...

  • Page 18: Appearance

    BACK-UP AC Output Port ON-GRID AC Output Port Grounding Terminal LED Indicator Mounting Plate Heat Sink *1: 1 x PV+/PV- for GEH3.0-1LU-20 inverters; and 2 x PV+/PV- for other type inverters. * 2: only for inverters in Australia. 3.5.2 Dimension...

  • Page 19: Indicator Description

    User Manual V1.1-2023-06-20 03 Product Introduction 3.5.3 Indicator Description Indicator Status Description The inverter is power on and in the standby mode. The inverter is starting up and in the self-check mode. The inverter is in normal operation under grid-tied or off-grid modes.

  • Page 20: Nameplate

    03 Product Introduction User Manual V1.1-2023-06-20 3.5.4 Nameplate The nameplate is for reference only. Product: Hybrid Inverter Model : GEH**-***-** GE trademark, product type, and product model DCmax: ***Vd.c. MPP: **... Vd.c. PV Input DC,max: **Ad.c. SC PV: **Ad.c. batt **...**Vd.c.,...

  • Page 21: Check And Storage

    • Connect the DC cables with the delivered terminals. The manufacturer shall not be liable for the damage if other terminals are used. • N represents the accessories' quantity delivered varies depending on the specific inverter type. DC connector: 1 x PV+/PV- for GEH3.0-1LU-20 inverters; and 2 x PV+/PV- for other type inverters. Expansion...

  • Page 22: Storage

    04 Check and Storage User Manual V1.1-2023-06-20 4.3 Storage If the equipment is not to be installed or used immediately, please ensure that the storage environment meets the following requirements: 1. Do not unpack the outer package or throw the desiccant away. 2.

  • Page 23: Installation

    User Manual V1.1-2023-06-20 05 Installation 5 Installation 5.1 Installation Requirements Installation Environment Requirements 1. Do not install the equipment in a place near flammable, explosive, or corrosive materials. 2. Do not install the equipment in a place that is easy to touch, especially within children’s reach. High temperature exists when the equipment is working.
  • Page 24 05 Installation User Manual V1.1-2023-06-20 Mounting Support Requirements • The mounting support shall be nonflammable and fireproof. • Install the equipment on a surface that is solid enough to bear the inverter weight. • Do not install the product on the support with poor sound insulation to avoid the noise generated by the working product, which may annoy the residents nearby.
  • Page 25 User Manual V1.1-2023-06-20 05 Installation Installation Tool Requirements The following tools are recommended when installing the equipment. Use other auxiliary tools on site if necessary. Safety RJ45 Safety Goggles Dust mask gloves crimping tool shoes Wire Diagonal Hammer Vacuum Heat gun stripper pliers cleaner...

  • Page 26: Inverter Installation

    05 Installation User Manual V1.1-2023-06-20 5.2 Inverter Installation 5.2.1 Moving the Inverter CAUTION • Operations such as transportation, turnover, installation and so on must meet the requirements of the laws and regulations of the country or region where it is located. •...
  • Page 27 User Manual V1.1-2023-06-20 05 Installation Diameter: 10mm Depth: 80mm Only Australia.

  • Page 28: Electrical Connection

    06 Electrical Connection User Manual V1.1-2023-06-20 6 Electrical Connection 6.1 Circuit Diagram NOTICE • N and PE wiring via ON-GRID and BACK-UP ports of the inverter are different based on the regulation requirements of different regions. Refer to the specific requirements of local regulations.
  • Page 29 06 Electrical Connection User Manual V1.1-2023-06-20 N and PE cables in the Main Panel shall be wired separately. NOTICE Ensure that the grounding of BACK-UP is correctly and tightened. Otherwise, the BACK-UP function may be abnormal in case of grid failure. Other areas except Australia, New Zealand, South Africa, etc., are applicable to the following wirings: Main Panel...

  • Page 30: Safety Precaution

    06 Electrical Connection User Manual V1.1-2023-06-20 6.2 Safety Precaution DANGER • All operations, cables and parts specification during the electrical connection shall be in compliance with local laws and regulations. • Disconnect the DC switch and the AC output switch of the inverter to power off the inverter before any electrical connections.

  • Page 31: Connecting The Ac Cable

    Monitoring Device) can be connected to the outside of the inverter for protection when the DC component of the leakage current exceeds the limit value. The following RCDs are for reference: Inverter Model RCD Type (ON-GRID) RCD Type (BACK-UP) GEH3.0-1LU-20 300mA 30mA GEH3.6-1LU-20 300mA 30mA GEH3.6M-1LU-20...
  • Page 32 06 Electrical Connection User Manual V1.1-2023-06-20 WARNING • Connect the AC cables to the corresponding terminals such as “L”, “N” and “PE” ports correctly. Otherwise it will cause damage to the inverter. • Ensure that the whole cable cores are inserted into the terminal holes. No part of the cable core can be exposed.
  • Page 33 06 Electrical Connection User Manual V1.1-2023-06-20 Type II Supported by GEH3.6M-1LU-20, GEH5.0M-1LU-20, GEH6.0M-1LU-20 inverters Copper, 2.5mm ≤ S ≤ 4mm...

  • Page 34: Connecting The Dc Input Cable(Pv)

    06 Electrical Connection User Manual V1.1-2023-06-20 6.5 Connecting the DC Input Cable(PV) DANGER • Do not connect one PV string to more than one inverter at the same time. Otherwise, it may cause damage to the inverter. • Confirm the following information before connecting the PV string to the inverter. Otherwise, the inverter may be damaged permanently or even cause fire and cause personal and property losses.
  • Page 35 06 Electrical Connection User Manual V1.1-2023-06-20 Click Click ≤ 600V Vaconn 7~8mm 7~8mm Click Click ≤ 600V...

  • Page 36: Connecting The Battery Cable

    06 Electrical Connection User Manual V1.1-2023-06-20 6.6 Connecting the battery cable DANGER • The battery used with the inverter shall be approved by the inverter manufacturer. The approved battery list can be obtained through the official website. • A short circuit in the battery may cause personal injury. The instantaneous high current caused by a short circuit can release a large amount of energy and may cause a fire.

  • Page 37: Communication

    06 Electrical Connection User Manual V1.1-2023-06-20 10mm 9.5-12.5mm 10mm 9.5-12.5mm 20mm ≤ S ≤ 35mm 6.7 Communication NOTICE Make sure that the communication device is connected to the right COM port. Route the communication cable far away from any interference source or power cable to prevent the signal from being influenced.

  • Page 38: Connecting The Com Cable (Load Control, Remote Shutdown, Di Signal, Generator Control, Dred, Rcr And Ems)

    06 Electrical Connection User Manual V1.1-2023-06-20 6.7.1 Connecting the COM cable (Load Control, Remote Shutdown, DI Signal, Generator Control, DRED, RCR and EMS) Port Definition Function Description DO1+ The inverter reserves a dry contact controlling Load Control port, which supports connecting additional contactors to enable/disable the load.
  • Page 39 06 Electrical Connection User Manual V1.1-2023-06-20 Remote Load Control Shutdown 1: DO1+ 4: Remote 2: N/A Shutdown 3: DO1- 5: GND Generator 6: DI+ 8: DO2+ 7: DI- 9: DO2- When using the standard Ethernet cable to connect for EMS function, only crimp PIN1 and PIN2 of the RJ45 into 2 wires of them.

  • Page 40: Connecting Bms Or Meter Com Cable

    06 Electrical Connection User Manual V1.1-2023-06-20 6.7.2 Connecting BMS or Meter COM Cable Connecting the Lead-acid Battery Thermo Sensor Cable NOTICE • The inverter is delivered with lead-acid battery thermo sensor cable with 3 meters in length. • Connect the RJ45 Modular Plug of the sensor cable to the inverter BMS port. Put the metal thermo header on the surface of the lead-acid battery for measurement.
  • Page 41 06 Electrical Connection User Manual V1.1-2023-06-20 Connecting the Li-ion Battery BMS Communication and Meter Communication Cables NOTICE • The communication cables between BMS and the battery, and between Meter and the inverter are delivered with the inverter, with default length of 3m and 10m separately. Please install the Meter and CT according to the actual situations.
  • Page 42 06 Electrical Connection User Manual V1.1-2023-06-20 NOTICE Power Limit functionality can be realized when the inverter is installed with the Meter. Testing to AS/NZS 4777.2:2020 for multiple phase combinations has not been conducted. The specific networking schemes are: Power Limit networking scheme (Single phase scenario) When the load connected is single-phase and no PV inverter is used under the self consumption mode, the Power Limit can be realized by connecting inverters with GM1000.
  • Page 43 06 Electrical Connection User Manual V1.1-2023-06-20 Power Limit networking scheme (Split phase scenario) When the load connected is split phase, the Power Limit can be realized by connecting inverters with GM3000. Connect the cables by following below requirements. Otherwise, it may cause Power Limit function failed.

  • Page 44: Installing The Com Module

    06 Electrical Connection User Manual V1.1-2023-06-20 6.7.3 Installing the COM module NOTICE • It supports setting the inverter; connecting to the server for monitoring the inverter and power plant operations etc. via WiFi Kit, Wi-Fi/LAN Kit and 4G module. • Refer to the delivered communication module user manual to get more introduction to the module.

  • Page 45: Equipment Commissioning

    07 Equipment Commissioning User Manual V1.1-2023-06-20 7 Equipment Commissioning 7.1 Check Before Power ON Checking Item The product is firmly installed at a clean place that is well-ventilated and easy-to operate. The PE, DC input, AC output, and communication cables are connected correctly and securely.

  • Page 46: System Commissioning

    08 System Commissioning User Manual V1.1-2023-06-20 8 System Commissioning 8.1 Indicators and Buttons Indicator Status Description The inverter is power on and in the standby mode. The inverter is starting up and in the self-check mode. The inverter is in normal operation under grid-tied or off-grid modes.

  • Page 47: Setting Inverter Parameters Via Storagemate App

    08 System Commissioning User Manual V1.1-2023-06-20 8.2 Setting Inverter Parameters via StorageMate App NOTICE Please set the inverter parameters first via StorageMate App to ensure its normal operation. StorageMate App is one smart phone application used to communicate with the inverter via bluetooth, WiFi, 4G or GPRS modules.

  • Page 48: Maintenance

    09 Maintenance User Manual V1.1-2023-06-20 9 Maintenance 9.1 Power Off the Inverter DANGER • Power off the inverter before operations and maintenance. Otherwise, the inverter may be damaged or electric shocks may occur. • Delayed discharge. Wait until the components are discharged after power off. Step 1: Turn off the AC breaker on the ON-GRID side of the inverter.

  • Page 49: Troubleshooting

    09 Maintenance User Manual V1.1-2023-06-20 9.4 Troubleshooting Perform troubleshooting according to the following methods. Contact the after-sales service if these methods do not work. Collect the information below before contacting the after-sales service, so that the problems can be solved quickly. •...
  • Page 50 09 Maintenance User Manual V1.1-2023-06-20 Fault Cause Solutions 1. If the problem occurs occasionally, the utility grid may be abnormal temporarily. The inverter will recover automatically after detecting that the utility grid is normal. 2. If the problem occurs frequently, check whether the grid voltage is within the The grid voltage is permissible range.
  • Page 51 09 Maintenance User Manual V1.1-2023-06-20 Fault Cause Solutions 1. If the problem occurs occasionally, the utility grid may be abnormal temporarily. The inverter will recover automatically after detecting that the utility grid is normal. 2. If the problem occurs frequently, check The moving whether the grid voltage is within the average of grid...
  • Page 52 09 Maintenance User Manual V1.1-2023-06-20 Fault Cause Solutions 1. If the problem occurs occasionally, the utility grid may be abnormal temporarily. The inverter will recover automatically after detecting that the utility grid is normal. 2. If the problem occurs frequently, check Utility grid whether the grid frequency is within the exception.
  • Page 53 09 Maintenance User Manual V1.1-2023-06-20 Fault Cause Solutions The utility grid is disconnected. The utility grid is disconnected 1. Check whether the utility grid is according Anti-islanding disconnected. to the safety 2. Contact the dealer or the after-sales service. regulations, but the grid voltage is maintained due to the loads.
  • Page 54 09 Maintenance User Manual V1.1-2023-06-20 Fault Cause Solutions Large DC of AC 1. If the problem is caused by an external fault The DC current L1 like a utility grid exception or frequency component of the exception, the inverter will recover output current automatically after solving the problem.
  • Page 55 09 Maintenance User Manual V1.1-2023-06-20 Fault Cause Solutions 1. If the exception is caused by an external Anti Reverse fault, the inverter will recover automatically current Abnormal after solving the problem. protection for fluctuation of load 2. If the problem occurs frequently and the PV hardwares station cannot work properly, contact the dealer or the after-sales service.
  • Page 56 09 Maintenance User Manual V1.1-2023-06-20 Fault Cause Solutions Disconnect the AC output switch and DC input The internal switch, then connect them 5 minutes later. Flash Fault Flash storage is Contact the dealer or the after-sales service if abnormal. the problem persists. 1.
  • Page 57 09 Maintenance User Manual V1.1-2023-06-20 Fault Cause Solutions 1. The PV Disconnect the AC output switch and DC input PV Continuous configuration is switch, then connect them 5 minutes later. Hardware not proper. Contact the dealer or the after-sales service if Overcurrent 2.

  • Page 58: Routine Maintenance

    09 Maintenance User Manual V1.1-2023-06-20 9.5 Routine Maintenance WARNING • Make sure that the inverter is powered off. • Wear proper PPE before any operations. Maintaining Item Maintaining Method Maintaining Period Check the heat sink, air intake, and air outlet System Clean Once 6-12 months for foreign matter or dust.

  • Page 59: Technical Parameters

    10 Technical Parameters User Manual V1.1-2023-06-20 10 Technical Parameters Technical Data GEH3.0- GEH3.6- GEH3.6M- GEH5.0- GEH5.0M- GEH6.0- GEH6.0M- 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 Battery Input Data Battery Type Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion Nominal Battery Voltage (V) Battery Voltage Range 40~60...
  • Page 60 10 Technical Parameters User Manual V1.1-2023-06-20 Technical Data GEH3.0- GEH3.6- GEH3.6M- GEH5.0- GEH5.0M- GEH6.0- GEH6.0M- 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 Start-up Voltage (V) Nominal Input Voltage (V) Max. Input Current per MPPT (A) Max. Short Circuit Current MPPT (A) Max.
  • Page 61 10 Technical Parameters User Manual V1.1-2023-06-20 Technical Data GEH3.0- GEH3.6- GEH3.6M- GEH5.0- GEH5.0M- GEH6.0- GEH6.0M- 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 Max. Apparent Power from 6,000 7,360 3,680 10,000 5,000 10,000 6,000 Utility Grid (VA) Nominal Output 220 / 230 / 240 Voltage (V) Output Voltage Range...
  • Page 62 10 Technical Parameters User Manual V1.1-2023-06-20 Technical Data GEH3.0- GEH3.6- GEH3.6M- GEH5.0- GEH5.0M- GEH6.0- GEH6.0M- 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 Max. Total Harmonic <3% <3% <3% <3% <3% <3% <3% Distortion Maximum Output Overcurrent Protection (A) Type of Voltage (a.c.
  • Page 63 10 Technical Parameters User Manual V1.1-2023-06-20 Technical Data GEH3.0- GEH3.6- GEH3.6M- GEH5.0- GEH5.0M- GEH6.0- GEH6.0M- 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 Maximum Output Overcurrent Protection (A) Nominal 220 / 220 / 220 / 220 / 220 / 230 220 / 230 220 / 230 / Output 230 /...
  • Page 64 10 Technical Parameters User Manual V1.1-2023-06-20 Technical Data GEH3.0- GEH3.6- GEH3.6M- GEH5.0- GEH5.0M- GEH6.0- GEH6.0M- 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 PV Reverse Polarity Integrated Protection Anti-islanding Integrated Protection Overcurrent Integrated Protection AC Short Circuit Integrated Protection Overvoltage Integrated Protection DC Switch Integrated...
  • Page 65 10 Technical Parameters User Manual V1.1-2023-06-20 Technical Data GEH3.0- GEH3.6- GEH3.6M- GEH5.0- GEH5.0M- GEH6.0- GEH6.0M- 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 Communication with BMS Communication RS485 with Meter Communication WiFi / WiFi + LAN / 4G with Portal Weight (kg) 19.6 20.8 20.0...
  • Page 66 10 Technical Parameters User Manual V1.1-2023-06-20 Technical Data GEH3.0- GEH3.6- GEH3.6M- GEH5.0- GEH5.0M- GEH6.0- GEH6.0M- 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 1LU-20 Mounting Wall Mounted Method Active Anti- islanding SMS (Slip-mode frequency) +AFD Method Type of Electrical single phase Supply System Country of China...
  • Page 67 10 Technical Parameters User Manual V1.1-2023-06-20 Technical Data GEH6.0-1LU-BR20 Battery Input Data Battery Type Li-Ion/Lead-acid Nominal Battery Voltage (V) Battery Voltage Range (V) 40~60 Start-up Voltage (V) Number of Battery Inp Max. Continuous Charging Current (A) Max. Continuous Discharging Current (A) Max.
  • Page 68 10 Technical Parameters User Manual V1.1-2023-06-20 Technical Data GEH6.0-1LU-BR20 Nominal Apparent Power from 6,000 Utility Grid (VA) Max. Apparent Power from 10,000 Utility Grid (VA) Nominal Output Voltage (V) Output Voltage Range (V) 165~280 Nominal AC Grid Frequency (Hz) AC Grid Frequency Range (Hz) 45~55 / 55~65 Max.
  • Page 69 10 Technical Parameters User Manual V1.1-2023-06-20 Technical Data GEH6.0-1LU-BR20 Nominal Output Voltage (V) Nominal Output Frequency (Hz) Output THDv (@Linear Load) <3% Switching from Grid Connected Mode to <10m Standalone Mode Switching from standalone mode to network <10m connected mode Efficiency Max.
  • Page 70 10 Technical Parameters User Manual V1.1-2023-06-20 Technical Data GEH6.0-1LU-BR20 Communication with Portal WiFi / WiFi +LAN / 4G Weight (kg) 21.5 Dimension (W×H×D mm) 505.9×434.9×154.8 Noise Emission (dB) <30 Topology Non-isolated Self-consumption at Night (W) <10 Ingress Protection Rating IP65 DC Connector MC4, VACONN Terminal AC Connector...
  • Page 71 Global Sales & Service Network * GE is a registered trademark of General Electric Company and is used under license by GoodWe Technologies Co., Ltd. © 2023 All Rights Reserved www.gesolarinverter.com sales@gesolarinverter.com; support1@gesolarinveter.com Local Contacts...
