Euhomy IM-F Instruction Manual

Hide thumbs Also See for IM-F:

Advertisement

Quick Links

Ice Maker
Instruction Manual
SKU：IM-F
Email：support@euhomy.com
Facebook：@Euhomy.Official

Advertisement

loading

Related Manuals for Euhomy IM-F

Summary of Contents for Euhomy IM-F

  • Page 1 Ice Maker Instruction Manual SKU：IM-F Email：support@euhomy.com Facebook：@Euhomy.Official...
  • Page 3 Email: support@euhomy.com Facebook: @Euhomy.Official The Euhomy team is available 24/7 to address your questions, comments, and concerns. Your satisfaction is our ultimate goal. We want to make everything right so you'll share your positive experience with other shoppers on Amazon.
  • Page 4 It may be that the PUA tube inside the machine fell off during transportation. You can remove the back cover of the machine and connect it by yourself. If you don't know how to operate, please contact the Euhomy team. We will give you a professional video to help you solve the problem.

  • Page 5: Table Of Contents

    Contents Safety Precautions 02-03 Operation & Installation 04-07 Tips & Maintenance Specifications Warranty Troubleshooting (support@euhomy.com)

  • Page 6: Safety Precautions

    Safety Precautions IMPORTANT SAFETY TIPS When using electrical appliances, basic safety precautions should be followed to reduce the risk of fire, electric shock, and injury to persons or property. Read all instructions before using any appliance： Do not operate this or any other appliance with a damaged cord. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or a similarly qualified person to prevent hazards.
  • Page 7 Safety Precautions Note: The wires in this electrical cord are color-coded as follows: Green or green with stripe COLOR WIRING Yellow Grounding White Neutral Black Live To prevent a hazard resulting from instability of the appliance, it must be placed on a flat, level surface.

  • Page 8: Operation & Installation

    Operation & Installation ASSEMBLY AND PARTS 1.Water tank cover 2.Unit top cover 3.Water separator pipe 4.Evaporator 5. Ice basket 6. Ice scoop 7.Window 8.Control panel A.Timer button B.Power button C.LCD display . Ambient temperature <M> and ice-making countdown <°F> indicators. .
  • Page 9 Operation & Installation UNPACKING YOUR ICE MAKER Remove the exterior and interior packaging. Check that the ice basket and ice scoop are included. If any parts are missing, please contact Customer Service. Clean the interior with a soft cloth dampened with plain lukewarm water. Take out the ice basket and scoop, and wash them in warm, soapy water.
  • Page 10 Operation & Installation OPERATION PANEL AND DISPLAY AREA DISPLAY AREA OPERATION AREA Remove the water tank cover and pour potable water into tank. Be sure to keep the water level below the max level. See the FULL mark in the following picture. Re-place the cover at once to prevent foreign matter from entering the tank.
  • Page 11 Operation & Installation Note: The ice-making cycle lasts about 13 to 25 minutes, depending on the ambient temperature. Depend- ing on the initial water temperature, the first ice-making cycle may take a little longer. In an extreme- ly hot environment, the ice-making cycle may vary but it will not exceed 35 minutes. If the ice cubes are not thick or large enough, during ice-making, press the <+>...

  • Page 12: Tips & Maintenance

    Tips & Maintenance CLEANING AND MAINTAINING YOUR ICE MAKER Before using your ice maker, it is strongly recommended to clean it thoroughly. Take out the ice basket. Clean the interior with diluted detergent, warm water, and a soft cloth. Rinse the interior with clean water. Drain out the water through the drainage port by removing the drain cap on the back and taking out the silicone plug.

  • Page 13: Specifications

    Specifications TECHNICAL PARAMETERS IM-F Protection Type Power 115V/60Hz Ice-Making Current 1.6A Ice-Harvest Current 2.6A Refrigerant R600a 1.13oz/32g Design Pressure High Side 260Psig Low Side 88Psig Net Weight 11kg Enclosure Stainless steel CIRCUIT DIAGRAM ELECTRICAL DIAGRAM Solenoid Valve magnetic control FOR ICE-MAKER...

  • Page 14: Warranty

    Warranty Euhomy offers a limited 1-year warranty (“ warranty period" ) on all of our products purchased new and unused from Euhomy company, with an original proof of purchase and where a defect has arisen, wholly or substantially, as a result of faulty manufacture, parts or workmanship during the warranty period.

  • Page 15: Troubleshooting-Support@Euhomy.com

    Troubleshooting-support@euhomy.com Problem Possible Cause Solution Turn off the unit. Add water to the < > is displayed Lack of water <FULL> mark. Restart the unit. < > code is Too much ice in the basket Remove ice cubes from the basket.
  • Page 16 Email：support@euhomy.com Facebook：@Euhomy.Official...
