OWNER'S MANUAL
YZF-R6X
13S-28199-20

Advertisement

Table of Contents
loading

Related Manuals for Yamaha 2008 YZF-R6X

Summary of Contents for Yamaha 2008 YZF-R6X

  • Page 1 OWNER’S MANUAL YZF-R6X 13S-28199-20...
  • Page 3 Welcome to the Yamaha world of motorcycling! As the owner of the YZF-R6X, you are benefiting from Yamaha’s vast experience and newest technology regarding the de- sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle is subsequently sold. Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your motorcycle and this manual.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10200 YZF-R6X OWNER’S MANUAL ©2007 by Yamaha Motor Co., Ltd. 1st edition, September 2007 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ....1-1 PRE-OPERATION CHECKS ..... 4-1 Adjusting the clutch lever free Location of important labels ....1-5 Pre-operation check list ....4-2 play ........... 6-23 Adjusting the rear brake light DESCRIPTION ........2-1 OPERATION AND IMPORTANT switch ........6-24 Left view ..........2-1 RIDING POINTS.........
  • Page 7 TABLE OF CONTENTS Replacing a turn signal light bulb ...........6-37 Replacing the license plate light bulb ...........6-38 Auxiliary light ........6-38 Supporting the motorcycle ....6-39 Front wheel ........6-39 Rear wheel ........6-41 Troubleshooting ......6-43 Troubleshooting charts ....6-44 MOTORCYCLE CARE AND STORAGE ..........7-1 Matte color caution ......7-1 Care ..........7-1 Storage ...........7-4...

  • Page 8: Safety Information

    SAFETY INFORMATION EAU10281 AND/OR WHEN MADE NECES- • Ride where other motorists can SARY BY MECHANICAL CONDI- see you. Avoid riding in another MOTORCYCLES SINGLE TIONS. motorist’s blind spot. TRACK VEHICLES. THEIR SAFE USE Many accidents involve inexperi- AND OPERATION ARE DEPENDENT Safe riding enced operators.
  • Page 9 Modifications made to this motorcycle other motorists can see you. the single most critical factor in the pre- not approved by Yamaha, or the re- The posture of the operator and vention or reduction of head injuries. moval of original equipment, may ren- passenger is important for proper Always wear an approved helmet.
  • Page 10 Maximum load: been specifically designed for use on create instability due to improper 190 kg (419 lb) this motorcycle. Since Yamaha cannot weight distribution or aerody- test all other accessories that may be namic changes. If accessories When loading within this weight limit,...
  • Page 11 SAFETY INFORMATION tor and may limit control ability, Always turn the engine off before or clothing, immediately wash the therefore, such accessories are leaving the motorcycle unattended affected area with soap and water not recommended. and remove the key from the main and change your clothes.

  • Page 12: Location Of Important Labels

    SAFETY INFORMATION EAU10381 Location of important labels Please read the following important labels carefully before operating this vehicle.
  • Page 13 SAFETY INFORMATION...

  • Page 14: Description

    DESCRIPTION EAU10410 Left view 1. Fuse box 2 (page 6-34) 8. Shock absorber assembly rebound damping force adjusting screw (page 3-23) 2. Front fork spring preload adjusting bolt (page 3-21) 9. Shift pedal (page 3-15) 3. Front fork rebound damping force adjusting screw (page 3-21) 10.Engine oil filter cartridge (page 6-12) 4.

  • Page 15: Right View

    DESCRIPTION EAU10420 Right view 1. Luggage strap holder (page 3-25) 9. Radiator cap (page 6-15) 2. Helmet holder (page 3-20) 10.Coolant reservoir (page 6-15) 3. Fuse box 1 (page 6-34) 11.Engine oil filler cap (page 6-12) 4. Main fuse (page 6-34) 12.Coolant drain bolt (page 6-16) 5.

  • Page 16: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 3-15) 2. Left handlebar switches (page 3-13) 3. Main switch/steering lock (page 3-2) 4. Multi-function meter unit (page 3-7) 5. Right handlebar switches (page 3-13) 6. Brake lever (page 3-15) 7. Throttle grip (page 6-19)

  • Page 17: Instrument And Control Functions

    Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red Do not place any key close to bow for driving.

  • Page 18: Main Switch/Steering Lock

    INSTRUMENT AND CONTROL FUNCTIONS Keep other immobilizer system EAU10471 EAU38530 Main switch/steering lock keys away from the main switch All electrical circuits are supplied with as they may cause signal inter- power; the meter lighting, taillight, li- ference. cense plate light and auxiliary light come on, and the engine can be start- ed.
  • Page 19 INSTRUMENT AND CONTROL FUNCTIONS To lock the steering To unlock the steering EAU34341 (Parking) The steering is locked, and the taillight, license plate light and auxiliary light are on. The hazard lights and turn signal lights can be turned on, but all other electrical systems are off.

  • Page 20: Indicator And Warning Lights

    “ ” warning light may flicker when have a Yamaha dealer check the elec- The corresponding indicator light flash- riding on a slope or during sudden trical circuit. es when the turn signal switch is acceleration or deceleration, but pushed to the left or right.
  • Page 21 The electrical circuit of the warning light can be checked by turning the key to “ON”. If the warning light does not come on for a few seconds, then go off, have a Yamaha dealer check the electrical cir- cuit.
  • Page 22 INSTRUMENT AND CONTROL FUNCTIONS Coolant Display Conditions What to do temperature TRIP A Under 39 °C ˚C Message “Lo” is displayed. OK. Go ahead with riding. (Under 103 °F) TRIP A 40–116 °C ˚C Temperature is displayed. OK. Go ahead with riding. (104–242 °F) Stop the vehicle and allow it to idle until TRIP A...

  • Page 23: Multi-Function Meter Unit

    “ON”. If the warning light does not come for a few seconds, then go off, have a on for a few seconds, then go off, have Yamaha dealer check the electrical cir- 1. Clock a Yamaha dealer check the electrical cuit.
  • Page 24 INSTRUMENT AND CONTROL FUNCTIONS a speedometer (which shows the Tachometer Clock riding speed) a tachometer (which shows engine speed) an odometer (which shows the to- km/h TRIP A tal distance traveled) two tripmeters (which show the distance traveled since they were last set to zero) a fuel reserve tripmeter (which shows the distance traveled since...
  • Page 25 INSTRUMENT AND CONTROL FUNCTIONS Odometer, tripmeter, and stopwatch between the various tripmeter, odome- 3. Push the “SELECT” button again modes ter, and stopwatch modes in the follow- to reset the stopwatch. ing order: F-TRIP → Stopwatch → TRIP A → Split-time measurement TRIP B →...
  • Page 26 INSTRUMENT AND CONTROL FUNCTIONS Coolant temperature display Air intake temperature display When the air intake temperature display is selected, “A” is displayed before the temperature. Self-diagnosis device TRIP A TRIP A ˚C ˚C 1. Coolant temperature display 1. Air intake temperature display The coolant temperature display indi- The air intake temperature display indi- cates the temperature of the coolant.
  • Page 27 If the right display indicates any error ror code. codes, note the code number, and then km/h have a Yamaha dealer check the vehi- NOTE: cle. If the right display indicates error code ECA11590...
  • Page 28 INSTRUMENT AND CONTROL FUNCTIONS Shift timing indicator light activity: To adjust the brightness of the multi- The indicator light will flash This function allows you to choose function meter displays and tachometer when activated. (This setting whether or not the indicator light 1.

  • Page 29: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS 1. Push the “RESET” button to select 1. Push the “RESET” button to select EAU12347 Handlebar switches the desired engine speed for acti- the desired engine speed for deac- vating the indicator light. tivating the indicator light. Left 2.
  • Page 30 INSTRUMENT AND CONTROL FUNCTIONS Right position. To cancel the turn signal EAU12733 Hazard switch “ ” lights, push the switch in after it has re- With the key in the “ON” or “ ” posi- turned to the center position. tion, use this switch to turn on the haz- ard lights (simultaneous flashing of all EAU12500...

  • Page 31: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU12820 EAU12870 EAU33851 Clutch lever Shift pedal Brake lever 1. Clutch lever 1. Shift pedal 1. Brake lever 2. “ ” mark The clutch lever is located at the left The shift pedal is located on the left 3.

  • Page 32: Brake Pedal

    INSTRUMENT AND CONTROL FUNCTIONS be sure to set it by aligning a groove on EAU12941 EAU13072 Brake pedal Fuel tank cap the adjusting knob with the “ ” mark on the brake lever. 1. Brake pedal 1. Fuel tank cap lock cover 2.

  • Page 33: Fuel

    Avoid spilling fuel on the hot en- as well as to the exhaust system. gine. Your Yamaha engine has been de- signed to use premium unleaded gaso- line with a research octane number of 95 or higher. If knocking (or pinging) oc-...

  • Page 34: Catalytic Converters

    INSTRUMENT AND CONTROL FUNCTIONS curs, use a gasoline of a different EAU13442 EAU39032 Catalytic converters Seats brand. Use of unleaded fuel will extend This vehicle is equipped with catalytic spark plug life and reduce maintenance converters in the exhaust system. Rider seat costs.
  • Page 35 INSTRUMENT AND CONTROL FUNCTIONS 1. Projection 1. Passenger seat lock 1. Projection 2. Seat holder 2. Unlock. 2. Seat holder 2. While holding the key in that posi- 2. Remove the key. Passenger seat tion, lift the front of the passenger NOTE: seat and pull it forward.

  • Page 36: Helmet Holding Cable

    INSTRUMENT AND CONTROL FUNCTIONS EAU39072 3. Pass one of the other snap hooks EWA14330 Helmet holding cable WARNING of the cable through the helmet strap buckle, and then clip the Never ride with a helmet attached to snap hook onto the cable holder as a helmet holding cable, since the shown.

  • Page 37: Adjusting The Front Fork

    INSTRUMENT AND CONTROL FUNCTIONS EAU38942 To increase the spring preload and Spring preload setting: Adjusting the front fork thereby harden the suspension, turn Minimum (soft): This front fork is equipped with spring the adjusting bolt on each fork leg in di- preload adjusting bolts, rebound damp- Standard: rection (a).
  • Page 38 INSTRUMENT AND CONTROL FUNCTIONS crease the compression damping force To increase the compression damping Rebound damping setting: and thereby soften the compression force and thereby harden the compres- Minimum (soft): damping, turn the adjusting bolt on sion damping, turn the adjusting bolt on 25 click(s) in direction (b)* Standard: each fork leg in direction (b).

  • Page 39: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS production, the actual number of clicks EAU42940 Spring preload Adjusting the shock absorber always represents the entire adjusting assembly range. To obtain a precise adjustment, This shock absorber assembly is it would be advisable to check the num- equipped with a spring preload adjust- ber of clicks of each damping force ad- ing ring, a rebound damping force ad-...
  • Page 40 INSTRUMENT AND CONTROL FUNCTIONS direction (a). To decrease the compres- Spring preload setting: Rebound damping setting: sion damping force and thereby soften Minimum (soft): Minimum (soft): the compression damping, turn the ad- 20 click(s) in direction (b)* Standard: Standard: justing bolt in direction (b). 16 click(s) in direction (b)* Maximum (hard): Maximum (hard):...

  • Page 41: Luggage Strap Holders

    Always have a Yamaha dealer entire adjustment range. To obtain a service the shock absorber. precise adjustment, it would be advis-...

  • Page 42: Exup System

    EAU15301 EXUP system Sidestand passenger seat, unhook the straps This model is equipped with Yamaha’s The sidestand is located on the left side from the hooks, and then install the EXUP (EXhaust Ultimate Power valve) of the frame. Raise the sidestand or seat with the straps hanging out from system.

  • Page 43: Ignition Circuit Cut-Off System

    INSTRUMENT AND CONTROL FUNCTIONS below and have a Yamaha dealer re- EAU44890 Ignition circuit cut-off system pair it if it does not function proper- The ignition circuit cut-off system (com- prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions.
  • Page 44 5. Push the start switch. Does the engine start? The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 6. Move the sidestand up. 7. Keep the clutch lever pulled.

  • Page 45: Pre-Operation Checks

    PRE-OPERATION CHECKS EAU15593 The condition of a vehicle is the owner’s responsibility. Vital components can start to deteriorate quickly and unexpectedly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leakage or loss of tire air pressure could have serious consequences.

  • Page 46: Pre-Operation Check List

    • If necessary, add recommended coolant to specified level. 6-15 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 47 • Make sure that operation is smooth. • Check cable free play. Throttle grip 6-19, 6-29 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-28 •...

  • Page 48: Operation And Important Riding Points

    3-27. should be on, otherwise have a short time. Always make sure Never ride with the sidestand Yamaha dealer check the electrical cir- that there is adequate ventila- down. cuit. tion. 1. Turn the key to “ON” and make 3.

  • Page 49: Shifting

    OPERATION AND IMPORTANT RIDING POINTS serve the battery. Do not crank the en- EAU16671 ECA10260 Shifting CAUTION: gine more than 10 seconds on any one attempt. Even with the transmission in the neutral position, do not ECA11130 coast for long periods of time CAUTION: with the engine off, and do not For maximum engine life, always...

  • Page 50: Tips For Reducing Fuel Consumption

    If any engine trouble should oc- result in engine overheating must be lights or at railroad crossings). cur during the engine break-in avoided. period, immediately have a Yamaha dealer check the vehi- EAU17081 cle. 0–1000 km (0–600 mi) Avoid prolonged operation above 8300 NOTE: r/min.

  • Page 51: Parking

    OPERATION AND IMPORTANT RIDING POINTS EAU17212 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10310 WARNING Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them.

  • Page 52: Owner's Tool Kit

    If you are not familiar with mainte- certain maintenance work correctly. nance work, have a Yamaha dealer do it for you. NOTE: If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 53: Periodic Maintenance And Lubrication Chart

    From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi). Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
  • Page 54 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ √ √ √ √ • Check for cracks or damage. 8 * Brake hoses •...
  • Page 55 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Brake pedal pivot • Lubricate with lithium-soap-based √...
  • Page 56 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Front and rear brake √ √ √...
  • Page 57 PERIODIC MAINTENANCE AND MINOR REPAIR • Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid. • Replace the brake hoses every four years and if cracked or damaged.

  • Page 58: Removing And Installing Cowlings And Panels

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU18712 EAU44931 Removing and installing cowl- Cowlings A and B ings and panels To remove one of the cowlings The cowlings and panels shown need 1. Remove the bolts, quick fasteners, to be removed to perform some of the and quick fastener screw.
  • Page 59 PERIODIC MAINTENANCE AND MINOR REPAIR 1. Quick fastener screw 1. Quick fastener 1. Cowling A 2. Quick fastener 2. Cowling B 3. Remove the forward-most projec- tion from the slot, slide the cowling forward, and then remove the re- maining projections from the slots as shown.
  • Page 60 PERIODIC MAINTENANCE AND MINOR REPAIR 2. Fit the projections into the slots, 3. Fit the projection on cowling A into slide the cowling rearward, and the hole in cowling B as shown. then fit the forward-most projection into the slot. 1.
  • Page 61 PERIODIC MAINTENANCE AND MINOR REPAIR To install the cowling 1. Fit the slot in cowling C over the projection on the front cowling. 1. Plastic fastener 1. Panel B 2. Projection 2. Bolt 3. Wire harness To install the panel 1.

  • Page 62: Checking The Spark Plugs

    Do not attempt to diagnose wipe off any grime from the spark plug such problems yourself. Instead, have threads. a Yamaha dealer check the vehicle. If a spark plug shows signs of electrode Tightening torque: Spark plug: erosion and excessive carbon or other 12.5 Nm (1.25 m·kgf, 9.0 ft·lbf)

  • Page 63: Engine Oil And Oil Filter Cartridge

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU38997 4. Remove the engine oil dipstick and Engine oil and oil filter car- wipe it clean, insert it back into the tridge hole (without screwing it in), and The engine oil level should be checked then remove it again to check the before each ride.
  • Page 64 NOTE: and drain bolt to drain the oil from An oil filter wrench is available at a the crankcase. Yamaha dealer. 9. Apply a thin coat of engine oil to the O-ring of the new oil filter car- tridge. 1. Bolt 2.
  • Page 65 PERIODIC MAINTENANCE AND MINOR REPAIR If the match marks are not aligned, Tightening torque: the shift arm will not move correctly Engine oil drain bolt: and you may not be able to shift up 43 Nm (4.3 m·kgf, 31 ft·lbf) or down.

  • Page 66: Coolant

    If the oil level warning light flickers EAU39085 or remains on, immediately turn the To check the coolant level engine off and have a Yamaha dealer 1. Place the vehicle on a level sur- check the vehicle. face and hold it in an upright posi- tion.
  • Page 67 PERIODIC MAINTENANCE AND MINOR REPAIR If water has been added to the coolant, have a Yamaha dealer check the antifreeze content of the coolant as soon as possible, otherwise the effectiveness of the coolant will be reduced. EWA10380 WARNING Never attempt to remove the radiator 1.
  • Page 68 PERIODIC MAINTENANCE AND MINOR REPAIR 3. Place a container under the engine to collect the used coolant. 4. Remove the radiator cap. EWA10380 WARNING Never attempt to remove the radiator cap when the engine is hot. 1. Coolant drain bolt 1.
  • Page 69 Tightening torque: CAUTION: the vehicle for coolant leakage. If Coolant drain bolt: coolant is leaking, have a Yamaha If coolant is not available, use 10 Nm (1.0 m·kgf, 7.2 ft·lbf) dealer check the cooling system. distilled water or soft tap water 13.

  • Page 70: Air Filter Element

    The engine idling speed must be maintenance and lubrication chart. checked as follows and, if necessary, Have a Yamaha dealer replace the air adjusted by a Yamaha dealer at the in- filter element. tervals specified in the periodic mainte- nance and lubrication chart.

  • Page 71: Valve Clearance

    250 kPa (36 psi) (2.50 kgf/cm²) Rear: from occurring, the valve clearance regarding the specified tires. 290 kPa (42 psi) (2.90 kgf/cm²) must be adjusted by a Yamaha dealer 90–190 kg (198–419 lb): at the intervals specified in the periodic Tire air pressure Front: maintenance and lubrication chart.
  • Page 72 LOAD YOUR VEHICLE. Make sure in it, or if the sidewall is cracked, con- that the total weight of the cargo, rid- tact a Yamaha dealer immediately and er, passenger, and accessories have the tire replaced. Tire information (cowling, saddlebags, etc.

  • Page 73: Cast Wheels

    Other tires may run fore each ride. If any damage is valve cores listed below to the danger of bursting at super found, have a Yamaha dealer re- avoid tire deflation during a high speeds. place the wheel. Do not attempt high-speed ride.

  • Page 74: Adjusting The Clutch Lever Free Play

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU33891 4. Tighten the locknut. Adjusting the clutch lever free NOTE: If the specified clutch lever free play play cannot be obtained as described above, proceed as follows. 1. Fully turn the adjusting bolt at the clutch lever in direction (a) to loos- en the clutch cable.

  • Page 75: Adjusting The Rear Brake Light Switch

    EAU22390 the point that a wear indicator almost Adjusting the rear brake light Checking the front and rear touches the brake disc, have a Yamaha switch brake pads dealer replace the brake pads as a set. The front and rear brake pads must be...

  • Page 76: Checking The Brake Fluid Level

    However, if the Use only the recommended quality brake fluid level goes down sud- 1. Minimum level mark brake fluid, otherwise the rubber denly, have a Yamaha dealer Rear brake seals may deteriorate, causing check the cause. leakage and poor braking perfor- mance.

  • Page 77: Changing The Brake Fluid

    EAU22730 EAU22760 Changing the brake fluid Drive chain slack Have a Yamaha dealer change the The drive chain slack should be brake fluid at the intervals specified in checked before each ride and adjusted the NOTE after the periodic mainte- if necessary.
  • Page 78 PERIODIC MAINTENANCE AND MINOR REPAIR proper wheel alignment. Use the end of Tightening torque: the swingarm as the reference point for Locknut: the alignment marks. 16 Nm (1.6 m·kgf, 11 ft·lbf) ECA10570 CAUTION: Improper drive chain slack will over- load the engine as well as other vital parts of the motorcycle and can lead to chain slippage or breakage.

  • Page 79: Cleaning And Lubricating The Drive Chain

    If a cable is damaged wet areas. Service the drive chain as or does not move smoothly, have a follows. Yamaha dealer check or replace it. ECA10581 CAUTION: Recommended lubricant: Engine oil...

  • Page 80: Checking And Lubricating The Throttle Grip And Cable

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU23111 EAU44271 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease throttle grip and cable brake and shift pedals The operation of the throttle grip should be checked before each ride. In addi- tion, the cable should be lubricated at the intervals specified in the periodic maintenance chart.

  • Page 81: Checking And Lubricating The Brake And Clutch Levers

    EWA10730 WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Recommended lubricant: The operation of the brake and clutch Lithium-soap-based grease levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.

  • Page 82: Lubricating The Swingarm Pivots

    The swingarm pivots must be lubricat- fork does not operate smoothly, damage and excessive oil leakage. ed at the intervals specified in the peri- have a Yamaha dealer check or re- odic maintenance and lubrication chart. pair it. To check the operation 1.

  • Page 83: Checking The Steering

    2. Hold the lower ends of the front fork legs and try to move them for- ward and backward. If any free play can be felt, have a Yamaha dealer check or repair the steering. 6-32...

  • Page 84: Battery

    Batteries produce explosive hy- drogen gas. Therefore, keep To charge the battery sparks, flames, cigarettes, etc., Have a Yamaha dealer charge the bat- away from the battery and pro- tery as soon as possible if it seems to vide sufficient ventilation when have discharged.

  • Page 85: Replacing The Fuses

    PERIODIC MAINTENANCE AND MINOR REPAIR sealed-type (MF) battery charg- EAU23704 Replacing the fuses er, have a Yamaha dealer The main fuse, the fuel injection system charge your battery. fuse, and fuse box 1 are located under the rider seat. (See page 3-18.) 1.

  • Page 86: Replacing A Headlight Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR 4. If the fuse immediately blows EAU39010 Specified fuses: Replacing a headlight bulb again, have a Yamaha dealer Main fuse: This model is equipped with quartz bulb check the electrical system. 50.0 A headlights. If a headlight bulb burns Fuel injection system fuse: out, replace it as follows.
  • Page 87 7. Have a Yamaha dealer adjust the ency of the glass, the luminosity headlight beam if necessary. of the bulb, and the bulb life will be adversely affected.

  • Page 88: Tail/Brake Light

    1. Remove the turn signal light lens If the tail/brake light does not come on, by removing the screw. have a Yamaha dealer check it. 1. Turn signal light bulb 3. Insert a new bulb into the socket, push it in, and then turn it clock- wise until it stops.

  • Page 89: Replacing The License Plate Light Bulb

    This model is equipped with an LED- type auxiliary light. 1. Screw If the auxiliary light does not come on, have a Yamaha dealer check it. 2. Remove the socket (together with the bulb) by pulling it out. 1. License plate light bulb 2.

  • Page 90: Supporting The Motorcycle

    EWA10820 wheel or performing other maintenance WARNING requiring the motorcycle to stand up- It is advisable to have a Yamaha right. Check that the motorcycle is in a dealer service the wheel. stable and level position before starting Securely support the motor- any maintenance.
  • Page 91 PERIODIC MAINTENANCE AND MINOR REPAIR 3. Remove the brake hose holder on NOTE: each side by removing the bolt and Make sure that there is enough space nut. between the brake pads before install- 4. Remove the brake caliper on each ing the brake calipers onto the brake side by removing the bolts.

  • Page 92: Rear Wheel

    12. While applying the front brake, EWA10820 push down hard on the handlebar WARNING several times to check for proper It is advisable to have a Yamaha fork operation. dealer service the wheel. Securely support the motor- cycle so that there is no danger 1.
  • Page 93 PERIODIC MAINTENANCE AND MINOR REPAIR 2. Lift the rear wheel off the ground ECA11070 NOTE: CAUTION: according to the procedure on If the drive chain is difficult to re- page 6-39. Do not apply the brake after the move, remove the wheel axle first, 3.

  • Page 94: Troubleshooting

    However, should your motorcycle 2. Install the drive chain onto the rear 2 Nm (0.2 m·kgf, 1.4 ft·lbf) require any repair, take it to a Yamaha sprocket. 7. Tighten the locknuts to their speci- dealer, whose skilled technicians have 3.

  • Page 95: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 96 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. NOTE: If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 97: Motorcycle Care And Storage

    Rust and corrosion can develop matte colored finished parts. Be Cleaning even if high-quality components are sure to consult a Yamaha dealer for ECA11141 advice on what products to use be- used. A rusty exhaust pipe may go un- CAUTION: fore cleaning the vehicle.
  • Page 98 MOTORCYCLE CARE AND STORAGE with mild detergent, alkaline pounds for plastic may leave NOTE: products and a soft brush may scratches on the windshield. Salt sprayed on roads in the winter may be used. Test the product on a small hid- remain well into spring.
  • Page 99 Note that the thermally induced discoloring of the portion of the ex- Make sure that there is no oil or Consult a Yamaha dealer for advice on haust pipe leading into the titanium what products to use. wax on the brakes or tires.

  • Page 100: Storage

    MOTORCYCLE CARE AND STORAGE EAU26180 3. Perform the following steps to pro- 4. Lubricate all control cables and the Storage tect the cylinders, piston rings, etc. pivoting points of all levers and from corrosion. pedals as well as of the side- Short-term a.

  • Page 101: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Fuel: Overall length: Type: Recommended fuel: 2040 mm (80.3 in) SAE 10W-30, SAE 10W-40, SAE 15W-40, Premium unleaded gasoline only Overall width: SAE 20W-40 or SAE 20W-50 Fuel tank capacity: 705 mm (27.8 in) 17.3 L (4.57 US gal) (3.81 Imp.gal) Overall height: Fuel reserve amount: -20 -10...
  • Page 102 SPECIFICATIONS Gear ratio: Loading: Front brake: 1st: Maximum load: Type: 31/12 (2.583) 190 kg (419 lb) Dual disc brake 2nd: (Total weight of rider, passenger, cargo and Operation: 32/16 (2.000) accessories) Right hand operation 3rd: Tire air pressure (measured on cold Recommended fluid: 30/18 (1.667) DOT 4...
  • Page 103 SPECIFICATIONS Battery: Coolant temperature warning light: Model: Engine trouble warning light: YTZ10S Voltage, capacity: Immobilizer system indicator light: 12 V, 8.6 Ah Headlight: Shift timing indicator light: Bulb type: Halogen bulb Bulb voltage, wattage × quantity: Fuses: Main fuse: Headlight: 12 V, 55.0 W ×...

  • Page 104: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.

  • Page 105: Motorcycle Noise Regulation (For Australia)

    This informa- b. The use of the vehicle after such tion will be needed when ordering device or element of design has spare parts from a Yamaha dealer. been removed or rendered inoper- ative by any person.
  • Page 106 INDEX Air filter element ........6-19 Front and rear brake pads, checking..6-24 Neutral indicator light ......3-4 Auxiliary light......... 6-38 Front fork, adjusting......3-21 Noise regulation (for Australia)....9-2 Front fork, checking ......6-31 Fuel............3-17 Battery........... 6-33 Oil level warning light ......3-4 Fuel consumption, tips for reducing..
  • Page 107 INDEX Throttle grip and cable, checking and lubricating ........... 6-29 Tires............6-20 Tool kit ............ 6-1 Troubleshooting........6-43 Troubleshooting charts ......6-44 Turn signal indicator lights ...... 3-4 Turn signal light bulb, replacing.... 6-37 Turn signal switch......... 3-14 Valve clearance ........6-20 Vehicle identification number....
  • Page 110 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2007.09-0.3×1 CR...
