Summary of Contents for Yamaha 2010 XVS1100Z

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL XVS1100Z XVS1100AZ 3B8-28199-24...
  • Page 2 EAU46090 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 Welcome to the Yamaha world of motorcycling! As the owner of the XVS1100Z/XVS1100AZ, you are benefiting from Yamaha’s vast experience and newest technology re- garding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4: Important Manual Information

    IMPORTANT MANUAL INFORMATION EAU10132 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10200 XVS1100Z/XVS1100AZ OWNER’S MANUAL ©2009 by Yamaha Motor Co., Ltd. 1st edition, June 2009 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.
  • Page 6: Table Of Contents

    TABLE OF CONTENTS LOCATION OF IMPORTANT Seats (XVS1100Z) ....... 4-13 Removing and installing LABELS ..........1-1 Seats (XVS1100AZ) ..... 4-14 the panel ........7-7 Helmet holder ....... 4-15 Checking the spark plugs ....7-7 SAFETY INFORMATION ....2-1 Storage compartment ....4-16 Engine oil ........
  • Page 7 TABLE OF CONTENTS Checking and lubricating Motorcycle noise regulation the brake and clutch levers ..7-24 (for Australia) ......10-2 Checking and lubricating the sidestand ......7-25 Lubricating the swingarm pivots ...7-25 Lubricating the rear suspension ...7-26 Checking the front fork ....7-26 Checking the steering ....7-27 Checking the wheel bearings ..7-27 Battery ..........7-27...
  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 LOCATION OF IMPORTANT LABELS 3 XVS1100Z Before you operate this vehicle, read the owner’s manual. Prima di usare il veicolo, leggete il manuale di istruzioni. Lire le manuel du propriétaire avant d’utiliser ce véhicule. Lesen Sie die Bedienungsanleitung bevor Sie dieses Fahrzeug fahren. Antes de conducir este vehículo, lea el Manual del Propietario.
  • Page 10 LOCATION OF IMPORTANT LABELS STATIONARY NOISE TEST INFORMATION TESTED 85.0 dB(A) 2875 r/min SILENCING SYSTEM : YAMAHA IDENTIFICATION : 5EL1 5EL-2118G-00...
  • Page 11: Safety Information

    SAFETY INFORMATION EAU10283 Safe Riding • Ride where other motorists can Perform the pre-operation checks each see you. Avoid riding in another time you use the vehicle to make sure it motorist’s blind spot. Be a Responsible Owner is in safe operating condition. Failure to Many accidents involve inexperi- As the vehicle’s owner, you are respon- inspect or maintain the vehicle properly...
  • Page 12 SAFETY INFORMATION due to excessive speed or under- This motorcycle is designed for on- A passenger should also observe cornering (insufficient lean angle road use only. It is not suitable for the above precautions. for the speed). off-road use. • Always obey the speed limit and Avoid Carbon Monoxide Poisoning never travel faster than warrant- Protective apparel...
  • Page 13 Yamaha accessories, which are avail- Shifting weights can create a sud- accessories to your motorcycle. Use able only from a Yamaha dealer, have den imbalance. Make sure that ac- extra care when riding a motorcycle been designed, tested, and approved cessories and cargo are securely that has added cargo or accessories.
  • Page 14 SAFETY INFORMATION modifications not specifically recom- clearance or cornering clearance, tor and may limit control ability, mended by Yamaha, even if sold and limit suspension travel, steering therefore, such accessories are installed by a Yamaha dealer. travel or control operation, or ob- not recommended.
  • Page 15: Description

    DESCRIPTION EAU32220 Left view XVS1100Z 1. Shift pedal (page 4-8) 8. Storage compartment (page 4-16) 2. Fuel cock (page 4-11) 9. Owner’s tool kit (page 7-1) 3. Headlight (page 7-30) 10.Fuse box (page 7-29) 4. Shock absorber assembly spring preload adjusting ring (page 4-17) 11.Engine oil level check window (page 7-9) 5.
  • Page 16 DESCRIPTION XVS1100AZ 1. Shift pedal (page 4-8) 10.Fuse box (page 7-29) 2. Fuel cock (page 4-11) 11.Engine oil level check window (page 7-9) 3. Headlight (page 7-30) 4. Shock absorber assembly spring preload adjusting ring (page 4-17) 5. Helmet holder (page 4-15) 6.
  • Page 17: Right View

    DESCRIPTION EAU32230 Right view XVS1100Z 1. Muffler 8. Rear brake light switch (page 7-21) 2. Battery (page 7-27) 9. Brake pedal (page 4-9) 3. Main fuse (page 7-29) 4. Fuel tank (page 4-10) 5. Front turn signal light (page 7-31) 6.
  • Page 18 DESCRIPTION XVS1100AZ 1. Muffler 2. Battery (page 7-27) 3. Main fuse (page 7-29) 4. Fuel tank (page 4-10) 5. Front turn signal light (page 7-31) 6. Main switch/steering lock (page 4-2) 7. Air filter element (page 7-12) 8. Rear brake light switch (page 7-21) 9.
  • Page 19: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 4-8) 2. Left handlebar switches (page 4-7) 3. Starter (choke) lever (page 4-12) 4. Speedometer unit (page 4-6) 5. Fuel tank cap (page 4-10) 6. Right handlebar switches (page 4-7) 7. Throttle grip (page 7-14) 8.
  • Page 20: Instrument And Control Functions

    Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red Do not place any key close to bow for driving.
  • Page 21: Main Switch/Steering Lock (Xvs1100Z)

    INSTRUMENT AND CONTROL FUNCTIONS Keep other immobilizer system EAU10460 EAU10471 Main switch/steering lock Main switch/steering lock keys away from the main switch (XVS1100Z) (XVS1100AZ) as they may cause signal inter- ference. The main switch/steering lock controls The main switch/steering lock controls the ignition and lighting systems, and is the ignition and lighting systems, and is used to lock the steering.
  • Page 22 INSTRUMENT AND CONTROL FUNCTIONS EAU10480 EWA10061 2. Push the key in from the “OFF” po- ON (XVS1100Z) WARNING sition, and then turn it to “LOCK” All electrical systems are supplied with Never turn the key to “OFF” or while still pushing it. power, and the headlight, meter lighting 3.
  • Page 23: Indicator And Warning Lights

    ” initially when the key is turned to “ON”, 5. Immobilizer system indicator light or if the warning light remains on, have (XVS1100AZ) a Yamaha dealer check the electrical 6. High beam indicator light “ ” circuit. EAU11020 Turn signal indicator light “...
  • Page 24 If this oc- do not keep more than one immobilizer circuit. curs, have a Yamaha dealer check the key on the same key ring! Immobilizer When the key is turned to “OFF” and 30 self-diagnosis system. (See page 4-6...
  • Page 25: Speedometer Unit

    If a problem is detected in any of those circuits, the engine trouble warning light will come on or flash. If this occurs, have a Yamaha dealer check the vehi- cle. ECA11170 NOTICE 1. “TRIP” button To prevent engine damage, be sure 2.
  • Page 26: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS EAU12348 Right (XVS1100AZ) position. To cancel the turn signal Handlebar switches lights, push the switch in after it has re- turned to the center position. Left EAU12500 Horn switch “ ” Press this switch to sound the horn. EAU12660 Engine stop switch “...
  • Page 27: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS The hazard lights are used in case of EAU12820 EAU12870 Clutch lever Shift pedal (XVS1100Z) an emergency or to warn other drivers when your vehicle is stopped where it might be a traffic hazard. ECA10061 NOTICE Do not use the hazard lights for an extended length of time with the en- gine not running, otherwise the bat-...
  • Page 28: Shift Pedal (Xvs1100Az)

    INSTRUMENT AND CONTROL FUNCTIONS EAU12880 EAU12890 EAU12941 Shift pedal (XVS1100AZ) Brake lever Brake pedal XVS1100Z 1. Shift pedal 1. Brake lever 2. Neutral position 1. Brake pedal The brake lever is located at the right The shift pedal is located on the left handlebar grip.
  • Page 29: Fuel Tank Cap

    INSTRUMENT AND CONTROL FUNCTIONS EAU13121 2. Turn the key counterclockwise to EAU13212 Fuel tank cap Fuel the original position, remove it, and Make sure there is sufficient gasoline in then close the lock cover. the tank. EWA10881 WARNING The fuel tank cap cannot be installed unless the key is in the lock.
  • Page 30: Fuel Cock

    EWA15151 WARNING With the fuel cock lever in this position, Your Yamaha engine has been de- fuel will not flow. Always turn the fuel Gasoline is poisonous and can signed to use regular unleaded gaso- cock lever to this position when the en- cause injury or death.
  • Page 31: Starter (Choke) Lever

    INSTRUMENT AND CONTROL FUNCTIONS This indicates reserve. With the fuel EAU13610 Starter (choke) lever “ ” cock lever in this position, the fuel re- serve is made available. Turn the fuel cock lever to this position if you run out of fuel while riding.
  • Page 32: Seats (Xvs1100Z)

    INSTRUMENT AND CONTROL FUNCTIONS EAU14213 Tightening torque: Seats (XVS1100Z) Passenger seat nut: 13 Nm (1.3 m·kgf, 9.4 ft·lbf) Passenger seat To remove the passenger seat Remove the nut and washer, and then pull the passenger seat up. 1. Bolt 2. Passenger seat holder To install the rider seat 1.
  • Page 33: Seats (Xvs1100Az)

    INSTRUMENT AND CONTROL FUNCTIONS 2. Install the passenger seat holder EAU14201 Tightening torque: Seats (XVS1100AZ) and bolts. Passenger seat nut: 3. Install the passenger seat. 13 Nm (1.3 m·kgf, 9.4 ft·lbf) Passenger seat Make sure that the seats are properly To remove the passenger seat secured before riding.
  • Page 34: Helmet Holder

    INSTRUMENT AND CONTROL FUNCTIONS 2. Install the passenger seat. EAU14282 Helmet holder XVS1100Z Make sure that the seats are properly secured before riding. 1. Bolt To install the rider seat 1. Helmet holder 1. Insert the projections on the front 2.
  • Page 35: Storage Compartment

    INSTRUMENT AND CONTROL FUNCTIONS To open the helmet holder, insert the EAU14481 Storage compartment key into the lock, and then turn the key The storage compartment is located on as shown. the left side of the vehicle. To lock the helmet holder, place it in the original position, and then remove the To open the storage compartment key.
  • Page 36: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS EAU14874 Adjusting the shock absorber assembly The shock absorber assembly is locat- ed under the rider seat and is equipped with a spring preload adjusting ring. ECA10101 NOTICE To avoid damaging the mechanism, do not attempt to turn beyond the 1.
  • Page 37 INSTRUMENT AND CONTROL FUNCTIONS XVS1100AZ XVS1100Z Spring preload setting: Minimum (soft): Standard: 3 (XVS1100Z) 4 (XVS1100AZ) Maximum (hard): 7 (XVS1100Z) 9 (XVS1100AZ) 6. Install the mudguard and ignitor unit panel by installing the quick 1. Quick fastener 1. Spring preload adjusting ring fasteners.
  • Page 38: Luggage Strap Holders

    Do not dispose of a damaged or vehicle upright. worn-out shock absorber as- sembly yourself. Take the shock absorber assembly to a Yamaha The built-in sidestand switch is part of dealer for any service. the ignition circuit cut-off system, which cuts the ignition in certain situations.
  • Page 39: Ignition Circuit Cut-Off System

    INSTRUMENT AND CONTROL FUNCTIONS below and have a Yamaha dealer re- EAU15314 Ignition circuit cut-off system pair it if it does not function proper- The ignition circuit cut-off system (com- prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions.
  • Page 40 INSTRUMENT AND CONTROL FUNCTIONS WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.
  • Page 41: For Your Safety - Pre-Operation Checks

    Final gear oil • Check vehicle for oil leakage. 7-10 • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check lever free play. • Adjust if necessary. Front brake • Check brake pads for wear.
  • Page 42 • Make sure that operation is smooth. • Check cable free play. Throttle grip 7-14, 7-23 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 7-23 •...
  • Page 43 FOR YOUR SAFETY – PRE-OPERATION CHECKS ITEM CHECKS PAGE • Check operation of ignition circuit cut-off system. Sidestand switch 4-19 • If system is not working correctly, have Yamaha dealer check vehicle.
  • Page 44: Operation And Important Riding Points

    (See page 6-2.) The (choke) turned off. neutral indicator light should come on. If not, ask a Yamaha dealer to check the electrical circuit. 4. Turn the starter (choke) on and completely close the throttle. (See page 4-12.)
  • Page 45: Starting A Warm Engine

    OPERATION AND IMPORTANT RIDING POINTS EAU16640 EAU16671 Shifting gears lets you control the Starting a warm engine Shifting amount of engine power available for Follow the same procedure as for start- starting off, accelerating, climbing hills, XVS1100Z ing a cold engine with the exception etc.
  • Page 46: Tips For Reducing Fuel Consumption

    OPERATION AND IMPORTANT RIDING POINTS and drive train, which are not EAU16800 EAU16841 Tips for reducing fuel con- Engine break-in designed withstand sumption There is never a more important period shock of forced shifting. in the life of your engine than the period Fuel consumption depends largely on between 0 and 1600 km (1000 mi).
  • Page 47: Parking

    If any engine trouble should occur ans or children are not likely to during the engine break-in period, touch them and be burned. immediately have a Yamaha dealer Do not park on a slope or on soft check the vehicle. ground, otherwise the vehicle may overturn, increasing the risk of a fuel leak and fire.
  • Page 48: Periodic Maintenance And Adjustment

    If you are not familiar with vehicle ser- If you do not have the tools or experi- vice, have a Yamaha dealer perform ence required for a particular job, have service. a Yamaha dealer perform it for you.
  • Page 49: Periodic Maintenance Chart For The Emission Control System

    From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi). Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
  • Page 50: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU1770C General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ √...
  • Page 51 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check bearing for looseness or √ √...
  • Page 52 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Shock absorber as- • Check operation and shock ab- √...
  • Page 53 PERIODIC MAINTENANCE AND ADJUSTMENT EAU18670 The air filter needs more frequent service if you are riding in unusually wet or dusty areas. Hydraulic brake service • Regularly check and, if necessary, correct the brake fluid level. • Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid.
  • Page 54: Removing And Installing The Panel

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18751 EAU19553 Removing and installing the Checking the spark plugs panel The spark plugs are important engine components, which are easy to check. The panel shown needs to be removed Since heat and deposits will cause any to perform some of the maintenance spark plug to slowly erode, the spark jobs described in this chapter.
  • Page 55: To Check/Install Spark Plugs

    3. Remove the spark plug as shown, diagnose such problems yourself. In- To install a spark plug with the spark plug wrench includ- stead, have a Yamaha dealer check 1. Clean the surface of the spark plug ed in the owner’s tool kit. the vehicle.
  • Page 56: Engine Oil

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU19824 Engine oil The engine oil level should be checked before each ride. In addition, the oil must be changed and the oil filter ele- ment replaced at the intervals specified in the periodic maintenance and lubri- cation chart.
  • Page 57: Final Gear Oil

    43 Nm (4.3 m·kgf, 31 ft·lbf) for oil leakage before each ride. If any mediately turn the engine off and leakage is found, have a Yamaha deal- 5. Refill with the specified amount of check for the cause. er check and repair the vehicle. In addi-...
  • Page 58 PERIODIC MAINTENANCE AND ADJUSTMENT 2. Remove the final gear oil filler bolt Tightening torque: Tightening torque: and its gasket, and then check the Final gear oil filler bolt: Final gear oil drain bolt: oil level in the final gear case. 23 Nm (2.3 m·kgf, 17 ft·lbf) 23 Nm (2.3 m·kgf, 17 ft·lbf) 4.
  • Page 59: Cleaning The Air Filter Element

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU20673 out with compressed air as shown. Cleaning the air filter element If the air filter element is damaged, The air filter element should be cleaned replace it. as follows at the intervals specified in the periodic maintenance and lubrica- tion chart.
  • Page 60: Adjusting The Carburetors

    Therefore, most carbu- checked and, if necessary, adjusted as retor adjustments should be left to a follows at the intervals specified in the Yamaha dealer, who has the neces- periodic maintenance and lubrication sary professional knowledge and expe- chart.
  • Page 61: Checking The Throttle Cable Free Play

    To prevent this cle, note the following points regarding from occurring, the valve clearance the specified tires. must be adjusted by a Yamaha dealer at the intervals specified in the periodic Tire air pressure maintenance and lubrication chart.
  • Page 62 It is not recommended to patch cause an accident. tact a Yamaha dealer immediately and a punctured tube. If unavoid- have the tire replaced. able, however, patch the tube...
  • Page 63: Tires (Xvs1100Az)

    The tire air pressure should be checked 225 kPa (2.25 kgf/cm², 33 psi) ed below have been approved for this and, if necessary, adjusted before each Rear: model by Yamaha Motor Co., Ltd. 250 kPa (2.50 kgf/cm², 36 psi) ride. Maximum load*: EWA10501...
  • Page 64 After extensive tests, only the tires list- Have a Yamaha dealer replace ed below have been approved for this excessively worn tires. Besides model by Yamaha Motor Co., Ltd. being illegal, operating the vehi- 1. Tire sidewall cle with excessively worn tires 2.
  • Page 65: Spoke Wheels (Xvs1100Z)

    If any To maximize the performance, durabil- damage is found, have a Yamaha ity, and safe operation of your motorcy- dealer replace the wheel. Do not cle, note the following points regarding attempt even the smallest repair to the specified wheels.
  • Page 66: Adjusting The Clutch Lever Free Play

    2. Valve stem locknut tained as described above or if the clutch does not operate correctly, have Tightening torques: 1. Clutch lever free play a Yamaha dealer check the internal Valve stem nut: 2. Locknut clutch mechanism. 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf) 3.
  • Page 67: Adjusting The Brake Lever Free Play

    If there is air in the hy- draulic system, have a Yamaha dealer bleed the system before operating the motorcycle. Air in the hydraulic system will dimin-...
  • Page 68: Brake Light Switches

    If a brake pad has worn to the point that the wear indicator groove has almost disappeared, have a Yamaha 1. Rear brake light switch 2. Rear brake light switch adjusting nut dealer replace the brake pads as a set.
  • Page 69: Checking The Brake Fluid Level

    However, if the Use only the recommended quality brake fluid level goes down sud- 1. Minimum level mark brake fluid, otherwise the rubber denly, have a Yamaha dealer Rear brake seals may deteriorate, causing check the cause. leakage and poor braking perfor- mance.
  • Page 70: Changing The Brake Fluid

    EAU23101 EAU23111 Changing the brake fluid Checking and lubricating the Checking and lubricating the Have a Yamaha dealer change the cables throttle grip and cable brake fluid at the intervals specified in The operation of all control cables and The operation of the throttle grip should...
  • Page 71: Checking And Lubricating The Brake And Shift Pedals

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU44272 EAU23142 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease brake and shift pedals brake and clutch levers Brake pedal Brake lever Shift pedal Clutch lever The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each...
  • Page 72: Checking And Lubricating The Sidestand

    EWA10731 WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Otherwise, the sidestand could contact the ground and distract the operator, re- sulting in a possible loss of control.
  • Page 73: Lubricating The Rear Suspension

    WARNING! To avoid injury, have a Yamaha dealer check or re- specified in the periodic maintenance securely support the vehicle so pair it.
  • Page 74: Checking The Steering

    If any free the wheel bearings. There is no need to check the electro- play can be felt, have a Yamaha lyte or to add distilled water. However, dealer check or repair the steering. the battery lead connections need to be checked and, if necessary, tightened.
  • Page 75 [ECA16302] burns. Avoid any contact with 2. If the battery will be stored for more Have a Yamaha dealer charge the bat- skin, eyes or clothing and al- than two months, check it at least tery as soon as possible if it seems to...
  • Page 76: Replacing The Fuses

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU46131 XVS1100AZ Replacing the fuses The main fuse is located under the igni- tor unit panel. The fuse box, which contains the fuses for the individual circuits, is located be- hind the storage compartment cover. (See page 4-16.) XVS1100Z 1.
  • Page 77: Replacing The Headlight Bulb

    6. Turn the key to “ON” and turn on Do not use a headlight bulb of a the electrical circuit in question to wattage higher than specified. check if the device operates. 7. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 7-30...
  • Page 78: Replacing A Turn Signal Light Bulb Or The Tail/Brake Light Bulb

    XVS1100Z 6. Install the headlight unit by install- ing the screws. 7. Have a Yamaha dealer adjust the headlight beam if necessary. 1. Screw 2. Disconnect the headlight coupler, and then remove the bulb cover.
  • Page 79: Replacing The Auxiliary Light Bulb (Xvs1100Az)

    PERIODIC MAINTENANCE AND ADJUSTMENT XVS1100AZ EAU33413 Replacing the auxiliary light bulb (XVS1100AZ) If the auxiliary light bulb burns out, re- place it as follows. 1. Remove the headlight unit by re- moving the screws. 1. Auxiliary light bulb socket 1. Screw 3.
  • Page 80: Supporting The Motorcycle

    However, should your motorcycle To service the front wheel require any repair, take it to a Yamaha 1. Stabilize the rear of the motorcycle dealer, whose skilled technicians have by using a motorcycle stand or, if...
  • Page 81 PERIODIC MAINTENANCE AND ADJUSTMENT heaters or furnaces. Gasoline or gasoline vapors can ignite or ex- plode, causing severe injury or property damage. 7-34...
  • Page 82: Troubleshooting Chart

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 83: Motorcycle Care And Storage

    Rust and corrosion can develop matte colored finished parts. Be ECA10772 even if high-quality components are sure to consult a Yamaha dealer for NOTICE advice on what products to use be- used. A rusty exhaust pipe may go un- Avoid using strong acidic wheel fore cleaning the vehicle.
  • Page 84 MOTORCYCLE CARE AND STORAGE off any detergent residue using Test the product on a small hid- plenty of water, as it is harmful den part of the windshield to Salt sprayed on roads in the winter may to plastic parts. make sure that it does not leave remain well into spring.
  • Page 85: Storage

    WARNING To prevent corrosion, avoid Contaminants on the brakes or tires Consult a Yamaha dealer for ad- damp cellars, stables (because can cause loss of control. vice on what products to use. of the presence of ammonia)
  • Page 86 MOTORCYCLE CARE AND STORAGE 3. Drain the carburetor float cham- spark plug electrodes while °C (90 °F)]. For more information bers by loosening the drain bolts; turning the engine over. on storing the battery, see page this will prevent fuel deposits from 7-27.
  • Page 87: Specifications

    SPECIFICATIONS Dimensions: Compression ratio: Quantity: 8.30 :1 0.19 L (0.20 US qt, 0.17 Imp.qt) Overall length: Starting system: Air filter: XVS1100AZ 2460 mm (96.9 in) Electric starter XVS1100Z 2405 mm (94.7 in) Air filter element: Lubrication system: Overall width: Dry element Wet sump XVS1100AZ 945 mm (37.2 in) Fuel:...
  • Page 88 SPECIFICATIONS Transmission type: Manufacturer/model: Rear: Constant mesh 5-speed XVS1100AZ BRIDGESTONE/EXEDRA XVS1100AZ 250 kPa (2.50 kgf/cm², 36 Operation: G703 psi) Left foot operation XVS1100Z BRIDGESTONE/EXEDRA XVS1100Z 225 kPa (2.25 kgf/cm², 33 Gear ratio: L309 psi) 1st: Rear tire: Loading condition: 40/17 (2.353) XVS1100AZ 90–203 kg (198–448 lb) Type: 2nd:...
  • Page 89 SPECIFICATIONS Bulb voltage, wattage × quantity: Rear brake: Parking lighting fuse: XVS1100AZ 10.0 A Type: Headlight: 12 V, 60 W/55 W × 1 Carburetor heater fuse: Single disc brake 15.0 A Operation: Tail/brake light: 12 V, 5.0 W/21.0 W × 1 Backup fuse: Right foot operation XVS1100AZ 10.0 A...
  • Page 90: Consumer Information

    Yamaha EAU26400 Vehicle identification number dealer or for reference in case the vehi- cle is stolen.
  • Page 91 The model label is affixed to the frame under the rider seat. (See page 4-13.) Record the information on this label in the space provided. This information will be needed when ordering spare parts from a Yamaha dealer. 10-2...
  • Page 92 INDEX Front fork, checking ......7-26 Fuel............4-10 Air filter element, cleaning..... 7-12 Neutral indicator light ......4-4 Fuel cock ..........4-11 Auxiliary light bulb, Noise regulation (for Australia)....10-2 Fuel consumption, tips for reducing..6-3 replacing (XVS1100AZ)...... 7-32 Fuel tank cap ........4-10 Oil level warning light ......
  • Page 93 INDEX Throttle cable free play, checking..7-14 Throttle grip and cable, checking and lubricating..... 7-23 Tires (XVS1100AZ) ......7-16 Tires (XVS1100Z) ......... 7-14 Tool kit ............ 7-1 Troubleshooting........7-33 Troubleshooting chart ......7-35 Turn signal indicator light......4-4 Turn signal light bulb or tail/brake light bulb, replacing ......
  • Page 96 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2009.06-0.3×1 CR...
