Weight 81g (with Slim battery)
Dimensions 80 x 42x 22 mm
Full Graphic Dual LCD Display
with EL back-lighting
WAP 1.1
Support Phase 2 + Features
SIM Application Tool Kit
Personal organizer
T9 Text input
Multi Party
CLIP/CLIR
Cell Broadcast
20 Numbers Redial
Power off timer
Calculator
World time
Games
Currency converter
Integrated Data / Fax modem
200 Extended Phonebook Memory
1
2
3
4
5
6
7
8
9
10
10
11
3
5
4
8
Earpiece
Microphone
antenna
Volume adjustment
Earphone jack
Ringing buzzer
Indicator
Outer display
Inner display
Battery lock/unlock knob
Folder (MX-6880)
Open to answer calls
close to end calls
1
6
11
9
Yes
2
7
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Maxon MX-6880
Summary of Contents for Maxon MX-6880
- Page 1 World time Games Currency converter Integrated Data / Fax modem 200 Extended Phonebook Memory Earpiece Microphone antenna Volume adjustment Earphone jack Ringing buzzer Indicator Outer display Inner display Battery lock/unlock knob Folder (MX-6880) Open to answer calls close to end calls...
-
Page 2: Table Of Contents
Dial a displayed number, answer an incoming call and store an entry End a call, exit a feature and set vibrator alert Switch the phone ON and OFF Clear a number Upward search Downward search Enter the menu or go back one step in the menu Enter the phone book or select a menu feature... -
Page 3: Introduction
Congratulations on choosing the MAXON MX-6880 GSM Dual Band mobile phone. This user guide describes the features of MX-6880. The MX-6880 has been designed to operate on any digital GSM network, GSM900, GSM1800 and GSM900/1800, subject to individual network roaming agreements. GSM has become a worldwide standard communications system, giving you the freedom to stay in touch wherever you are. -
Page 4: Safety
Safety Personal ● operation of any radio equipment including mobile phones may interfere with the function of inadequately shielded medical devices such as hearing aids and pacemakers. You must consult the manufacturer of the device or your physician before use ●... -
Page 5: Getting Started
Getting Started Read this section before attempting to use your phone. It tells you how to attach, charge and care for the phone’s battery. We have also included general information about the digital GSM network and given instructions of how to insert and unlock the SIM. Your phone has an indicator to visually show its status when you cannot see the display. -
Page 6: The Battery
The Battery Your phone is supplied with a rechargeable battery and quick charger. Before you use the phone for the first time, it is important that you fully charge the battery. Removing and Attaching the Battery ● to remove, slide in the direction of the arrow remove the battery from the phone ●... -
Page 7: Battery Performance
Removing Battery Performance To maintain battery performance you should operate the phone until you will see the low power warning message LOW BATTERY or preferable, the phone switches itself OFF. If the battery is only partly used before recharging, it can self-adjust to holding a reduced charge with the resultant progressive reduction in operating time. -
Page 8: Network Connection
Network Connection The SIM Your network provider will supply you with a plug-in SIM for use with your phone. The SIM (Subscriber Identity Module) is your personal key to the digital GSM network. All the information needed to connect you to the network and to initiate billing for your calls is stored in the gold- plated area along with names, numbers and messages which you have entered into the phone book or received. -
Page 9: Set Time
Set Time ● enter the current time. For example if the time is 12:34 (Use the to clear an error) Unlocking the SIM To prevent unauthorized use, the SIM is protected by a PIN1 (Personal Identity Number) code. When enabled, you must enter the PIN1 each time you switch your phone ON. -
Page 10: The Display
The Display The display will give you a lot of information via its indicators and symbols. Indicates your current position in the display. Indicates your current selection. The scrollbar appears when the menu contains more than 6 or 8 options, and it indicates if you can scroll up or down. -
Page 11: Basics
The Indicator LED In Service The phone has a built-in indicator which can show Green and flashes at different speeds according to the status of the phone and battery. Out of Service 1.11 The phone has a built-in indicator which can show Red and flashes at different speeds according to the status of the phone and battery. -
Page 12: Making Calls
Making Calls The network operator name must appear in the center of the display before you can make or receive calls. Signal strength is indicated by the bars in the top right of the display (six bars for optimum signal strength). Call quality can be affected by physical obstructions, so moving only a few metres may significantly improve signal strength. -
Page 13: Emergency Calls
Emergency Calls ● it should be possible to call the emergency services in any country which uses the digital GSM network provided you are within network coverage (check for signal strength bars). If your network operator does not have a roaming agreement in the area (no displayed name) ‘EMERGENCY CALLS ONLY’... -
Page 14: Basics
Basics This section will help you to get to know the phone’s features, phone book and call menus, provides details about customising the phone for your own use and shows you how to use the basic operating features. The Feature Menu Selecting a Feature by Search Selecting a Feature by Number Feature Menu Structure... -
Page 15: The Feature Menu
The Feature Menu All the operating features of the phone are stored in the easy to use menu. A feature can be selected directly via its feature number (see list on next page) or by searching and selecting using the keys (to move the cursor) at the top of the keypad as follows: - enter the feature menu or go back one step. -
Page 16: Selecting A Feature By Number
Selecting a Feature by Number FEATURE NUMBER ● for example, to change the ring type: Please note that you can press and hold exit a menu feature (the phone will exit on its own after a long delay) (hold) -
Page 17: Feature Menu Structure
Feature Menu Structure 111. READ 1. MESSAGE 11. SMS 112. SEND/EDIT 113. SEND ONLY 114. REPLY 115. DELETE 116. TEMPLATE 117. FORMAT 118. S.C.NUMBER 119. VALIDITY 1110. ALERT TONE 1111. T9 LANGUAGE 121. LISTEN 12. VOICE MAIL 122. NUMBER 131. READ 13.BROADCAST 132. -
Page 18: Phone Book Menu Structure
Phone Book Menu Structure (see section 4 for details) -
Page 19: Customising
Customising Display Text ● The phone will display text in the language of the SIM (automatic) or you can choose a language from a list Greeting Animation and Message ● You can select one of three greeting animation to be displayed each time the phone is switched ON and ●... -
Page 20: Sim Pin2 Change
OLD PIN1 NEW PIN 1 NEW PIN 1 ● The PIN can be disabled to allow other people to use your phone without having to reveal the PIN. Remember to enable the PIN1 again after their use PIN1 SIM PIN2 Change ●... -
Page 21: Keypad Sound
Keypad Sound ● to change the sound of the keypad (beep, tones, off) Information Tones ● you can switch the information tones (see list below) ON and OFF ● an information tone sounds when: - the battery is low - a call is proceeding - switching the phone ON/OFF - auto redialling - location update... -
Page 22: Basic Features
Basic Features Voice Mail ● When a voice mail received it displays animated icon on outer LCD. ● if you subscribe to a voice mail service where the message retrieval number is fixed on the SIM card, you can access One touch Mail by long pressing on Key 1. (memory location 1 will be reserved for One Touch Voice Mail) PRESS 3 SEC... -
Page 23: Dtmf Tones
Setting Up Billing ● All the call cost information that you need to enter can be checked and edited through one menu: STATUS - check the current rate and currency PRICE/UNIT - edit the call price per unit CURRENCY - select a currency 3.11 DTMF Tones ●... -
Page 24: The Phone Book
● The alarm will be active for 60 seconds in volume. When the alarm is active, press to cancel. When an alarm is set, a bell will be displayed in the top of the display Off Timer (Power Off Timer) ●... -
Page 25: The Phone Book
The Phone Book The phone can store telephone numbers and names onto the SIM. This means that you will always have important numbers with you, even if the SIM is being used in a different phone. The number of memory locations and the number of characters and digits that you can store in each location are SIM dependent. -
Page 26: To Look Up A Number
● enter the name NAME Press and hold to exit the phone book. To Look up a Number ● enter the phone book and select LOOK UP ● to look up in alphabetical order ● to look up in location number order Phone Book Dialling There are five ways to dial a stored number. -
Page 27: Your Own Number
Your Own Number ● You can store your own number if the SIM supports it ● If your SIM does not support your own number, you can store it in the Phone Book Memory Access ● if your SIM has two phone book memories (MEMORY A and MEMORY B) you can access both A and B or only B (sometimes MEMORY B is referred to as Fixed Dialled Numbers) -
Page 28: Network Features
Network Features In addition to making and receiving calls, the digital GSM network offers other advanced benefits detailed in this section. Some of the features may not be supported by your network operator or by a foreign network when roaming. Text Message SMS Messages Cell Broadcasts... -
Page 29: Sms Messages
language then switch the feature ON. The number of channel locations on the SIM is limited to its memory capacity, so you may have to overwrite old channel numbers to enter new one. Note: Contact your local dealer for information about the broadcast channel numbers. - Page 30 To Send a SMS Message ● enter the SEND/EDIT menu, select the message, edit if necessary then send. Messages that have not been sent successfully or not sent yet are marked by a black diamond SELECT (TYPE NUMBER) ( (TYPE INITIAL LETTER) (SELECT)) (CHECK RECEIVING NUMBER/EDIT)
- Page 31 Creating a Template Message ● if your regularly send similar messages, you can create a template which will automatically appear (ready to edit) each time you create a new message provided that the feature is switched ON ● for example: Dear...
-
Page 32: Cell Broadcasts
Cell Broadcasts Switching Cell Broadcasting ON/OFF ● there must be at least one channel entered and one language selected before you can switch cell broadcasting ON (ON) ● switching cell broadcasting OFF will save battery power Cell Broadcasting Channels ● to view the list of selected channels ●... -
Page 33: Call Forwarding
Call Forwarding There are two call forwarding options which you can use to be assured that all your incoming calls are answered. The phone number which the calls are forwarded (diverted) to can be entered via the keypad or recalled from the Phone Book. -
Page 34: Call Barring
Call Barring You can set any combination of the following call bars to help manage network usage and increase security. The network provider will supply a special four digit password so that you can activate the call bars. You can change the password to any four digit code of your choice if you find it difficult to remember or think someone else knows it. -
Page 35: Network Selection
Network Selection You can choose which method your phone uses to connect you to a foreign GSM network when operating outside your home country (roaming). Normally you would select Automatic mode (see below) but you can choose “Manual” or “Periodic” and force a search for available networks or request network reselection. -
Page 36: New Network
New Network ● if a new network starts to operate after your phone was produced, its name will not be recognisable. You will still be able to select the network but it will only be identified by the country and network codes. To enter the name into the phone COUNTRY CODE NETWORK CODE... -
Page 37: Call Waiting
Call Waiting ● if during conversation you hear a soft ringing tone, a second caller is trying to contact. You will then have the opportunity to accept the call and use the Call menu options (first held,new call answered) ● you must activate call waiting before the feature will work 5.18 ●... -
Page 38: Getting Started
Mobile Internet (WAP) Your MX-6880 is able to access the Internet. It is however, provided that your network operator supports this service. You may also have to pay a subscription for this service. WAP offers users of mobile phones the possibility to access Internet information and communication in the same way, as you know it from a computer. - Page 39 Bookmarks ● It is possible to save app. 50 WAP pages as book- marks. This will give you a quick access to your favourite pages To choose a bookmark (SELECT BOOKMARK) To edit (SELECT BOOKMARK) To add (TYPE ADDRESS) To delete ●...
- Page 40 Use of the menu key when on-line ● When you are on-line and press This menu is dynamic in the way that the content changes according to the WAP page that you visit. Some menu points will therefore only be available on certain WAP pages.
- Page 41 Security ● Some WAP services require that the security functionality is turned on. If security is turned on all messages from the phone to the network will be encrypted (SELECT SECURITY ON) Bearer ● You can choose either SMS or data connection. The speed and cost of the WAP service depend on which type you use.
-
Page 42: T9 Text Input
T9 Text Input (optional) T9 Text input Read this first! Getting into T9 Text Input Mode The Display Headline Typing Words with T9 Text Input Selecting Alternate Words Deleting Characters Space Characters Punctuation and Symbols Mode Indicators State Indicators Typing Numbers Other Mode Indicators T9 Text Input Read this first! -
Page 43: The Display Headline
The Display Headline Mode: This field indicates the current mode. See the paragraph about mode indicators. Info: This field indicates the number of characters left of the current message (maximum 160 characters). In read mode this field will indicate the total number of characters of the received message. -
Page 44: Selecting Alternate Words
"i", and press the 6key for "m". Note that the displayed word changes as you type it. Always type to the end of the word before you change what appears to be a mistake. The down arrow key gives you alternative words. Selecting Alternate Words Many words share identical numerical sequences. -
Page 45: Punctuation And Symbols
Punctuation and Symbols Press key to display the first of a series of pages of additional symbols. Cycle through the three pages by pressing the up or down arrow key and select a symbol by pressing its corresponding number on the keypad, and you will automatically return to the previous mode. -
Page 46: State Indicators
State Indicators To capitalize the next letter that you will type, long-push the key with the letter that you need. Note that the shift indicator appears in the top of the display. Shift is released by long-pushing the following letter. Typing Numbers Press the key repeatedly until the Numeric indicator... - Page 47 Miscellaneous Calculator The calculator in your phone adds, subtracts, multiplies, divides, and converts currency values. This calculator has a limited accuracy and rounding errors may occur, especially in long divisions. Usage of the calculator: 1. Press 2. When ‘0’ is displayed on the screen, enter the first number in the calculation.
- Page 48 Adventure game consists of three games and two bonuses. If you start game, it’ll roll automatically and you can play selected game.When you get total 20 medals, game is over. And, you can get a bonus of 500 points in Each game every perfect success.
-
Page 49: Organizer
Organizer View Entries New Entry Go To Day/Week and Weekly/Monthly View To Do List Settings Limitations of the Organizer... -
Page 50: View Entries
Organizer The Organizer makes it possible for you to keep track of important meeting or events that you need to do. You can also let the phone remind you before an appointment or birthday. In this way, you can be pretty sure that you don’t miss anything important as like as appointment, to do and birthday, no matter where you are. -
Page 51: Go To Day/Week And
TIME - to write the time of appointment DATE - to write the date of appointment ALARM SETTING - to set alarm (on time, 5, 10, 15, 30minute or choice the time[custom] or no alarm) In the case of “NEW BIRTHDAY”, ENTER NAME - to enter name DATE - to write the date of birth YEAR OF BIRTH - to write year of birth... -
Page 52: View To Do List
View to Do List ● If you select this menu, as the submenu, you can see “TO DO ENTRY”. This is used when you write brief memos. Submenu is divided into two sections. The one is “with due date”, the other is “with no due date”. Whenever each submenu selected, you can see the each text, if you saved some memos. -
Page 53: Troubleshooting
Troubleshooting The Phone Will Not Switch ON Some Calls Are Not Processed Someone Else is Receiving My Calls 10.1 Display Messages 'PLEASE INSERT SIM' 'NO NETWORK' 'EMERGENCY CALLS ONLY' 'INVALID SIM' 'ENTER PUK 1/2' Troubleshooting The Phone Will Not Switch ON ●... -
Page 54: Accessories
“EMERGENCY CALLS ONLY” ● you are outside co-operating network coverage but another network in your area will allow emergency calls subject to signal strength “INVALID SIM” ● the phone is SIM-locked and will not accept the inserted SIM. Insert the correct SIM or contact your dealer 10.2 “ENTER PUK1/2”... - Page 55 Accessories Standard Charger ● charges a slim battery(AX-841) to its full capacity in 1 hours ● charges a standard battery (AX-840) to its full capacity in 1.5 hours. ● available with four different wall plugs;EU, UK, AUS, US 11.1 Car Charger ●...
-
Page 56: Index
Index Security – Missed Accessories 11.1 – National Any Key Answer 3.12 – Phone extension – Redialling Battery – Waiting – Attaching – Charging Cell broadcasts – Performance – Alert – Power level – Channels – Removing – Display – Language Basic Features –...
