Remote Controller - Toshiba RAV-162BH-PE Service Manual

6.1

Remote controller

B U T T O N
ON/OFF
MODE SELECT
TIME ADJUST
TIMER SELECT
Tel: 01823 665660
Heronhill - for all your Toshiba requirements
6. REMOTE CONTROLLER
-46-
-46-
I N D I C A T O R
LED (RED)
AUTO
COOL
MODE
HEAT 1
HEAT 2
FAN ONLY
AUTO
LOW
FAN
MED
HIGH
TEMP.
(1) CLOCK
(2) ON TIME
TIME
(3) OFF TIME
ON
OFF
ON → OFF
TIMER
←
ON OFF
CYCLE
www.heronhill.co.uk
Run/Stop
Auto Changeover
Cooling
Heating
Heating
(with indoor fan operation at defrost)
Fan only
Auto Fan Speed Control
Low Fan Speed
Med. Fan Speed
High Fan Speed
Temperature setting
(1) Present Time Adjust
(2) ON Time setting
(3) OFF Time setting
ON Timer
OFF Timer
ON
OFF
24H CYCLE Timer
-46-
O P E R A T I O N
→ OFF Timer
→
ON Timer
