5.1 Indoor unit
RAV-132UH-PE
Distributor strainer
capillary tube
ø2.0 x 200 l x 2P
Refrigerant pipe (Smaller side)
ø6.4mm (1/4" )
Tel: 01823 665660
Heronhill - for all your Toshiba requirements
5. REFRIGERANT PIPING DIAGRAM
Indoor unit
Heat exchanger
-41-
www.heronhill.co.uk
Strainer
Refrigerant pipe (Larger side)
ø12.7mm (1/2" )
Fax: 01823 665807
Cooling
Heating
