2.6 Outdoor unit

RAV-162AH-PE
RAV-262AH-PE
RAV-262AH8-PE
K n o c k - o u t h o l e f o r d r a i n
( 2 - 2 0 x 6 0 l o n g h o l e )
Hole for drain
(2-ø19 hole)
Anchor bolt hole
( 4 - 1 2 x 1 8 l o n g h o l e )
Model
RAV-162AH-PE
RAV-262AH-PE
RAV-262AH8-PE
Tel: 01823 665660
Heronhill - for all your Toshiba requirements
Air outlet
Blow out guide
mounting hole
( 4 - ø 3 e m b o s s i n g )
Space required for service
Outlet
(Space for wiring
and piping)
When installed with the
inlet faced to the wall side
A
740
790
-20-
www.heronhill.co.uk
Refrigerant piping joint
(larger side D)
Refrigerant piping joint
(Smaller side C)
Electric parts
Carrying handle
b o x
( B o t h s i d e s )
(Space for wiring
and piping)
Outlet
When installed with the
outlet faced to the wall side
B C
380 ø6.4
430 ø9.5
Earth screw
( M 6 )
Terminal cover
(Unit: mm)
D
ø12.7
ø15.9
