Individual Multi-Part Forms
• Size
– Minimum Width: 3.9" (100 mm)
– Maximum Width: 14.3" (364 mm)
– Minimum Length: 2.75" (70 mm)
– Maximum Length: 14.3" (364 mm)
• Normal Print Mode (the factory default)
– Up to 6-part forms (original + 5)
– Maximum Thickness: 0.0142" (0.36 mm)
• High Impact Mode
– Up to 8-part forms (original + 7)
– Maximum Thickness: 0.0189" (0.48 mm)
Switching Between Normal and
High Impact Mode
Normal to High Impact
Press MODE/HIGH IMPACT.
The LED beside HIGH IMPACT comes
on and H-IMPCT appears at the end of
the first line of the display.
High Impact to Normal
Press LF/NORMAL PRIN.
The LED beside HIGH IMPACT goes out
and NORMAL appears at the end of
the first line of the display.
Load Individual Sheets/Forms
1. Pull out the sheet supports (1) and move the
sheet guide (2) to the right as far as it will go (the
travel of the sheet guide is limited).
2. Place a letter size or larger sheet/form on the
platform anywhere within the "Paper range when
Auto Align is ON" area
The sheet loads in to the print position,
automatically aligning so that it is square with the
print path.
8
