Cleaning and Maintenance

Cleaning the roller brush.

Follow Fig.1 take out the Hair-clean-tool from charging base.
Follow Fig.2 moved the tool to clean hairs in roller brush.
Fig 1
Cleaning the QQ6
Fig 2
QQ6
16
The Sonic wall create an invisible barrier that QQ6 will not cross.
Power indicator LED
Sonic receiver
Sonic receiver
Instructions:
1. This CleanMate Sonic Wall is Powered by 2 AA batteries. Make sure to install the
included AA rechargeable batteries in correct polarity.
2.
To turn on the Sonic Wall, slide the power switch to position ON.
3.
When power on, the blue LED light up still 70 sec., then will light off into waiting
mode.After QQ6 start working in 6 sec., will wake up Sonic Wall and blue LED light
up.If QQ6 stop working, after 10 sec., Sonic Wall will into waiting mode for power
saving.
4. The best effective distance of Sonic Wall barrier is about 3M(10 ft).
5.
When LED is blinking, it means battery low.
-
Charging base
Slide switch
You can charge battery by charging base, please see above drawing.
Step 1: The power switch of Sonic Wall, must set "ON" position.
Step 2: Press and Slide out the "Slide switch" from charging base.
Step 3: Plug the DC plug into DC inlet.
Step 4: Blue LED is blinking. When charging is complete, LED will light steady.
6. When QQ6 cleaning, the Sonic Wall position must be away from charging base at
least 1m(3 ft), and avoid face to charging base.
7. When QQ6 complete cleaning , you can power off the Sonic wall by slided the power
switch to "OFF" position.
QQ6 detects the invisible barrier,
it will turn around and head to another direction.

Sonic Wall Setup

Power switch
Charging inlet
Battery cover
DC inlet
Sonic-Wall
DC Plug
