TECHNICAL DATA

Mains voltage:
Absorbed power:
Size: LxHxD:
Pressure:
Water tank capacity:
Power cable length:
Weight:
The appliance complies with the following EC
directives:
• Low Voltage Directive 2006/95/EC and subsequent
amendments;
• EMC Directive 2004/108/EC and subsequent amendments;
• Stand-by European Regulation 1275/2008 and subsequent
amendments;
• Materials and accessories coming into contact with food
conform to EEC regulation 1935/2004.
TROUBLESHOOTING...
Problem
No espresso coffee is delivered
The espresso coffee drips from
the edges of the filter holder
rather than the holes
The espresso coffee is cold
220-240V ˜ 50/60Hz
1100W
mm
197x322x303 (385)
15 bar
1 L
1,40 m
4,7 kg
Possible causes
No water in the tank
The holes in the filter holder are blocked
The espresso boiler outlet is blocked
Limescale in the water circuit
The filter holder has been inserted incor-
rectly or is dirty
The espresso boiler gasket has lost elasti-
city or is dirty
The holes in the filter holder spouts are
blocked
The OK light is not on when the coffee
delivery button is pressed
No preheating was done
The cups were not preheated
Limescale in the water circuit
DISPOSAL
In compliance with European directive 2002/96/EC,
the appliance must not be disposed of with house-
hold waste, but taken to an authorised waste separa-
tion and recycling centre.
Solution
Fill the tank with water
Clean the filter holder spout holes
Clean as described in the "Cleaning" section
Descale as described in the "Descaling" section
Attach the filter holder correctly and rotate firmly
as far as it will go
Have the espresso boiler gasket replaced by Custo-
mer Services
Clean the filter holder spout holes
Wait until the OK light comes on
Pre-heat as indicated in the "Tips for a hotter cof-
fee" section
Pre-heat the cups with hot water
Descale as described in the "Descaling" section
18
