Installation
WARNING! PCI cards, like all computer equipment, can be severely
damaged by static electricity. Be sure that you are properly grounded
before opening your computer case or touching your PCI card.
StarTech.com recommends that you wear an anti-static strap when
installing any computer component. If an anti-static strap is unavailable,
discharge yourself of any static electricity build-up by touching a large
grounded metal surface (such as the computer case) for several
seconds. Also be careful to handle the PCI card by its edges and not
the gold connectors.
Hardware Installation
1.
Turn your computer off and any peripherals connected to the
computer (i.e. Printers, external hard drives, etc.). Unplug the power
cable from the rear of the power supply on the back of the computer.
2.
Remove the cover from the computer case. Refer to documentation
for your computer system for details.
3.
Locate an open PCI or PCI-X slot and remove the metal cover plate
on the rear of the computer case. Refer to documentation for your
computer system for details.
4.
Insert the card into the open PCI or PCI-X slot and fasten the card's
bracket to the rear of the case.
5.
Place the cover back onto the computer case.
6.
Insert the power cable into the socket on the power supply and
reconnect all other connectors removed in Step 1.
7.
Attach the 8-port DB9 breakout dongle to the connector on the card.
