S L I M
Display Size:
Maximum load:
VESA Patterns:
Display Size:
Maximum load:
VESA Patterns:
U S E R M A N U A L
MF441*
ATTENTION:
F L A T
24" - 55"
70 lbs / 32 kg
75 x 75 to 400 x 400
30" -80"
75 lbs / 34 kg
75 x 75 to 600 x 400
BEFORE INSTALLING, READ ALL WARNINGS AND CAUTIONS ON REVERSE SIDE.
FOR MORE INFORMATION, GO TO:
www.monstermounts.com
MF641
*MF441 used in diagrams, steps also apply to MF641.
M O U N T
MF441
MF641
Advertisement
Related Manuals for Monster Mounts MF441
Summary of Contents for Monster Mounts MF441
- Page 1 75 x 75 to 600 x 400 U S E R M A N U A L MF441* MF641 *MF441 used in diagrams, steps also apply to MF641. ATTENTION: BEFORE INSTALLING, READ ALL WARNINGS AND CAUTIONS ON REVERSE SIDE. FOR MORE INFORMATION, GO TO:...
-
Page 2: Warnings And Cautions
Warnings & Cautions IT IS HIGHLY RECOMMENDED THAT THIS PRODUCT BE INSTALLED BY A PROFESSIONAL. PLEASE REVIEW THIS INSTRUCTION MANUAL COMPLETELY BEFORE STARTING THE INSTALLATION PROCESS. WARNING: A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions. -
Page 3: Package Contents
Package contents 1 Wall plate (x1) 2 vBar (x2) 3 Lock cords (x2) 4 Bubble level (x1) A1 M4x12 mm bolt (x4) A2 M5x12 mm bolt (x4) A3 M6x12 mm bolt (x4) A4 M8x16 mm bolt (x4) A5 M8x25 mm bolt (x4) A6 M5 washer (x4) - Page 4 1a. Mount on Wood Wall 60 mm (2.4”) Ø5 mm (Ø3/16”)
- Page 5 1b. Mount on Solid Brick or Concrete Block 60 mm (2.3”) Ø10.5 mm (Ø7/16”)
- Page 6 2. Install vBar Brackets A7 (optional) A1-A5 A6 (with A1 or A2 only)
- Page 7 3. Hook Display on Wall Plate / Unlock...
- Page 8 Monster Mounts 20218 Hamilton Avenue Torrance, CA 90502 FOR MORE INFORMATION, VISIT: www.monstermounts.com AUM118 v2.5...
