QView QD1200 User Manual

Digital visualizer
Hide thumbs Also See for QD1200:

Advertisement

Quick Links

PRECAUTIONS
Please follow these precautions:
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
To prevent electrical shock, do not open the cabinet. Refer to qualified
personnel for service only.
Do not use the unit continuously for more than 24 hours with camera auto
focus on. It may cause damage to the camera lens.
Be careful not to spill water or other liquids onto the unit, or allow combustible
or metallic objects to get inside the cabinet.
Unplug the visualizer from the wall outlet when it is not being used for
a long period of time.
Clean the cabinet with a soft cloth lightly moistened with a mild detergent
solution.
Clean the lens carefully with an air spray or soft dry cloth to avoid scratching
it.
When the lamps flash or become dark, they should be replaced with new
ones.
Avoid switching arm lights and back light frequently.
CONTACTS:
QOMO Hitevision, LLC
Toll Free: 1-866-990QOMO
E-Mail: info@qomo.com
Web: www.qomo.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QD1200 and is the answer not in the manual?

Questions and answers

Summary of Contents for QView QD1200

  • Page 1 PRECAUTIONS Please follow these precautions: To prevent fire or shock hazard, do not expose the unit to rain or moisture. To prevent electrical shock, do not open the cabinet. Refer to qualified personnel for service only. Do not use the unit continuously for more than 24 hours with camera auto focus on.
  • Page 2: Table Of Contents

    CONTENTS: PARTS IDENTIFICATION ................3 CONTROL PANEL ..................3 BUTTON INSTRUCTION................4 REMOTE CONTROL ..................5 CONNECTIONS ..................... 6 BASIC PREPARATIONS................. 6 OUTPUT MODE AND VERTICAL FREQUENCY (60Hz) ......10 PAL/NTSC VIDEO OUTPUTS ..............10 INSTALLING QOMO VISUALIZER SOFTWARE ...........11 WORKING ON THE STAGE .................
  • Page 3: Parts Identification

    USB IMAGE CAPTURE ................18 CONTROLLING THE VISUALIZER FROM THE COMPUTER ..... 19 CONTROLLING PROJECTOR BY VISUALIZER.......... 19 FOLDING THE UNIT..................23 SPECIFICATIONS ..................24 TECHNICAL SUPPORT................26 PARTS IDENTIFICATION Camera Camera stand Arm lights Button instruction Connectors Back light Connectors Remote control slot Stage...
  • Page 4: Button Instruction

    Save (Save captured images) Far/Near (Focus far or near) Mem (Multiple Screen Display) Ppw (Control the projector On/Standby) Pin (Projector input signal selection) (Move the image up/down) POWER (Control the visualizer On/Off) CCD/PC1/PC2 (CCD/RGB input signal selection) S-VIDEO/ VIDEO (S-VIDEO/ VIDEO input signal selection) LAMP (Control the arm lights and back light) AUTO (To auto adjust brightness, auto white balance and auto focus) (Increase and decrease magnification)
  • Page 5: Remote Control

    REMOTE CONTROL POWER (Control the visualizer power On/Off) ROTATE (Rotate the image) FREEZE (Freeze the image) LAMP (Control the arm lights and back light) SAVE (Save captured images) NEG (Display film negatives) MIRROR (V-reverse the image) XGA (Switch between SVGA mode and XGA mode) RECALL (Multiple screen display) TEXT (Switch between image/text mode) B&W (Switch between Color mode and Black &...
  • Page 6: Connections

    AUTO (To auto adjust brightness, auto white balance and auto focus) CCD/PC1/PC2 (CCD/RGB input signal selection) S-VIDEO/ VIDEO (S-VIDEO/ VIDEO input signal selection) VOLUME+/- (Increase or decrease the volume) RED+/- (Increase or decrease the red hue) BLUE+/- (Increase or decrease the blue hue) BRIGHT+/- (Increase or decrease the brightness) SCROLL / (Move the image up/down)
  • Page 7 1. Use one hand holds the base of the visualizer, use the other hand carefully lift up the camera stand of the unit. 2. Open the arm lights and rotate the camera head until they are in proper positions. Arm lights 3.
  • Page 8 Rear Panel S-VIDEO AUDIO VIDEO S-VIDEO AUDIO VIDEO AUDIO AUDIO IN PROJECTOR OUT -COMPUTER- IN OUT-12V- IN RGB Input RS232 Cable Screen Projector Side Panel PROJECTOR RGB IN AUDIO IN RS232 Connect visualizer’s PROJECTOR port to the RGB IN port of the projector port with the RGB cable provided together the visualizer.
  • Page 9 Note: You can connect a laptop computer to the RGB IN port of side panel with a RGB cable. Step 4: Connect to the first video equipment with S-Video input. S-Video Cable S-Video out Audio out Video equipment Rear Panel AUDIO VIDEO S-VIDEO...
  • Page 10: Output Mode And Vertical Frequency (60Hz)

    Step 6: Connections for external control from the computer. Side Panel PROJECTOR MIC RGB IN AUDIO IN RS232 RS-232 cable USB cable RS 232 connector of the computer USB connector of the computer Use the computer RS232 cable (9-pin to 9-pin) to make the connections shown below to control the visualizer from an external computer.
  • Page 11: Installing Qomo Visualizer Software

    INSTALLING QOMO VISUALIZER SOFTWARE This function is to snap and display images with the USB interface, which includes displaying static and dynamic pictures, snapping dynamic images and playback the dynamic images with the media player in Windows XP. A. Connect the computer and visualizer with the USB cable. Insert the software CD that comes with your purchased visualizer into the CD-ROM drive.
  • Page 12 D. Click , then copy files E. Click to finish the setup. F. Shut down your computer when prompted, so the changes will take effect. * Please pay attention to the following: Computer hardware requirement: CPU: 2.4GHz, RAM: 256M or above, Graphic card 64M, USB 2.0 port, Hard disk 40G or more, Monitor...
  • Page 13: Working On The Stage

    display resolution higher than XGA (1024*768). Operating system: Windows XP SP2 (Service Pack 2). Must use the high-speed USB cable provided together with the visualizer. When connect the visualizer to a desktop computer with the high-speed USB cable provided together with visualizer, we recommend using the USB port on the rear of the mainframe as the USB port on the front of the computer might have interference.
  • Page 14: Light

    LIGHT The arm lights are on when the power is on. Each time you press the “LAMP” buttons, the lighting changes as below. The arm lights turn on The back light turns on All the lights turn off ADJUSTING IMAGE SIZE In order to reduce or enlarge the image size displayed on the screen, press the “...
  • Page 15: Focusing

    CCD. Press the “AUTO” button to adjust the white balance automatically. AUTO ADJUSTMENT One of the QD1200’s special functions is auto adjustment. Press the “AUTO” button to auto adjust the brightness, the white balance and the focus.
  • Page 16: Color And B&W Mode Switch

    Notes: RGB OUT always outputs RGB IN signals. PROJECTOR ON/STANDBY Press the “POWER” button to turn on the QD1200’s power and press the “Ppw” button to turn the projector power on. To turn the projector standby after use, press the “Ppw” button more than 2 seconds, and then the projector enters to the standby mode.
  • Page 17: Image Reversion

    INFRARED REMOTE CONTROL The QD1200’s remote control can control the camera from different angels. Please note that an infrared remote control can only be used up to a certain distance to the unit. Objects situated between the visualizer and the infrared remote control and a weak battery may interfere with the reception.
  • Page 18: Usb Image Capture

    visualizer can be used as a 3-D scanner for your computer. Connect the Visualizer to your computer with the supplied USB cable. The QOMO Visualizer Software is available on the supplied CD-ROM. USB IMAGE CAPTURE You can capture and control images on the visualizer from a computer connected with a USB connector.
  • Page 19: Controlling The Visualizer From The Computer

    folder on your computer. Display the current visualizer images continuously (the fastest frame rate is 10 frames per second) Stop image continuous display Choose the image displaying size. Open an image. Save the captured image to computer. CONTROLLING THE VISUALIZER FROM THE COMPUTER You can control the visualizer from a computer connected with a RS232 connector.
  • Page 20 When the indicator of “Current RS-232 Connection Status” is green, that means the connection between the visualizer and the computer’s RS232 connector is good. If the indicator is red, please check if the RS232 cable is connected correctly. When all the cables are connected correctly, please click “Projector”...
  • Page 21 BE EF 03 06 00 BA D2 01 00 00 60 01 00 In the POWRE ON box,Input : be, ef, 03, 06, 00, ba, d2, 01, 00, 00, 60, 01, 00. Then use the same input rule to input other code. b.
  • Page 22 Visualizer’s TXD pin------------Projector’s RXD pin Visualizer’s GND pin------------Projector’s GND pin 5. If you can not use buttons on the operation panel to control the projector, please use Code-Writing software’s projector control code testing function to check if the control code is correct. Click “Projector”...
  • Page 23: Folding The Unit

    1. Check to see if the source control codes of projector are correct. 2. Check to make sure the connection between the visualizer and the projector is correct. FOLDING THE UNIT 1. Fold the right arm light down first onto the base, then the left arm down. Rotate the camera head clockwise until the camera head is parallel to the camera stand.
  • Page 24: Specifications

    Cautions: a. Don’t lay the unit down flat. b. Don’t try to stand it on its rear or sides. c. Don’t try to pick up this unit by pulling the camera stand. NOT THIS WAY SPECIFICATIONS Color system NTSC or PAL system Pickup device 1/3″CCD Resolution...
  • Page 25 Image Freeze Image Save & Recall 9 frames save, 3 x 3 multiple screen display Arm light: 1.5W LED lamps x 2 Lights Back light: 4W LED lamps C Video IN (RCA) (1) S Video IN (4-pin DIN) (1) Audio IN (Mini Jack) (2) Input connectors MIC IN (phone jack)(1) PC Audio (2)
  • Page 26: Technical Support

    Projector RS232 cable (6-pin to 9-pin) USB cable Audio convert cable AC adapter User’s manual Quick Start-up guide Software CD Infrared remote control Warranty card * Design and specifications are subject to change without prior notice. TECHNICAL SUPPORT How to Reach QOMO: By Phone Call us at 1-866-990QOMO.
