- Page 1 User Manual Digital Thermometer YDTC-13 Digital Barometer YDBC-05 also covers models YDTC-13R, YDTC-13RT, YDTC-13N, YDTC-13NT YDBC-05R, YDBC-05RT, YDBC-05N, YDBC-05NT Software version 1.22 2015...
- Page 2 © 2015 Yacht Devices Ltd. Document YDBC05TC13-004. March 24, 2015. Web: http://www.yachtd.com/ NMEA 2000® is a registered trademark of National Marine Electronics Association. SeaTalk NG is a registered trademark of Raymarine UK Limited. Garmin® is a registered trademark of Garmin Ltd.
-
Page 3: Table Of Contents
Contents Introduction Warranty and Technical Support Product Specification Device Connection and Testing Programming the Device APPENDIX А. Troubleshooting APPENDIX B. Description of Connectors and Joints APPENDIX С. NMEA 2000 Messages Package Contents Device 1 pc. This Manual 1 pc. -
Page 4: Introduction
Introduction This Manual contains information on how to install, configure and operate YDTC-13 digital thermometers (hereinafter Thermometer) and YDBC-05 digital barometers (hereinafter Barometer) intended for using on pleasure crafts. The Thermometer and Barometer (hereinafter, where the differences are not critical, Devices) have one digital sensor. Up to 50 devices may be used on a vessel simultaneously;... - Page 5 Devices are supplied with different types of connectors, making it possible to connect them to networks of different manufacturers without any adapters. The Device model is shown on the case. Type of the connector, compatibility Device model (see Appendix B) YDBC-05R, YDTC-13R Raymarine SeaTalk NG Female YDBC-05RT,...
-
Page 6: Warranty And Technical Support
Warranty and Technical Support The Device warranty is valid for two years from the date of purchase. If a Device was purchased in a retail store, when applying under a warranty case, the sale receipt can be requested. The Device warranty is terminated in case of violating the instructions of this Manual, case integrity breach, repair or modification of the Device without manufacturer’s written permission. -
Page 7: Product Specification
Product Specification Figure 1. Combined drawing of the Thermometer and Barometer — 7 —... - Page 8 Device parameter Value Unit Operating voltage (from an NMEA 2000 network) 7..16 Protection against reverse polarity — Consumption current of the Thermometer / Barometer 24 / 24 Load Equivalency Number Operating temperature range (except the Thermometer sensor) -40..+80 °С Weight of the Thermometer / Barometer 31 / 11 NMEA 2000 data output resolution 0.01...
-
Page 9: Device Connection And Testing
Device Connection and Testing The Device requires no maintenance; calibration of the digital sensors has been performed by the manufacturer. When deciding where to install the Device, choose a dry mounting location. Avoid places where the Device can be flooded with water, this can damage it. The Thermometer sensor has a waterproof case made of stainless steel and is not intended for permanent location in hostile environments such as sea water. - Page 10 After connecting the Device, close the lock on the connection to ensure its water resistance and reliability. Figure 1. SeaTalk NG bus with the YDBC-05RT, YDTC-13R and YDBC-05R (left to right) After turning on the bus power supply, the Device LED will produce short signals every 2 seconds.
- Page 11 PGN 0x1F11A (127258) with data on magnetic variation, the Device will produce six LED signals with a period of 0.5 seconds when such message is received for the first time after power is on. This usually happens within 15 seconds after the Device is turned on.
- Page 12 Figure 2. Raymarine c125 MFD devices list with Barometer and Thermometer The Thermometer can be reprogrammed by the user to display data in other indicators, such as «Sea temperature», «Temperature in the engine room», «Temperature in the refrigerator» (see «Programming the Device»). The Thermometer sensor cable can be elongated up to 100 m by the user himself —...
- Page 13 Figure 3. Garmin GPSmap 721 display with the connected Barometer and two Thermometers (note that the warranty for the modified Device is not maintained). To do this, turn the Device off, cut the cable in the middle (see Appendix B) and extend it with a three- conductor wire and properly insulate the joints.
-
Page 14: Programming The Device
The core section of the connection cable must not be less than 0.2 sq. mm, with the diameter of 0.5 mm. Cables of UTP 3, UTP 5, UTP 5e categories with the AWG-24 and AWG-22 labelling used for telephone lines and computer networks are suitable for the role of a connection cable. - Page 15 Figure 1. Setting the chart datum and magnetic variation on Raymarine c125 To select a programming method, refer to the documentation of your chartplotter. In some cases you may need to update the plotter firmware. Theoretically, programming the Device can be performed using a plotter of any manufacturer. —...
- Page 16 STEP 1. Putting the Device into standby mode The Device enters standby mode if, when it is switched on, the chart datum is set on the plotter as follows: • to “Australian Geodetic 1966” for the Thermometer • to “European 1950 (Mean, European Datum)” for the Barometer Or if the magnetic variation on the plotter is set to a user-defined value with the following parameter: •...
- Page 17 STEP 2. Putting the Device into programming mode If the Device was put into standby mode by setting the chart datum (magnetic variation), all the subsequent steps should be carried out with the setting of chart datum (magnetic variation). In the standby mode, without turning the Device power off, change the chart datum setting on the plotter •...
- Page 18 Thermometer only, the Barometer always has the “atmospheric pressure” data type). Table 1. Setting NMEA 2000 messages for the Barometer and Thermometer Messages Description setting Maximum compatibility mode. Transfer of the measured value in 0 (factory messages: PGN 0x1FD06 (130310), PGN 0x1FD07 (130311), PGN setting) 0x1FD0A (130314) (for the Barometer only) with instance 0, PGN 0x1FD08 (130312) (for the Thermometer only) with instance 0.
- Page 19 (130314) and PGN 0x1FD08 (130312) depends on the plotter manufacturer. Data on the refrigerator temperature with instance 3 can be displayed as “Temperature in refrigerator № 3”. In practice, we have not seen plotters with such ability. Please note that all the messages transmitted by the Device are informational. They can be used by other devices during their operation (to show them on a display or to trigger an alarm when exceeding a predetermined level), but are not used as automated control data for autotuning.
- Page 20 Table 2. Setting type of a data source for the Thermometer NMEA 2000 messages, PGN Data type Description setting 0x1FD06 0x1FD07 0x1FD08 (130310) (130311) (130312) Sea Temperature. 1 (factory Outside Temperature. setting) Inside Temperature. Engine Room Temperature. Main Cabin Temperature. Live Well Temperature.
- Page 21 Table 3. Device actions in response to setting changes Magnetic Chart datum Result variation Incrementing the message setting by one. Upon Bermuda 1957 20°E reaching 16, the setting value is set to zero. Bogota Incrementing the message setting by one. Upon Observatory 21°E reaching 16, the setting value is set to zero.
- Page 22 Please note that changing the Device settings occurs only when changing the plotter configuration. To increase the value of the message setting by 3, first change the setting to the first value from Table 3, then to the second, and then back to the first one. After each change, wait for the Device confirming signal (lighting of LEDs for 3 seconds).
-
Page 23: Appendix А. Troubleshooting
APPENDIX А. Troubleshooting Fault Possible reasons and solution 1. No power supply on the bus. Check if the bus pow- er is supplied (NMEA 2000 network requires a separate The LED does not power connection and can not be powered by a plotter or another Device connected to the network). - Page 24 Table continued Fault Possible reasons and solution 1. Incorrect Device settings. Put the Device into the The Device is displayed programming mode and reset it to the factory settings. in the list of Devices, but 2. Incompatible equipment. Make sure that your data do not appear on hardware supports messages transferred by the Device.
-
Page 25: Appendix B. Description Of Connectors And Joints
APPENDIX B. Description of Connectors and Joints Figure 1. Connectors of the Devices with indices R (left), RT (center), N and NT (right) in the end of model name — 25 —... - Page 26 Figure 2. Digital sensor of the Thermometer — 26 —...
-
Page 27: Appendix С. Nmea 2000 Messages
APPENDIX С. NMEA 2000 Messages Rec- Tran- Period, Message Comments eive smit ISO Acknowledgment PGN 059392 (0x0E800) ISO Request PGN 059904 (0x0EA00) ISO Address Claim PGN 60928 (0x0EE00) Acknowledge Group Function PGN 126464 (0x1EE00) Periodic transmission is Product Information performed for compatibility PGN 126996 (0x1F014) with some models of equipment. - Page 28 Table continued Rec- Tran- Period, Message Comments eive smit Environmental Can be disabled when a user is Parameters programming the Device. PGN 130310 (0x1FD06) Environmental Can be disabled when a user is Parameters programming the Device. PGN 130311 (0x1FD07) Temperature Thermometer only.
