Operating Manual
JE1510
OPERATING MANUAL
15.4" 16:9 DIGITAL LCD-TV
15.4
Please keep this operating manual for future references.
Important Notes :
1. Before operating the unit, please read these instructions carefully.
2. Retain this manual for future reference.
3. Do not remove any WARNING stickers on the unit.
4. You are advised to follow the instructions carefully when operating the unit.
5. Do not use any chemical solvent, cleaning agent or corrosive detergent to
clean away dirt on the surface of the screen. By doing so, you may cause
irreversible damage to the surface of the TFT screen. To clean o dirt or
ngerprints, we recommend the use of a soft damp lens cleaning cloth.
6. Using spare parts from another manufacturer may caused permanent damage
to the unit.
7. Install unit in a dry location away from condensation.
8. Ensure no metal or foreign materials are dropped in between the display screen
and enclosure.
9. Do not use anything to block the cooling assemblies on the unit.
10. Ensure the plugs are properly plugged in before operating the unit.
11 Should the LCD panel be broken, do avoid all human contact with the broken
glass or uid leaking out from the enclosure. If come into contact, do ush and
clean a ected areas with plenty of water. Seek medical attention immediately.
12. When operating the display unit, do avoid touching or pressing on the LCD
glass panel. Excessive force may cause irreparable damage to the LCD
screen.
Pub.05-10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jensen JE1510
Summary of Contents for Jensen JE1510
- Page 1 JE1510 OPERATING MANUAL 15.4" 16:9 DIGITAL LCD-TV 15.4 Please keep this operating manual for future references. Important Notes : 1. Before operating the unit, please read these instructions carefully. 2. Retain this manual for future reference. 3. Do not remove any WARNING stickers on the unit.
-
Page 2: Table Of Contents
Safety Precautions: 1. Ensure the plug is securely plugged into the main socket before operating the unit. 2. Ensure the Voltage on the main socket is the same as speci ed on the unit. 3. Use parts only manufactured by the unit manufacturers. 4. -
Page 3: Introduction
CONTENTS: PC Adjust Setting ----------------------------------------------------------- 7. ANNEX A LCD Maintenance -------------------------------------------------------------- 8. ANNEX B Troubleshooting ---------------------------------------------------------------- Common Problems ------------------------------------------------------------- 9. SPECIFICATIONS --------------------------------------------------------------- 1. INTRODUCTION: Overview : New technology in LCD monitors allows the enjoyment of a higher quality picture display and higher brightness; lighter in weight and slimmer body design, power saving capabilities and low radiation, giving you a safe, relaxing and environmental- friendly visual enjoyment. -
Page 4: Product Specifications
12. Two auxiliary monitor inputs: One fixed NTSC composite, one selectable composite, S-Video or component ( HDTV ) 13. HDTV ready Contents/Accessories : (Please check the content of the Package.) JE1510 OPERATING MANUAL 15.4" 16:9 DIGITAL LCD-TV 15.4 Please keep this operating manual for future references. -
Page 5: Front Panel Control
2. Front Panel Controls: PANEL CONTROL : 1. POWER : Power On/Off 6. VOLUME 2. MODE : Mode Select 7. VOLUME 3. CHANNEL +/- : Channel Select 8. SPEAKER : Loud Speaker 4. MENU : Menu Setting 9. IR STEREO TRANSMITTER : 5. -
Page 6: Installation Guide
4. INSTALLATION GUIDE: When Connecting to a TV Cable: 1. Remove Antenna Socket cover. 2. Plug the cable to the input socket on the unit. 3. Connect the cable that comes along with the unit to the one you are using when needed. -
Page 7: Vga Input
* VGA Input: This unit provides VGA (Computer) input connector. 1. Connect computer VGA output to the monitor VGA input using VGA cable. 2. To connect audio source, using audio cable to connect from computer audio output to VGA audio input. Noted: When connect VGA input, please set OSD (AV1 Select) to "PC"... -
Page 8: Volume Setting
* Volume Setting: 1. Press "Volume +/- " ( / ) button on TV front control panel or remote control to adjust volume level. * Channel Select: 1. Press "Channel " button on remote control or TV Front Control Panel to change/select channels. -
Page 9: Osd Settings
6. OSD Settings: This monitor provide "OSD" setting, enable you to customize the setting for monitor. Noted: Before adjust settings, ensure all the video source is in correct mode. Management Setting : Press "MENU" button, osd menu will display on screen, press "SET select "TV setting", and press "ENTER"... - Page 10 6. OSD Settings: This monitor provide "OSD" setting, enable you to customize the setting for monitor. Noted: Before adjust settings, ensure all the video source is in correct mode. Management Setting : Press "MENU" button, osd menu will display on screen, press "SET select "AV1 setting", and press "ENTER"...
- Page 11 6. OSD Settings: This monitor provide "OSD" setting, enable you to customize the setting for monitor. Noted: Before adjust settings, ensure all the video source is in correct mode. Management Setting : Press "MENU" button, osd menu will display on screen, press "SET select "Management setting", and press "ENTER"...
- Page 12 7. ANNEX A: LCD Monitor Care & Cleaning Tips: To avoid possible shock hazard, be sure the LCD TV is turn o and unplugged from the main electrical outlet before cleaning. Do not use any form of solvents on the LCD monitor. Cleaning the LCD Monitor: 1.
-
Page 13: Specifications
9. SPECIFICATIONS: Panel Type Active Matrix LCD-TFT Display Size 15.4"(Diagonal) Aspect Ratio 16:9 Resolution 102,4000 Pixel (1280x800) Display Colors 16.7 M Luminance 500 cd/m Contrast Ratio 500 :1 View Angle H: <100 degrees, V: 50 degrees TV-System NTSC Speakers 2 x 3W Audio DAC 96 kHz/24-Bit Audio-D/A-Converter Inputs...
