XVision VIS600ZR Manual

Colour 100m long range ir nightvision camera

Advertisement

Quick Links

VIS600ZR
Model:
Colour 100m Long Range
IR Nightvision Camera

Before you begin

Please unpack the box carefully and identify that all the parts are present.
The camera is suitable for indoor or outdoor use. Please bear in mind the following points when
choosing a mounting position.
The camera must be positioned so that it will not point directly into the sun (sunrise and
sunset) or any bright light, as this may cause damage to the camera.
Avoid viewing areas where half the area is in bright sunlight and the other half is dark,
such as in the shadow of a building. All types of cameras have difficulty in 'seeing' with
such a large lux level variation.
Do not cut the camera cables, this will void the warranty.
Make sure you use only the recommended power supply. Damage caused to the camera by
incorrect voltage or wiring is not covered by the warranty.
Model:
VIS600ZR
Colour Long Range IR Zoom
Camera with 100m Nightvision
CCTV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIS600ZR and is the answer not in the manual?

Questions and answers

Summary of Contents for XVision VIS600ZR

  • Page 1: Before You Begin

    CCTV VIS600ZR Model: Colour 100m Long Range IR Nightvision Camera Before you begin • Please unpack the box carefully and identify that all the parts are present. The camera is suitable for indoor or outdoor use. Please bear in mind the following points when choosing a mounting position.
  • Page 2 The VIS600ZR colour long range IR camera is designed for high risk applications. It offers super high resolution 550 TVL images from its Sony 1/4" HQ1 Super HAD CCD sensor and will provide images in complete darkness up to 100 metres and beyond 100 metres in light levels above 0.02 lux.
  • Page 3: Warning And Caution

    WARNING & CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDU CE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE REFER SERVICINGTO QUALIFIED SERVICE PERSONNEL._______________ The lighting flash with an arrowhead symbol, within an equilateral triangle is Intended to alert the user to the presen ce of un-insulated “dangerous voltage”...
  • Page 6: Warnings And Cautions

    Warnings & Cautions This information is provided to ensure your safety and to prevent any losses financial or otherwise. Please read it carefully and use the product accordingly. Warning / Attention / Special Mark Messages Ignoring this information may result in material loss and or serious personal injuries including death Indicates “...
  • Page 7: Rs-485 Communication Control

    Connection RS-485 communication control Connecting to RS -485 Control Cable CONTROL CABLE SPEC TRX+ RS-485+ TRX- RS-485- Using a RS-485 communication it will be able to control the ZOOM / FOCUS and OSD menu by IR Remote Controller & Receiver or by any Pelco-D type Controller. (1) The ease which it controls from the PC Using a RS-485 converter it connects to RS-485 control cable outside camera and serial cable...
  • Page 8: Main Setup Menu

    Operating your camera Menu Configuration MAIN SETUP MENU CAM TITLE WHITE BALANCE ATW (OUTDOOR) MANUAL BACKLIGHT MIDDLE HIGH MOTION DET FOCUS MODE ZOOM TRK ZOOM SPEED D-ZOOM DISP ZOOM MAG ZOOM POS INIT LENS INIT EXPOSURE BRIGHTNESS IRIS SHUTTER SSNR SENS-UP SPECIAL USER PRESET...
  • Page 9 To access the dip switches and camera controls unscrew the round cover located under the main camera body towards the front (as shown below).
  • Page 11: Operating Your Camera

    Operating your camera Menu Set Up 1.Press the SET button to access the main setup mode. Main Setup menu is displayed on the monitor screen. MAIN SETUP CAM TITLE WHIET BAL BACK LIGHT MOTION DET FOCUS EXPOSURE SPECIAL RESET EXIT 2.
  • Page 12: Cam Title

    Operating your camera 4. When completed move the arrow indicator to “ EXIT” and press the SET button. Notes Features marked with a have an accessible submenu. Access the submenu by pressing the SET button. CAM TITLE Use this feature to designate a name for the camera which will display on the Motion screen.
  • Page 13 Operating your camera 3. Press SET button. 4. You can enter up to 15 characters. ®Á Move the cursor to the character entry field using the LEFT or RIGHT button ®Ë Use UP, DWON, LEFT, and RIGHT buttons to select a desired character. ®È...
  • Page 14 Operating your camera 5. Selection on screen position of the CAM TITLE. ®Á Move the cursor to “POS” and press SET button. ®Ë The CAM TITLE is displayed on the top-left of the monitor screen. (Default position) ®È Select the position by using the 4-directional buttons then press the SET button to confirm the position.
  • Page 15: White Balance Control

    Operating your camera WHITE BALANCE CONTROL Your camera provides three “WHITE BAL” control modes for your choosing in Adjusting the white balance. 1. Press the SET button to access the main setup menu and move the indicator to “WHITE BAL” using the UP or DOWN button. 2.
  • Page 16: Backlight Off

    Notes Proper White Balance may not be obtained under the following conditio When the scene contains mostly high color temperature object such as a blue sky or sunset. When the scene is dim If your camera directly face a fluorescent lamp or is used in an environment of varying lighting conditions.
  • Page 17: Motion Detection

    Operating your camera MOTION DETECTION This product has a feature that allows you to observe movements of object in 4 different areas on the screen and the words “ ” appear on MOTION DETECTION the screen when movement is detected: hence a single individual can conduct Supervision efficiently.
  • Page 18 FOCUS MAIN SETUP CAM TITLE WHIET BAL BACK LIGHT MOTION DET FOCUS EXPOSURE SPECIAL 1. Press the SET button to access the main setup menu and then position the indicator over “FOCUS” using the UP or DOWN button. 2. Press the SET button MODE : You can select the most suitable zoom mode.
  • Page 19 Operating your camera ONE PUSH : Focus is automatically adjusted just once after zoom position is changed. Select “ONE PUSH” and press the SET button to confirm. Increase or decrease optical zoom (ZOOM) or digital zoom (D-ZOOM) positions using the directional buttons while verifying the changes on screen.
  • Page 20 FAST : To move zoom fast SLOW : To move zoom slowly Notes The °∞ Z OOM SPEED°± mode cannot be used if °∞ MODE°± is set to °∞ A UTO°± and °∞ Z OOM TRK°± is °∞ O N°± D-ZOOM : Configure magnification limit from x2~x10 using this feature.
  • Page 21 Operating your camera ZOOM POS INIT : Configure zoom position using this feature. Position the indicator over “ZOOM POS INIT” using the LEFT or RIGHT button FOCUS SETUP MODE AUTO ZOOM TRK ZOOM SPEED FAST D-ZOOM DISP ZOOM MAG ZOOM POS INIT LENS INIT Notes Preset setting has priority over a ZOOM POS INIT setting...
  • Page 22 EXPOSURE EXPOSURE SETUP BRIGHTNESS 25…... IRIS AUTO SHUTTER -------- NORMAL SSNR SENS-UP 1. Press the SET button to access the main setup menu and then position the indicator over “EXPOSURE” using the UP or DOWN button. 2. Press the SET button BRIGHTNESS : Use this feature to adjust image brightness.
  • Page 23 Operating your camera IRIS : Set “IRIS” to “AUTO” or “MANUAL” Position the indicator over “IRIS” using UP or DOWN button and then select the desired iris mode using the LEFT or RIGHT button EXPOSURE SETUP BRIGHTNESS 25…... IRIS AUTO SHUTTER -------- NORMAL...
  • Page 24 A.FLK (NTSC: 1/100, PAL: 1/120) : Flicker-free mode ESC : Automatic shutter speed setting (Optimal) MANUAL : Manual shutter speed setting 2. If you choose “MANUAL” select the optimal shutter speed In MANUAL mode the optimal shutter speed needs to be designated Select form 1/60 “Sens-up”...
  • Page 25 Operating your camera AGC (Auto Gain Control) : For brighter images. 1. Position the indicator over “AGC” using the UP or DOWN button 2. Set “AGC” to the desired mode using the LEFT or RIGHT button HIGH : Wide range gain value adjustment. NORMAL : Normal range fain value adjustment OFF : Disable EXPOSURE SETUP...
  • Page 26 Operating your camera Notes Changing °∞ A GC°± setting from NORMAL to HIGH results in greater sensitivity as well As on screen noise. Setting :AGC°± to OFF locks °∞ S SNR°± configuration SENS-UP : This feature ensures clear images at night or under low lighting conditions.
  • Page 27 SPECIAL SPECIAL SETUP USER PRESET PRIVACY DAY/NIGHT COLOR SYNC COMM ADJ IMAGE ADJ 1. Press the SET button to access the main setup menu and then position the indicator over “SPECIAL” using the UP or DOWN button. 2. Press the SET button USER PRESET : Preset user-designated configurations using this feature Position the indicator over “USER PRESET”...
  • Page 28 PRESET NO : Up to eight different preset configurations are supported USER PRESET SETUP PRESET NO. 1 PRESET MODE PRESET SAVE PRESET CLEAR PRESET DEFINED PRESET NO : Configure initial settings under FOCUS EXPOSURE PRESET SAVE : Save configured preset USER PRESET SETUP PRESET NO.
  • Page 29 PRESET CLEAR : Clear configured preset. USER PRESET SETUP PRESET NO. 1 PRESET MODE PRESET SAVE PRESET CLEAR PRESET DEFINED END : Revert to the SPECIAL SETUP menu USER PRESET SETUP PRESET NO. 1 PRESET MODE PRESET SAVE PRESET CLEAR PRESET DEFINED PRIVACY : Mask privacy area using this feature.
  • Page 30 GROUP : Choose up to eight groups. Each group can consist of four mask areas. AREA SEL : Configure eight mask areas. AREA MODE : Mask area display MASK TONE : Adjust desired mask color level TOP : TO move the mask area up BOTTOM : To move the mask area down LEFT : To move the mask area left RIGHT : To move the mask area right...
  • Page 31 SYNC : Two synchronization modes are available INTERNAL and EXTERNAL LINE-LOCK in LINE-LOCK mode it synchronizes the camera’s video out signal to the external SYNC signal. SPECIAL SETUP USER PRESET PRIVACY DAY/NIGHT COLOR SYNC COMM ADJ IMAGE ADJ INT : Internal synchronization LL : External line-lock synchronization If you choose LL you can adjust the desired phase Press the SET button...
  • Page 32 CAM ID : Assign ID number to the camera. It is restricted available to set ID from 1 to 255 DISP CAM ID : Displays camera ID on top left corner of the screen BAUD RATE : Configure baud rate from 9600 19200, 38400, 57600 bps. UART MODE : Configure parity bit to NONE.
  • Page 33: Remote Control Operating

    Operating your camera Remote Control Operating The remote control is an optional extra, contact your local distributor for details AUTO FOCUS AUTO/ MANUAL PRESET PRESET CAMERA ID & PRESET MENU SET/OK CANCEL CAMERA GROUP CANCEL RESET GROUP GROUP FAST PATTERN NEAR SLOW ZOOM...
  • Page 34 Operating your camera Remote Control Operating Receiver Setting to use with IR Remote Controller (Factory default : Baud Rate = 2400bps, Chart is same as above) Buzzer On/Off 485(+), ( -) Power Connector Baud Rate Setting (DC12V in)
  • Page 35: Troubleshooting

    Troubleshooting Refer to the following table if you are experiencing trouble with your camera Contact an authorized technician if the table does not provide you with a Solution to the trouble. Problem Solution °‹ Check the power cable and the wiring between No display the camera and the monitor °‹...
