Sony SRS-D211 Service Manual page 11

Ref. No. Part No. Description
FH906 1-533-313-11 FUSE HOLDER
FH907 1-533-313-11 FUSE HOLDER
FH908 1-533-313-11 FUSE HOLDER
< IC >
IC101 6-706-641-01 IC LA4631-E
IC601 6-704-237-01 IC TDA7490L
IC901 6-700-776-01 IC KIA78S09P-TP
< JACK >
J106 1-566-822-61 JACK (FRONT L)
J107 1-566-822-61 JACK (FRONT R)
< COIL >
L601 1-400-914-11 FIXED INDUCTOR 33mH
L602 1-400-914-11 FIXED INDUCTOR 33mH
< TRANSISTOR >
Q51 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q55 8-729-230-60 TRANSISTOR 2SA1586-YG
Q56 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q154 8-729-029-14 TRANSISTOR DTC144EUA-T106
< RESISTOR >
R51 1-216-829-11 METAL CHIP
R52 1-216-841-11 METAL CHIP
R56 1-216-833-11 METAL CHIP
R57 1-216-833-11 METAL CHIP
R58 1-216-833-11 METAL CHIP
R59 1-216-841-11 METAL CHIP
R66 1-216-821-11 METAL CHIP
R151 1-216-829-11 METAL CHIP
R152 1-216-821-11 METAL CHIP
R154 1-216-813-11 METAL CHIP
R155 1-216-829-11 METAL CHIP
R251 1-216-829-11 METAL CHIP
R252 1-216-821-11 METAL CHIP
R650 1-218-331-11 METAL CHIP
R651 1-218-882-11 METAL CHIP
R652 1-216-833-11 METAL CHIP
R653 1-216-843-11 METAL CHIP
R654 1-216-837-11 METAL CHIP
R655 1-218-743-11 METAL CHIP
R656 1-216-837-11 METAL CHIP
R657 1-216-843-11 METAL CHIP
R658 1-218-863-11 METAL CHIP
R659 1-218-331-11 METAL CHIP
R660 1-216-795-11 METAL CHIP
R661 1-216-829-11 METAL CHIP
R662 1-216-815-11 METAL CHIP
R663 1-216-815-11 METAL CHIP
R664 1-216-815-11 METAL CHIP
R665 1-216-815-11 METAL CHIP
R666 1-216-815-11 METAL CHIP
R667 1-216-815-11 METAL CHIP
R671 1-216-829-11 METAL CHIP
R684 1-216-797-11 METAL CHIP
************************************************************
Remarks Ref. No.
4.7K 5% 1/10W
47K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
47K 5% 1/10W
1K 5% 1/10W
4.7K 5% 1/10W
1K 5% 1/10W
220 5% 1/10W
4.7K 5% 1/10W
4.7K 5% 1/10W
1K 5% 1/10W
51K 5% 1/10W
30K 0.5% 1/10W
10K 5% 1/10W
68K 5% 1/10W *
22K 5% 1/10W
130K 0.5% 1/10W
22K 5% 1/10W
68K 5% 1/10W
4.7K 0.5% 1/10W
51K 5% 1/10W
6.8 5% 1/10W
4.7K 5% 1/10W
330 5% 1/10W
330 5% 1/10W
330 5% 1/10W
330 5% 1/10W
330 5% 1/10W
330 5% 1/10W
4.7K 5% 1/10W
10 5% 1/10W
Part No. Description
A-1103-095-A CONTROL BOARD, COMPLETE
*********************
1-830-411-11 CABLE 6P
2-345-705-01 KNOB, VOLUME
< CAPACITOR >
C1 1-107-714-11 ELECT
C2 1-107-714-11 ELECT
C3 1-107-714-11 ELECT
C101 1-126-963-11 ELECT
C102 1-162-966-11 CERAMIC CHIP
C103 1-216-864-11 SHORT CHIP
C104 1-216-864-11 SHORT CHIP
C105 1-126-963-11 ELECT
C106 1-162-927-11 CERAMIC CHIP
C201 1-126-963-11 ELECT
C202 1-162-966-11 CERAMIC CHIP
C203 1-216-864-11 SHORT CHIP
C204 1-216-864-11 SHORT CHIP
C205 1-126-963-11 ELECT
C206 1-162-927-11 CERAMIC CHIP
C604 1-164-677-11 CERAMIC CHIP
C605 1-126-957-11 ELECT
C609 1-162-964-11 CERAMIC CHIP
C702 1-107-826-11 CERAMIC CHIP
C703 1-126-947-11 ELECT
C712 1-126-933-11 ELECT
C713 1-126-933-11 ELECT
C716 1-162-927-11 CERAMIC CHIP
C717 1-126-934-11 ELECT
C720 1-126-947-11 ELECT
C721 1-100-566-91 CERAMIC CHIP
C722 1-100-566-91 CERAMIC CHIP
C801 1-127-888-51 CERAMIC
C803 1-127-888-51 CERAMIC
C804 1-126-933-11 ELECT
C805 1-107-826-11 CERAMIC CHIP
C806 1-126-934-11 ELECT
< CONNECTOR >
CN1 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
< DIODE >
D701 8-719-077-29 DIODE SLC-22MG3F (POWER)
D703 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB101 1-216-864-11 SHORT CHIP
FB102 1-216-864-11 SHORT CHIP
FB111 1-216-864-11 SHORT CHIP
FB112 1-216-864-11 SHORT CHIP
FB113 1-216-864-11 SHORT CHIP
FB114 1-216-864-11 SHORT CHIP
FB115 1-216-864-11 SHORT CHIP
FB116 1-216-864-11 SHORT CHIP
FB201 1-216-864-11 SHORT CHIP
FB202 1-216-864-11 SHORT CHIP
SRS-D211
AMP CONTROL
Remarks
10uF 20% 50V
10uF 20% 50V
10uF 20% 50V
4.7uF 20% 50V
0.0022uF 10% 50V
0
0
4.7uF 20% 50V
100PF 5% 50V
4.7uF 20% 50V
0.0022uF 10% 50V
0
0
4.7uF 20% 50V
100PF 5% 50V
0.033uF 10% 16V
0.22uF 20% 50V
0.001uF 10% 50V
0.1uF 10% 16V
47uF 20% 35V
100uF 20% 16V
100uF 20% 16V
100PF 5% 50V
220uF 20% 16V
47uF 20% 35V
0.1uF 10% 25V
0.1uF 10% 25V
0.1uF 10% 50V
0.1uF 10% 50V
100uF 20% 16V
0.1uF 10% 16V
220uF 20% 16V
0
0
0
0
0
0
0
0
0
0
11
