  • Page 1 aaxa TECHNOLOGIES User Guide...
  • Page 2 Caution! WARNING: Please use this product as instructed. Misuse may cause injury or death. DO NOT use while driving. Caution for Battery Use • Do not pierce or puncture the battery DO NOT expose to water or wet with sharp objects. surfaces.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: ST200 at a glance Connecting a Micro SD Card Main Unit Front/Back Connecting to a USB Host Remote & Keypad Chapter 3: Menu Screens Accessories Portable Media Player Chapter 2: Getting Started Video Player Menu...

  • Page 4: Chapter 1: St200 At A Glance

    Chapter 1 ST200 at a Glance Main Unit Front/Back Power Button DC Power VGA Input Micro SD Card Power Switch Focus Wheel HDMI Headphone Out AV Input USB Port...

  • Page 5: Remote & Keypad

    Both the keypad and remote can be used to navigate through the menus. The “Main Menu Navigation” on the remote functions exactly the same as the directional pad on the ST200 unit. The Media Player Menu Navigation allows you to control the media you are currently playing.

  • Page 6: Accessories

    Accessories VGA Cable Remote Tripod A/V Cable Power Adapter *Under various circumstances, the actual accessories may be different from those shown in the pictures above.

  • Page 7: Chapter 2: Getting Started

    (custom models only). “Stand by mode” consumes power even when the projector is idle. Powering OFF the projector Switch the On/Off switch to “Off” to turn off the projector. Note: The ST200 Projector battery does not charge when the projector is in operation.

  • Page 8: Focus Adjustment / Short-Throw Optics

    Spin the focus wheel left or right until the image becomes clear. Short-Throw Optics • The ST200 incorporates a short-throw optical system. Short- throw optics have the advantage of delivering a brighter and larger image at a shorter “throw” distance. The calculation of a projector’s throw ratio is (distance / picture width) and the ratio...
  • Page 9 Step 4. Connect the new battery harness to the receptacle on the PCBA. Step 5. Install the battery until it fits in correctly onto the ST200 and rein- stall the (3) screws Note: The ST200 Projector already comes with the battery preinstalled.

  • Page 10: Connecting To A Computer Via Vga

    Connecting to a Computer via VGA Step 1: Connect the large end of the to your computer’s VGA Cord VGA Adapter Step 2: to your ST200’s Connect the small end of the VGA Adapter VGA Cord Step 3: In the Main Menu Select “INPUT” icon...
  • Page 11 Connecting to a Computer Cont. Step 4: Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your com- puter most computers require “turning on” the video output feature. Each computer is different. Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are standard instructions for a Windows 7 computer –...

  • Page 12: Connecting To A Computer Via Hdmi

    Connecting to a Computer via HDMI Step 1: Connect one end of the to your computer’s HDMI Adapter HDMI Cord Step 2: Connect one end of the to your ST200s HDMI Adapter HDMI Cord Step 3: In the Main Menu Select “INPUT”...
  • Page 13 Connecting to a Computer Cont. Step 4: Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your com- puter most computers require “turning on” the video output feature. Each computer is different. Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are standard instructions for a Windows 7 computer –...

  • Page 14: Connecting To Composite Video

    Connecting to Composite Video Step 1: Connect one end of the to your ST200’s Composite Cord A/V Adapter Step 2: to your devices Connect opposite end of Composite Cord Composite Cord...
  • Page 15 Step 4: Turn on your multimedia device. Connectivity with multimedia devices The ST200 can connect to many media devices including: iPod, iPhone, iPad, VHS players, DVD players, smart phones, cameras, video game consoles and other peripherals with ease. *Apps on smart phones require video out capabilities to be displayed with the...

  • Page 16: Connecting To Hdmi Video

    Connecting to HDMI Video Step 1: Connect one end of the to your ST200’s HDMI HDMI Adapter Step 2: Connect one end of the to your devices HDMI HDMI Adapter...

  • Page 17: Phones

    Turn on your multimedia device. If avaiable select 1280x720 or 1920x1080 Connectivity with multimedia devices The ST200 can connect to many media devices including: iPod, iPhone, iPad, VHS players, DVD players, smart phones, cameras, video game consoles and other peripherals with ease.

  • Page 18: Connecting Speakers/Headphones

    Connecting Speakers/Headphones Step 1: Connect your speakers/headphones the projector’s speaker adapter. 3.5 mm cord Speaker Adapter Step 2: Ensure the power and volume on your speaker or headphones is turned on. Step 3: Place the headphones on and enjoy! CAUTION for Headphone Use •...
  • Page 19 Micro SD Card How to insert your Micro SD Card • Slide in your SD card into the SD card slot on the left side of the ST200. (as shown in picture) • Gently slide the SD card until it clicks into place.
  • Page 20 Micro SD Card Cont. File Menu System • The ST200 will show all folders and files you have on your SD Card in the C: drive. • Use the directional buttons to navigate Media Player menu to different folders or files.
  • Page 21 USB Host How to insert your USB Drive • Slide your USB Drive into USB adapter. (as shown in picture) • Gently slide the drive until it cannot go in any further. How to access your USB Drive • Once your USB Drive has been in- serted, you can navigate to any media content in the main menu.
  • Page 22 USB Host Cont. File Menu System • The ST200 will show all folders and files you have on your USB Drive. • Use the directional buttons to navigate Media Player menu to different folders or files. • In the Media Player selection you can choose from either one of the following: Videos, Audio, Pictures, and Text.

  • Page 23: Portable Media Player

    Chapter 3 Portable Media Player Main Menu The ST200 features a built in PMP (Portable Media Player) function. This function allows the projector to play videos, pictures, music files, and text. To access the main menu simply turn on the projector.

  • Page 24: Video Player Menu

    • Choose which file you wish to play. Select the “Video” icon. The ST200 will show all folders and files you have on your USB or SD Drives. Use the directional buttons to navigate to different folders or files.

  • Page 25: Playing Videos

    Video Player Menu Playing Videos To use the video controls, use the directional keys to highlight the option you wish to choose. • To open the video player menu, press Keystone Up “OK” on the projector. Directional Right • To close the video player menu, hit “back”...

  • Page 26: Video Playback Faq

    Video Playback FAQ How do I loop a video? 1. Choose either USB or SD Card for playback. 2. Navigate the folders until you reach the file you wish to play. 3. Highlight the file you want to play, then confirm the selection. 4.

  • Page 27: Photo Viewer Menu

    • Choose which file you wish to play. Select the “Photo” icon. The ST200 will show all folders and files you have on your USB or SD Drives. Use the directional buttons to navigate to different folders or files.
  • Page 28 Photo Menu Viewing Pictures To use the photo controls, use the directional keys to highlight the option you wish to choose. • To open the photo player menu, Keystone Up press “OK” on the projector. Directional Left • To close the video player menu, hit “back”...

  • Page 29: Photo Faq

    Photo Slideshow FAQ How do I play a slideshow? How do I manually control the slideshow? 1. Choose either USB or SD Card for playback. After selecting the photo you wish to be displayed, you can press “play” to start the slideshow (as outlined in the previous FAQ).

  • Page 30: Music Player Menu

    • Choose which file you wish to play. Select the “Audio” icon. The ST200 will show all folders and files you have on your USB or SD Drives. Use the directional buttons to navigate to different folders or files.
  • Page 31 Music Player Menu Listening to Audio To use the audio controls, use the directional keys to highlight the option you wish to choose. When the player menu is not open you can control the volume with the left and right directional buttons on the projector or from the remote. •...

  • Page 32: Music Faq

    Music Playback FAQ How do I loop a song? How do I create a song playlist? Insert your media device (either mi- 1. Choose either USB or SD Card croSD card or USB) into computer. for playback. Make a new folder on media device (folder name will be the name of the playlist).

  • Page 33: Ebook Viewer Menu

    Use the directional buttons to navigate to different folders or files. Viewing text files The ST200 Pico Projector allows you to view text files. Select the file you want to view in the file menu for the particular storage device on which the file is stored. You can press the left and right arrow buttons on the directional pad or remote to flip through the pages you have in the present folder.

  • Page 34: Setup Menu

    PC Setup • Upgrade Within the settings menu there are Sound four more submenus that allow you to • Sound Mode • Balance customize your ST200 to the settings • Auto Volume you want. • Surround Sound Time • Clock •...

  • Page 35: Picture Settings

    Picture Settings Picture Mode • Changes the picture mode to different settings depending on your choosing. Color Mode • Adjusts the color temperature from hot to cool (red to blue). Slideshow Time • Adjusts the time for your slide- shows. Aspect Ratio •...

  • Page 36: Sound Settings

    Sound Settings Sound Mode • Change the sound mode depend- ing on what is currently playing. Balance • Adjusts the balance of the sound, from left to right. Auto Volume • Sets the projector to auto-detect for the volume. The projector will auto detect the appropriate sound mode.

  • Page 37: Time Settings

    Time Settings Clock • Adjust the time/date. Off Time • Sets a time for auto turn off of projector On Time • Sets a time for the projector to auto turn on. Sleep Timer • Sets a timer until the projector to go into sleep mode Auto Sleep •...

  • Page 38: Option Settings

    Option Settings OSD Language • Changes the language of the device. Restore Factory Default • Restores the projector to factory settings. OSD Duration • Allows the projector to set a duration for the selected OSD language. Current Version • Displays you the current version you have installed for the projec-...

  • Page 39: Keystone Adjustments

    Keystone Adjustments What is Keystoning? “Keystoning” occurs when a projector is aligned non-perpendicularly to a screen, or when the projection screen has an angled surface. The image that results from one of these misalignments will look trapezoidal rather than square. Digital Keystone Adjustments By adding a special, selectable, algorithm to the scaling, some new projectors are able to alter the image before it reaches the projection lens.
  • Page 40 If the image looks trapezoidal with the top larger (as pictured right), press the top button on the direc- tional pad on the top of the ST200 until the keystone effect corrects and the picture turns into a square projection.

  • Page 41: Chapter 4: Technical Details

    Be sure to setup the computer to enable a video signal output. On some laptops this is done by pressing and holding Function F5 key. If using the ST200 as an external monitor on Windows based systems, this can be done by selecting “extend my desktop to this monitor”. The native resolution of the ST200 projector is 1280x720.

  • Page 42: Technical Details

    Technical Details Troubleshooting THE PROJECTOR DOES NOT TURN ON Possible Causes Solution There is no power Check to ensure the power outlet or battery source is good. check the power adapter to ensure a proper connection with the wall outlet as well as the proejctor.

  • Page 43: Specifications

    Specifications Brightness 150 Lumens Native Resolution 1280x720(720P) Maximum Resolution 1920x1080(1080P) Contrast Ratio 2000:1 Projectoin Lens: Manual Focus Image Size: 10~100 inches Lamp: Triple RGB LEDs with Vibrant Color Technology Life 15,000hrs Video in: Composite A/V VGA(mini-VGA) HDMI Audio Output: 1.0 W stereo speakers 3.5 mm audio jack SD Card MicroSD Card Slot...
  • Page 44 Please direct all customer service inquiries to: AAXA Technologies, Inc. 1541 Parkway Loop Suite F Tustin, CA 92780 (714) 957-1999 info@aaxatech.com...
