Directions Be careful not to cause any physical damage by dropping or throwing LXC1050IR. Especially keep the device out of reach from children. Do not disassemble LXC1050IR. No After Service is assumed when disassembled. Use only the power adapter provided with LXC1050IR.
4.2. Quick Installation Guide ........................12 4.2.1. Connect PC and LXC1050IR to network.................. 12 4.2.2. Install IP installer and set IP parameters on LXC1050IR ............13 4.2.3. Remote video connection to LXC1050IR ................. 16 4.2.4. Additional settings through connection to the Admin Page ............17 Trouble Shooting ...........................
It enables real time transmission of video of up to 1080P. Remote clients can connect to LXC1050IR for the real time video data through various client solutions running on PC or smart device. LXC1050IR is specialized in video transmission which economic and practical products removing sensor, replay, etc and the videos can be only available in the field and place where needed.
1.2. Specification Camera Image sensor Progressive scan 1/2.9 inch CMOS 2.0M pixels Full resolution 1,920 x 1,080 pixels (Full HD) Min. illumination 0.2Lux (Color, DSS On), 0.00 Lux (IR LED On) S/N Ratio 50dB or more White Balance Auto Supported Off/ON Lens Built-in Fixed Mega Pixel Lens, f=4mm, F2.0...
Figure 2-3. Connector for external connection Power : Power input for supplying 12V DC power. Caution : If LXC1050IR is powered by PoE, do not plug in DC Jack with active DC power into DC power connector. Network (LAN) 100Mbps Ethernet connector (RJ-45) with PoE standard (802.3af).
Factory Default Switch Factory default switch is provided for returning the IP camera to factory default state. Unscrew the cover to access the switch. Press the switch about 5 seconds while power is applied to return to factory default state ’...
3. On Site Installation Use cables and conduits that are suitable for the installation. Particular attention should be paid in the installation so that no moisture is allowed to penetrate into the unit through the cables or conduits during the life time of the product.
1. Prepare a PC to run programs for the installation and video connection (PC is needed to assign IP address to LXC1050IR) 2. Connect LXC1050IR as shown in dotted line in Figure 4-1. The DC power through DC adaptor is no need to connect if LAN switch supports PoE (IEEE802.3af).
4.2.2. Install IP installer and set IP parameters on LXC1050IR 1. Please insert the Setup CD into your CD-ROM drive, and then please setup Figure 4-2-1. IP Installer Setup 1 2. Please click ‘Install’ button to begin the Installation. Figure 4-2-2. IP Installer Setup 2 3.
Page 14
4. XNET IP Installer program is automatically launched like below right after the program installation. Please double click XNET camera on the list. Figure 4-3. IP Installer Start box 5. Select the camera of which you wish to change the IP address and click (Set IP Address) button to bring up the following box in Figure 4-4.
Page 15
When you enter the IP address and click Set button, the box shown in Figure 4-4 will appear. Figure 4-5. Select Network Adapter Box 7. Select the adapter and click select button to change the IP address of the camera. Rev.1.1 (Sep.
4.2.3. Remote video connection to LXC1050IR 1. Connection through Web Viewer Web Viewer offers simplest way of video connection to LXC1050IR. For video connection, enter the IP address of LXC1050IR in the URL window of Internet Explorer as: Can be omitted the [e.g.] Port 80...
2. Connection through NVR2 NVR2 is a multi-channel CMS program for to IP camera or Video server. Install NVR2 on remote PC to connect to these products. It is needed to assign connection information to NVR2 program before connection. Details for the NVR2 can be found in [NVR2 User’s Guide]. Figure 4-7.
5. Trouble Shooting 5.1. No power is applied In case of Standard PoE (Power over Ethernet) Power supply through standard PoE is possible only when the following conditions are met. 1. Standard PoE is supported on the product. 2. The LAN switch supports standard PoE. Make sure that both the IP camera and the LAN switch support standard PoE (IEEE 802.3af) ...
5.2. Cannot connect to the Video Check the status of the network connection through PING test. Try the following on your PC : Start > Run > Cmd > Ping IP address (Ex : Ping 172.16.42.51) If “Reply from ~” message is returned (① in the figure below), the network connection is in normal state.
5.3. Windows Vista or Windows 7 Windows Vista and Windows 7 users need to configure UAC (User Access Control) and Privilege Level for proper recording and still video capture in NVR2 and Web Viewer. <Windows Vista> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts”...
Page 21
<Windows 7> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts” in control panel 2) Double-click “Change User Account Control setting” 3) Set to “Never notify” Rev.1.1 (Sep. 2014)
Page 22
2. Privilege Level Control 1) Select “NVR” icon on the desktop 2) Click right mouse button and select “properties” 3) Check “Privilege Level” in “Compatibility” tab Rev.1.1 (Sep. 2014)
5.4. Technical Assistance If you need any technical assistance, please contact your dealer. For immediate service please provide the following information. 1. Model name 2. MAC address and Registration number 3. Purchase date 4. Description of the problem 5. Error message Rev.1.1 (Sep.
