Infinova V6822-TA Series User Manual

Hd megapixel vandal resistant low light ip minidome camera
Hide thumbs Also See for V6822-TA Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
V6822-TA Series
HD Megapixel Vandal Resistant
Low Light IP Minidome Camera

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V6822-TA Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Infinova V6822-TA Series

Summary of Contents for Infinova V6822-TA Series

  • Page 1: User Manual

    V6822-TA Series HD Megapixel Vandal Resistant Low Light IP Minidome Camera User Manual...
  • Page 2 Infinova. Infinova reserves the right to change this manual and the specifications without prior notice. The most recent product specifications and user documentation for all Infinova products are available on our web site www.infinova.com.
  • Page 3 Read this manual carefully before installation. This manual should be saved for future use. Important Safety Instructions and Warnings: Electronic devices must be kept away from water, fire or high magnetic radiation. Clean with a dry cloth. Provide adequate ventilation. Unplug the power supply when the device is not to be used for an extended period of time.

  • Page 4: Table Of Contents

    CONTENTS Chapter I System Introduction ..............1 1.1 Product Description................. 1 1.2 Product Features ..................1 1.3 System Requirement ................2 1.4 Product Model ..................3 1.5 Specifications ..................3 1.6 Precautions ....................5 Chapter II Installation Instruction............6 Chapter III IE Browser Settings .............. 10 3.1 Equipment Connection................

  • Page 5: Chapter I System Introduction

    1920×1080@30fps or 1280×720@30fps. V6822-TA series supports motion detection functions, which are able to link with alarm to store and snapshoot images. Privacy mask can protect certain private area from being seen by operator.

  • Page 6: System Requirement

    Supports simultaneous multi-user access and parameters configuration via Web Server Compatible with Infinova’s V2216 digital video surveillance software, easy to integrated with other video surveillance software Provides standard SDK, easily incorporated with the digital surveillance...

  • Page 7: Product Model

    HD Megapixel IP minidome camera, Vandal-resistant, 3-axis, Day/night, 1/3 inch CMOS sensor, H.264/M-JPEG, 1.0Mpx, PoE/12VDC/24VAC, Surface mount, 3.0-9.0mm motorized zoom lens 1.5 Specifications Model V6822-TA series Image Sensor 1/3" low light progressive scan CMOS Dynamic Range 72.4dB Lens F1.2, f=3.0-9.0mm X (Panning): 0°~340°;...
  • Page 8 Major stream: 1920 1080, 1280 1024, 1280 960, 1280 720, 1024 768, 800 600 (for V6822-TA2 series); Optional Resolution 1280 720, 1024 768, 800 600 (for V6822-TA0 series); Minor stream: 720 576, 720 480, 640 480, 352 288, 352 240 Maximum Frame Rate 30fps Variable bit rate;...

  • Page 9: Precautions

    1.6 Precautions 1. Do not drop the camera or subject it to strong knock. 2. Do not point the camera lens toward the sun or other strong light. 3. Do not install the camera in environment with temperature beyond the acceptable range (from -10°C to 50°C).

  • Page 10: Chapter Ii Installation Instruction

    CHAPTER II INSTALLATION INSTRUCTION Step 1: Prepare mounting holes According to the figures below to drill mounting holes and cable hole at the desired position. Figure 2-1 Base (Unit: mm) Figure 2-2 Step 2: Install upper housing Loosen the three mum-head screws in bubble flange and take off the bubble. For ease of installation, upper housing and dome bubble are connected with a safety rope.
  • Page 11 NETWORK 802.3 af PoE Figure 2-4 V6822-TA series cameras support bi-directional audio, providing with 1-ch audio input and 1-ch audio output. They also support 2-ch alarm inputs and 1-ch relay output. In addition to 12VDC/24VAC power supply, they can work on power over Ethernet (PoE).
  • Page 12 to your surveillance need. Then fasten the screws. The camera features X, Y, Z 3-axis adjustment. It allows 0°~340° panning adjustment, 0°~80° tilting adjustment and 0°~340° rotating adjustment. Figure 2-5 Step 4: Install dome bubble Install the bubble flange to upper housing. Align the screw holes of the two parts.
  • Page 13 Figure 2-6 Figure 2-7 Dimensions (Unit: mm) Figure 2-8...

  • Page 14: Chapter Iii Ie Browser Settings

    Directx 9.0c. InfiPlayerAX 3.1 Equipment Connection V6822-TA series IP minidome camera can be directly connected to a computer, or connected to a network. Note: Check whether the connection is tight or not before power-on. 3.2 Software Installation...
  • Page 15 successful login. Click the link to run, or store the exe file, then run it. Figure 3-1 If the installation fails, check whether there is video viewed through other IE window or page. You should close the video or the IE window directly. If it successes, click refresh, you can view the live video.
  • Page 16 Figure 3-4 Note: If InfiPlayerAX control installation falls, the live video won’t display. Then, you should change the IE security level. 1. Select “Tool” in the menu bar, and then select “Internet Options” from the drop-down menu. 2. Select “Security” in the pop-up Internet options. 3.

  • Page 17: Chapter Iv Basic Function Operation

    CHAPTER IV BASIC FUNCTION OPERATION This chapter mainly introduces the settings and operation of V6822-TA series. 4.1 Live View Start IE browser after the server is powered on about 60 seconds, and then enter IP address, such as http://192.168.1.100 (default), in the address field.
  • Page 18 Figure 4-2 Live View V6822-TA series IP minidome camera supports H.264 and M-JPEG video compression formats. After successful login, it enters H.264 major stream live video interface. Users can also select H.264 minor stream or MJPEG from the drop-down list of stream type. In the H.264 major or minor stream type, users can do recording, snapshootting, and audio in/out settings.
  • Page 19 recording storage path. Default: C:\InfiPlayerAX\ Video. Users can set the snapshooting and recording storage path in the audio and video settings interface. indicates audio input/output disabled. Click the buttons to enable audio input/output and then the buttons will be shown as indicates that the motion detection and privacy mask functions are disabled.

  • Page 20: System

    Figure 4-3 Settings Interface With the help of navigation menu on the left, Super user can perform the following operations: Basic Information View, Time Settings and Advanced Settings, Network Settings, Camera Settings (including Basic Set, Effect Set, White Balance, Focus, Reset), Audio & Video Settings, Alarm Settings, Record Management, Account Settings (Add/Delete User, Change Password), Log, etc.
  • Page 21 4.2.2 Time Settings Figure 4-4 “Time” Settings Time Zone Settings Time Zone: Select the desired time zone in the scroll box, and then click “Save” to save it. There are 33 time zones for your selection: GMT-12:00~GMT~GMT+13:00. If Daylight Saving Time is applied in your region, please enable daylight saving time.
  • Page 22 4.2.3 Advanced Settings Figure 4-5 “Advanced” Settings Software Update Free software update is provided for V6822-TA series camera, and this update service can reduce system maintenance budget. According to system update requirement submitted by user, we will send update letter for confirming the version of the product and provide the latest software for download, and help user to update the V6822-TA series camera.
  • Page 23 Figure 4-6 Select update file, and press “Open” button. The selected update file will be displayed in the Software Update box. After that, click “Submit” button to update software, the following information will appear: Figure 4-7 Click “Yes” button, run the program to finish the update. The response time is due to the program type.
  • Page 24 Note: Available only for the super user. Factory Settings V6822-TA series camera provides online reset function, which greatly facilitates reset adjustment. “Keep current IP unchanged”, click “Reset” button and the system will Select pop up a message to confirm factory reset.

  • Page 25: Network Settings

    Online Reboot Click “Reboot” button, the dialog box This operation will take 60 seconds, are Click “OK” and the system will restart. There is you sure to continue pop up. time prompt in the web page during reboot. After reboot, it will skip to new web page.
  • Page 26 4.3.2 FTP Settings Figure 4-10 FTP Settings V6822-TA series camera has the function of alarm associated with FTP upload (alarm triggered image snapshot). Configure server IP, user name and password in the FTP settings and activate FTP handling way in alarm settings, then alarm...
  • Page 27 4.3.3 SMTP Settings Figure 4-11 SMTP Settings User needs to set mail server, recipient, etc in SMTP settings interface. Server IP: Set mail server address. From: Set sender’s mail address. To: Mail address of recipient. CC: Mail address of the person copy to. Authentication: Enable or disable authentication function.
  • Page 28 4.3.4 HTTPS Settings Figure 4-12 HTTPS Settings V6822-TA series camera supports HTTPS protocol. You can import the CA certificate in the interface. 4.3.5 802.1X Settings Figure 4-13 802.1X Settings V6822-TA series camera supports 802.1X protocol. You have to enable 802.1X authentication when needed.
  • Page 29 (3) Max Throughput (4) Min Delay Recommended: Normal Service. 4.3.7 IGMP Settings Figure 4-15 IGMP Settings V6822-TA series camera supports multicast function. In the IGMP interface, users can select the stream type and set the state, multicast IP address and RTP port.
  • Page 30 4.3.8 SIP Settings Figure 4-16 SIP Settings SIP Server: to configure SIP server for device; SIP Server IP: the IP address of SIP server; Port: the port number of SIP server; Server ID: the ID of SIP server; Device ID: the device ID used for registration with SIP server; Alarm ID: the ID registered for device alarm;...

  • Page 31: Camera Settings

    4.3.9 MDA Settings Figure 4-17 MDA Settings In MDA settings interface, you can set the Sever which the motion detection alarm uploads to. State: disable or enable motion detection alarm upload. When it’s on, you can set camera name, user name, password, server IP and Port number. After setting completed, click “Save”...
  • Page 32 Figure 4-18 Basic Settings 4.4.1 Basic Settings You can set the following parameters: Flicker frequency: 50Hz or 60Hz. CVBS: It automatically changes with the flicker frequency. (Notes: analog videos are shut off after MJPEG stream is enabled. To enable analog videos, please disable MJPEG stream.) Enable or disable backlight compensation or digital WDR.
  • Page 33 Contrast Enhance: 1~6 levels match with 6 kinds of Gamma curve separately. If it is set to Auto, the system will adjust automatically. 4.4.2 Exposure Settings Figure 4-19 Exposure Settings Exposure set, auto aperture, ICR control, ICR switch time, scene, AGC, shutter...
  • Page 34 speed and manual AGC can also be set in this interface. Exposure Set: Manual, Scene and Shutter priority. In the Scene mode, indoor or outdoor can be selected and AGC can be set (maximum 64X); if set to manual mode, shutter speed can be set from and manual AGC can be 1/25s to 1/8000s set to...
  • Page 35 Figure 4-20 Effect Set - General Drag the slider to adjust the brightness, sharpness, hue, contrast, saturation and 3D denoise.
  • Page 36 Figure 4-21 Effect Set - Mode The camera supports 6 video effect modes. Users can set and save Name, ICR control mode and Scene parameters for each mode. Click “Factoryset” to restore it to default settings. The camera provides 7 Scene modes: Normal, Anti Fog, Motion, Entrance, Natrium, Sharpen, USrMode.
  • Page 37 In the Mode call, users can set effect mode call status and call period. 4.4.4 White Balance Settings Figure 4-22 White Balance Settings The camera has rich white balance modes, including Auto, Manual, Incandescent light, Cool white fluorescent light, Sun light, Cloudy and Natrium light.
  • Page 38 4.4.5 Focus Settings Figure 4-23 Focus Settings V6822-TA series IP camera is built-in motorized zoom lens for remote focal length adjustment. Click “Focus” in camera settings interface to enter focus settings. In this page, you can select focus mode, zoom/focus and call focus preset.
  • Page 39 Figure 4-24 After focus finished, it will return to the interface as shown in Figure 4-23. The focus time will be different as the lens original positions are different. Focus process lasts 15s at most. You can stop focus by clicking Stop button during focusing. Left-click one section, the frame of this section will turn to green and the camera will focus for this area, shown as below:...
  • Page 40 Figure 4-25 Manual focus: click manual focus to enter the interface as below.
  • Page 41 Figure 4-26 Click to zoom wide/zoom tele. Click focus near/focus far. Focus Limit: the camera can call focus limit. There are 5 options: Near, Middle, Far, User set 1, User set 2. The effects for Near, Middle and Far are default; but User set 1 and User set 2 can be specified by users.

  • Page 42: Audio & Video Settings

    Do set Focus limit to near before reset. 4.4.6 Reset In the interface, you can restore all the Camera Settings parameters to the factory default settings. 4.5 Audio & Video Settings Click the button Audio & Video in the navigation bar to display the following interface.
  • Page 43 Resolution: For H.264 major stream, the resolution of V6822-TA2 series comes up to 1920 1080, with 1280 1024, 1280 960, 1280 720, 1024 768, 800 600 optional, while the resolution of V6822-TA0 series comes up to 1280 720, with 1024 768 and 800 600 optional. or H.264 minor stream, the resolution comes to 720 576, 480, 640 480, closed...
  • Page 44 Bit Rate: There are 2 modes of bit rate: variable rate (vbr) and constant rate (cbr). The variable rate can adjust the bandwidth that it occupies automatically according to the complexity of image, because the complexity of real video sequence keeps changing, details, speed, etc, and the variable rate setting mode can be used to choose how much bandwidth should be used.
  • Page 45 4.5.2 OSD Figure 4-28 OSD Mode 1 OSD settings include: Text OSD and Date OSD. The camera supports two OSD modes: Mode 1, Mode 2. You can switch the mode only if Text 2 is on. Only if Text 1, Text 2 and Date OSD are set to “On”, you can set the text content and the display position of text and date.
  • Page 46 To cancel OSD, set it to “Off” and then click the button “Save”. 4.5.3 Privacy Mask V6822-TA series camera supports 4 privacy masks. If there is certain location within the surveillance area where operators are not allowed to see, and thus,...
  • Page 47 Privacy Mask can be applied. System covers and shields the sensitive area via Privacy Mask setting, to avoid operators observing certain sensitive locations on monitor. Note: do turn on privacy mask function in Live View interface before privacy mask setting (see Section 4.1). Figure 4-30 Privacy Mask Settings How to set the privacy masks: Tick the box of motion detection area number.
  • Page 48 4.5.4 Motion Detection Figure 4-31 Motion Detection Settings V6822-TA series camera supports motion detection. Users can easily set the motion detection areas (up to 4) with the mouse. Note: do turn on motion detection function in Live View interface before motion detection setting (see Section 4.1).
  • Page 49 To cancel a motion detection area, just cancel the box ticking. 4.5.5 Shelter Alarm Figure 4-32 V6822-TA series camera supports shelter alarm function. Users can easily set the shelter alarm areas with the mouse. At first, enable shelter alarm. Click the button “Draw” with the mouse, press the left mouse button and drag on the video till a blue frame displays on the screen.
  • Page 50 It will trigger alarm when the video within the area is shielded. Refer to Section 4.6 for alarm contact details. 4.5.6 Link Configure Figure 4-33 For each stream, the total of 90 port and RTSP port is 5. In this interface, you can set the video numbers of 90 port and RTSP port.
  • Page 51 To change the saving path, click the button “Browse” and select the path from the popup dialog box. 4.5.8 Audio Settings Figure 4-35 Audio Settings Sample Rate: 8K. Format: G.711-U.

  • Page 52: Alarm Settings

    4.6 Alarm Settings Click “Alarm” in the navigation bar to display the following Alarm Settings interface: Figure 4-36 Alarm Settings Alarm Configuration I/O In 1, I/O In 2: Settable 2-channel alarm inputs. Each alarm input has 2 modes: Grounded Circuit or Open Circuit. Alarm out Contact: used to set sending way of alarm.

  • Page 53: Record Management

    Alarm Schedule V6822-TA series camera can set the effective alarm schedule. Select the alarm period (if Sunday is selected, alarm will be enabled during the set period of each Sunday; if everyday is selected, alarm will be enabled during the set period of everyday), and then, set the time period.
  • Page 54 4.7.1 Record Setting Figure 4-37 Record setting Recording video type: Select the type of videos to record, major stream or minor stream. SD card when full: Overwrite or Stop. Overwrite means newly recorded videos automatically overwrite the previous videos when the SD card is full; Stop means recording stops when the SD card is full.
  • Page 55 4.7.2 Replay Figure 4-38 Replay Video Search: set the start and end time, and then click the search button. All videos recorded during this period of time will display in the list. Figure 4-39 Searching Videos...
  • Page 56 Replay: to replay a video, double click a file in the list with the mouse or select a file and then press the “Play” button . During playing, click to pause or stop playing. Click the button on the right of video window, the right window will disappear, show as below: Figure 4-40 Click the button , the interface will restore.

  • Page 57: Account Settings

    Figure 4-41 Downloading Videos Save to: Set the path to save the downloaded files. If resetting required, click the button “Browse”. AVI/H.264 drop-down list box: select the downloaded file attribute. In the download list, file total size, status and process will display. Click the button “Start”, and then the files in the list will be downloaded in order.
  • Page 58 Figure 42 Account Settings 1. Add Users (1) Click “ ”, enter the interface of “Add a User”. Figure 4-43 Add a User (2) Enter the desired User Name and Password (Note: User name and password shall include letter, number and underline only. No special character is allowed. The string length of user name is legal between 1 and 24 characters and that of password is between 5 and 20 characters.) (3) Click “OK”...

  • Page 59: System Log

    Figure 4-45 Click “OK” button, the selected user would be deleted and the account list would be automatically updated. 3. User Password Change Click button in the account list, the dialog box of Edit User Information will pop up: Figure 4-46 Input the old password, enter the desired new password for twice and then click “OK”...
  • Page 60 Figure 4-48 It can display 30 logs on a page. The user can turn over the pages or skip to the desired page by clicking the below arrows. Click “Delete logs”, a prompt will come out. Then, click “Yes” to clear logs.

  • Page 61: Appendix I Magnetic Ring Filter Instruction

    APPENDIX I MAGNETIC RING FILTER INSTRUCTION To reduce electromagnetic interference that power supply generates, it is necessary to install a magnetic ring filter with the power cable of Infinova front-end IP device. To install a magnetic ring filter with power supply: Step 1: Open the magnetic ring filter and lead the power cable through.

  • Page 62: Appendix Ii Questions & Solutions

    APPENDIX II QUESTIONS & SOLUTIONS The following table describes the symptoms causes and solutions for the problems. Symptoms Possible Causes Solutions Wrong power connection Reconnect power cable Power supply failure Repair or replace power supply PCB fuse damage Replace the fuse Immediate startup after Restart 10 seconds later The network...

  • Page 63: Appendix Iii Cable Diameter Calculation And Lightning & Surge Protection

    APPENDIX III CABLE DIAMETER CALCULATION AND LIGHTNING & SURGE PROTECTION Relation between 24VAC Cable Diameter and Transmission Distance In general, the maximum allowable voltage loss rate is 10% for AC-powered devices. The table below shows the relationship between transmission power and maximum transmission distance under a certain specified cable diameter, on condition that the 24VAC voltage loss rate is below 10%.
  • Page 64 Lightning & Surge Protection The product adopts multi-level anti-lightning and anti-surge technology integrated with gas discharge tube, power resistor and TVS tube. The powerful lightning and surge protection barrier effectively avoids product damage caused by various pulse signals with power below 4kV, including instantaneous lightning, surge and static.
  • Page 66 Infinova 51 Stouts Lane, Monmouth Junction, NJ 08852, U.S.A. Tel: 1-888-685-2002 (USA only) 1-732-355-9100 Fax: 1-732-355-9101 sales@infinova.com V1.3 1401...
