2-886-622-12 (1)
Trinitron Color TV
GB
Operating Instructions
• Before operating the unit, please read this manual thoroughly and retain
it for future reference.
KV-AW21
P52
© 2006 Sony Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WEGA KV-AW21 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony WEGA KV-AW21

Summary of Contents for Sony WEGA KV-AW21

  • Page 1 2-886-622-12 (1) Trinitron Color TV Operating Instructions • Before operating the unit, please read this manual thoroughly and retain it for future reference. KV-AW21 © 2006 Sony Corporation...

  • Page 2: Specifications

    Specifications KV-AW21P52 Note Power requirements 220-240 V AC, 50/60 Hz Power consumption (W) Indicated on the rear of the TV Television system Color system PAL, PAL 60, NTSC3.58 (AV IN), NTSC4.43 Stereo/Bilingual System A2 Bilingual B/G Channel coverage VHF : E2 to E12 /UHF : E21 to E69/ CATV : S01 to S03, S1 to S41 8 (Antenna) 75-ohm external terminal...
  • Page 3 WARNING • Dangerously high voltages are present inside the TV. • TV operating voltage: 220 – 240 V AC. • Do not plug in the power cord until you have completed making all other connections; otherwise a minimum leakage current might flow through the antenna and other terminals to ground.

  • Page 4: Getting Started

    C Getting Started Step 1 Insert the batteries (supplied) into the remote. • Do not use old or different types of batteries together. Step 2 Connect the antenna cable (not supplied) to 8 (antenna input) at the rear of the TV. •...
  • Page 5 Setting up your TV (“Initial Setup”) When you turn on your TV for the first time, the “Initial Setup” menu will appear. You can adjust settings below using the buttons on the remote control or TV front panel. Press V , v , B or b to select or adjust items, then press Select the desired menu language.

  • Page 6: Connecting Optional Components

    Connecting optional components You can connect a wide range of optional components to your TV. Connecting cables are not supplied. Connecting to the TV (front) Step 1 Step 2 PROG (MONO) WEGA GATE (MONO) Audio/Video cable Camcorder PROG (MONO) WEGA GATE (MONO) Connecting to the TV (rear)

  • Page 7: Troubleshooting

    • Count the number of times the 1 (standby) indicator flashes. Press 1 (main power) to turn off your TV. Contact your nearest Sony service center. The TV screen sometimes goes blank for slightly longer than usual during channel change.

  • Page 8: Tv Buttons And Remote Control

    TV buttons and remote control Turn off or turn on the TV. Remote control sensor. Wake Up indicator. Standby indicator. PROG +/– Select program number. 2 +/– Adjust volume. PROG WEGA GATE (MONO) Select TV or video input. WEGA GATE menu operations (see H) V,v,B,b Select or adjust items.
  • Page 9 TV buttons and remote control (continued) Select TV or video input. Input numbers. For program numbers 10 and above, enter the second digit within two seconds. Not function for your TV. Select picture mode options: “Vivid”, “Standard”, “Custom”* (see I). * When the “Custom”...
  • Page 10 WEGA GATE navigator WEGA GATE is a gateway that allows you access to preset TV channels, connected external inputs and “Settings” menu. WEGA GATE External Inputs “TV” watch the preset TV Settings channels (see D) Select Confirm Select Confirm External Inputs Video 1 “External Inputs”...

  • Page 11: Picture Setting

    “Picture” setting Press WEGA GATE and select “Settings”. Picture Make sure the “Picture” icon ( ) is selected, Picture Mode: Vivid Picture Adjustment then press Color Temperature: Cool Intelligent Picture: Signal Level Indicator: Select Confirm “Picture Mode” Choose either “Vivid” (bright, contrast and sharp), “Standard”...

  • Page 12: Sound Setting

    “Sound” setting Press WEGA GATE and select “Settings”. Sound Press V or v to select the “Sound” icon ( ), Balance then press Select Confirm “Balance” Press v or B to emphasize the left speaker. Press V or b to emphasize the right speaker.

  • Page 13: "Channel Setup" Setting

    “Channel Setup” setting Press WEGA GATE and select “Settings”. Channel Setup Auto Program Press V or v to select the “Channel Setup” Manual Program Program Sorting/Edit icon ( ), then press Select Confirm “Auto Program” Preset channels automatically. “Manual Program” Manually preset desired channels and channels that cannot be preset automatically (see Presetting channels manually).

  • Page 14: Presetting Channels Manually

    “Channel Setup” setting (continued) Presetting channels manually After selecting “Manual Program”, select the program number to which you want to preset a channel. (1) Make sure “Program” is selected, then press (2) Press V or v until the program number you want to preset appears on the menu, then press Select the desired channel.

  • Page 15: Setup Setting

    “Setup” setting Setup Press WEGA GATE and select “Settings”. Language: English Press V or v to select the “Setup” icon ( ), Picture Rotation Video Label then press Color System: Auto Factory Settings Select Confirm “Language” Change the menu language. Press V or v to select either “English”...
