Page 1: Technical Data
User’s Guide bintec R4100 / R4300 Technical Data © Copyright July 17, 2006 Funkwerk Enterprise Communications GmbH Version 0.9... - Page 2 Purpose This document is part of the user’s guide to the installation and configuration of bintec gateways run- ning software release 7.4.5 or later. For up-to-the-minute information and instructions concerning the latest software release, you should always read our Release Notes, especially when carrying out a software update to a later release level.
-
Page 3: Table Of Contents
R4100 ........ - Page 4 User’s Guide Technical Data...
-
Page 5: Bintec R4100
R4100 bintec R4100 Delivery size Your gateway is supplied with the following parts: ■ Cable sets/power supply: – Ethernet cable – ISDN cable – Serial cable – Splitter serial/Ethernet – Power supply ■ Funkwerk Companion CD ■ Documentation: –... - Page 6 R4100 Feature Data Dimensions/weight (B x H x D): Dimensions without cables 295 mm x 160 mm x 41 mm Weight approx. 1260 g Transport weight (incl. documenta- approx. 2,6 kg tion, cabling, packaging) Memory 32 MB SDRAM, 8 MB Flash-ROM...
-
Page 7: Leds
R4100 Feature Data Plugs used: Serial interface RJ45 Ethernet interface RJ45 ISDN interface RJ45 ISDN-PRI interface RJ45 Community Passwords, PAP, CHAP, SAFERNET Security Technol- MS-CHAP, MS-CHAP v.2, PPTP, PPPoE, PPPoA, Callback, Access Control Lists, CLID, NAT, SIF, VPN mit PPTP or IPSec, MPPE Encryption,... - Page 8 R4100 Figure 1-1: LEDs on bintec R4100 In operational mode the LEDs display the following status information: Status Information Power Power is off. Power is on. Status perma- Error. nently on or flashing The gateway is active. Ethernet 1 to 5 upper line: The gateway is connected to the Ethernet.
-
Page 9: Connections
R4100 Status Information ISDN-3/2 upper line: ISDN-2: ISDN D channel is active. flashing ISDN-2: At least one ISDN B channel is active. lower line: ISDN-3: ISDN D channel is active. flashing ISDN-3: At least one ISDN B channel is active. -
Page 10: Pin Assignments
R4100 The connections are arranged as follows: 1. I/O Power Switch Ethernet interface with serial interface ETH1/ mode Console Socket for power 7. ISDN-0 - ISDN interface supply ISDN-3 Ethernet interface 8. PRI-0 - ISDN-PRI interface DMZ/ETH5 PRI-1 Ethernet interface... - Page 11 R4100 An RJ45 socket is used for connecting: Figure 1-3: Ethernet 10/100Base-T interface (RJ45 socket) The Ethernet sockets have the following pin assignment: Function TD + TD - RD + Not used Not used RD - Not used Not used...
-
Page 12: Isdn Basic Rate Interfaces
R4100 Function RX (Console) GND (Console) RD - (Ethernet) GND (Console) TX (Console) Table 1-4: RJ45 socket for Ethernet connection resp. serial interface (Console) The combined Serial-Ethernet-sockets are not equipped with Auto-MDIX tech- nology. 1.5.2 ISDN Basic Rate Interfaces... -
Page 13: Isdn-Pri Interfaces
R4100 Function Send (+) Receive (+) Receive (-) Send (-) Not used Not used Table 1-5: RJ45 socket for ISDN connection 1.5.3 ISDN-PRI Interfaces The ISDN-PRI interfaces are connected using a RJ45 socket. The supplied cable combines the RJ45 plug required for the ISDN-PRI connection and the RJ45 plug required by the gateway. - Page 14 R4100 Function Not used Not used Not used Table 1-6: RJ45 socket for ISDN-PRI connection Note for NTs in Germany In Germany, "Transmit" (NT-->TE) is often designated "S2Mab" (a and b) on the plug and "Receive" (TE-->NT) "S2Man" (a and b).
-
Page 15: Bintec R4300
General Product Features The general product features cover performance features and the techni- cal requirements for installation and operation of your gateway. These features are outlined in the following table: Feature Data Product name bintec R4300 Technical Data bintec User’s Guide... - Page 16 10/100 Mbps, auto sensing, MDIX; one port with serial interface mode supports the following baud rates: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bauds ISDN-WAN S0 (2) Built-in DMZ/ETH5 Additional Ethernet switch port X.21 interface (2) Built-in bintec User’s Guide Technical Data...
-
Page 17: Leds
User’s Guide BRICKware for Windows Software Reference Table 2-1: General product features LEDs The LEDs on your bintec R4300 Gateway indicate the states and the activ- ity of the gateway. They are arranged as follows: Technical Data bintec User’s Guide... - Page 18 One ISDN B channel is active. flashing Both ISDN B channels are active. ISDN-1 B/D upper line: ISDN D channel is active. lower line: One ISDN B channel is active. flashing Both ISDN B channels are active. bintec User’s Guide Technical Data...
-
Page 19: Connections
All connections are located on the rear of the gateway. bintec R4300 offers a 4-port Ethernet switch including a port with serial interface mode, a DMZ/ETH5 interface, two ISDN interfaces as well as two X.21 interfaces. Technical Data bintec User’s Guide... -
Page 20: Pin Assignments
Ethernet interface with integrated 4-port switch (ETH1 - ETH4) and a separate Ethernet interface (DMZ/ETH5). The 4-port switch can be used to connect single PCs as well as additional switches The ETH1/Console interface can also be used as serial interface. bintec User’s Guide Technical Data... - Page 21 Not used RD - Not used Not used Table 2-3: RJ45 socket for Ethernet connection The Ethernet sockets are not equipped with Auto-MDIX technology. The combined Serial-Ethernet-sockets have the following pin assignment: Function TD + (Ethernet) Technical Data bintec User’s Guide...
-
Page 22: Isdn Basic Rate Interfaces
2.5.2 ISDN Basic Rate Interfaces bintec R4300 provides two ISDN S interfaces, which can be used, e.g., for backup purposes. A RJ45 socket is used for connecting: Figure 2-4: ISDN S interface (RJ45 socket) bintec User’s Guide Technical Data... -
Page 23: Interfaces
Table 2-5: RJ45 socket for ISDN connection 2.5.3 X.21 Interfaces bintec R4300 provides two X.2 interfaces. A 26-pole mini Delta ribbon socket is used for connecting: Figure 2-5: X.21 interface (26-pole mini Delta ribbon socket) Technical Data bintec User’s Guide... - Page 24 Mode 0 B1 (14) DTR (B) B2 (15) DTR (A) B3 (16) DCD (B) B4 (17) DCD (A) B5 (18) DSR (B) B6 (19) DSR (A) B7 (20) TxC (B) B8 (21) TxC (A) B9 (22) bintec User’s Guide Technical Data...
- Page 25 R4300 X.21 V.35 V.36 (DB-15) (M34) (DB-37) Signal Pin no. Mode 1 B10 (23) Mode 2 B11 (24) TxCE (B) B12 (25) TxCE (A) B13 (26) Table 2-6: DB-15 socket for X.21 connection Technical Data bintec User’s Guide...
- Page 26 R4300 bintec User’s Guide Technical Data...
