Open the chuck as far as possible.
Remove the chuck retaining screw by turning it clockwise
using a screwdriver.
Tighten an Allen key into the chuck and strike it with
a hammer as shown.
Remove the Allen key.
Remove the chuck by turning it counterclockwise.
with the chuck retaining screw.
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations
and the implementation of safety devices, certain residual
risks can not be avoided. These include:
Injuries caused by touching any rotating/moving parts.
Injuries caused when changing any parts, blades or
Injuries caused by prolonged use of a tool. When using
any tool for prolonged periods ensure you take regular
Impairment of hearing.
Health hazards caused by breathing dust developed when
using your tool (example:- working with wood, especially
oak, beech and MDF.)
Warning! Let the tool work at its own pace. Do not overload.
Charging the battery
time, or after prolonged storage, it will only accept an 80%
charge. After several charge and discharge cycles, the battery
will attain full capacity. The battery may become warm while
charging; this is normal and does not indicate a problem.
Do not charge the battery at ambient temperatures
below 4 °C or above 40 °C. Recommended charging
temperature: approx. 24 °C.
To charge the battery (5), remove it from the tool and
insert it into the charger (7). The battery will only fit into
the charger in one way. Do not force. Be sure that the
battery is fully seated in the charger.
Plug in the charger.
Check if the charging indicator is flashing green. If the
charging indicator lights up is green continuously, the
battery is either fully charged or too hot and cannot be
charged. If this happens, remove the battery from the charger,
let the battery cool down for approx. 1 hour and re-insert it.
After approx. 1 hour of charging, the charging indicator will
change colour from flashing green to green continuously.
The battery is now fully charged.
Remove the battery from the charger.
Selecting the direction of rotation (fig.D)
For drilling and for tightening screws, use forward (clockwise)
rotation. For loosening screws or removing a jammed drill bit,
use reverse (counterclockwise) rotation.
To select forward rotation, push the forward/reverse slider
(2) to the left.
To select reverse rotation, push the forward/reverse slider
to the right.
To lock the tool, set the forward/reverse slider into the
to set the torque for tightening screws. Large screws and hard
workpiece materials require a higher torque setting than small
screws and soft workpiece materials. The collar has a wide
range of settings to suit your application.
For drilling in wood, metal and plastics, set the collar (3) to
the drilling position by aligning the symbol on the
For screwdriving, set the collar to the desired setting.
If you do not yet know the appropriate setting, proceed as
- Set the collar (3) to the lowest torque setting.
- If the clutch ratchets before the desired result is
achieved, increase the collar setting and continue
tightening the screw. Repeat until you reach the correct
setting. Use this setting for the remaining screws.
