Page 1: Instruction Manual
HDMI EXTENDER WITH IR CT-HDVD-EXT-IR180 Instruction Manual MADE IN CHINA... - Page 2 www.cabletronix.com www.nacebrands.com IMPORTANT SAFETY INSTRUCTIONS： NOTE: There is a separate transmitter and receiver unit. The system will not work if both units are reversed. 1. Do not plug/unplug the extenders or HDMI inputs or outputs while anything is powered on. 2.
- Page 3 www.cabletronix.com www.nacebrands.com 3. Panel Description 1. HDMI to RJ45 transmitter 1 DC5V power input (power supply included) 2 HDMI signal input 3 IR signal output to connect to the emitter extension cable 4 Reset Button 5 RJ45 signal output to the receiver 6 HDMI signal indicator.
- Page 4 www.cabletronix.com www.nacebrands.com 4. Installation Procedures 1. Cat5e/6/6a/7 network cable FOLLOW THE STANARD OF IEEE-568B: 1- ORANGE/WHITE 2-ORANGE 3- GREEN/WHITE 4- BLUE 5- BLUE/WHITE 6-GREEN 7-BROWN/WHITE 8-BROWN 2. Connections HDMI Source Connection instructions: 1) Connect the TX HDMI input with the HDMI output of a source device. 2) Connect TX and RX with CAT5E/6/6A/7 cable.
- Page 5 www.cabletronix.com www.nacebrands.com Note: Extension limit is 180’- Inferior copper clad aluminum (CCA) cable will not work at the specified distance Q: What do I do if the RX “LINK” LED is flashing all the time? 1) Make sure the network cable connection follows the standard of IEEE- 568B. 2) Check whether the TX has a HDMI signal input.
- Page 6 www.cabletronix.com www.nacebrands.com 6. Specification Note Items Specifications HDMI signal Compatible with HDCP Resolution 480i@60Hz, 480p@60Hz, 576i@50Hz, supported 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz Network Low resistance and consumption oxygen-free cable copper core（CAT5E/6/6A/7） Do not use CCA cable! Transmission CAT6:180 ft at 1080P length IR remote Support 20~60KHz wide frequency IR remote...
- Page 7 www.cabletronix.com www.nacebrands.com CABLETRONIX 1-Year Limited Warranty CABLETRONIX. (the "Company") warrants to the Original Purchaser that the item purchased is free from defects in workmanship or material under normal use. This warranty starts on the date of shipment of the hardware to the Original Purchaser. During the warranty period, the Company agrees to repair or replace, at its sole option, without charge to Original Purchaser, any defective component.
