Primex XR PERSONAL SERIES Installation & User Manual
Lcd clock
Hide thumbs
Also See for XR PERSONAL SERIES:
- Install manual (43 pages) ,
- Installation manual (38 pages) ,
- Install & user's manual (32 pages)
Subscribe to Our Youtube Channel
Related Manuals for Primex XR PERSONAL SERIES
Summary of Contents for Primex XR PERSONAL SERIES
- Page 1 XR T YNCHORNIZATION XR P LCD C ERSONAL ERIES LOCK & U NSTALLATION UIDE Doc Part No.: XRA4Z200-INST 082713...
- Page 2 Unit #4 Halifax, West Yorkshire HX3 5AX Newmarket, ON L3Y 8V6 Email info@primexinc.com info@primexwireless.ca info@primexwireless.co.uk www.primexwireless.com www.primexwireless.ca primexwireless.co.uk Telephone (800) 537-0464 (800) 330-1459 0800-3896996 (262) 248-0061 (905) 952-0134 01422-349462 Primex Wireless XR Personal Series LCD Clock Installation & User Guide...
-
Page 3: Table Of Contents
Initialize the Clock Verify Adequate Signal Hang a Personal Series LCD Clock Remove Clock from Clock Lock Mount Tabletop Use of the Personal Series Clock Replace Batteries Troubleshoot Support Warranty Primex Wireless XR Personal Series LCD Clock Installation & User Guide... -
Page 4: About This Guide
BOUT THIS UIDE Audience This guide is intended for users tasked with configuring and installing XR Personal Series LCD Clock for use with the Primex Wireless XR Time Synchronization system. Product Models This guide supports XR Time Synchornization models and accessories listed below. -
Page 5: Regulatory Compliance
FCC Radiation Exposure Limits To comply with FCC RF exposure requirements in section 1.1307, a minimum separation distance of 20 cm is required between the antenna and all persons. Primex Wireless XR Personal Series LCD Clock Installation & User Guide... - Page 6 Europe – EU Declaration of Conformity and Restrictions Hereby, Primex Wireless Inc. declares that this equipment: The Primex Wireless “Personal Series LCD Clock” complies with the essential requirements and other relevant provisions of Directive 1999/5/EC. This equipment is marked with and can be used throughout the European community.
-
Page 7: Safety Precautions
Immersion or spraying of the clock may cause permanent damage. Be sure to test any cleaning solutions on a small area of the clock before using it on the entire clock. Primex Wireless XR Personal Series LCD Clock Installation & User Guide... -
Page 8: Introducing The Personal Series Lcd Clock
The Personal Series LCD Clock is a stylish timepiece for use in personal spaces with the convenience of network monitoring and time synchronization on the Primex Wireless XR Time Synchronization system. With the ability to mount securely to the wall or stand on a table or desktop, the Personal Series Clock offers great deployment flexibility. -
Page 9: Personal Series Lcd Clock Operation
PERATION The Personal Series LCD Clock can be installed anywhere indoors within range of the Primex Wireless transmitter. At 2:01, 6:01, and 10:01 a.m. and p.m. daily, the unit will synchronize its time by scanning the last channel from which it received a signal. The scan will terminate after one minute if a signal is not received. -
Page 10: Operational Indicators
Flashing Unit has not received a signal for at least 4 days Low Battery Visible Low battery Indicator Battery Use Recommendation Use Only High Quality Alkaline Batteries Primex Wireless XR Personal Series LCD Clock Installation & User Guide... - Page 11 The use of heavy duty and zinc carbon batteries is not recommended, as they will not last as long as high-quality name-brand alkaline batteries. WARNING: Do Not Use Lithium or Rechargeable Cells. Figure 3: Personal Series Clock - Back View Illustration Primex Wireless XR Personal Series LCD Clock Installation & User Guide...
-
Page 12: Setup Procedures
Guidelines Ensure that the Primex Wireless Transmitter is broadcasting during the time you are verifying the signal. Primex Wireless transmitters with external antennas broadcast for only 27 minutes each hour, from 39 minutes before the hour to 6 minutes after the following hour. - Page 13 If the clock is in a marginal signal area, it will beep once every few seconds. No beeping means no signal is received. The Personal Series Clock will work in marginal signal areas but may have a slightly reduced battery life. Primex Wireless XR Personal Series LCD Clock Installation & User Guide...
-
Page 14: Hang A Personal Series Lcd Clock
#4 screw. The screw must protrude from the wall .1 in. (.25cm). Hang the Personal Series Clock 1. Install hardware to hang the clock. 2. Hang the clock on the hardware. Primex Wireless XR Personal Series LCD Clock Installation & User Guide... -
Page 15: Remove Clock From Clock Lock Mount
To remove an Personal Series Clock from a Clock Lock mount, follow the steps illustrated in the figure below. Figure 4: Remove Personal Series Clock from Clock Lock Mount Primex Wireless XR Personal Series LCD Clock Installation & User Guide... -
Page 16: Tabletop Use Of The Personal Series Clock
The Personal Series Clock has an easel stand on the back of the clock, To place the clock on a table or desk, simply unfold both sides of the easel stand. Figure 5: Personal Series Clock -- Back View Primex Wireless XR Personal Series LCD Clock Installation & User Guide... -
Page 17: Replace Batteries
The receiver will search until a signal is found, scanning rapidly through 72MHz channels. The receiver will look for a time signal for 1 minute, and then switch to scanning in 30- minute intervals until receiving a signal. Normal operation begins once a signal is received. Primex Wireless XR Personal Series LCD Clock Installation & User Guide... -
Page 18: Troubleshoot
The clock does not beep after pressing The clock is not receiving a signal from the Primex Test the clock in a different location. the button to verify network Wireless Transmitter or the batteries are defective. -
Page 19: Support
Contact Technical Support Before contacting Primex Wireless Technical Support, make sure you have satisfied the system requirements that are listed in your product documentation. Also, you should be at the computer on which the problem occurred, in case it is necessary to replicate the problem. -
Page 20: Warranty
Primex Corporation warrants this product to be free from defects in materials and workmanship for a standard of one year from the date of purchase. Primex will at its sole option, repair or replace any components that fail in normal use. Such repairs or replacements will be made at no charge to the customer for replacement parts.
