Owner's Manual
Voyage
This instruction contains 5 pages:
Page 1: Foreword
Page 2: Unpack and inspect parts contained
Page 3: Notes before installation and
Page 4:
Wire Connection and Canopy installation
Page 5: B
U L
R
Toll Free: 1-855-676-7247
WARNING : Read and follow these instructions carefully and be mindful of all warnings shown throughout.
lade and Pull Chain Knob installation
4VO40
Hanging system installation
Net weight
KGS.
9.0
19.8
LBS.
Advertisement
Table of Contents
Related Manuals for TroposAir Voyage 4VO40
Summary of Contents for TroposAir Voyage 4VO40
- Page 1 Owner’s Manual Voyage 4VO40 This instruction contains 5 pages: Page 1: Foreword Page 2: Unpack and inspect parts contained Page 3: Notes before installation and Hanging system installation Page 4: Wire connection and Canopy installation Page 5: B lade and Pull Chain Knob installation Net weight KGS.
- Page 2 READ AND SAVE THESE INSTRUCTIONS WARNING : TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO PERSONS, PLEASE OBSERVE THE FOLLOWING : 1]. To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly before beginning.
- Page 3 Unpack and inspect fan carefully to be certain all contents are included. Mounting Hardware Bag Bracket For Mounting Bracket: Flat Washer x2 Spring Washer x2 Downrod Machine Screw x2 Wood Screw x2 Assembly For Wire Connection: Wire Nut x 3 For Blade Installation: Canopy Blade Screw x 9...
-
Page 4: Hanging The Fan
WARNING: blades should be at least 7 feet from floor Note 1: Note 2: Turn off power at breaker Use metal outlet box suitable box to avoid possible for fan support. electrical shock. Outlet box must support 35 lbs min. O FF O FF O 1. - Page 5 2. WIRE CONNECTION Making electrical wire connection Follow diagram below and make sure that all exposed wires are secured inside wire nuts or terminal block. Note : Wires from house may vary in color and may not include ground wire ( green ). *White wire from house to white wire from fan *Black wire from house to black wire and blue wire from fan *Ground wire from house to green wire from downrod and from mounting bracket...
- Page 6 4. BLADE INSTALLATION 4A. Attach canvas blades onto blade frames 4B. Attach blade assembly to motor Connect spring hooks (6) from blade frame to Remove 3 motor stoppers by removing screws. relative eyelets on canvas blade. Secure Blade Assembly to the motor with Note: Leave those two eyelets of Tip and 2 motor screws provided from hardware bag.
