Summary of Contents for Schaerer Euroca 2

  • Page 2 M.Schaerer Ltd. Phone: +41 31 858 51 11 User manual Gewerbestrasse 15 Fax: +41 31 858 51 40 BASE 2 - 02 3302 Moosseedorf E-Mail: info@schaerer.com Switzerland Internet: www.schaerer.com Order number: 020'221...
  • Page 3 All information, technical data and illustrations contained in this guide reflect the latest factual position at the time of going to print. M. SCHAERER AG reserves the right to introduce modifications at any time without specific notification.
  • Page 4 Header Page 0-2 BASE-2-02.00...
  • Page 5 Header Safety Instructions & Warnings! Before using the machine for the first time, please read the information in the Operating Instructions very carefully. They contain important directions concerning safety, and the use and maintenance of the machine. Before using the machine for the first time, please read the information in the Operating Instructions very...
  • Page 6 Header Safety Instructions & Warnings! Unauthorised Operators Persons unfamiliar with the Operating Instructions, children or those under the influence of alcohol, drugs or medicines may not operate the coffee machine or only do so under supervision. Dangerous parts of self-service coffee machines, such as steam and hot water outlet points must be clearly marked for customers to see.

  • Page 7: Base-2-02.00 Page

    Do not place the machine on a hot surface or in the vicinity of an oven. The machine may not be used in a large-scale kitchen without the specific written approval of an M. Schaerer AG authorised Customer Service Agent. Temperature The ambient temperature must not fall below 10 °C or exceed 40 °C.
  • Page 8 Servicing The machine must be serviced by an M. Schaerer AG authorised Customer Service Agent every 12 to 15 months. Storage If the machine is to be out of service for a lengthy period, clean and empty it, switch it off and remove plug from socket.

  • Page 9: Table Of Contents

    CONTENTS KAP. TEXT SEITE 1 INTRODUCTION .............................. 1-1 1.1 Welcome to the SCHAERER-Euroca-2 ....................1-1 1.2 Purpose ..............................1-1 1.3 How this manual is organised ........................1-1 2 PRODUCT DESCRIPTION ..........................2-1 2.1 Introduction of Euroca-2 ........................... 2-2 2.2 Product data of Euroca-2.......................... 2-5 2.3 How is the machine equipped of Euroca-2 ....................
  • Page 10 Header Page 0-8 BASE-2-02.00...

  • Page 11: Introduction

    1.2 Purpose These operating instructions will help you to get acquainted with the fantastic features of the Schaerer office coffee machine Euroca-2 very soon. Information regarding the correct maintenance, operating features and technical data can be found therein.
  • Page 12 Introduction. Page 1-2 BASE-2-02.01...

  • Page 13: Product Description

    Product description PRODUCT DESCRIPTION OF EUROCA-2 Sect. TEXT ..........................Page 2.1. Introducing the Euroca-2 ....................2-2 2.1.1 Overall instructions ......................2-2 2.1.2. Installation plan ........................ 2-3 2.1.3. Purpose of use......................... 2-4 2.1.4 Safety precautions ......................2-4 2.1.5. Labelling of the Euroca-2 ....................2-5 Product data of the Euroca-2..................
  • Page 14 Product description 2.1 Introduction 2.1.1 Introduction 1. Bean container grinder 1 (standard grinder) 2. Bean container grinder 2 (option) 3. Slide for closing the beans container 4. Inlet opening for additional coffee powder and cleaning tabs 5. Cup platform ( heated ) 6.
  • Page 15 Product description 2.1.2 Installation planning BASE-2-02.02 Page 2-3...
  • Page 16 Product description 2.1.3 User facility The following beverages can be made with the Schaerer office: Coffee creme Ristretto Espresso coffee Decaffeinated coffee („light coffee“) Steam to heat up milk Hot water for aromatic tea Cappuccino (option) Milky coffee Latté Hot milk Milk foam 2.1.4 Safety precautions...

  • Page 17: Product Data Of Euroca-2

    Product description 2.1.5 How is the product marked of Euroca-2 Just in case of a warranty or malfunction please write the type plate data from your machine in the following field! The type plate is to be found in the machine above the grounds drawer.

  • Page 18: How Is The Machine Equipped Of Euroca-2

    The phase must be secured with 16A. For special voltages please contact M. Schaerer Ltd or an authorized representative. 2.2.4 Water connection / outlet...

  • Page 19: Accounting Systems

    Product description 2.3.3 Standard accessories of the Euroca-2 are not included in the specification Designation Order No. - Additional chip card „ PROGRAMM “ 063941 „ KEY BLOCK “ 063931 „ COFFEE TEST “ 063932 „ MANAGER “ 063940 „ LOAD “ 063937 „...
  • Page 20 Product description Page 2-8 BASE-2-02.02...
  • Page 21 Indicating- and operating elements INDICATING- AND OPERATING ELEMENTS Kap. TEXT ..........................Page 3.1. Indicating and operating elements ................3-2 Chip card functions ....................... 3-3 3.2.1. Standard chip cards ......................3-3 3.2.2. Optional chip cards for normal operation................. 3-4 3.2.3. Chip cards for accounting operation ................3-4 3.3.
  • Page 22 Indicating- and operating elements 3.1 Indicating- and operating elements on / off LED Two-lined illuminated LCD- Stand-By Key Decaf-key incl. LED Display Free selection product key Stop- and minus-key incl. LED and product incl. LED symbols Chip card insertion which Cleaning and recognises the single chip Shift-key and LED...

  • Page 23: Chip Card Functions

    Indicating- and operating elements 3.2 Chip card function The office coffee machine has been equipped with a modern control unit. In order to ensure a simple programming of the machine, a few programming groups have been created, which can be activated by the corresponding chip card. By using those chip cards these programming groups can be protected from misuse.
  • Page 24 Indicating- and operating elements 3.2.2 Optional chip cards In normal operation the PROGRAM card serves for statistical purposes. With an installed accounting system the necessary settings can be made with it. - Switch accounting operation ON / OFF - Price switching level 1 + 2 (automatic machine on, off and switching times) - Change product price and article number - Display MONEY sales - Delete MONEY sales...

  • Page 25: Error And Display Messages

    Indicating- and operating elements 3.3 Error and display message 3.3.1 Machine blocked, no more drawing possible If the following information appears on the display, any product delivery will be blocked: After switching on the machine all drinks drawing is blocked whilst the system selection locked warms up ( approx.
  • Page 26 Indicating- and operating elements The Frigo door is open ( option ). Check the refrigeratordoor for correct locking. If selection locked the problem exist further: door open Call your customer service ! The battery of the machine's own control system must be replaced. battery flat Call your customer service ! Serial EEPROM is defective.
  • Page 27 Indicating- and operating elements The lifting motor is defective. Call your customer service ! pistonmotor timeout The Cappuccinatore is missing or incorrectly assembled. select product If the problem persists. outlet missing Call your customer service ! 3.3.3 Output of steam products disabled If one of the following messages appears on the bottom line of the display, delivery of steam products is barred.
  • Page 28 Indicating- and operating elements There is a malfunction in the automatic coffee powder portioner (obtainable as option). Select product pulseswitch defective Call your customer service ! With appropriate programming (forced cleaning) 50 more coffees can be drawn or select product 1 more hour of coffee before delivery is blocked and the machine must be cleaned.

  • Page 29: Messages When The Machine Is Operating

    The milk container is empty ( option ) select product milk empty 3.5 Operating modes The SCHAERER Euroca-2 has three operating modes: If this information appears on the display, then your machine is ready for use, i.e. select product 12:00 22.01.1999...
  • Page 30 Indicating- and operating elements Page 3-10 BASSE-2-02.03...

  • Page 31: Installation And Operation Of The Machine

    4 INSTALLATION AND OPERATION OF THE MACHINE 4.1 First installation and operation Your office coffee machine will be installed by one of our authorized Schaerer representatives. It is important that after the basic adjustment of the machine and after every adjustment done by you to save the news data on the SAVE DATA cards which is delivered with every machine.
  • Page 32 Installation and operation of the machine Page 4-2 BASE-2-02.04...

  • Page 33: Operation

    Local control OPERATION Sect. TEXT ..........................Page 5.1. Introduction ........................5-3 5.2. Daily operation ....................... 5-3 5.2.1. Set up operational readiness ................... 5-3 5.2.2. Prepare coffee products ....................5-3 5.2.2.1. Prepare coffee products by the second level ..............5-4 5.2.3. Caffeine-free coffee ....................... 5-4 5.2.3.1.
  • Page 34 Local control 5.7. Programming with option chip cards ................ 5-27 5.7.1. PROGRAM card ......................5-27 5.7.1.1. Menu overview....................... 5-27 5.7.1.2. Programmable security level ..................5-27 5.7.1.3. Release and block accounting operation............... 5-28 5.7.1.4. Price switching ....................... 5-28 5.7.1.5. MONEY card price level 1+2 ..................2-29 5.7.1.6.

  • Page 35: Daily Use

    The indications in this chapter will help you to get acquainted with the basic functions of your machine. They are the basic conditions for a simple daily use without any difficulties. A correct installation by the authorized Schaerer representative is the basic condition for a proper functionning of the Euroca-2. CAUTION : Improper use can result in scalding! 5.2 Daily use...

  • Page 36: Prepare Coffee Products By The Second Level

    Local control select product choise 1 supply 1 4. The whole production process is now being done completely automatically. Depending on your machine’s program : - The product keys can be repressed as often as you wish - the same goes for pre- selection or mixed operation.

  • Page 37: Caffeine-Free Coffee Via Grinder And Decaf Key

    Local control 4. Fill coffee powder into the charging hopper. 5. Press the red blinking key. 6. The coffee is prepared and delivered. Always only use ground coffee. CAUTION: with improper operation there is a danger of scalding. 5.2.3.2. Coffeine-free coffee via grinder and DECAF key The Euroca-2 has to be prepared for caffeine-free by means of the grinder, released ex works or by the service technician.
  • Page 38 Local control By pushing the -key again, the outcome of the water will be finished, as long as the Start / Stop-operation is released. Hot water can not be preselected. When the Euroca-2 is switched on and is heating up, a selection of hot water is locked. CAUTION : Improper use can result in scalding! 5.2.5.

  • Page 39: Prepare Hot Milk ( With Frigo Option )

    Local control 5.2.6. Prepare hot milk ( with Frigo option ) Option : 1. Place an empty cup under the delivery spout. Select the key for milk select product 12:00 22.01.1999 3. The product is delivered. By repeated pressing of the key the drawing of milk can be prematurely ended, providing Start / Stop operation has been released.

  • Page 40: Automatically Prepare Cappuccino Magic, Milky Coffee Or Latté ( With Frigo Option )

    Local control 5.2.8. Automatically prepare Cappuccino Magic, milky coffee or latté ( with Frigo option ) Option : If an accounting system is installed on the Euroca-2 and is released, please read the instructions in Section 6.0. Coffee and hot water are simultaneously ready for drawing. By pressing the key preselected products are deleted (only if no accounting is active).
  • Page 41 Local control 5.2.10. Preparing Cappuccino using the Cappuccinatore CPT Description Unit components: 1. O-ring seals ( 063111 ) 2. Regulating screw 3. Suction hose 4. Cappuccinatore components 5. Steam nozzle (CPT connection) 6. O-ring ( 063112 ) Insert the suction hose (3) into the milk container. Completely close the temperature regulating screw (2) by turning it clockwise as far as possible, then release one full turn.

  • Page 42: Daily Cleaning

    Local control 5.3. Daily cleaning To achieve optimal quality of all drinks which are delivered, regular and thorough cleaning of the Euroca-2 and the installed options is indispensable. Please observe the safety regulations for the cleaning agent. Intermediate rinsing: Intermediate rinsing is available in normal and in accounting operation. An intermediate rinsing can be executed as required.
  • Page 43 Local control 3. Draw out the grounds container within five seconds otherwise the machine reverts to normal operational readiness: The LEDs of the keys blink. cleaning manual cleaning Simultaneously with both hands ( safety regulation ) press the - keys, until the brewing flask has run into the cleaning position. !! Caution : Never reach into the machine in this phase Danger of accident !!
  • Page 44 9. Press the knob of the deliver carriage and push downwards. cleaning insert tablet 10. Drop a cleaning agent tablet authorised by the SCHAERER customer service into the manual charging hopper. cleaning insert tablet Wird eine mehrteilige Reinigungstablette verwendet,ist darauf zu achten das der ganze Inhalt der Tablettenkapsel in den Trichtr geworfen wird.
  • Page 45 13. Open the refrigerator door and draw out the milk container. 14. Place a cleaning container with 4 litres of cold water and the cleaning agent recommended by Schaerer into the Frigo. Use the water/cleaning agent mixing ratio in accordance with the description on the packaging of the cleaning agent.
  • Page 46 Local control 18. Press key briefly. 19. The automatic line rinsing from the Frigo to the foamer head is started. 20. Remove the cleaning container from the Frigo. Clean the hoses with a clean cloth. Clean the interior of the Frigo with lukewarm water containing bicarbonate of soda or vinegar.
  • Page 47 Local control 23. Grasp the foamer head and draw it off forwards. A brief acoustic signal sounds. 24. Hold the foamer head with the right hand (left-handers vice-versa) and using the left hand draw the hose insert straight out with gentle sideways rocking movements.
  • Page 48 29a. 29. Soak the hoses, the delivery insert and all foamer head parts overnight in the cleaning agent recommended by M. Schaerer. Before reassembling and fitting the foamer head, thoroughly wash off all parts with clean water in order that all cleaning agent residues are rinsed away.
  • Page 49 Local control 33a. 33. The hose with the foamer setting screw must be fitted on to the right side of the foamer head. (The hose nipples of the foamer head are of different lengths, and the boreholes of the foamer head are of different depths. If the hose nipples are pressed into the foamer head the wrong way round then the two elements cannot be pressed together sufficiently.
  • Page 50 Local control 5.3.2. Instructions for cleaning the Cappuccinatore CPT (optional) Description Unit components: 1. O-ring seals ( 063111 ) 2. Regulating screw 3. Suction hose 4. Cappuccinatore components 5. Steam nozzle (CPT connection) 6. O-ring ( 063112 ) Daily cleaning At the end of the working day , the Cappuccinatore needs to be cleaned as follows: Pour approximately 20 ml Rowa CPM into the cleaning bowl and insert the end of the suction hose (3) into the cleaning bowl.

  • Page 51: Shutdown / Switch Off The Machine

    Local control 5.4. Shutdown / switch off the machine At the end of the working day the machine is switched to the Standby mode. For this purpose press during approx. 3 seconds the -key. The display shows: <<standby>> 12.00 22.01.1999 If the machine is not going to be operated for a longer period of time, then the same must be disconnected from the main power supply and the water connection must be interrupted by closing the water.

  • Page 52: Programming Of The Machine

    If the machine has to be moved to a new location do not push the machine trolley. For safety reasons it must always be pulled. The machine trolley must not be used for transporting goods. M. Schaerer Ltd. will accept no liability for damage or consequential losses arising through incorrect handling of the trolley machine.

  • Page 53: Chef Card

    Local control 5.6.1. CHEF card The most important settings or changes which are necessary for daily operation can be made with the CHEF card. 5.6.1.1. Menu overview Read off product counters for coffee and tea by use of keys Reset product counter to zero Regulate filling quantity Change grinding quantity Change switching on and off times...

  • Page 54: Change Grinding Quantity (Coffee Powder )

    Local control 5.6.1.4. Change grinding quantity ( coffee powder )) With this function the quantity of coffee powder to be used for each individual coffee product can be individually specified. 1. Push CHEF card into the card reader. 2. Press key till menu: change grinding quanti.

  • Page 55: Change Metering Time Steam, Hot Milk And/Or Milk Foam

    Local control 5.6.1.6. Change metering time Steam, hot milk and/or milk foam With this function the milk delivery and/or milk foam metering time for each individual product can be individually specified. The Start/Stop function is released : The metering time cannot be set. The delivery of the products is fixed by a timeout and can only be changed by a service technician.

  • Page 56: Change Time

    Local control 9. Press key. 10. Press keys to set the minutes of the switching-on time. Switch-on 23:30 Switch-off 06:15 11. Press key. 12. Press keys to reach the next menu, draw out CHEF card normal operational readiness. If the machine has switched off automatically, it can be switched on again at any time by pressing the key.

  • Page 57: Change Pin Code

    SAVE DATA cards (A + The SAVE DATA cards should be kept in a safe place where it can be readily found. Only use the SAVE DATA cards after prior discussion with the authorised SCHAERER customer service.

  • Page 58: Store Machine Data On Card

    Local control 5.6.2.2. Store machine data on card 1. Push SAVE DATA card into the card reader. 2. Press keys till menu: SAVE DATA machine card 3. Press key to transfer data from machine to card: ... save ... 4. Data are transferred if acoustic signal sounds and then the machine returns to normal operational readiness: select product 12:00...

  • Page 59: Programming With Options-Chip Cards

    Local control 5.7. Programming with option chip cards The chip cards which are described in this Section are obtainable as options and are not included in the standard scope of supply of the Euroca. You will find the chip cards that are obtainable and a brief description of them in Section 3.2.2.
  • Page 60 Local control 5.7.1.3. Release or block accounting operation With this function the accounting operation programmed by the authorised SCHAERER customer service can be released or blocked. It is only applicable for machines with connected accounting system. 1. Push PROGRAM card into the card reader.
  • Page 61 Local control 5.7.1.5. MONEY card Price level 1 + 2 change 1. Push PROGRAM card into the card reader. 2. Press keys till menu: change prices select product 3. Press required product. price level - 1 product price 0:00 4. With the keys enter the first product price ( 0-99.99 ).
  • Page 62 Local control insert card SAVE DATA / Key ... 12. If the changed date are to be stored on the DATA SAVE card, push in DATA SAVE card..SAVE ... 13. 13. Wait until acoustic signal sounds. credit operation 12.00 22.01.1999 14.

  • Page 63: Display Master Card

    Local control 5.7.1.8. Display MONEY sales 1. Push PROGRAM card into the card reader. 2. Press keys till menu: sales amount Money amoeunt 0.00 3. Press keys to reach the next menu, draw out CHEF card normal operational readiness. 5.7.1.9. Delete MONEY sales 1.

  • Page 64: Log In Master Card

    Local control 5.7.1.12. Log in MASTER card Push PROGRAM card into the card reader. Press keys till menu: log on MASTER execute ' Decaf ' Press key. remove card Draw out PROGRAM card: insert card MASTER / PROGRAM Push in MASTER card. card logged in remove card Draw out MASTER card.

  • Page 65: Change Pin Code

    Local control 5.7.1.14. Change PIN code 1. Push PROGRAM card into the card reader. 2. Press keys till menu: change PIN code execute ' Decaf ' 3. Press key. change PIN code execute ' Decaf ' 4. Press key. PIN-code 0000 ` +/- ` ` Decaf `...

  • Page 66: Coffee Test Card

    Local control 5.7.2.3. Release keys 1. Push KEY BLOCK card into the card reader. 2. All product keys which do not light up red are blocked: button locked select product 3. Press product key, which is to be released. The lamp of the relevant key lights up red. 4.
  • Page 67 Local control 6. With key confirm. grind test select product To check further products, repeat steps 3 to 6. 7. Reinsert the grounds container. 8. Draw out COFFEE TEST card -> Automat moves back to normal position: select product 12:00 22.01.1999 BASE-2-02.05 Page 5-35...
  • Page 68 Local control Page 5-36 BASE-2-02.05...

  • Page 69: Accounting Systems

    Accounting systems 6. ACCOUNTING SYSTEMS Options : This Section concerns those users who have equipped the SCHAERER Euroca-2 with an accounting system. Possible accounting systems The Euroca-2 can be operated with or without accounting systems. Various systems and possibilities are available for the accounting operation.

  • Page 70: The Master Card

    Accounting systems 6.1 The MASTER card The MASTER card is an account chip card which can be used in conjunction with all types of systems, in other words both internal and external accounting systems. It entitles its holder to obtain drinks from the machine free of charge and without the drinks being booked to the accounting system.

  • Page 71: Money Card

    Accounting systems 6.2.1 MONEY card The MONEY card is a credit card which must be inserted in the card reader for the drawing of a drink. The drawings are charged to the card and the remaining credit is displayed. The various MONEY cards (MONEY A - J) only differ in their price gradations ( 255 %, 0 % of the programmed product prices).

  • Page 72: Program Individual Filling And Grinding Quantity Of The Coffee Products

    Accounting systems Program individual filling and grinding quantity of the coffee products 6.2.1.2 credit operation 12.00 22.01.1999 Push MONEY card into the card reader: credit xx.xx select product Hold key pressed approx. 4 sec. select product store ?` Decaf ` 3.

  • Page 73: Load Card

    With the LOAD card, credit can be loaded onto or deleted from the MONEY cards. If no LOAD card is available, the MONEY cards can be loaded by the authorised SCHAERER customer service. The LOAD card is obtainable as an option and is not included in the standard scope of supply of the Euroca-2.
  • Page 74 Accounting systems 4. Draw out LOAD card. insert card MONEY / LOAD - 5. Push MONEY card into the card reader. Amount = Balance amount xx.xx Entry = Amount to be loaded entry x.xx 6. With the keys enter the loading amount. For each key press a factor which has been programmed by the service technician is added key, or subtracted = key.

  • Page 75: Chip Cards Info

    Accounting systems 6.2.2.5 Display and delete MONEY card charge 1. Push LOAD card into the card reader. 2. Press keys till menu: = Total amount of the charges of all MONEY cards since the load MONEY-cards last deletion amout 0.00 3.

  • Page 76: Release Money Card

    Accounting systems 6.2.2.7 Release MONEY card 1. Push LOAD card into the card reader. 2. Press keys till menu: release MONEY-card execute ` Decaf ` 3. Press key. remove card 4. Draw out LOAD card: insert card Money / LOAD 5.

  • Page 77: Money History

    Accounting systems 6.2.2.9 MONEY - History Push LOAD card into the card reader. Press keys till menu: MONEY history display ' Decaf ' Press key. No. xx xxxxx 12.00 22.01.1999 The card and register number, the time and the date of the last card writing are displayed.

  • Page 78: Program Card

    Accounting systems 6.2.3 PROGRAM card In the MONEY accounting operation the PROGRAM card is required for statistical purposes and for the setting of operator-relevant data. The PROGRAM card is obtainable as an option and is not included in the standard scope of supply of the Euroca.

  • Page 79: Token Tester

    Accounting systems 6.3 Token tester and related systems Chip cards required - no cards - MASTER-card (see chapter 6.1) To begin with, all functional sequences described in this Section are available in the Euroca-2 when in operational readiness and in the basic setting for daily use. With the Euroca-2 MONEY card operation can be conducted in parallel with jeton operation, providing this has been released by the service technician.

  • Page 80: External Accounting Via Bar Till

    Accounting systems 3. Press the required product button. The machine delivers the drink. For coin tester with more than one price categories ask your authorised SCHAERER customer service. The coin tester will not accept coins unless the machine is switched on and accounting mode is actuated using the PROGRAM card (see chapter 5.7.1.3).

  • Page 81: Frigo

    Product description of the Frigo FRIGO Options : This Section concerns those users who have equipped the SCHAERER Euroca II with a Frigo. Sect. TEXT ..........................Page 7.1. Product description of the Frigo .................. 7-2 7.1.1. General view of the Frigo....................7-2 7.1.2.

  • Page 82: Product Description Frigo

    Installation plan See under Section 2.1.2. 7.1.3. Purpose of use of the Frigo With the Frigo the following additional drinks can also be prepared on a SCHAERER Euroca II: - Cappuccino - Milky coffee - Latté - Hot milk - Milk foam Page 7-2 BASE-2-02.07...

  • Page 83: Safety Precautions Frigo

    7.1.4. Safety precautions Frigo The maintenance of the machine must be carried out every 12 to 15 months by a customer service authorised by M. SCHAERER AG. & Without the express written approval of M. SCHAERER AG the machine may not be used in large-scale catering establishments.

  • Page 84: Product Data Of The Frigo

    70 W / 0.49 A 220/240 V AC (PNE) 50/60 Hz Enquiries should be made of M. SCHAERER AG or of one of its authorised customer services regarding special voltages. This machine meets the EU standard 89/336 in regard to radio interference (EMC).

  • Page 85: Malfunctions And Remedies

    Product description of the Frigo 7.3. MALFUNCTIONS AND REMEDIES 7.3.1. The Frigo does not function Check whether the temperature regulator is set at zero; the supply current is interrupted; the circuit breaker (FI) of the electrical installation has tripped; have checked by a service technician. the connection Frigo to coffee machine is interrupted When the Frigo is not connected via the Euroca II: the mains connector is damaged or is wrongly inserted in the socket...

  • Page 86: Controls Of The Frigo

    Montagehinweis für das Luftregulierventil Dieser Montagehinweiskleber muss sauber gehalten werden. dieser stark Verschmutzt oder nicht mehr ganz erkenn-bar, muss ein neuer Kleber M.Schaerer AG ange-fordert und ersetzt werden. Page 7-6 BASE-2-02.07...

  • Page 87: Setting Up The Frigo

    7.5. COMMISSIONING AND SETTING UP THE FRIGO 7.5.1. First use The Frigo is set up and commissioned by a customer service authorised by M. SCHAERER AG. See also Section 4.2. 7.5.2. Setting the temperature 1. Open the Frigo service door.

  • Page 88: Cleaning Of The Frigo

    Two variants are available and can be set up by a service technician authorised by Schaerer. 1. The milk lines are automatically rinsed : After the drawing of each milk product a rinsing is announced and after its completion all preselected products are automatically activated.

  • Page 89: Steam Cleaning

    The steam cleaning prevents this. In the five seconds after the delivery of the milk product two brief steam blasts are issued. This ensures that each product is delivered unspoiled in colour and in taste. The steam cleaning is set by a service technician authorised by Schaerer. 7.6.3. Defrosting the Frigo As soon as the ice layer exceeds 3 mm the refrigerator should be defrosted.
  • Page 90 Product description of the Frigo 7.6.4. Cleaning care of the Frigo 1. External cleaning : Wash the outside of the Frigo with lukewarm water, wipe with cold water and dry with a soft cloth. Do not use scouring agents. 2. Internal cleaning : Take out the milk container and clean it.
  • Page 91 Standard-Programming Standard-Programming Euroca-2 ( Software NT 2000 V 1.00 ) Product release/ release/ Risretto Lefts 45 % locked 0 ms locked locked release/ release/ Espresso Lefts 45 % locked 0 ms locked locked release/ release/ Coffee Lefts 45 % locked 0 ms locked locked...

  • Page 92: Standard-Programming

    Standard-Programming Standard-Programming Euroca-2 ( Software NT 2000 V 1.00 ) Start / Stop Milk time out 0-150 sec Milk-time dosage 0-99 sec Milk release/locked Standard 10.0 sec Standard 10.0 sec Start / Stop Milk foam-time out 0-150 sec Milk foam-time dosage 0-99 sec Milk foam release/locked Standard 10.0 sec...
  • Page 93 Index 9. INDEXVERZEICHNIS — C — — A — Air regulating valve for setting milk foam....7-7 Chip cards PIN code change PROGRAM ..5-33 Chip cards standard..........3-3 Chip cards system MONEY ........6-2 — B — Clean coffee machine ......... 5-10 Cleaning..............
  • Page 94 Index 9. INDEXVERZEICHNIS — E — — J — Error message steam products ......3-7 Jeton verifier and related systems...... 6-11 Error message tea products ......... 3-7 External accounting via Shank system....6-12 — K — — F — KEY BLOCK card..........5-33 KEY BLOCK card menu overview ......
  • Page 95 Index 9. INDEXVERZEICHNIS — N — — R — Normal accessories of the Euroca-2 are Rating plates ..........Appendix 2 included in the specification......2-6 Read off product counter ........5-21 Release accounting operation ......5-28 — O — Release keys ............5-34 Release MONEY card ..........
  • Page 96 Index BASE-2-02.09 Page 9-4...

  • Page 97: A Appendix

    Electrical equipment for use within specified voltage limits. 89/336/EEC ELECTROMAGNETIC COMPATIBILITY A CERTIFICATE OF CONFORMITY CAN BE OBTAINED ON REQUEST FROM THE FOLLOWING ADDRESS. M.Schaerer AG Gewerbestrasse 15 CH - 3302 Moosseedorf Phone : ++41 31 85 85 111 ++41 31 85 85 140 E-Mail : http://www.schaerer.com...
  • Page 98 19... Serial no DA..DA..HW..HW..A.2.1 Steam generator - (type - DA) M. Schaerer AG, CH-3302 Moosseedorf Typ : SO II F-Nr. : DA..: Year of construction : 19.. 12 bar : 192ºCVol. : 0.8 l : 230 VAC : 10ºC...

  • Page 99: Environmental Information On The Euroca

    A.3.8 Energy consumption: Energy consumption was as low as technically feasible at the time the machine was developed. A.3.9 SCHAERER If recycling is not possible the machine must be disposed of properly and in Euroca-2 accordance with local and legal regulations.
