DX Air Curtain
In case of heating
• The heating operation mode is selected in accordance with the room temperature and operation starts after
approximately 3 to 5 minutes.
• After the heating operation has stopped, FAN operation may continue for approx. 30 seconds.
• When the room temperature reaches the set temperature and the outdoor unit stops, low fan speed is discharged
and the air volume decreases.
REQUIREMENT
When restarting the operation after stop
• When restarting the operation immediately after stop, the air conditioner does not operate for approx. 3minutes to
protect the machine.
 Recommendation for Winter and Summer Operation
The outlet grille can be manually adjusted to 5 different positions. In winter the outlet grille needs to be adjusted
outwards (Heating), in summer inwards (Fan Only). The airstreams then needs to be adjusted in a way that the air
stream reaches the ground at room temperature.
Winter
• Outlet Grille Angled Outwards
• Air Curtain: HEATING
• Air Conditioning: HEATING
Summer
• Outlet Grille Angled Inwards
• Air Curtain: FAN ONLY
• Air Conditioning: COOLING
