MULTI-LINK
U S E R
Made in Canada - Rev. A - 12 / 03 / 2008
S i t e i n t e r n e t
PROGRAM REMOTE-STARTER OPTIONS WITH ONE CLICK
The MULTI-LINK displays and changes the remote-starters programming options.
ONCE THE INTALLATION IS COMPLETE CONNECT THE DATA-LINK WIRE FROM THE
REMOTE-STARTER TO THE MULTI-LINK. DO NOT CONNECT A BYPASS OR INTERFACE
MODULE (CHAINING) WHEN PROGRAMMING THE REMOTE-STARTER.
Black
Copyright © 2008, FORTIN AUTO RADIO INC
G U I D E
h t t p : / / w w w. i f a r. c a
INTERFACE
LCD SCREEN
SELECTION LINE
The 2nd line is always the
current selection.
MULTI-LINK WHEEL
Red White
Black
Black
(4pin) RS-232 Data-Link
ALL RIGHTS RESERVED
SCROLL DOWN
PRESS THE WHEEL TO SELECT
SCROLL UP
SYMBOLS:
INDICATES THE CURRENT SELECTION
LINK CONNECTED
x
LINK DISCONNECTED
SCOLL/SELECT OPTIONS
Scroll up and down with the wheel to
view the programming options, press
the wheel to select the option and
choose the setting.
TO EXIT THE WRITTING MODE
move the cursor to this symbol
and select.
P.1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fortin Multi-Link
Summary of Contents for Fortin Multi-Link
- Page 1 SCROLL UP and select. INSTALLATION ONCE THE INTALLATION IS COMPLETE CONNECT THE DATA-LINK WIRE FROM THE REMOTE-STARTER TO THE MULTI-LINK. DO NOT CONNECT A BYPASS OR INTERFACE MODULE (CHAINING) WHEN PROGRAMMING THE REMOTE-STARTER. Black Red White Black...
- Page 2 MULTI-LINK. REMOTE STARTER OPTION MODIFICATION The MULTI-LINK stores the remote-starter options in its own permanent memory and can save up to 4 different presets. These presets can be written read to/from a remote-starter at any time.
- Page 3 WRITE OPTION QUICK COPY & PASTE The MULTI-LINK stores only 1 version of the quick-copy options in its own non-permanent memory and can not save it. Subsequent quick copies will over-write existing memory. -R.S. MENU-...
- Page 4 DIAGNOSTIC -DIAGNOSTIC MENU- SCROLL Zone that triggered the alarm DOWN Select: -R.S. MENU- DIAGNOSTIC DIAGNOSTIC ALARM EXIT PRESS ON THE Zone that triggered the Remote Starter WHEEL Select: DIAGNOSTIC R.S. DATA LINK VIEWER -MAIN MENU- SCROLL DOWN -MAIN MENU- D.LINK VIEWER To view the real-time status of 2-way Data- BACK LIGHT SOUND...
- Page 5 : / / w w w . i f a r . c a MODIFIEZ LES OPTIONS DU DÉMARREUR EN 1 CLIC! Le MULTI-LINK permet de voir et de modifier les options des démarreurs FORTIN! INTERFACE SYMBOLES: ÉCRAN LCD...
- Page 6 X.X.xx et plus sont compatible avec le MULTI-LINK. MODIFICATION D'OPTION DU DÉMARREUR À DISTANCE Le MULTI-LINK emmagasine les options du démarreur à distance dans sa mémoire permanent et peut sauvegarder jusqu'à 4 différentes programmations. -R.S. MENU- SCROLL Pour changer les options du démarreur à...
- Page 7 SUR LA ROULETTE sélectionnez: WRITE OPTION QUICK COPY & PASTE Le MULTI-LINK emmagasine seulement 1 version de l’option de copie rapide dans sa mémoire temporaire et ne peut être sauvegardé. Chaque nouvelle copie efface l’ancienne. -R.S. MENU- SCROLL DOWN Pour télécharger les options d'un autre -R.S.
- Page 8 DIAGNOSTIC -R.S. MENU- SCROLL Zones qui ont déclenché l’alarme: DOWN Sélectionnez: -R.S. MENU- DIAGNOSTIC ALARM DIAGNOSTIC EXIT APPUYEZ Zones qui ont arrêté le démarreur à SUR LA ROULETTE distance: Sélectionnez: DIAGNOSTIC R.S. DATA LINK VIEWER -MAIN MENU- SCROLL DOWN -MAIN MENU- D.LINK VIEWER Pour voir en temps réel, les statuts de BACK LIGHT...
