Summary of Contents for BenQ treVolo
- Page 1 ® Bluetooth Speaker User Manual...
- Page 2 Copyright Copyright 2014 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BenQ Corporation.
-
Page 3: Table Of Contents
Connecting to AC outlet ................5 Turning on and off the speaker ..............5 Pairing and connecting Bluetooth® devices ..........6 System status indicators ................7 Caution ......................9 Using BenQ Audio ............ 10 Initial setup ....................10 Playing ......................11 Maintenance and care ..........16 Troubleshooting ..................16 Cleaning the speaker ................ -
Page 4: Introduction
Introduction Overview ® Thank you for purchasing the BenQ treVolo Bluetooth speaker. Indulge in music streaming from your smart devices, computers, or any other ® Bluetooth devices without cables. Features • No physical connection required. • Rechargeable battery provides hours of performance. -
Page 5: Operations
Play/pause Micro USB port (Answer) Connecting to AC outlet Please charge the battery for 3 hours for the first time using your BenQ ® treVolo Bluetooth speaker by connecting it with the power adapter plugging into a live AC (main) outlet. You can begin to use the speaker while the battery in charge. -
Page 6: Pairing And Connecting Bluetooth® Devices
Flip out both speaker panes and enjoy your music. If the paired device comes with phone feature, BenQ treVolo will become a speakerphone. To answer incoming calls, press play/pause button. To hang up, press mode button. To suspend the current call and switch to the new incoming call, press play/pause button. -
Page 7: System Status Indicators
The circle of power button will blink in blue. Turn on ® Bluetooth of your device to discover and pair with “BenQ treVolo” Speaker memory The speaker can remember up to eight paired devices. If there is an additional device to be paired, no longer the least recent connected device is paired with the speaker. - Page 8 ® Streaming via Bluetooth LINE OUT By attaching an audio cable to your treVolo speaker from line out jack plugging into your home audio system as illustrated above, you can use your ® treVolo speaker as a Bluetooth intermediate to stream from your device to your home audio system.
-
Page 9: Caution
• Phone calls override music playing via connected devices. • You can also use BenQ treVolo as a USB audio terminal. Simply plug the cable from USB audio source into micro USB port of BenQ treVolo, and BenQ treVolo will be turned on automatically. -
Page 10: Using Benq Audio
BenQ Audio. Initial setup For the very first time of using BenQ Audio, you will be prompted to enter an e-mail address. Validity of e-mail format will be checked. Once passed, no longer will this initial setup be required at the device. -
Page 11: Playing
® Be sure to turn on Bluetooth at your device to stream audio content to BenQ treVolo. Exclusively for devices come with Android™ 4.2 or above, ® BenQ Audio can automatically turn on Bluetooth for you by switching on Auto pair to treVolo at Settings. - Page 12 • Press to begin play the first track in the list. Press to randomly play tracks in the list. • By pressing the dots icon , tracks can be added into a playlist or deleted from the device. Using BenQ Audio...
- Page 13 Drag the white dot anywhere in the bar to set the volume for minimum to maximum. Tap to set sleep timer. Tap to go back to the previous page. Tap to advance to right panel of the app. Using BenQ Audio...
-
Page 14: Sleep Timer
OK to have the device enter sleep mode accordingly. Right panel Once is tapped or simply drag the whole screen to the left, the right panel will be displayed. Drag it to the right to go back to previous page. Using BenQ Audio... -
Page 15: User Guide
By tapping on the album art, the current can be played/paused. • In the purple area in the middle, information such as remaining battery power about BenQ treVolo will be revealed. • In the red area at the bottom, tap on EXIT will quit the app. -
Page 16: Maintenance And Care
Troubleshooting Problem Solution Speaker will not 1. Make sure you are using the BenQ AC power adapter turn on shipped with the speaker. 2. The speaker is connected to a working AC (mains) outlet to restore the battery to operational mode and charge the battery. - Page 17 Bluetooth functionality if possible. ® •Remove “BenQ treVolo” from the paired Bluetooth device list on your device. Pair and connect over again. •Press and hold the power button for 7 seconds or more to force the speaker to shut down. Turn on the speaker and pair with your device.
-
Page 18: Cleaning The Speaker
• Do not use solvents, chemicals, or sprays. • Do not allow liquids to spill or objects to drop into any of the openings. Contact customer service ® For questions about BenQ’s treVolo Bluetooth speaker, contact your local dealer. For contact information, visit http://www.benq.com. Maintenance and care... -
Page 19: Specifications
Specifications Performance Frequency response 60 Hz ~ 20 kHz Play time 12 hours (depends on user scenarios) Connection ® ® Bluetooth Bluetooth 4.1 (with aptX) Input 3.5 mm stereo input, USB audio I/O port Micro USB x1, Line-in x1, Line-out x1, Power jack Physical Button definition Power, Volume up, Volume down, Sound mode...
