Summary of Contents for Runtastic RUNDC1
- Page 1 Receiver with chest strap for heart rate monitoring via smartphone OPERATING INSTRUCTIONS...
-
Page 2: Electromagnetic Compatibility
1 Chest strap (consisting of a sensor and elastic strap) (Art.no. RUNDC1, model: T000260) incl. lithium battery (3V, CR2032) The elastic strap can be found in the cardboard insert in which the chest strap sensor is packaged;... - Page 3 The following section provides you with information about using batteries: Always replace a battery with a battery of the same type. Batteries should not be charged or re- activated by any other means and they should not be disassembled, discarded in a fire or short-circuited.
-
Page 4: Installation & Commissioning
1. Installing the runtastic app/activation code Insert the below mentioned link in the address bar of your browser to get to the runtastic homepage. The descriptions on this site will help you to finish the activation of the code step by step. - Page 5 Otherwise you will have the opportunity to purchase the heart rate function as well as many other functions from the App Store or Market. 2. Connect your runtastic hardware Plug the receiver into the headphone jack on your smartphone. Observe the correct positioning of the...
- Page 6 The receiver will be turned on and consume battery when it is plugged in the phone even the runtastic app is not activated. Please take off the receiver when it is not in use. The battery life of the receiver is around 2.5 years if it is used 1 hour per day.
- Page 7 "enabled", followed by the option "Heart Rate Sensor" and the setting "runtastic". Windows Phone 7: Go to "Settings" and select "Heart Rate Settings". Set the option "runtastic Receiver (5.3 kHz)" to ON. 4. Attaching the chest strap Front of sensor: Rear of sensor: Sensor contact surfaces Connect the elasticated strap to the sensor.
- Page 8 To ensure good contact with your skin you will need to moisten the contacts of the sensor or apply an ECG gel (available from health stores). Switching between coded uncoded transmission 16 coded and one uncoded channel can be selected. Pressing the button on the front of the chest strap switches between the coded channels.
- Page 9 chest strap. Switch to point "Receiver + Chest strap (5.3 kHz)" again, your smartphone will establish a connection to the chest strap again on the new channel. BlackBerry: Go to "Settings" and select "Heart Rate Settings", under point "Sensor channel" you can see on which channel the chest strap is sending.
- Page 10 most fitness equipment, thereby enabling you to use the chest strap with many other devices, such as treadmills and cross trainers. CHANGING THE BATTERY FOR THE RECEIVER Open the housing of the receiver as shown in the illustration. Remove the old battery and insert a new CR1220 3V battery.
-
Page 11: Technical Data
Reattach the cover of the receiver. CHANGING THE BATTERY FOR THE CHEST STRAP Open the battery compartment cover by inserting a coin and turning it counterclockwise. Remove the old battery and insert a new CR2032 3V battery. When doing this please ensure that the positive terminal (+) is facing upwards. -
Page 12: Declaration Of Conformity
Summary of the declaration of conformity: Krippl- Watches hereby declares that the receiver (art. no. RUNDC1, model: 92-1103800-01) and chest strap (art. no. RUNDC1, model: T000260) conform to the basic requirements and other relevant provisions of Directive 2004/108/EC. You can access the declaration of conformity in its...
