INSTALLATION MANUAL FOR TFP AIR CLEANER
Materials Supplied
1 TFP
4 mounting brackets
4 hanging straps
2 Red, 7" collar connections
4 8/32" X 3/4" sheet metal screws
8 8/32" X 3/8" sheet metal screws
4 pieces of mounting foam
1 set of installation \ operating instructions
1 warranty card
ATTENTION
The TFP can be installed in several different
ways. Please read all suggested methods before
attempting installation.
Electrical
The TFP is equipped with a standard power supply,
on a 5' 5" cable. Lighted ON/OFF switch.
C
US
Model TFP3000
Model TFP3000HEPA
ATTENTION
The furnace fan and/or HRV must operate
continuously for Type 1 and Type 2 installations.
If they do not operate continuously, then
interlocking them electrically with the TFP is
acceptable. Consult a certified electrician.
* LEAVE FOR HOMEOWNER
NOTE: Due to ongoing research and product development, specifications,
ratings and dimensions are subject to change without notice.
TFP-3000
0111
