SM10 Unpacking & Assembly Instructions The SM10 comes partially assembled. Follow the steps below to complete the assembly. WARNING: COMPONENTS OF THE SM10 ARE LARGE AND HEAVY. USE CAUTION WHEN ASSEMBLING THIS MACHINE. MATERIALS AND TOOLS REQUIRED FOR ASSEMBLY 9/16”...
Page 3
ASSEMBLY Figure 1 shows an assembled SM10. Figure 1. SM10 main components. 1. Place the weight cell in its final resting spot. 2. Bolt on the top tube using a 5/8” socket with extension and combination wrench using two 7/16” x 5” bolts, 7/16” washers, and 7/16” nuts, end cap washers and end caps.
Page 4
SM10 Unpacking & Assembly Instructions 3. Mount adjustable pulley bracket. When shipped, the adjustable pulley bracket looks like the ones shown in Figure 4. The bolts need to be removed and the bracket needs to be positioned so that the top of the bracket is in the top hole as shown by the arrow in Figure 4.
Page 5
SM10 Unpacking & Assembly Instructions ADJUSTABLE CROSSOVER CABLE ROUTING NOTE: THE INFORMATION BELOW IS FOR REFERENCE ONLY. THE CABLE ON THE SM10 HAS BEEN INSTALLED AT THE FACTORY. Figure 6. Adjustable crossover cable routing.
Page 6
SM10 Unpacking & Assembly Instructions Figure 7. Adjustable crossover cable end detail. Using a 7/8” wrench, tighten the jam nut onto the adjustable pulley threads as shown in Figure 7. Place a rubber cap on the top of the cable as shown in Figure 7 (right).
Page 7
HARDWARE Hardware Figure 1. Assembly Parts. The parts shown in Hardware Figure 1 are used to assemble the SM10. They are: A. 7/16” x 5” hex head bolt (2) B. 7/16” flat washer (2) C. 7/16” cap washer (use on head end of the 6” bolt so end cap will fit on the nut) (2) D.
